Search Results (25)

The automotive market is looking for innovative braking solutions that can mitigate or eliminate secondary emissions. For this reason, new braking paradigms have been developed, and magnetorheological brakes could be considered a suitable solution due to their performance and controllability features. Reliability is a key factor for automotive braking systems, so it is essential to analyze the behavior of such technological solutions in iterative cycles to understand their capability of maintaining brake performance throughout their operative lifecycles. This article presents a preliminary experimental durability analysis and defines the testing standard procedures to be used as boundaries for this analysis. Then, a durability test bench is developed and produced to evaluate the magnetorheological fluid over an equivalent distance of 100,000 km. After the tests, the fluid’s characteristics are compared to its original features using a rheometer apparatus and Scanning Electron Microscopy (SEM). Full article

This work focused on the development of a complete laboratory procedure for the rheological characterization of magnetorheological fluids (MRFs) by combining information gained from the literature and practical work performed in the laboratory. The procedure developed involves all the experimental stages for a comprehensive analysis, starting from the sample preparation, choice of the optimal measuring system, definition of the test, and rheometric parameters for the execution of an accurate and reliable analysis. Magnetorheology is a critical approach for studying the field-dependent properties of MRFs; however, measurement errors, often stemming from inappropriate rheometric test parameters, pose significant challenges. Additionally, sedimentation, caused by the large density mismatch between magnetic particles and the carrier fluid, presents a major obstacle that can compromise the analysis. Extensive work was performed for selecting the test parameters as well as defining the most relevant type of analysis to conduct with the defined procedure for the definition of the essential properties of an MRF for braking applications. This work is essential for the development of accurate card material for simulation tools, paving the way for broader utilization of MRFs in cutting-edge technologies. Full article

The Halbach array is a significant advancement in designing permanent magnets with a specialized arrangement due to their unique capacity to generate strong unidirectional magnetic fields, which have attracted substantial attention in various applications. This arrangement allows for the construction of more efficient and compact magnetic systems, contributing to innovation across multiple fields. This study introduces a segmented Halbach array design using NdFeB permanent magnets in a cylindrical configuration, optimized to maximize flux density and minimize flux leakage. Critical design parameters, including the magnet dimensions and the gap width between the magnets, are systematically analyzed to identify the optimal arrangement. A corresponding simulation design was performed by COMSOL Multiphysics software, which can model complex magnetic fields and flux patterns. The proposed Halbach array design offers significant advantages over conventional magnet arrangements, including a 50% increase in flux density, a 75% reduction in magnet material usage, and improved magnetic field uniformity. Using the segmented Halbach arrangement in the development of passive magnetorheological braking systems can double the braking torque, leading to higher torque output in more compact designs. The outcomes of this research contribute to the progress of energy efficiency, providing efficient and reliable braking performance. Full article

Magnetorheological (MR) brakes are flourishing in low-torque applications due to their dynamic controllability nature. Researchers have introduced multi-layer and multipole concepts to increase the torque–volume ratio (TVR) of the MR brake. However, the combination of these two ideas did not exist due to the design limitations. Therefore, this study aims to design a brake that combines the multipole magnetic field and multi-layered structure concepts. The axial slots were introduced on the brake rotor and the stator drum axial surfaces to achieve a high TVR. These slots stop the flux bypass in the inner layers; therefore, the magnetic flux can also reach the brake’s outer layers. This brake was designed with multiple stator and rotor drums and MR fluid layers. The number of poles was placed so that the magnetic field from these poles traveled in a closed loop via the stator, rotor, and MR layers. A 3D model of the brake was prepared for the virtual study. Electromagnetic simulations were conducted to analyze the effect of axial slots’ and other design parameters of the brake. According to those simulation results, the axial slots’ width and position significantly affect the brake output torque. The maximum torque obtained from the brake is 38 Nm, and the TVR value of the brake is 41 Nm/dm³. Additionally, multiphysics simulations were performed to understand the Joule-heating effect of the magnetic coil and the frictional heating in MR fluid. Results showed that the maximum possible temperature in the brake is under the MR fluid temperature limits. Therefore, this multipole multi-layered (MPML) MR brake with axial slots idea is very useful for high-torque MR brake growth. Full article

