Retrofitting existing buildings to be more energy-efficient is a tremendous contribution to the sustainability of society. The application of photovoltaic integrated shading devices (PVSDs) accords with this ambition by blocking out unwanted radiant heat gain and generating clean electricity. The deployment of PVSDs needs sensible design strategies to optimize the production of renewable energy while retaining the aesthetic quality of the built-up environment, especially in historic campuses. The concept was tested in a case study of buildings in South China University of Technology (SCUT) using Ladybug 1.4.0 and PVsyst 7.2, utilizing the existing “Xia’s shading” design method in historical environments and optimizing the design from the perspective of photovoltaic performance. Firstly, the photovoltaic (PV) panels were integrated as architectural components, and the parameters were incorporated into a mathematical equation based on “Xia’s shading” design method. This was followed by the assessment of the solar energy harvesting potential based on simulated annual solar irradiation values. Lastly, the PV panels’ solar irradiation potential under these different parameters was shown in figures to identify the optimum parameters combination for PVSD applications. The proposed methodology could evolve as a design tool and thus further assist in promoting the large-scale adoption of PVSDs in retrofit projects. Full article

The measurement and analysis of the spatial attributes of the street canyon hold significant importance in the advancement of photovoltaic integrated shading devices (PVSDs). This study offers the space aspect ratio index AR_(h) as a more efficient method for determining the optimal location for installing PVSDs on building facades in various street canyons. The AR_(h) index addresses the limitations of the current quantitative index. This study examined the evolving regulations of indoor thermal conditions, natural lighting, and the performance of PVSDs in various street canyons. It assessed the viability of implementing PVSDs in different canyons and suggested development plans based on the variation law. The findings demonstrated that AR_(h) is capable of effectively assessing and directing the implementation of PVSDs. When AR_(h) is below 0.6, the shade of surrounding buildings has the least impact on the photovoltaic power output and building energy consumption in various street canyons. In this scenario, the building has the largest yearly energy-saving rate, making it highly ideal for implementing PVSDs on the building façade. In summary, the suitability of the AR_(h) index in various street sceneries was assessed, offering valuable insights for the widespread implementation of PVSDs and street planning, thereby optimizing the utilization of solar energy. The findings of this study will be advantageous in diminishing the utilization of non-renewable energy sources in urban areas and mitigating carbon emissions to safeguard the environment. Full article

Pursuing innovations in sustainable architectural solutions, this study examines the impact of a climate-adaptive building envelope with dynamic photovoltaic integrated shading devices (PVSDs) on building performance. A major challenge in designing PVSDs is the lack of established guidelines for geometry and operations. We delve into the complexities and potential benefits of integrating dynamic PVSD designs into building performance simulations, particularly considering their time-varying geometric and operational aspects. This research assesses a range of similar PVSD design options with differing patterns, emphasizing their effects on solar energy potential, daylighting, and thermal efficiency. We conducted tests on south-oriented PVSDs (featuring two-axis rotation) in Houston, Texas, focusing on variables such as panel count (4 or 36), rotation angle range, and operational patterns (synchronized or individual). Regarding solar potential, the four-panel synchronized PVSD option outperformed static shading by 2.1 times. For daylighting and thermal performance, the 36-panel synchronized option with a wide rotation range and the four-panel individual option proved superior to other PVSD configurations, improving up to an average of 36% (sDA300/50%) and 1.5 °C, respectively. Our findings emphasize the critical role of integrating geometric design and operational patterns in PVSDs for enhanced system effectiveness and highlight PVSD design and application limitations. Our findings emphasize the critical role of integrating geometric design and operational patterns in PVSDs for enhanced system effectiveness. Furthermore, they shed light on the limitations in the PVSD design process and practical applications. Full article

PV windows are seen as potential candidates for conventional windows. Improving the comprehensive performance of PV windows in terms of electrical, optical, and heat transfer has received increasing attention. This paper reviews the development of BIPV façade technologies and summarizes the related experimental and simulation studies. Based on the results of the literature research, the average comprehensive energy-saving rate of BIPV façades can reach 37.18%. Furthermore, limitations and optimization directions of photovoltaic integrated shading devices (PVSDs), photovoltaic double-skin façades, and photovoltaic windows are presented. To improve the energy-saving potential of windows as non-energy efficiency elements of buildings, smart PV windows are proposed to be the key to breakthrough comprehensive performance. However, not all switchable windows concepts can be applied to PV windows. Typical studies on smart windows and PV windows are sorted out to summarize the challenges and optimization of smart PV window technical solutions. Considering the technological innovations in smart PV windows, two requirements of energy-saving materials and building envelopes are put forward. The advances in materials and the building envelope are complementary, which will promote the sophistication and promotion of solar building technology. Full article

