FinFET transistors with fin channel lengths of 160 nm and 2000 nm and a planar MOSFET transistor with channel lengths of 180 nm and 90 nm are presented with characteristic curves at various Gate biases. A finalized algorithm with kink effects was effectively responsible for addressing the field effect transistors. The algorithm included the modified conventional current–voltage formula and a nonlinear heat-associated kink solution which was simplified as a Gaussian form. Three parameters in the modified model included k_N (which was related with channel width, channel length, and gate oxide capacitor, and was proportional to the mobility of carriers), Vth (threshold voltage), and λ (the inverse of early voltage). Those parameters were determined to minimize the discrepancies between the measured data and the fitting values, but left kinks located at around (V_GS-Vth), which were deliberately eliminated by the Gaussian form because of the agitation of thermal kink effects. The whole fitting was made to be as close as possible to the as-measured I_DS-V_DS. In the meantime, those determined parameters were physically meaningful after the analysis had been performed. Full article

The main purpose of this study was to research and develop maximum power point tracking (MPPT) of a photovoltaic module array (PVMA) with partial module shading and sudden changes in solar irradiance. Modified cat swarm optimization (MCSO) was adopted to track the global maximum power point (GMPP) of the PVMA. Upon a sudden changes in solar irradiance or when certain modules in the PVMA were shaded, the maximum power point (MPP) of the PVMA will change accordingly, and multiple peak values may appear on the power–voltage (P-V) characteristic curve. Therefore, if the tracking pace is constant, the time required to track the MPP might extend, and under certain circumstances, the GMPP might not be tracked, as only the local maximum power point (LMPP) can be tracked. To prevent this problem, a maximum power point tracker based on MCSO is proposed in this paper in order to adjust the tracking pace along with the slope of the P-V characteristic curve and the inertia weight of the iteration formula. The initial voltage for tracking commencement was set to 0.8 times the voltage at the maximum power point of the PVMA under standard test conditions. Firstly, MATLAB 2022a was used to construct the four-series, three-parallel PVMA model under zero shading and partial shading. The feedback of PVMA voltage and current was obtained, where the GMPP was tracked with MCSO. From the simulation results, it was proven that, under different shading percentages and sudden changes in solar irradiance for partial modules in the PVMA, the MCSO proposed in this paper provided better tracking speed, dynamic response, and steady performance compared to the conventional CSO. Full article

The Onshore Wind Power All-DC Generation System (OWDCG) is designed to integrate with renewable energy sources by modifying the grid structure. This adaptation supports the grid infrastructure and addresses the challenges of large-scale wind power AC collection and harmonic resonance during transmission. Crucially, small disturbance stability parameters are essential for ensuring the system’s stable operation. Unlike conventional power systems, the OWDCG exhibits strong coupling between subsystems, accentuating the small disturbance stability issue due to the dynamic nature of its converter control system. The impedance method facilitates the decomposition of such systems into subsystems, offering insights into the destabilization mechanism through the lens of negative impedance contribution. This approach is conducive to conducting small disturbance stabilization analyses. To tackle this issue, the initial step involves deriving the input and output equivalent impedance models of the subsystem, considering the topological structure, control features, and operational dynamics of the OWDCG. Subsequently, the impact of circuit and control parameters on the system’s impedance characteristics and small-disturbance stability is examined through Bode diagrams and Nyquist curves. This analysis identifies critical parameters for small-disturbance stability, guiding the stable operation and parameter optimization of the OWDCG. The analysis highlights that the main control strategies for stability are the Modular Multilevel Converter (MMC) DC voltage control and the inner-loop current control gain. Validation of the theoretical findings is achieved through simulation results using PSCAD/EMTDC. Full article

Recently, a swarm-based method called Artificial Hummingbird Algorithm (AHA) has been proposed for solving optimization problems. The AHA algorithm mimics the unique flight capabilities and intelligent foraging techniques of hummingbirds in their environment. In this paper, we propose a modified version of the AHA combined with genetic operators called mAHA. The experimental results show that the proposed mAHA improved the convergence speed and achieved better effective search results. Consequently, the proposed mAHA was used for the first time to find the global maximum power point (MPP). Low efficiency is a drawback of photovoltaic (PV) systems that explicitly use shading. Normally, the PV characteristic curve has an MPP when irradiance is uniform. Therefore, this MPP can be easily achieved with conventional tracking systems. With shadows, however, the conditions are completely different, and the PV characteristic has multiple MPPs (i.e., some local MPPs and a single global MPP). Traditional MPP tracking approaches cannot distinguish between local MPPs and global MPPs, and thus simply get stuck at the local MPP. Consequently, an optimized MPPT with a metaheuristic algorithm is required to determine the global MPP. Most MPPT techniques require more than one sensor, e.g., voltage, current, irradiance, and temperature sensors. This increases the cost of the control system. In the current research, a simple global MPPT method with only one sensor is proposed for PV systems considering the shadow conditions. Two shadow scenarios are considered to evaluate the superiority of the proposed mAHA. The obtained results show the superiority of the proposed single sensor based MPPT method for PV systems. Full article

The partial shading conditions significantly affect the functionality of solar power plants despite the presence of multiple maximum power point tracking systems. The primary cause of this problem is the presence of local maxima in the power–current and/or power–voltage characteristic curves that restrict the functionality of the conventional maximum power point tracking systems. The present article proposes a modified algorithm based on the simplified equivalent circuit of solar cells to improve the functionality of traditional maximum power point tracking systems. This algorithm provides a method for regularly monitoring the photo-current of each solar module. The upper and lower boundaries of the regulating parameter such as current or voltage are decided very precisely, which is helpful to find the location of the global maximum. During a sequential search, the control system accurately determines the lower and upper boundaries of the global maximum. Simultaneously, the maximum power point tracking system increases the photovoltaic current up to one of these boundaries and applies one of the conventional algorithms. Additionally, the control system regularly monitors the photovoltaic characteristics and changes the limits of regulating parameter concerning any change in global maximum location. This proposed method is fast and precise to locate the global maximum boundaries and to track global maximum even under fast-changing partial shading conditions. The improved performance and overall efficiency are validated by simulation study for variable solar irradiance. Full article
