Pod counting of rapeseed is a critical step in breeding, cultivation, and agricultural machinery research. Currently, this process relies entirely on manual labor, which is both labor-intensive and inefficient. This study aims to develop a semi-automatic counting instrument based on transmission image processing and proposes a new algorithm for processing transmission images of pods to achieve non-destructive, accurate, and rapid determination of the seed count per pod. Initially, the U-NET network was used to segment and remove the stem and beak from the pod image; subsequently, adaptive contrast enhancement was applied to adjust the contrast of the G-channel image of the pod to an appropriate range, effectively eliminating the influence of different varieties and maturity levels on the translucency of the pod skin. After enhancing the contrast, the Sauvola algorithm was employed for threshold segmentation to remove the pod skin, followed by thinning and dilation of the binary image to extract and remove the central ridge lines, detecting the number and area of connected domains. Finally, the seed count was determined based on the ratio of each connected domain’s area to the mean area of all connected domains. A transmission imaging device that mimics the human eye’s method of counting seeds was designed, incorporating an LED transmission light source, photoelectric switch-triggered imaging slot, an industrial camera, and an integrated packaging frame. Human–machine interaction software based on PyQt5 was developed, integrating functions such as communication between upper and lower machines, image acquisition, storage, and processing. Operators simply need to place the pod in an upright position into the imaging device, where its transmission image will be automatically captured and processed. The results are displayed on a touchscreen and stored in Excel spreadsheets. The experimental results show that the instrument is accurate, user-friendly, and significantly reduces labor intensity. For various varieties of rapeseed pods, the seed counting accuracy reached 97.2% with a throughput of 372 pods/h, both of which are significantly better than manual counting and have considerable potential for practical applications. Full article

With the rapid development of the information age, the need for high-resolution reconnaissance and surveillance is becoming more and more urgent. It is necessary to develop photoelectric pods with a high-precision stabilization function, which isolate the influence of external disturbance and realize the tracking of maneuvering targets. In this paper, the internal frame stabilization loop control technique is studied. Firstly, the mathematical models of the current loop are established. Secondly, the friction model, parametric model, and mechanical resonance model of the system are identified. Finally, a fourth-order tracking differentiator and a fifth-order extended state observer are designed. Through simulation verification, the stability performance of HO-ADRC, increasing by 145.17%, is better than that of PID. In terms of disturbance suppression and noise removal ability, HO-ADRC is also better than PID. Full article

The ball joint is a multi-degree-of-freedom transmission pair, if it can replace the inner frame in the aviation photoelectric pod to carry the optical load, which will greatly simplify the system structure of the photoelectric pod and reduce the space occupied by the inner frame. However, installation errors in ball joint siting introduce nonlinear errors that are difficult to correct and two degree of freedom angular displacement of the ball joint is difficult to detect, which limits application in the precision control of two degrees of freedom systems. Studies of spherical capacitive sensors to date have not tested sensors for use in an inner frame stabilisation mechanism nor have they analysed the influence of installation error on sensor output. A two-axis angular experimental device was designed to measure the performance of a ball joint capacitive sensor in a frame stabilisation mechanism in an aeronautical optoelectronic pod, and a mathematical model to compensate for ball joint capacitive sensor installation error was created and tested. The experimental results show that the resolution of the capacitive sensor was 0.02° in the operating range ±4°, the repeatability factor was $0.86\%$, and the pulse response time was 39 $\mathsf{\mu }$s. The designed capacitive sensor has a simple structure, high measurement accuracy, and strong robustness, and it can be integrated into ball joint applications in the frames of aeronautical photoelectric pods. Full article