In this work, a flower-shaped shading system with integrated tracking photovoltaic, suitable for sustainable extensive urban coverages, is designed. Detailed photovoltaic energy yield simulations with a single-diode model approach are performed to disclose the potential of the proposed tracking photovoltaic shading device (PVSD). Simulations are performed with reference to a case study. A double-layer space truss is used to house the innovative modular photovoltaic tracking system, and the first application is envisaged for the coverage of a public market area of a sunny municipality in Southern Italy. By comparing it with the traditional photovoltaic fixed system, the results of the simulations show a steadier energy generation of the new PVSD, and it also provides better coverage with renewable energy during the hours of the day when the traditional system produces low electric energy. Lastly, an early interactive prototype of the PVSD system is presented. The tracking mechanism is carefully designed, 3D-printed at a small scale and tested with a motorized dynamic system controlled by a microcontroller board. The realization of the physical prototype and the engineering of the movement mechanism confirmed the feasibility and the correct functioning of the conceived system opening to real-scale applications. Full article

The building sector contributes to 40% of the total final energy consumption and 36% of CO2 emissions in Europe, and these are set to increase in the coming years. International directives are pushing towards a decarbonisation roadmap to improve the quality of cities and the health of citizens. Buildings have a potentially central role in terms of energy transition as a means to produce and save energy. Photovoltaic shading devices (PVSDs) protect buildings from direct solar radiation and overheating while producing renewable electricity onsite and increasing the users’ thermal comfort. Even though the potential of the PVSD is considerable, the sector is still unexplored, and few studies on the topic are available in the literature. This systematic review aims to present an exhaustive overview of the current literature on state-of-the-art PVSDs by analysing the scientific framework in terms of the status of the research. It presents a performance-based approach focusing on innovative products, PVSD design strategies, and energetic performance in distinct climate conditions and configurations. In particular, 75 articles and about 250 keywords were identified, selected, and analysed. The literature review serves as a basis for further R&D activities led by both the industrial and the academic sectors. Full article

Building-integrated photovoltaic (BIPV) façades are a promising technique for improving building energy performance. This study develops energy simulation models of different photovoltaic-integrated shading devices (PVSDs) in single-story and multi-story office buildings. A cross-region study in China is carried out to explore the energy performance of PVSDs in five climate zones. The shading effect of the upper PVSDs is taken into account. The results show that (1) PVSDs can be applicable in hot and cold climates; shading effects lead to a notable difference in the optimal PVSDs style. The average comprehensive energy saving ratios of different PVSDs ranged from 16.12% (fixed PV louvres in the vertical plane) to 51.95% (lower single panel). The most rewarding PVSDs are for single-story buildings in Kunming and the least suitable are for multi-story buildings in Guangzhou. (2) In climate zones with little air-conditioning energy consumption, avoiding considerably increased lighting consumption by PVSDs is vital. (3) To reduce shading effects, solar panels with smaller widths or vertical placements can be adopted. In addition, the distance of the PV modules from the top edge of the windows is also critical. Building performance evaluation in the early design stage enables maximum benefits for the same input (total area of PV panels). The research methodology and data analysis presented can guide parameters design and the geographical applicability of PVSDs, providing a reference for optimal building energy performance. Full article

This paper presents the impact on energy performance and visual comfort of retrofitting photovoltaic integrated shading devices (PVSDs) to the façade of a prototype office building in a hot desert climate. EnergyPlus™ and the DIVA-for-Rhino© plug-ins were used to perform numerical simulations and parametric analyses examining the energy performance and visual comfort of five configurations, namely: (1) inclined single panel PVSDs, (2) unfilled eggcrate PVSDs, (3) a louvre PVSD of ten slats tilted 30° outward, (4) a louvre PVSD of five slats tilted 30° outward, and (5) an STPV module with 20% transparency which were then compared to a reference office building (ROB) model. The field measurements of an off-grid system at various tilt angles provided an optimum tilt angle of 30°. A 30° tilt was then integrated into some of the PVSD designs. The results revealed that the integration of PVSDs significantly improved overall energy performance and reduced glare. The unfilled eggcrate PVSD did not only have the highest conversion efficiency at ȵ 20% but generated extra energy as well; an essential feature in the hot desert climate of Saudi Arabia. Full article
