This paper presents the results of beam investigations on semiconductor IR lasers using novel detectors based on thermocouples. The work covers the design, the fabrication of detectors, and the experimental validation of their sensitivity to IR radiation. The principle of operation of the manufactured detectors is based on the Seebeck effect (the temperature difference between hot and cold junctions induced voltage appearance). The devices were composed of several thermocouples arranged in a linear array. The nano- and microscale thermocouples (the hot junctions) were fabricated using a typical Si-compatible MEMS process enhanced with focused ion beam (FIB) milling. The performance of the hot junctions was tested, focusing on their sensitivity to IR radiation covering the near-infrared (NIR) radiation (λ = 976 nm). The output voltage was measured as a function of the detector position in the XY plane. The measurement results allowed for reconstructing the Gaussian-like intensity distribution of the incident light beam. Full article

This study develops a TEMH (thermoelectric energy micro harvester) chip utilizing a commercial 0.18 μm CMOS (complementary metal oxide semiconductor) process. The chip contains a TEMH and temperature sensors. The TEMH is established using a series of 54 thermocouples. The use of the temperature sensors monitors the temperature of the thermocouples. One temperature sensor is set near the cold part of the thermocouples, and the other is set near the hot part of the thermocouples. The performance of the TEMH relies on the TD (temperature difference) at the CHP (cold and hot parts) of the thermocouples. The more the TD at the CHP of the thermocouples increases, the higher the output voltage and output power of the TEMH become. To obtain a higher TD, the cold part of the thermocouples is designed as a suspended structure and is combined with cooling sheets to increase heat dissipation. The cooling sheet is constructed of a stack of aluminum layers and is mounted above the cold part of the thermocouple. A finite element method software, ANSYS, is utilized to compute the temperature distribution of the TEMH. The TEMH requires a post-process to obtain the suspended thermocouple structure. The post-process utilizes an RIE (reactive ion etch) to etch the two sacrificial materials, which are silicon dioxide and silicon substrate. The results reveal that the structure of the thermocouples is completely suspended and does not show any injury. The measured results reveal that the output voltage of the TEMH is 32.5 mV when the TD between the CHP of the thermocouples is 4 K. The TEMH has a voltage factor of 8.93 mV/mm²K. When the TD between the CHP of the thermocouples is 4 K, the maximum output power of the TEMH is 4.67 nW. The TEMH has a power factor of 0.31 nW/mm²K². Full article

The focused ion beam (FIB) technique was used to fabricate a nanothermocouple (with a 90 nm wide nanojunction) based on a metal–semiconductor (Pt–Si) structure, which showed a sensitivity up to 10 times larger (with Seebeck coefficient up to 140 µV/K) than typical metal–metal nanothermocouples. In contrast to the fabrication of nanothermocouples which requires a high-tech semiconductor manufacturing line with sophisticated fabrication techniques, environment, and advanced equipment, FIB systems are available in many research laboratories without the need for a high-tech environment, and the described processing is performed relatively quickly by a single operator. The linear response of the manufactured nanothermocouple enabled sensitive measurements even with small changes of temperature when heated with a stream of hot air. A nonlinear response of the nanothermocouple (up to 83.85 mV) was observed during the exposition to an argon-laser beam with a high optical power density (up to 17.4 Wcm⁻²), which was also used for the laser annealing of metal–semiconductor interfaces. The analysis of the results implies the application of such nanothermocouples, especially for the characterization of laser beams with nanometer spatial resolution. Improvements of the FIB processing should lead to an even higher Seebeck coefficient of the nanothermocouples; e.g., in case of the availability of other suitable metal sources (e.g., Cr). Full article

In this research, a new application of reduced graphene oxide (rGO) for a complementary metal-oxide-semiconductor (CMOS)-MEMS infrared (IR) sensor and emitter is proposed. Thorough investigations of IR properties including absorption and emission were proceeded with careful calibration and measurement with a CMOS thermoelectric sensor. The thermocouples of the sensor consist of aluminum and n-polysilicon layers which are fabricated with the TSMC 0.35 μm CMOS process and MEMS post-process. In order to improve the adhesion of rGO, a sensing area at the center of the membrane is formed with an array of holes, which is easy for the drop-coating of rGO material upon the sensing region. To evaluate the performance of the IR sensor with rGO, different conditions of the IR thermal radiation experiments were arranged. The results show that the responsivity of our proposed CMOS-MEMS IR sensor with rGO increases by about 77% compared with the sensor without rGO. For different IR absorption incident angles, the measurement of field of view shows that the CMOS-MEMS IR sensor with rGO has a smaller view angle, which can be applied for the application of long-distance measuring. In addition, characteristics of the proposed thermopile are estimated and analyzed with comparisons to the available commercial sensors by the experiments. Full article

