Performance assessment of nuclear waste repositories requires state-of-the-art knowledge of radionuclide transport properties. Additionally, the short-term development under thermal pulses and the long-term development of the near field—due to influences such as gas generation—must be evaluated. Key thermal-hydro-mechanical-chemical processes are strongly coupled on different spatial and temporal scales. To understand these coupling mechanisms, numerous material models and numerical codes have been developed. However, the existing constitutive approaches—which have been adapted to describe small-scale laboratory experiments and validated against real-scale field observations—are often unable to capture long-term material behavior with sufficient precision. To build the confidence, a more comprehensive understanding of the system at micro- and macroscopic scales is required. Most observed macroscopic processes result from microscopic changes in the crystal structure and/or crystalline aggregates, as well as changes in material properties under the influence of various factors. To characterize these physical fields in crystals, microscopic investigations, such as visualization, or geophysical methods are introduced to verify the understanding at the microscale. Two cases are demonstrated for the presented concept using microscale information: one deals with the mechanically and thermally driven migration of fluid inclusions in rock salt, the other with dilatancy-controlled gas transport in water-saturated clay material. Full article

The control system for a micro-hydropower plant using an Archimedes screw turbine is the focus of this work. Three control systems were implemented based on a Barreda micro-hydropower plant (Spain) currently in operation: an optimal water level control ($OWLC$) system, a maximum power point monitoring ($MPPT$) system, and a water level control ($WLC$) system. The comparison was made using several assessment indicators: electricity production, micro-hydropower plant efficiency, and gearbox fatigue. The electricity production is similar in the $OWLC$ and $MPPT$ systems (energy gain $+0.5\%$) and significantly lower in the $WLC$ system (energy gain $-12\%$). The efficiency of the micro-hydro plant is similar in the $OWLC$ and $MPPT$ systems (average efficiency gain $+0.9\%$) and significantly lower in the $WLC$ system (average efficiency gain $-15\%$). The mechanical stress on the gearbox is similar in the $OWLC$ and $WLC$ systems and significantly higher in the $MPPT$ system. It can be concluded that the $OWLC$ system performs better as concerns the three assessment indicators used, followed by the $MPPT$ system. The $WLC$ system is not recommended for use, due to its low electricity production and low efficiency of the micro-hydropower plant. Full article

In this paper, mechanical property tests of sandstone with multiple shapes of prefabricated fractures (single, T-shaped, and Y-shaped fractures) are carried out through the MTS815 rock mechanics testing machine and the Teledyne ISCO D-Series Pumps system. Considering the hydro-mechanical coupling effects, the experiments reveal the key thresholds, strength characteristics and deformation laws of multi-shape fractured sandstones during the progressive failure process. According to the elastic-plastic theory, the continuous damage theory and the statistical damage theory, a new damage model is constructed, which fully reflects the coupled effects among water, micro flaws and macroscopic prefabricated fractures. The crack closure stress σ_cc, crack initiation stress σ_ci and damage stress σ_cd of multi-shape fractured sandstone samples are determined by the proposed volumetric strain response method. In the range of 0–90°, the σ_cc and σ_ci of the multi-shape fractured sandstone samples are different, as well as the angles when the σ_cd and peak strength (σ_c) reach their peak values. The stress ratios (the σ_cc/σ_c, σ_ci/σ_c, and σ_cd/σ_c are collectively referred to as stress ratios) are hardly affected by the shape and inclination of the fractures inside the rock. According to strength analysis and deformation characteristics, the weakening effect of water has less of an influence on the strength than prefabricated fractures. The stress–strain curve obtained, based on the hydro-mechanical coupling test, is in good agreement with the theoretical curve generated by the damage constitutive model, verifying the rationality of the damage constitutive model. In addition, the fracture inclination only affects the numerical value of the total damage variable of multi-shape fractured sandstone samples, and has minor effects on its variation trend. Full article

A concept of a nanoporous anodic aluminum oxide (AAO) membrane as a vibro-active micro/nano-filter in a micro hydro mechanical system for the filtration, separation, and manipulation of bioparticles is reported in this paper. For the fabrication of a nanoporous AAO, a two-step mild anodization (MA) and hard anodization (HA) technique was used. Atomic force microscopy (AFM) and scanning electron microscopy (SEM) were used to analyze the surface morphology of nanoporous AAO. A nanoporous structure with a pore diameter in the range of 50–90 nm, an interpore distance of 110 nm, and an oxide layer thickness of 0.12 mm with 60.72% porosity was obtained. Fourier-transform infrared spectroscopy (FTIR) and energy-dispersive X-ray spectroscopy (EDS) were employed to evaluate AAO chemical properties. The obtained results showed that the AAO structure is of hexagonal symmetry and showed where Al₂O₃ is dominant. The hydrophobic properties of the nanoporous surface were characterized by water contact angle measurement. It was observed that the surface of the nanoporous AAO membrane is hydrophilic. Furthermore, to determine whether a nanomembrane could function as a vibro-active nano filter, a numerical simulation was performed using COMSOL Multiphysics 5.4 (COMSOL Inc, Stockholm, Sweden). Here, a membrane was excited at a frequency range of 0–100 kHz for surface acoustics wave (SAW) distribution on the surface of the nanoporous AAO using a PZT 5H cylinder (Piezo Hannas, Wuhan, China). The SAW, standing acoustic waves, and travelling acoustic waves of different wavelengths were excited to the fabricated AAO membrane and the results were compared with experimental ones, obtained from non-destructive testing method 3D scanning vibrometer (PSV-500-3D-HV, Polytec GmbH, Waldbronn, Germany) and holographic interferometry system (PRISM, Hy-Tech Forming Systems (USA), Phoenix, AZ, USA). Finally, a simulation of a single nanotube was performed to analyze the acoustic pressure distribution and time, needed to center nanoparticles in the nanotube. Full article

