The problem of the shape optimization of tubular-type plug-flow chemical reactors equipped with a fluid flow-based cooling system is considered in this work. The hydraulic radius R_h(z) = 2A(z)/P(z) and an equivalent surface area-based radius R_s = P(z)/(2π) were computed from the cross-sectional area A(z) and perimeter P(z) measured along the nasal duct of Northern reindeer and used for shape optimization as nature-inspired design. The laminar flow in the cooling system was modeled using the Navier–Stokes equations for an incompressible liquid. In the central tube, a set of chemical reactions with temperature-dependent rates was considered. The temperature and flow velocity fields, pumping pressure, mass flow rate, and total heat flux J_th were obtained by numerical methods. Comparative analyses of the efficiency of different geometries were conducted on Pareto frontiers for hydraulic resistivity Z_h, thermal resistivity Z_th, thermal inlet length L_th, and entropy production S_irr as a sum of contributions from chemical reactions, thermal, and viscous dissipation. It was shown that the tube with R_s(z) as an interface between the reactor and cooler has the best Pareto efficiency using the (Z_h,Z_th,L_th) objective functions. Surprisingly, this design also exhibits the lowest S_irr and a more uniform distribution S_irr(z) (i.e., equipartition) among other designs. This geometry is suggested for densely packed tubular reactors. Full article

This study presents an experimental investigation focused on the interaction between a transverse injection of cold air (blowing) and the boundary layer over a heated flat plate. The flat plate was equipped with a cylindrical coil heater positioned at its center along the flow direction. The constant heat flux was maintained using a variable resistance potentiometer. The flat plate with the heater was mounted inside a subsonic wind tunnel to sustain a constant laminar air flow. The primary objective of this research was to examine the effects of cold air injections through localized holes in the flat plate near the trailing edge on the thermal boundary layer thickness ${\delta }_t(x,R{e}_x,Pr)$. The thermal boundary layer thickness was measured using K-type thermocouples and PT-100 RTD sensors, which are made to move precise, small distances using a specially constructed traversing mechanism. Cold air was injected using purposefully fabricated metal capillary tubes force-fitted into holes through the hot flat plate. The metal tubes were thermally insulated using class-F insulation, which is used in electric motor windings. The presented work focused on a fixed free-stream velocity and a fixed cold-injection velocity less than the free-stream velocity but for two-variable heat fluxes. The results show that the thermal boundary layer thickness generally increased due to the secondary cold flow. Full article

In this paper, the heat transfer and flow characteristics of a helically coiled tube with twisted elliptical in a low Reynolds number (Re = 500–3000) flow were investigated numerically. The working fluid flowed in a laminar regime. Numerical results were compared with empirical correlations in the existing literature, demonstrating the accuracy of the analysis in this study. Firstly, we investigated the effects of geometric parameters and Reynolds number on the heat transfer and flow characteristics. The results showed that lower twist pitch length and semi-major axis length could induce sufficient fluid mixing and a larger temperature gradient near the tube wall, enhancing the heat exchange and producing larger friction resistance. Overall, the heat transfer performances were improved by about 1.04–1.21 times and 1.02–1.23 times for different semi-major axis lengths and different twist pitch lengths, respectively, compared to the smooth helical coil. Secondly, by changing the working fluid, it was found that the Nu when oil was chosen as the working fluid was all 6–6.8 times higher than that of water. Moreover, the effect of using Al₂O₃ nanofluids with a concentration of 0.10 wt.%, 0.25 wt.% and 0.50 wt.% was discussed. It can be seen that the heat transfer capacity of nanofluids increased by approximately 2–18% compared to the reference model with water as the working fluid, and the nanofluid solution with higher concentration has better heat transfer performance. Finally, Nu and f correlations are given to predict the heat transfer and pressure drop in practical applications. Full article

A comprehensive review of published works dealing with numerical modelling of forced convection heat transfer and hydrodynamics of nanofluids is presented. Due to the extensive literature, the review is limited to straight, smooth, circular tubes, as this is the basic geometry in shell-and-tube exchangers. Works on numerical modelling of forced convection in tubes are presented chronologically in the first part of the article. Particular attention was paid to the method of the solution of governing equations, geometry of the heating section, and boundary conditions assumed. Influence of nanoparticles on heat transfer and flow resistance are discussed. Basic information is summarized in tabular form, separately for single-phase approach and two-phase models. The second part of the article contains the correlation equations proposed in the presented papers for the calculation of the Nusselt (Nu) number or heat transfer coefficient, separately for laminar and turbulent flow. Details of the type of nanofluids, the concentration of nanoparticles, and the Reynolds (Re) number range are also presented. Finally, advantages and disadvantages of individual numerical approaches are discussed. Full article

