Search Results (14)

Introduction: Intramedullary nailing is widely used for long bone fractures. Traditional systems are reliable, but they present some complications regarding lack of modularity or possible growth plate damage. Methods: A novel locking rod–screw system featuring a central rod and a grooved screw with a secondary interlocking mechanism was developed and tested. Mechanical testing followed ASTM F543 and ISO 6475 standards using a 3.0 mm steel alloy prototype. Results: The system withstood mechanical testing >200,000 cycles at loads up to 200 N with no rates of failure or loosening, significantly outperforming other implants of the same size (3.0 mm TENS). Conclusions: The proposed implant demonstrates superior biomechanical performance in vitro, enabled by its unique hollow screw and secondary locking configuration. This modular and minimally invasive system shows promise for use in cases of smaller long bones, personalized paediatric fractures, and all types of diaphyseal fractures, but does warrant in vivo validation. Full article

Background/Objectives: This study evaluates the structural strength of various fixation models for distal tibial fractures using finite element analysis, comparing the biomechanical performance of different interlocking and blocking screw configurations in intramedullary nail fixation. Methods: Finite element models were developed for three different screw configurations: two interlocking screws (T2S), three interlocking screws (T3S), and two interlocking screws combined with two blocking screws (T2SBS2). Material properties were assigned using SAWBONES^® models, reflecting established biomechanical characteristics. The models were subjected to static axial loading (800 Nm), internal rotation (3500 Nm), and external rotation stresses. The stress distribution and structural integrity of each fixation model were analyzed. Results: The T3S model demonstrated the lowest maximum von Mises stress values across all loading conditions. Under axial loading, the maximum VMS at the medial first screw contact was the lowest in the T3S model (65.96 MPa) compared to T2S (135.68 MPa) and T2SBS2 (150.30 MPa). Similarly, internal rotation loading resulted in the lowest stress at the medial first screw site in T3S (64.86 MPa), compared to significantly higher stresses in T2S (136.29 MPa) and T2SBS2 (158.11 MPa). The T2SBS2 configuration showed effective stress reduction at the distal interlocking screws, highlighting its potential for improved load sharing. Conclusions: The findings underscore the importance of the secure fixation of the initial interlocking screw in distal tibial fractures. The fixation model utilizing three interlocking screws provided the most favorable overall stress distribution, whereas the inclusion of blocking screws effectively reduced stress concentrations at distal screw sites. Full article

Background and Clinical Significance: Non-prosthetic peri-implant fractures (NPPIFs) are rare injuries occurring around internal fixation devices, and are distinct from periprosthetic fractures. While most studies focus on the femur, humeral NPPIFs remain poorly documented. This case illustrates a complex humeral NPPIF and highlights key surgical considerations. Case Presentation: A 62-year-old woman presented with a spiral humeral shaft fracture (AO 12B2) after a fall. Following closed reduction and antegrade intramedullary nailing, an intraoperative peri-implant fracture occurred at the distal interlocking screw. CT imaging revealed a complex fracture extending from the lateral condyle to the proximal humerus. Treatment included implant removal and open reduction with dual plate fixation—lateral distal and helically contoured proximal plates—plus cerclage bands and antibiotic-loaded beads. Recovery was uneventful, with a full range of motion achieved at six months. At one year, the DASH score and MEPS were 86 and 75, respectively. Conclusions: Humeral NPPIFs are challenging and require individualized, biomechanically sound strategies. This case reinforces the importance of intraoperative assessment and careful implant selection in humeral fracture management. Full article

Background: Hip fractures are prevalent among the elderly and impose a significant burden on healthcare systems due to the associated high morbidity and costs. The increasing use of intramedullary nails for hip fracture fixation has inadvertently introduced risks; these implants can alter bone elasticity and create stress concentrations, leading to peri-implant fractures. The aim of this study is to investigate the outcomes of peri-implant hip fractures, evaluate the potential causes of such fractures, determine the type of treatment provided, assess the outcomes of said treatments, and establish possible improvement strategies. Methods: We conducted a retrospective observational study on 33 patients with peri-implant hip fractures (PIFs) who underwent surgical management at Río Hortega University Hospital from 2010 to 2022. The collected data included demographics, initial fracture characteristics, the peri-implant fracture classification, implant details, surgical outcomes, functional scores, and complications. Functional capacity was evaluated using the Parker Mobility Score (PMS). Results: The cohort (91% female, mean age 87.6 years) included 34 peri-implant fractures. The mean time from the initial fracture to the PIF was 47.2 months (nine patients developed PIFs within 2 months). Most fractures (76%) were managed with implant removal and the insertion of a long intramedullary nail, with cement augmentation in 31% of cases. The mean surgical time was 102 min, and the average hospital stay was 9.6 days. Postoperative complications occurred in 27%, with a perioperative mortality rate of 9%. Functional capacity showed a significant decline, with an average PMS loss of 4.16 points. Mortality at one year post-PIF was 36%, rising to 83% at five years. Radiographic consolidation was observed in 72% of cases at an average of 6.04 months, though 24% of patients died before consolidation. Statistically significant correlations were found for PMS pre-index fracture (PMS1: r = 0.354, p < 0.05), pre-PIF (PMS2: r = 0.647, p < 0.001), and post-PIF (PMS3: r = 0.604, p < 0.001). Conclusions: Peri-implant hip fractures present complex challenges due to their surgical difficulty and impact on patient mobility and survival. Successful management requires individualized treatment based on fracture type, implant positioning, and patient factors. These findings underscore the need for preventive measures, particularly in implant choice and techniques like overlapping and interlocking constructs, to minimize the secondary fracture risk. Full article