This paper discusses the problem of thermocycling effect of light-curing polymer–ceramic composites. Cyclic thermal shocks were simulated in laboratory conditions. As a rule, these loads were supposed to reproduce the actual conditions of biomaterials exploitation. Periodically variable stresses occurring in dental restorations are associated with the wear of cold and hot foods and beverages. They lead to changes in the properties of composites, including the properties of the surface layer. The aim of the work was to assess the impact of cyclic hydrothermal interactions on the properties of the surface layer of composites relevant to the operational quality. Two commercial materials manufactured by the world’s leading producer (3M ESPE)—Filtek Z550, Filtek Flow and two experimental, micro-hybrid and flow type composites marked Ex-mhyb(P) and Ex-flow(P), respectively. All tests were carried out before and after hydro-thermal cycles (flowing water thermocycling). Micro-hardness test using the Vickers method, indentation hardness, and resistance to tribological wear in a ball–disc system in sliding friction conditions were performed. In addition, observations of the surface layer of composites on the SEM (scanning electron microscope) were carried out. It was noticed that semi-liquid composites, containing a smaller amount of filler, retain higher stability of mechanical and tribological properties of the surface layer under cyclic hydro-thermal loads. Coefficient of friction of samples after hydro-thermal cycles increased for micro-hybrid materials and Filtek Flow (FFlow) composite. In the case of Ex-flow(P) material, the coefficient of friction decreased. The microhardness of composites also changed, the variability of this size depended on the type of material. Composites with a higher content of filler particles were characterized by greater variability of microhardness under the influence of thermocycles. The resistance to tribological wear also changed in a similar way. Composites containing higher volume fraction of inorganic filler showed higher tribological wear after thermocycling. The wear resistance of flow composites changed to a lesser extent, after thermocycling increased. The paper also showed that, in real kinematic nodes, the surface layer of light-curing ceramic–polymer composites is exposed to significant non-tribological (erosive, thermal, and chemical) defects that synergize with tribological ones. In slip pairs loaded dynamically, under mixed friction conditions, tribological wear of PMCCs (polymer matrix ceramic composites) is manifested by spalling (spalling of the material flakes, in particular the polymer phase) and pitting (crushing wear caused by wear products, in particular large filler particles or clusters, previously adhesively extracted). Full article

Micro-hydro systems can be used as a promising new source of renewable energy generation, requiring a low investment cost of hydraulic, mechanical, and electrical equipment. The improvement of the water management associated with the use of pumps working as turbines (PATs) is a real advantage when the availability of these machines is considered for a wide range of flow rates and heads. Parallel turbomachines can be used to optimize the flow management of the system. In the present study, experimental tests were performed in two equal PATs working in parallel and in single mode. These results were used to calibrate and validate the numerical simulations. The analysis of pressure variation and head losses was evaluated during steady state conditions using different numerical models (1D and 3D). From the 1D model, the installation curve of the system was able to be defined and used to calculate the operating point of the two PATs running in parallel. As for the computational fluid dynamics (CFD) model, intensive analysis was carried out to predict the PATs′ behavior under different flow conditions and to evaluate the different head losses detected within the impellers. The results show system performance differences between two units running in parallel against a single unit, providing a greater operational flow range. The performance in parallel design conditions show a peak efficiency with less shock losses within the impeller. Furthermore, by combining multiple PATs in parallel arrangement, a site’s efficiency increases, covering a wide range of applications from the minimum to the maximum flow rate. The simulated flow rates were in good agreement with the measured data, presenting an average error of 10%. Full article

This paper reviews recent investigations and achievements in the design of controllable functional components for improving microfluidic systems, its effectiveness, and functionality. The main purpose was to design novel microstructures with piezoelectric properties (microresonators), which enable one to control the effectiveness of fluid flow in micro-hydro-mechanical devices for biomedical/biochemical purposes. Controllable properties were obtained by incorporating different types of binders in a piezoelectric ceramic matrix (lead zirconate titanate): polyvinyl butyral (PVB), poly methyl methacrylate (PMMA), and polystyrene (PS). The change in chemical composition of PZT helps to manipulate the piezoelectric characteristics, surface morphology, mechanical properties, etc., of the designed microfluidic element with the microstructure in it. Full article

The increase in contributions from non base load renewables, such as wind and solar, can have adverse effects on the stability of an electrical grid. In this study, the possibility of rapidly loading a Francis turbine from a tail water depression (TWD) mode for providing additional system frequency control is investigated. Based on the analysis of full-scale TWD test results and key findings from the transient testing of a micro-hydro scale turbine unit, a detailed description of the TWD transition process is given. The formulation of an improved turbine model for use in one-dimensional hydro-electric plant models is presented with simulation results compared to full-scale data. The analytical model, which calculates output power according to the conservation of angular momentum and identified sources of loss, is used in parallel with full-scale and model scale test observations to elucidate the events and mechanisms occurring during this proposed transition. The output response, in terms of active power, was found to be highly dependent on guide vane opening rate in both full-scale and model tests. For an approximate doubling in opening rate, the duration of the reverse power flow was reduced by 38% and 21%, for full-scale and model units, while the low pressure transient increased by 16% and 8%, respectively. The analytical model was shown to capture the general response characteristic in all cases tested; however, output power response was over predicted due to two identified model assumptions made, while, for the more rapid opening, the penstock pressure was under predicted by approximately 15%. Full article