As an auxiliary component with the largest energy consumption in the fuel cell power system, the electric air compressor is of great significance to improve the overall efficiency of the system by reducing its power consumption under the premise of meeting the cathode intake demand. In this paper, the flow state of the gas in the flow field of the fuel cell TSEAC (two-stage electric air compressor) is analyzed by simulation, and the accuracy of the simulation results is verified by experiments. Through the research on the gas compression work of the fuel cell TSEAC, it is found that the higher temperature rise of the gas during the compression process will increase the compression work, thereby reducing the efficiency of the fuel cell TSEAC. Therefore, based on the field synergy theory, this paper designs the heat dissipation structure of the TSEAC elbow. In the common working conditions of fuel cell TSEAC, micro-fin tube is an effective energy-saving structure that takes into account heat dissipation enhancement and flow resistance, and its ratio of micro-fin height to laminar bottom layer thickness ε/δ = 1.6 has the best energy-saving effect. Finally, the energy-saving effect of the micro-fin tube is verified by simulation. The load torque of the optimized fuel cell TSEAC is reduced from 1.540 N·m to 1.509 N·m, and the shaft power is reduced from 14.51 kW to 14.22 kW. Its efficiency increased by 1.9%. Full article

The pressure change rate (PCR) of the brake chamber is the key control parameter and evaluation index in the pneumatic braking system for intelligent braking. The PCR threshold value of commercial vehicle brake chambers for braking comfort is analyzed. The PCR measurement method based on a laminar flow resistance tube is proposed, and the PCR test system is designed. The simulation model of a PCR test system for commercial vehicle brake chambers is presented. By analyzing the simulation and experimental results, it is validated that the PCR test system of commercial vehicle brake chambers has the function of measuring PCR in real time. Finally, according to the MSA (Measurement System Analysis) evaluation method, the performance of the PCR test system for commercial vehicle brake chambers is analyzed, and the correctness and applicability of the test system are verified. Full article

For intelligence brakes in the electronic pneumatic brake system of commercial vehicles, the pressure change rate is used as the key control parameter and evaluation index. This can improve the brake safety, stability, and ride comfort of the vehicle. The real-time detection of the brake pressure change rate for commercial vehicles is the premise for realizing the accurate control of brake pressure change rate. Based on Poiseuille’s law, an efficient measurement method of brake pressure change rate is proposed for commercial vehicles, and a new measuring device with an isothermal container and laminar flow resistance tube as the core components is designed. Through thermal insulation performance tests, flow resistance tests and measurement accuracy tests, combined with simulations, the effects of structural parameters and copper wire filling density on the performance of the isothermal container are analyzed, and these key parameters are optimized to improve the thermal insulation performance. A tubular laminar flow resistance tube composed of 304 stainless steel capillaries in parallel is designed. The influence mechanism of core parameters such as the number, radius, and length of laminar flow channels on its performance is studied, and the optimal parameter array is selected to optimize its performance. The experimental platform for measuring brake pressure change rate is constructed. By comparing the measurement curve of brake pressure change rate under simulation and experiment, the correctness and effectiveness of the pressure change rate measurement principle and the key components for electronically controlled pneumatic brakes of commercial vehicles are verified to meet engineering requirements. Full article

The mass transfer of ozone and oxygen into water through non-porous membranes was studied using computational fluid dynamics (CFD) modelling and fundamental convection-diffusion theory. Ozone is a gaseous oxidant that is widely applied in drinking water treatment. Membrane contactors are an alternative to conventional gas dispersion methods for injection of ozone gas mixtures into water. Few studies have explored computational approaches for membrane based ozone transport. In this investigation, quantitative concentration profiles across a single polydimethylsiloxane (PDMS) capillary membrane tube with internal gas flow and external liquid flow were obtained, including single mass transfer resistances and overall mass transfer coefficients for ozone and oxygen for varying membrane lengths, thicknesses, and laminar flow liquid side velocities. Both the influence of diffusivity and solubility of gases in the membrane were considered with the applied model. Previous studies have neglected the solubility of gases in the membranes in their analysis of ozone and oxygen gas fluxes. This work shows that the solubility has a significant impact of the overall mass transfer coefficients, in particular for oxygen. The main resistance for ozone was found in the liquid side, while for oxygen it was in the membrane. Mass transfer correlations based on heat transfer analogies revealed Sherwood (Sh) correlations for ozone and oxygen with good agreement to literature data, indicating that the applied computational model returns sensible results. The outcome of this study provides an initial basis for computational predictions of ozone and oxygen mass transfer for different membrane materials, flow conditions and reactor designs. Full article
