With the increased necessity of a high power density and efficient system in aerospace and marine industries, integrated motor drives provide an excellent solution in the modern era. Therefore, a close structural and functional integration of passive components has become a prerequisite task to make a compact overall system. This article reviews the existing motor drives system with integrated passive technologies. To start, the design aspect of the traditional and integrated filter inductors, using the area product approach, is discussed. Subsequently, layouts of traditional and integrated inductors are presented. The available capacitor technologies, suitable for integration, are also discussed with pros and cons of each capacitor type. Full article

The present trend of aerospace industries is being shifted towards a “More Electric Aircraft” system which needs to be high power dense. For this purpose, the integration technologies have gained massive interest, providing the benefits of reduced losses, weight, volume and cost. In this article, the integration concept of a passive filter inductor is presented for a permanent magnet synchronous motor. The integrated motor eliminates the need of an external inductor, thus, eliminates the added inductor losses, mass, volume and cost associated with it. The motor utilizes its’s inherent inductance to use it as a filter inductor instead of implementing a discrete inductor that is commonly placed between inverter and the motor terminals. Optimization study is carried out, where the filter branch windings are tapped, in terms of improving mass and volume and performance parameters such as power losses and torque ripple. From the optimization study, the motor with minimum weight and volume is experimentally validated at the rated conditions, in order to prove the concept feasibility. Total system weight and volume of integrated and traditional motor drives are compared, which gives the minimum weight of 2.26 kg and 3.14 kg respectively, and the minimum volume of 0.54 L and 1.1 L respectively. Full article

The modeling of stator and rotor faults is the basis of the development of online monitoring techniques. To obtain reliable stator and rotor fault models, this paper focuses on dynamic modeling of the stator and rotor faults in real-time, which adopts a multiple-coupled-circuit method by using a winding function approach for inductance calculation. Firstly, the model of the induction machine with a healthy cage is introduced, where a rotor mesh that consists of a few rotor loops and an end ring loop is considered. Then, the stator inter-turn fault model is presented by adding an extra branch with short circuit resistance on the fault part of a stator phase winding. The broken rotor bar fault is then detailed by merging and removing the broken-bar-related loops. Finally, the discrete models under healthy and faulty conditions are developed by using the Tustin transformation for digital implementation. Moreover, the stator and rotor mutual inductances are derived as a function of the rotor position according to the turn and winding functions distribution. Simulations and experiments are performed on a 2.2-kW/380-V/50-Hz three-phase and four-pole induction motor to show the performance of the stator and rotor faults, where the saturation effect is considered in simulations by exploiting the measurements of a no load test. The simulation results are in close agreement with the experimental results. Furthermore, magnitudes of the characteristic frequencies of 2f₁ in torque and (1 ± 2s)f₁ in current are analyzed to evaluate the stator and rotor fault severity. Both indicate that the stator fault severity is related to the short circuit resistance. Further, the number of shorted turns and the number of continuous broken bars determines the rotor fault severity. Full article

This paper presents a novel analytical method (NAM) of inductance identification for a direct drive permanent magnet synchronous motor (DDPMSM) with a stator winding fault (SWF), which considers the spatial position of the shorted turns. First, the structure of the DDPMSM is introduced and its key parameters are reported. Second, the NAM on the inductance identification is elaborated. The inductance analytical expressions of the faulty coil are derived in detail, in which the inductances of the faulty coil and the fault branch can be quickly calculated according to the spatial position coordinates of fault turns. Then, the model of DDPMSM with SWF is established. Finally, using the NAM, finite-element method (FEM), and the simplified analytical method (SAM), the inductances of the faulty coil and the branch are calculated under different fault conditions. Additionally, the fault current of the faulty coil is also studied, where the value of the fault current reflects the fault severity. The comparisons among the FEM, NAM, and SAM show that the accuracy of the NAM is higher than that of the SAM. Full article