A multi-objective intelligent optimization algorithm-based attitude control strategy for magnetorheological semi-active suspension is proposed to address the vehicle attitude imbalance generated during steering and braking. Firstly, the mechanical properties of the magnetorheological damper (MRD) are tested, and the parameters in the hyperbolic tangent model of the magnetorheological damper are identified through experiments. Secondly, a simulation model of the whole vehicle multi-degree-of-freedom vehicle dynamics including magnetorheological damper is established, and the whole-vehicle Linear Quadratic Regulator (LQR) controller is designed. Then, the optimization design model of the joint vehicle controller and vehicle dynamics is established to design the optimization fitness function oriented to the body attitude control performance, and the attitude optimal controller is calculated with the help of multi-objective intelligent optimization algorithm. Simulation results show that the proposed control method is able to improve the body roll angle, body pitch angle, and suspension dynamic deflection well on the basis of ensuring no deterioration in other performance indexes, ensuring good attitude control capability of the vehicle and verifying the feasibility of the control strategy. Full article

The magnetorheological brake (MRB) epitomized a revolutionary modification in the braking systems because of its extremely efficient and well-controlled performance. To increase the safety and controllability of automotive braking system, researchers have developed a different MRB structures. Although much research on magnetorheological brakes has shown positive results in terms of brake torque, braking time, thermal efficiency, etc., the ability to increase braking force by expanding the disc surface, through which the magnetic field operates in a compact structure, is restricted. To address this issue, a new multipole MRB configuration with a unique pole head design that maintains compactness. Initially, the conceptual design was achieved by leveraging the combined impact of the twin disc-type structure and multipole concept. The model was used in a dynamic simulation to show how the braking torque of a magnetorheological braking system varies with coil current. The effects of circular sector pole head shape on braking performance were investigated using COMSOL Multiphysics software (version 5.5). A three-dimensional electromagnetic model of the proposed MRB was developed to examine the magnetic flux intensity and the impact of magnetic field dispersion on the proposed pole head structure of a magnetorheological brake. Based on simulation results, the circular sector pole head configuration is capable of increasing the active chaining regions for the MR fluid on the rotor surface, allowing for a more effective use of magnetic flux throughout the whole surface of a rotating brake disc, thereby increasing the magnetic field usage rate. The acquired simulation results show an increase in braking torque while keeping a compact and practical design structure. Full article

This article focuses on modelling and validating a groundbreaking magnetorheological braking system. Addressing shortcomings in traditional automotive friction brake systems, including response delays, wear, and added mass from auxiliary components, the study employs a novel brake design combining mechanical and electrical elements for enhanced efficiency. Utilizing magnetorheological (MR) technology within a motor–brake system, the investigation explores the influence of external magnetic flux from the nearby motor on MR fluid movement, particularly under high-flux conditions. The evaluation of a high-magnetic-field mitigator is guided by simulated findings with the objective of resolving potential issues. An alternative method of resolving an interaction between an electric motor and a magnetorheological brake is presented. In addition, to test four configurations, multiple absorber materials are reviewed. Full article

Knee orthosis plays a vital role in enhancing the wellbeing and quality of life of individuals suffering from knee arthritis. This study explores a machine-learning-based methodology for predicting a user’s gait subphase using inertial measurement units (IMUs) for a semiactive orthosis. A musculoskeletal simulation is employed with the help of existing experimental motion-capture data to obtain essential metrics related to the gait cycle, which are then normalized and scaled. A meticulous data capture methodology using foot switches is used for precise synchronization with IMU data, resulting in comprehensive labeled subphase datasets. The integration of simulation results and labeled datasets provides activation data for effective knee flexion damping following which multiple supervised machine learning algorithms are trained and evaluated for performances. The time series forest classifier emerged as the most suitable algorithm, with an accuracy of 86 percent, against randomized convolutional kernel transform, K-neighbor time series classifier, and long short-term memory–fully convolutional network, with accuracies of 68, 76, and 78, respectively, showcasing exceptional performance scores, thereby rendering it an optimal choice for identifying gait subphases and achieving the desired level of damping for magnetorheological brake-mounted knee orthosis based on simulated results. Full article

