Butler Matrix networks are well established as beamforming networks for phased antenna arrays. The challenge we address in this work is to cover the entire (advanced 5G or 6G) FR3 band (7–24 GHz) with a single network, while retaining low losses and minimal size. The employed multilayer topology is also well established; however, the matching between the utilized hybrid couplers and the phase shifters constitutes a major challenge for such a wideband operation. This is achieved herein by employing meander lines with appropriate curvature and introducing two distinct design methods for the Butler Matrix. The first method focuses on designing individual components separately, followed by their integration into the overall Butler Matrix structure. This approach is demonstrated through the design, prototyping, measurements, and validation of an 8 × 8 Butler Matrix beamformer, which operates across the 6–16 GHz band (FR3 Low). The second method introduces a wideband-matching technique which simplifies the implementation process by designing the Butler Matrix as a single, unified structure. This technique is applied to both 4 × 4 and 8 × 8 Butler Matrices, which are implemented and simulated for the low FR3 band. Both design methods result in wideband operation and compact size and meet the desired performance criteria. Full article

This paper proposes a cognitive radio network (CRN)-based hybrid wideband precoding for maximizing spectral efficiency in millimeter-wave relay-assisted multi-user (MU) multiple-input multiple-output (MIMO) systems. The underlying problem is NP-hard and non-convex due to the joint optimization of hybrid processing components and the constant amplitude constraint imposed by the analog beamformer in the radio frequency (RF) domain. Furthermore, the analog beamforming solution common to all sub-carriers adds another layer of design complexity. Two hybrid beamforming architectures, i.e., mixed and fully connected ones, are taken into account to tackle this problem, considering the decode-and-forward (DF) relay node. To reduce the complexity of the original optimization problem, an attempt is made to decompose it into sub-problems. Leveraging this, each sub-problem is addressed by following a decoupled design methodology. The phase-only beamforming solution is derived to maximize the sum of spectral efficiency, while digital baseband processing components are designed to keep interference within a predefined limit. Computer simulations are conducted by changing system parameters under different accuracy levels of channel-state information (CSI), and the obtained results demonstrate the effectiveness of the proposed technique. Additionally, the mixed structure shows better energy efficiency performance compared to its counterparts and outperforms benchmarks. Full article

Global navigation satellite system (GNSS) array antenna receivers are widely used to suppress wideband interference in navigation countermeasures. However, existing array antenna receivers all adopt a digital array structure and digital beamforming technique, and they have limited analog-front-end (AFE) dynamic range. In strong interference scenarios, AFE saturation will occur, which limits the maximum interference suppression ability of the array receiver. Aiming at this issue, this paper proposes a robust wideband interference suppression method for GNSS array antenna receivers based on a hybrid beamforming technique. Firstly, a novel, fully connected hybrid array receiver structure is proposed. Secondly, the corresponding hybrid beamforming method is proposed at the same time, and it realizes the complete elimination of the strong wideband interference by joint suppression in the analog domain and digital domain. After mathematical simulations, it is verified that, compared to the digital beamforming-based anti-jamming technique, the proposed method can effectively suppress strong wideband interference, and the maximum interference suppression ability is improved by 36 dB. Full article

Relay-assisted hybrid beamforming plays an inevitable role in enhancing network coverage, transmission range, and spectral efficiency while simultaneously reducing hardware cost, power consumption, and hardware implementation complexity. This study investigates a cognitive radio network (CRN)-based hybrid wideband transceiver for millimeter-wave (mm-wave) decode-and-forward (DF) relay-assisted multiuser (MU) multiple-input multiple-output (MIMO) systems. It is worth mentioning that the underlying problem has not been addressed so far, which is a real motivation behind the proposed algorithm. The joint optimization of hybrid processing components and the constant amplitude constraints imposed by the analog beamforming solution make this problem non-convex and NP-hard. Furthermore, the analog beamformer common to all sub-carriers is another challenging aspect of the underlying problem. To derive the frequency-flat analog processing component in the radio frequency (RF) domain and frequency-dependent baseband processing matrices in the baseband domain, the original complicated problem is reformulated as two single-hop sum-rate maximization sub-problems. Taking advantage of this decomposition, the sum spectral efficiency is maximized through RF precoding and combining. On the other hand, the impact of interference among transmitted data streams and inter-user interference (IUI) is minimized via baseband processing matrices. Finally, computer simulations are conducted by changing system parameters, considering both perfect and imperfect channel state information (CSI). Simulation results demonstrate that the proposed algorithm achieves performance close to full-complexity precoding and outperforms other well-known hybrid beamforming techniques. Specifically, more than 95% efficiency is achieved with perfect CSI, and more than 90% efficiency is attained under the assumption of 30% error in the estimated channels. Full article

Most of the previous work on hybrid transmit and receive beamforming focused on narrowband channels. Because the millimeter wave channels are expected to be wideband, it is crucial to propose efficient solutions for frequency-selective channels. In this regard, this paper proposes an iterative analog–digital multi-user equalizer scheme for the uplink of wideband millimeter-wave massive multiple-input-multiple-output (MIMO) systems. By iterative equalizer we mean that both analog and digital parts are updated using as input the estimates obtained at the previous iteration. The proposed iterative analog–digital multi-user equalizer is designed by minimizing the sum of the mean square error of the data estimates over the subcarriers. We assume that the analog part is fixed for all subcarriers while the digital part is computed on a per subcarrier basis. Due to the complexity of the resulting optimization problem, a sequential approach is proposed to compute the analog phase shifters values for each radio frequency (RF) chain. We also derive an accurate, semi-analytical approach for obtaining the bit error rate (BER) of the proposed hybrid system. The proposed solution is compared with other hybrid equalizer schemes, recently designed for wideband millimeter-wave (mmWave) massive MIMO systems. The simulation results show that the performance of the developed analog–digital multi-user equalizer is close to full-digital counterpart and outperforms the previous hybrid approach. Full article

One of the key elements of future 5G and beyond mobile technology is millimeter-wave (mmWave) communications, which is targeted to extreme high-data rate services. Furthermore, combining the possibility of a wideband signal transmission with the capability of pencil-beamforming, mmWave technology is key for accurate cellular-based positioning. However, it is also well-known that at the mmWave frequency band the radio channel is very sensitive to line-of-sight blockages giving rise to unstable connectivity and inefficient communication. In this paper, we tackle the blockage problem and propose a solution to increase the communication reliability by means of a coordinated multi-point reception. We also investigate the advantage of this solution in terms of positioning quality. More specifically, we describe a robust hybrid analog–digital receive beamforming strategy to combat the unavailability of dominant links. Numerical examples are provided to validate the efficiency of our proposed method. Full article
