Plasma-enhanced atomic layer deposition (ALD) is a common method for fabricating Hf_0.5Zr_0.5O₂ (HZO) ferroelectric thin films that can be performed using direct-plasma (DP) and remote-plasma (RP) methods. This study proposed co-plasma ALD (CPALD), where DPALD and RPALD are applied simultaneously. HZO films fabricated using this method showed wake-up-free polarization properties, no anti-ferroelectricity, and high fatigue endurance when DPALD and RPALD started simultaneously. To minimize defects in the film that could negatively affect the low polarization properties and fatigue endurance, the direct plasma power was reduced to 75 W. Thus, excellent fatigue endurance for at least 10⁹ cycles was obtained under a high total remanent polarization of 47.3 μC/cm² and an applied voltage of 2.5 V. X-ray photoelectron spectroscopy and transmission electron microscopy were used to investigate the mechanisms responsible for these properties. The HZO films fabricated by CPALD contained few lattice defects (such as nonstoichiometric hafnium, nonlattice oxygen, and residual carbon) and no paraelectric phase (m-phase). This was attributed to the low-carbon residuals in the film, as high-energy activated radicals were supplied by the adsorbed precursors during film formation. This facilitated a smooth transition to the o-phase during heat treatment, which possessed ferroelectric properties. Full article

Hafnia-based nanostructures and other high-k dielectrics are promising wide-gap materials for developing new opto- and nanoelectronic devices. They possess a unique combination of physical and chemical properties, such as insensitivity to electrical and optical degradation, radiation damage stability, a high specific surface area, and an increased concentration of the appropriate active electron-hole centers. The present paper aims to investigate the structural, optical, and luminescent properties of anodized non-stoichiometric HfO₂ nanotubes. As-grown amorphous hafnia nanotubes and nanotubes annealed at 700 °C with a monoclinic crystal lattice served as samples. It has been shown that the bandgap E_g for direct allowed transitions amounts to 5.65 ± 0.05 eV for amorphous and 5.51 ± 0.05 eV for monoclinic nanotubes. For the first time, we have studied the features of intrinsic cathodoluminescence and photoluminescence in the obtained nanotubular HfO₂ structures with an atomic deficiency in the anion sublattice at temperatures of 10 and 300 K. A broad emission band with a maximum of 2.3–2.4 eV has been revealed. We have also conducted an analysis of the kinetic dependencies of the observed photoluminescence for synthesized HfO₂ samples in the millisecond range at room temperature. It showed that there are several types of optically active capture and emission centers based on vacancy states in the O_3f and O_4f positions with different coordination numbers and a varied number of localized charge carriers (V⁰, V⁻, and V²⁻). The uncovered regularities can be used to optimize the functional characteristics of developed-surface luminescent media based on nanotubular and nanoporous modifications of hafnia. Full article

The development of novel materials with coexisting volatile threshold and non-volatile memristive switching is crucial for neuromorphic applications. Hence, the aim of this work was to investigate the memristive properties of oxides in a Hf–Nb thin-film combinatorial system deposited by sputtering on Si substrates. The active layer was grown anodically on each Hf–Nb alloy from the library, whereas Pt electrodes were deposited as the top electrodes. The devices grown on Hf-45 at.% Nb alloys showed improved memristive performances reaching resistive state ratios up to a few orders of magnitude and achieving multi-level switching behavior while consuming low power in comparison with memristors grown on pure metals. The coexistence of threshold and resistive switching is dependent upon the current compliance regime applied during memristive studies. Such behaviors were explained by the structure of the mixed oxides investigated by TEM and XPS. The mixed oxides, with HfO₂ crystallites embedded in quasi amorphous and stoichiometrically non-uniform Nb oxide regions, were found to be favorable for the formation of conductive filaments as a necessary step toward memristive behavior. Finally, metal–insulator–metal structures grown on the respective alloys can be considered as relevant candidates for the future fabrication of anodic high-density in-memory computing systems for neuromorphic applications. Full article

In this work, we show a correlation between the composition and the microstructural and optical properties of bright and uniform luminescent porous silicon (PSi) films. PSi films were synthesized by electrochemical etching using nitric acid in an electrolyte solution. PSi samples synthesized with nitric acid emit stronger (up to six-fold greater) photoluminescence (PL) as compared to those obtained without it. The PL peak is shifted from 630 to 570 nm by changing the concentration ratio of the HF:HNO₃:(EtOH-H₂O) electrolyte solution, but also shifts with the excitation energy, indicating quantum confinement effects in the silicon nanocrystals (Si-NCs). X-ray photoelectron spectroscopy analysis shows a uniform silicon content in the PSi samples that emit the strongest PL. High-resolution transmission electron microscopy reveals that the Si-NCs in these PSi samples are about ~2.9 ± 0.76 nm in size and are embedded in a dense and stoichiometric SiO₂ matrix, as indicated by the Fourier transform infrared analysis. On the other hand, the PSi films that show PL of low intensity present an abrupt change in the silicon content depth and the formation of non-bridging oxygen hole center defects. Full article

Metal deposition on silicon in hydrofluoric acid (HF) solutions is a well-established process for the surface patterning of silicon. The reactions behind this process, especially the formation or the absence of molecular hydrogen (H₂), are controversially discussed in the literature. In this study, several batch experiments with Ag⁺, Cu²⁺, AuCl₄⁻ and PtCl₆²⁻ in HF matrix and multicrystalline silicon were performed. The stoichiometric amounts of the metal depositions, the silicon dissolution and the molecular hydrogen formation were determined analytically. Based on these data and theoretical considerations of the valence transfer, four reasons for the formation of H₂ could be identified. First, H₂ is generated in a consecutive reaction after a monovalent hole transfer (h⁺) to a Si–Si bond. Second, H₂ is produced due to a monovalent hole transfer to the Si–H bonds. Third, H₂ occurs if Si–Si back bonds of the hydrogen-terminated silicon are attacked by Cu²⁺ reduction resulting in the intermediate species HSiF₃, which is further degraded to H₂ and SiF₆²⁻. The fourth H₂-forming reaction reduces oxonium ions (H₃O⁺) on the silver/, copper/ and gold/silicon contacts via monovalent hole transfer to silicon. In the case of (cumulative) even-numbered valence transfers to silicon, no H₂ is produced. The formation of H₂ also fails to appear if the equilibrium potential of the 2H₃O⁺/H₂ half-cell does not reach the energetic level of the valence bands of the bulk or hydrogen-terminated silicon. Non-hydrogen-forming reactions in silver, copper and gold deposition always occur with at least one H₂-forming process. The PtCl₆²⁻ reduction to Pt proceeds exclusively via even-numbered valence transfers to silicon. This also applies to the reaction of H₃O⁺ at the platinum/silicon contact. Consequently, no H₂ is formed during platinum deposition. Full article