Magnetorheological fluid brakes are a promising technology for developing high-performance drive-by-wire braking systems due to their controllability and adaptability. This research aims to design an optimal magnetorheological fluid brake for motorcycles and their performance. The proposed model utilizes mathematical modeling and finite element analysis using commercial software. Furthermore, the optimization of this MR brake is determined through multi-objective optimization with a genetic algorithm that maximizes braking torque while simultaneously minimizing weight and the cruising temperature. The novelty lies in the geometric shape of the disc, bobbin, and MR fluid channels, which results in a light MR brake weighing 6.1 kg, an operating temperature of 89.5 °C, and a power consumption of 51 W with an output braking torque of 303.9 Nm. Additionally, the control performance is evaluated using an extended Kalman filter controller. This controller effectively regulates braking torque, speed, and slip rate of both the rear and front wheels based on road characteristics and motorcycle dynamics. This study’s findings show that the front wheel necessitates higher braking torque compared to the rear wheel. Moreover, the slip rate is higher on the rear wheel than on the front wheel, but the front wheel stops earlier than the rear wheel. Full article

A magnetorheological brake (MRB) works on the shearing effect of MR fluid in the magnetic field to develop resistance between the stator and the rotor, which are relative moving surfaces. Researchers achieved high torque volume ratios in magnetorheological fluid braking systems by adding multiple layers and using multipole approaches. Even though several designs already exist, there is a need for innovative ideas and advanced structures of MRBs for practical engineering applications. The number of magnetic poles, pole geometry and placement have a significant effect on the performance of multipole MR brakes. This research focused on the effect of the pole head geometry in a multipole dual disc compact MR brake to understand the relationship between the geometry and its magnetic flux flow. The magnetic field generated by the electromagnetic coil’s orthogonal travel through pole heads, rotor and MR fluid layers results in friction to fulfill the action of braking that achieves maximum brake torque. This flow depends on the magnetic pole head area and corresponding core dimensions. This study considered polygon, square, hexagon, trapezoid and ellipse pole head profiles in place of the conventional circular pole and the best possible core dimensions were used for each geometry. To study the brake’s performance, COMSOL Multiphysics software (version 5.5) commonly used for 3D electromagnetic modeling was used to simulate and examine the magnetic flux intensity for various pole head configurations. Results indicate an improvement compared to previous works, considering the same dimensional limitations and the flux leakage between the adjacent poles being much less. The hexagonal and elliptical pole heads had better magnetic field area, magnetic intensity distribution and higher magnetic flux lines piercing through the MR fluid perpendicularly than the circular and square pole heads. An increment of 3.88% for braking torque performance was obtained, and the braking torque was significantly enhanced. Full article

The paper presents a field model of coupled phenomena occurring in an axisymmetric magnetorheological brake. The coupling between transient fluid dynamics and electromagnetic and thermal fields as well as mechanical equilibrium equations is taken into account. The magnetic field in the studied brake is of an excited hybrid manner, i.e., by the permanent magnets (PMs) and current I_s in the excitation winding. The finite element method and a step-by-step algorithm have been implemented in the proposed field model of coupled phenomena in the considered brake. The nonlinearity of the magnetic circuit and rheological properties of a magnetorheological fluid (MR fluid) as well as the influence of temperature on the properties of materials have been taken into account. To solve equations of the obtained field model, the Newton–Raphson method and the coupled block over-relaxation method have been implemented. The elaborated algorithm has been successfully used in the analysis of the phenomena in the considered magnetorheological brake. The accuracy of the developed model and its usefulness have been verified by a comparative analysis of the results of simulation and laboratory tests carried out for the developed prototype of the studied brake. Full article

