The estimation of robot pose and pipe diameter is an essential task for reliable in-line inspection (ILI) operations and the accurate assessment of pipeline attributes. This paper addresses the problem of robot pose and pipe diameter estimation for natural gas pipelines based on 3D time-of-flight (ToF) sensors. To tackle this challenge, we model the problem as a non-linear least-squares optimization that fits 3D ToF sensor measurements in its local coordinates to an elliptic cylindrical model of the pipe inner surface. We identify and prove that the canonical ellipse-based estimation method (C-EPD), which uses a canonical residual function, suffers from bias in diameter estimation due to its asymmetry to depth errors. To overcome this limitation, we propose the robust and unbiased estimation of pose and diameter (RU-EPD) approach, which employs a novel error-based residual function. The proposed function is symmetric to depth errors, effectively reducing estimation bias. Extensive numerical simulations and prototype pipeline experiments demonstrate that RU-EPD outperforms C-EPD, achieving an at least six times lower estimation bias and a 2.5 times smaller estimation error range in pipe diameter and about a 2 times smaller estimation error range in pose estimation. Full article

This paper presents a study of the feasibility of using in-line inspection (ILI) techniques with long-range communication-capable robotic systems deployed with advanced inspection sensors in natural gas distribution pipelines, which are rare in the literature. The study involved selecting appropriate antennas and determining the appropriate communication frequency for an ILI robot operating on Istanbul 12″ and 16″ steel pipelines. The paper identifies the frequency windows with low losses, presents received signal strength indicator (RSSI) and signal-to-noise ratio (SNR) information for various scenarios, and evaluates the impact of T-junctions, which are known to be the worst components in terms of communication. To utilize the pipeline as a waveguide, low-attenuation-frequency windows were determined, which improved communication by a factor of 500 compared to aerial communication. The results of laboratory tests on a 50 m pipeline and real-world tests on a 2.4 km pipeline indicate that long-distance communication and video transmission are possible at frequencies of around 917 MHz with low-gain antennas. The study also assessed the impact of the early diagnosis of anomalies without incidents on the environment, achievable with ILI robots using long-range wireless communication. Full article

An accurate estimation of pipe attributes, pose of pipeline inspection gauge (PIG), and downstream pipeline topology is essential for successful in-line inspection (ILI) of underground compressible gas pipelines. Taking a 3D point cloud of light detection and ranging (LiDAR) or time-of-flight (ToF) camera as the input, in this paper, we present the simultaneous pipe-attribute and PIG-pose estimation (SPPE) approach that estimates the optimal pipe-attribute and PIG-pose parameters to transform a 3D point cloud onto the inner pipe wall surface: major- and minor-axis lengths, roll, pitch, and yaw angles, and 2D deviation from the center of the pipe. Since the 3D point cloud has all spatial information of the inner pipe wall measurements, this estimation problem can be modeled by an optimal transformation matrix estimation problem from a PIG sensor frame to the global pipe frame. The basic idea of our SPPE approach is to decompose this transformation into two sub-transformations: The first transformation is formulated as a non-linear optimization problem whose solution is iteratively updated by the Levenberg–Marquardt algorithm (LMA). The second transformation utilizes the gravity vector to calculate the ovality angle between the geometric and navigation pipe frames. The extensive simulation results from our PIG simulator based on the robot operating system (ROS) platform demonstrate that the proposed SPPE can estimate the pipe attributes and PIG pose with excellent accuracy and is also applicable to real-time and post-processing non-destructive testing (NDT) applications thanks to its high computational efficiency. Full article

Corrosion is considered as one of the most predominant causes of pipeline failures in the oil and gas industry and normally cannot be easily detected at the inner surface of pipelines without service disruption. The real-time inspection of oil and gas pipelines is extremely vital to mitigate accidents and maintenance cost as well as to improve the oil and gas transport efficiency. In this paper, a new, non-contact optical sensor array method for real-time inspection and non-destructive evaluation (NDE) of pipelines is presented. The proposed optical method consists of light emitting diodes (LEDs) and light dependent resistors (LDRs) to send light and receive reflected light from the inner surface of pipelines. The uniqueness of the proposed method lies in its accurate detection as well as its localization of corrosion defects, based on the utilization of optical sensor array in the pipeline, and also the flexibility with which this system can be adopted for pipelines with different services, sizes, and materials, as well as the method’s economic viability. Experimental studies are conducted considering corrosion defects with different features and dimensions to confirm the robustness and accuracy of the method. The obtained data are processed with discrete wavelet transform (DWT) for noise cancelation and feature extraction. The estimated sizes of the corrosion defects for different physical parameters, such as inspection speed and lift-off distance, are investigated and, finally, some preliminary tests are conducted based on the implementation of the proposed method on an in-line developed smart pipeline inspection gauge (PIG) for in-line inspection (ILI) application, with resulting success. Full article