This article suggests a new waveguide design that utilizes a “walled” architecture. Instead of relying on conventional gap waveguide structures to create electronic bandgaps and prevent field leakage, the proposed design introduces a “walled” guiding mechanism. This technique preserves transmission while maintaining the multilayer approach and eliminates the need for nails or chemical bonds to attach the layers. Simulations were carried out in the W-band (75–110 GHz) and D-band (110–170 GHz) using several metals, and measurements were performed in the W-band using aluminum. The simulation results show that the reflection coefficient was less than −40 dB over the entire D-band. At the same time, the average insertion loss was around 0.0054 dB/mm and around 0.0065 dB/mm for silver and gold, respectively. Similarly, the reflection coefficient was less than −45 dB over the 75–110 GHz range, with an average insertion loss of 0.0018 dB/mm for silver and 0.003 dB/mm for gold, respectively. The aluminum model’s reflection coefficient was less than −35 dB, and the average insertion loss was 0.0035 dB/mm. The experimental results achieved a reflection coefficient of less than –30 dB and the average transmission coefficient was −0.2 dB, with an insertion loss of 0.002 dB/mm. The simple stacking ability of the weightless walled metal plates and easy fabrication makes the proposed transmission line a promising technology in mmWave and Terahertz applications. Full article

Extracapsular hip fractures are very common in the elderly. They are mainly treated surgically with an intramedullary nail. Nowadays, both endomedullary hip nails with single cephalic screw systems and interlocking double screw systems are available on the market. The latter are supposed to increase rotational stability and therefore decrease the risk of collapse and cut-out. A retrospective cohort study was carried out, in which 387 patients with extracapsular hip fracture undergoing internal fixation with an intramedullary nail were included to study the occurrence of complications and reoperations. Of the 387 patients, 69% received a single head screw nail and 31% received a dual integrated compression screw nail. The median follow-up was 1.1 years, and in that time, a total of 17 reoperations were performed (4.2%; 2.1% for single head screw nails vs. 8.7% for double head screws). According to the multivariate logistic regression model adjusted for age, sex and basicervical fracture, the adjusted hazard risk of reoperation required was 3.6 times greater when using double interlocking screw systems (p = 0.017). A propensity scores analysis confirmed this finding. In conclusion, despite the potential benefits of using two interlocking head screw systems and the increased risk of reoperation in our single center, we encourage to other researchers to explore this question in a wider multicenter study. Full article

The C-Nail^® system is a novel intramedullary fixation method for displaced intra-articular calcaneal fractures. The aim of this study was to evaluate the biomechanical performance of the C-Nail^® system and compare it with conventional plate fixation for the treatment of displaced intra-articular calcaneal fractures using finite element analysis. The geometry of a Sanders type-IIB fracture was constructed using the computer-aided design software Ansys SpaceClaim. The C-Nail^® system (Medin, Nové Mesto n. Morave, Czech Republic) and the calcaneal locking plate (Auxein Inc., 35 Doral, Florida) and screws were designed according to the manufacturer specifications. Vertical loading of 350 N and 700 N were applied to the subtalar joint surfaces to simulate partial weight bearing and full weight bearing. Construct stiffness, total deformation, and von Mises stress were assessed. The maximum stress on the C-Nail^® system was lower compared with the plate (110 MPa vs. 360 MPa). At the bone level the stress was found to have higher values in the case of the plate compared to the C-Nail^® system. The study suggests that the C-Nail^® system can provide sufficient stability, making it a viable option for the treatment of displaced intra-articular calcaneal fractures. Full article