Many studies focus on the torque-to-dimension ratio when designing magnetorheological brakes (MRB), especially for ankle foot orthosis (AFO) devices. Vane MRB is one type of MRB with a limited angle of motion that is naturally suitable to be applied to AFO. However, very few implement quality function deployment (QFD) when making MRB, whereas QFD is an essential factor in making product designs. In this study, a tiny vane-type MR brake (TVMRB) was successfully made using the QFD method. Torque characteristics are determined by analysis of magnetic flux density, theoretically, by 3D simulation, and by using Ansys Maxwell experimentally. For consideration, the analysis was carried out with fluid gap variations (0.5 mm, 0.75 mm, and 1 mm) and current variations (0.5–2 A with 0.5 A increments). As a result, ignoring the leakage of MR fluid (MRF), at a constant rotation of 10 rpm, the smallest torque of 6.14 Nm was obtained at the fluid gap variation of 1 mm and input current of 0.5 A, whereas the largest torque was 46.71 Nm at the fluid gap variation of 0.5 mm and input current of 2 A. Apart from torque, this article will also discuss other brake performances in the form of operational range and power consumption. Finally, the structure of the TVMRB design is compared with other designs presented in the House of Quality (HOQ). Full article

In order to improve the response characteristics of magnetorheological fluid brake (MRB) and reduce the braking fluctuation rate, an improved grey wolf optimization algorithm was proposed to adjust the parameters of the proportion integration differentiation (PID) controller. Firstly, an MRB system was designed and constructed, and its transfer function was determined. Moreover, by adopting the iterative method of logistic curve, an enhanced grey wolf optimization algorithm (EGWOA) was presented. Using the EGWOA, the parameters of the PID controller were optimized to improve the control performance of the system. Finally, the simulation and experiment were carried out. The results showed that EGWOA has a faster response output and overall better performance without overshoot compared with the conventional PID and grey wolf optimization algorithm (GWOA) PID controller. Full article

Recently, magnetorheological grease (MRG) has been utilized in magnetorheological (MR) brakes to generate a braking torque based on the current applied. However, the high initial viscosity of MRG has increased the off-state torque that led to the viscous drag of the brake. Therefore, in this study, the off-state viscosity of MRG can be reduced by the introduction of dilution oil as an additive. Three samples consist of pure MRG (MRG 1) and MRG with different types of dilution oil; hydraulic (MRG 2) and kerosene (MRG 3) were prepared by mixing grease and spherical carbonyl iron particles (CIP) using a mechanical stirrer. The rheological properties in the rotational mode were examined using a rheometer and the torque performances in MR brake were evaluated by changing the current of 0 A, 0.4 A, 0.8 A, and 1.2 A with fixed angular speed. The result shows that MRG 3 has the lowest viscosity which is almost 93% reduction while the viscosity of MRG 2 has lowered to 25%. However, the torque performances generated by MRG 3 were highest, 1.44 Nm, when 1.2 A of current was applied and followed by MRG 2 and MRG 1. This phenomenon indicated that the improvement of torque performances was dependent on the viscosity of MRG. By reducing the viscosity of MRG, the restriction on CIP to form chain formation has also decreased and strengthen the torque of MRG brake. Consequently, the utilization of dilution oil in MRG could be considered in MR brake in near future. Full article

With the diversification of robots, modularization of robots has been attracting attention. In our previous study, we developed a robot that mimics the principle of human joint drive using a straight-fiber-type pneumatic rubber artificial muscle (“artificial muscle”) and a magnetorheological fluid brake (“MR brake”). The variable viscoelastic joints have been modularized. Therefore, this paper evaluates the basic characteristics of the developed Joint Module, characterizes the variable viscoelastic joint, and compares it with existing modules. As basic characteristics, we confirmed that the Joint Module has a variable viscoelastic element by experimentally verifying the joint angle, stiffness, viscosity, and tracking performance of the generated torque to the command value. As a characteristic evaluation, we verified the change in motion and response to external disturbances due to differences in driving methods through simulations and experiments and proved the strength of the variable viscoelastic joint against external disturbances, which is a characteristic of variable viscoelastic joints. Based on the results of the basic characterization and the characterization of the variable viscoelastic drive joint, we discussed what kind of device the Joint Module is suitable to be applied to and clarified the position of the variable viscoelastic joint as an actuator system. Full article