Two-dimensional (2D) materials have shown promise in various optical and electrical applications. Among these materials, semiconducting transition metal dichalcogenides (TMDs) have been heavily studied recently for their photodetection and thermoelectric properties. The recent progress in fabrication, defect engineering, doping, and heterostructure design has shown vast improvements in response time and sensitivity, which can be applied to both contact-based (thermocouple), and non-contact (photodetector) thermal sensing applications. These improvements have allowed the possibility of cost-effective and tunable thermal sensors for novel applications, such as broadband photodetectors, ultrafast detectors, and high thermoelectric figures of merit. In this review, we summarize the properties arisen in works that focus on the respective qualities of TMD-based photodetectors and thermocouples, with a focus on their optical, electrical, and thermoelectric capabilities for using them in sensing and detection. Full article

This paper introduces a thermoelectric-type sensor with a built-in heater as an alternative approach to the measurement of vacuum pressure based on frequency modulation. The proposed sensor is fabricated using the TSMC (Taiwan Semiconductor Manufacturing Company, Hsinchu, Taiwan) 0.35 μm complementary metal-oxide-semiconductor-microelectro-mechanical systems (CMOS–MEMS) process with thermocouples positioned central-symmetrically. The proposed frequency modulation technique involves locking the sensor output signal at a given frequency using a phase-lock-loop (PLL) amplifier to increase the signal-to-noise ratio (SNR) and thereby enhance the sensitivity of vacuum measurements. An improved first harmonic signal detection based on asymmetrical applied heating gives a precise measurement. Following calibration, the output voltage is in good agreement with the calibration values, resulting in an error of 0.25% under pressures between 0.1–10 Torr. Full article

Thermocouples classically consist of two metals or semiconductor components that are joined at one end, where temperature is measured. Carbon black is a low-cost semiconductor with a Seebeck coefficient that depends on the structure of the carbon particles. Different carbon black screen-printing inks generally exhibit different Seebeck coefficients, and two can therefore be combined to realize a thermocouple. In this work, we used a set of four different commercially available carbon-black screen-printing inks to print all-carbon-black thermocouples. The outputs of these thermocouples were characterized and their Seebeck coefficients determined. We found that the outputs of pure carbon-black thermocouples are reasonably stable, linear, and quantitatively comparable to those of commercially available R- or S-type thermocouples. It is thus possible to fabricate thermocouples by an easily scalable, cost-efficient process that combines two low-cost materials. Full article

The fabrication and characterization of a thermoelectric energy harvester using the complementary metal oxide semiconductor (CMOS)-microelectromechanical system (MEMS) technology were presented. The thermoelectric energy harvester is composed of eight circular energy harvesting cells, and each cell consists of 25 thermocouples in series. The thermocouples are made of p-type and n-type polysilicons. The output power of the energy harvester relies on the number of the thermocouples. In order to enhance the output power, the energy harvester increases the thermocouple number per area. The energy harvester requires a post-CMOS process to etch the sacrificial silicon dioxide layer and the silicon substrate to release the suspended structures of hot part. The experimental results show that the energy harvester has an output voltage per area of 0.178 mV·mm⁻²·K⁻¹ and a power factor of 1.47 × 10⁻³ pW·mm⁻²·K⁻². Full article

This paper presents the fabrication and characterization of energy harvesting thermoelectric micro generators using the commercial complementary metal oxide semiconductor (CMOS) process. The micro generator consists of 33 thermocouples in series. Thermocouple materials are p-type and n-type polysilicon since they have a large Seebeck coefficient difference. The output power of the micro generator depends on the temperature difference in the hot and cold parts of the thermocouples. In order to increase this temperature difference, the hot part of the thermocouples is suspended to reduce heat-sinking. The micro generator needs a post-CMOS process to release the suspended structures of hot part, which the post-process includes an anisotropic dry etching to etch the sacrificial oxide layer and an isotropic dry etching to remove the silicon substrate. Experiments show that the output power of the micro generator is 9.4 mW at a temperature difference of 15 K. Full article

This work presents a thermoelectric micro generator fabricated by the commercial 0.35 μm complementary metal oxide semiconductor (CMOS) process and the post-CMOS process. The micro generator is composed of 24 thermocouples in series. Each thermocouple is constructed by p-type and n-type polysilicon strips. The output power of the generator depends on the temperature difference between the hot and cold parts in the thermocouples. In order to prevent heat-receiving in the cold part in the thermocouples, the cold part is covered with a silicon dioxide layer with low thermal conductivity to insulate the heat source. The hot part of the thermocouples is suspended and connected to an aluminum plate, to increases the heat-receiving area in the hot part. The generator requires a post-CMOS process to release the suspended structures. The post-CMOS process uses an anisotropic dry etching to remove the oxide sacrificial layer and an isotropic dry etching to etch the silicon substrate. Experimental results show that the micro generator has an output voltage of 67 μV at the temperature difference of 1 K. Full article