In the current study, we designed and manufactured a scaffold and fixation system for the reconstruction of long-bone segmental defects in a rabbit tibia model. We used biocompatible and biodegradable materials, polycaprolactone (PCL) and PCL soaked with sodium alginate (PCL-Alg) to manufacture the scaffold, interlocking nail and screws using a phase separation casing method. Degradation and mechanical tests on the PCL and PCL-Alg scaffolds indicated that both were suitable for faster degradation and early weight-bearing capacity. PCL scaffold surface porosity facilitated the infiltration of alginate hydrogel through the scaffold. Cell viability results showed that the number of cells increased on Day 7 and decreased marginally by Day 14. For accurate placement of the scaffold and fixation system, a surgical jig was designed and 3D-printed using biocompatible resin in a stereolithography (SLA) 3D printer, then cured with UV light for increased strength. Our cadaver tests using New Zealand White rabbit confirmed our novel jigs’ potential for accurate placement of the bone scaffold, intramedullary nail and the alignment of the fixation screws in future reconstructive surgeries on rabbit long-bone segmental defects. Additionally, the cadaver tests confirmed that our designed nails and screws were strong enough to carry the surgical insertion force. Therefore, our designed prototype has the potential for further clinical translational study using the rabbit tibia model. Full article

Breakage of tibial interlocking nails is a rare complication and is associated with tibial nonunion. The distal part of a broken tibial nail is difficult to extract and can be a real challenge. Preoperative planning is important, as the retrieval techniques of broken implants are not routine operations. There are various techniques and instruments described by different authors with none being uniformly successful. Therefore, surgeons should know as many methods as possible to choose the most suitable one. Minimally invasive retrieval techniques should be favored because of their reduced morbidity, while fenestration extraction methods should be used as the second intention. Cannulated intramedullary nails are more prone to benefitting from minimally invasive retrieval techniques than solid ones. This paper reviews and describes the present techniques used to extract the distal part of broken tibial nails, to serve as a quick guide for surgeons who need it. Full article

Background and Objectives: Freehand distal interlocking of intramedullary nails is technically demanding and prone to handling issues. It requires precise placement of a screw through the nail under fluoroscopy guidance and can result in a time consuming and radiation expensive procedure. Dedicated training could help overcome these problems. The aim of this study was to assess construct and face validity of new Digitally Enhanced Hands-On Surgical Training (DEHST) concept and device for training of distal interlocking of intramedullary nails. Materials and Methods: Twenty-nine novices and twenty-four expert surgeons performed interlocking on a DEHST device. Construct validity was evaluated by comparing captured performance metrics—number of X-rays, nail hole roundness, drill tip position and drill hole accuracy—between experts and novices. Face validity was evaluated with a questionnaire concerning training potential and quality of simulated reality using a 7-point Likert scale. Results: Face validity: mean realism of the training device was rated 6.3 (range 4–7). Training potential and need for distal interlocking training were both rated with a mean of 6.5 (range 5–7), with no significant differences between experts and novices, p ≥ 0.234. All participants (100%) stated that the device is useful for procedural training of distal nail interlocking, 96% wanted to have it at their institution and 98% would recommend it to colleagues. Construct validity: total number of X-rays was significantly higher for novices (20.9 ± 6.4 versus 15.5 ± 5.3, p = 0.003). Success rate (ratio of hit and miss attempts) was significantly higher for experts (novices hit: n = 15; 55.6%; experts hit: n = 19; 83%, p = 0.040). Conclusion: The evaluated training device for distal interlocking of intramedullary nails yielded high scores in terms of training capability and realism. Furthermore, construct validity was proven by reliably discriminating between experts and novices. Participants indicate high further training potential as the device may be easily adapted to other surgical tasks. Full article

Background: Operative management of proximal humeral fractures is still challenging. While antegrade nailing has become a valid option in fracture fixation, risk factors for adverse events, and failure have not been sufficiently clarified. Methods: All patients of a single trauma center undergoing surgery for proximal humeral fractures with the Targon PH⁺ nail between 2014 and 2021 were evaluated retrospectively. This included complications, revisions, and failures. Pre- and postoperative radiographic imaging were assessed regarding fracture’s complexity, anatomic reduction, reconstruction of the medial hinge, metaphyseal head extension, and fixation of the implant in the calcar region. Follow-up was at a minimum of 12 months. Results: A total number of 130 patients with a mean age of 74.5 years (range 63–94, SD ± 8.2) are included in this study. Two- and three-part fractures were found in 58 patients, while 14 patients showed four-part fractures. Overall, a complication rate of 34.2% and an implant failure rate of 15.4% was found. Four-part fractures showed a significantly higher complication rate than two- and three-part fractures. Four-part fractures also showed significantly higher revisions (p = 0.005) and implant failures (p = 0.008). The nonsufficient anatomical reduction was found to be a risk factor for complications (p < 0.0001), implant failures (p < 0.0001), and later humeral head osteonecrosis (p < 0.0001). Insufficiently reconstructed medial hinges (p = 0.002) and a metaphyseal head extension of under 8 mm (p = 0.005) were also demonstrated as risk factors for osteonecrosis of the humeral head. Conclusions: Four-part fractures in an elderly population show high complication, revision, and implant-failure rates. Therefore, demonstrated radiologic risk factors should be evaluated for improvements. Anatomical reduction and fixation near the calcar proved to be vital for successful antegrade nailing of complex fractures. To prevent osteonecrosis of the humeral head, reconstruction of the medial hinge and metaphyseal head extension should be evaluated. Full article

In minimally invasive bone fracture reduction surgery, broken femur bones are firmly fixed to a metallic intramedullary nail (IMN) after they are properly aligned. One of the greatest challenges of this process is that surgeons cannot directly see holes on the IMN, which increases the difficulty of the procedure and results in the requirement of taking a large number of X-ray images to find the location and direction of holes. We propose a novel distal interlocking screw guidance system that consists of a parallel guidance system using a laser pointer (PGSLP) and a mechanical fine-adjustment device (FAD). The PGSLP is used to make the planes of the C-arm and FAD parallel. The FAD is used to concentrically align the IMN hole with the guiding hole. The performance of the proposed device was evaluated by a series of experiments. The tilted angle error between the C-arm and FAD was measured to be 1.24 ± 0.715°. The translational error between the IMN hole and guiding hole was measured to be 0.378 ± 0.120 mm. Since the proposed guiding system is simple, cost-effective, and accurate, we expect it will soon be used in real operations. Full article

Since the removal of a metallic interlocking nail system leaves a blank cavity inside a healed bone, bioactive and biodegradation materials have been used instead to induce bone formation and eliminate complications of the material removal procedure. The previous study presented the possibility of an interlocking nail fabrication from polylactic acid (PLA), polycaprolactone (PCL), and hydroxyapatite (HA) using 3D printing, namely fused filament fabrication (FFF), for canine diaphyseal fractures. Therefore, a finite element analysis (FEA) was used to predict the maximum principal stress of this 3D-printed composite interlocking nail to stabilize a canine femoral fracture, and the biomechanical performance was evaluated for the treatment of canine femoral shaft fractures using both traditional and new fixation techniques. Three-dimensional FEA models were created, and the composite interlocking nail was tested for implant strength and stability. Three types of canine femoral shaft fracture (proximal shaft fracture, middle shaft fracture, and distal shaft fracture) fixed by traditional and new fixation techniques, consisting of two, four, and six locking screws, were analyzed with a multilevel factorial design technique. The maximum principal stresses of the composite interlocking nail were compared with each fixation technique. According to the multilevel factorial design, gap type, fracture gap, and fixation techniques are factors that affect the maximum principal stress of the composite interlocking nail for two and four locking screws. For six locking screws, all factors, including gap type, fracture gap, nail length, and fixation techniques, significantly affect the maximum principal stress. The use of a 3D-printed composite interlocking nail system with new fixation techniques demonstrated lower maximum principal stresses than the interlocking nail system that used a traditional fixation technique. The results of this study could help orthopedic veterinary surgeons to understand the biomechanical performances of traditional and new fixation techniques. Furthermore, surgeons may use the numerical results of this analysis to choose a fixation technique based on a patient’s condition. Full article

The biomaterials polylactic acid (PLA), polycaprolactone (PCL), and hydroxyapatite (HA) were selected to fabricate composite filaments for 3D printing fused filament fabrication (FFF), which was used to fabricate a composite biomaterial for an interlocking nail for canine diaphyseal fractures instead of metal bioinert materials. Bioactive materials were used to increase biological activities and provide a high possibility for bone regeneration to eliminate the limitations of interlocking nails. HA was added to PLA and PCL granules in three ratios according to the percentage of HA: 0%, 5%, and 15% (PLA/PCL, PLA/PCL/5HA, and PLA/PCL/15HA, respectively), before the filaments were extruded. The test specimens were 3D-printed from the extruded composite filaments using an FFF printer. Then, a group of test specimens was coated by silk fibroin (SF) using the lyophilization technique to increase their biological properties. Mechanical, biological, and chemical characterizations were performed to investigate the properties of the composite biomaterials. The glass transition and melting temperatures of the copolymer were not influenced by the presence of HA in the PLA/PCL filaments. Meanwhile, the presence of HA in the PLA/PCL/15HA group resulted in the highest compressive strength (82.72 ± 1.76 MPa) and the lowest tensile strength (52.05 ± 2.44 MPa). HA provided higher bone cell proliferation, and higher values were observed in the SF coating group. Therefore, FFF 3D-printed filaments using composite materials with bioactive materials have a high potential for use in fabricating an interlocking nail for canine diaphyseal fractures. Full article
