10 pages, 4307 KiB
Article
Low-Temperature Solution-Processed HfZrO Gate Insulator for High-Performance of Flexible LaZnO Thin-Film Transistor
by Yeoungjin Chang, Ravindra Naik Bukke, Jinbaek Bae and Jin Jang
Nanomaterials 2023, 13(17), 2410; https://doi.org/10.3390/nano13172410 - 25 Aug 2023
Cited by 3 | Viewed by 2088
Abstract
Metal-oxide-semiconductor (MOS)-based thin-film transistors (TFTs) are gaining significant attention in the field of flexible electronics due to their desirable electrical properties, such as high field-effect mobility (μFE), lower IOFF, and excellent stability under bias stress. TFTs have widespread applications, [...] Read more.
Metal-oxide-semiconductor (MOS)-based thin-film transistors (TFTs) are gaining significant attention in the field of flexible electronics due to their desirable electrical properties, such as high field-effect mobility (μFE), lower IOFF, and excellent stability under bias stress. TFTs have widespread applications, such as printed electronics, flexible displays, smart cards, image sensors, virtual reality (VR) and augmented reality (AR), and the Internet of Things (IoT) devices. In this study, we approach using a low-temperature solution-processed hafnium zirconium oxide (HfZrOx) gate insulator (GI) to improve the performance of lanthanum zinc oxide (LaZnO) TFTs. For the optimization of HfZrO GI, HfZrO films were annealed at 200, 250, and 300 °C. The optimized HfZrO-250 °C GI-based LaZnO TFT shows the μFE of 19.06 cm2V−1s−1, threshold voltage (VTH) of 1.98 V, hysteresis voltage (VH) of 0 V, subthreshold swing (SS) of 256 mV/dec, and ION/IOFF of ~108. The flexible LaZnO TFT with HfZrO-250 °C GI exhibits negligible ΔVTH of 0.25 V under positive-bias-temperature stress (PBTS). The flexible hysteresis-free LaZnO TFTs with HfZrO-250 °C can be widely used for flexible electronics. These enhancements were attributed to the smooth surface morphology and reduced defect density achieved with the HfZrO gate insulator. Therefore, the HfZrO/LaZnO approach holds great promise for next-generation MOS TFTs for flexible electronics. Full article
(This article belongs to the Topic Advances in Functional Thin Films)
Show Figures

Figure 1

8 pages, 2701 KiB
Article
MOSs-String-Triggered Silicon-Controlled Rectifier (MTSCR) ESD Protection Device for 1.8 V Application
by Ruibo Chen, Hao Wei, Hongxia Liu, Fei Hou, Qi Xiang, Feibo Du, Cong Yan, Tianzhi Gao and Zhiwei Liu
Micromachines 2023, 14(3), 632; https://doi.org/10.3390/mi14030632 - 10 Mar 2023
Viewed by 2261
Abstract
In this work, a new low voltage-triggered silicon-controlled rectifier named MTSCR is realized in a 65 nm CMOS process for low voltage-integrated circuits electrostatic discharge (ESD) protections. The MTSCR incorporates an external NMOSs-string, which drives the internal NMOS (INMOS) of MTSCR to turn [...] Read more.
In this work, a new low voltage-triggered silicon-controlled rectifier named MTSCR is realized in a 65 nm CMOS process for low voltage-integrated circuits electrostatic discharge (ESD) protections. The MTSCR incorporates an external NMOSs-string, which drives the internal NMOS (INMOS) of MTSCR to turn on, and then the INMOS drive SCR structure to turn on. Compared with the existing low trigger voltage (Vt1) ESD component named diodes-string-triggered SCR (DTSCR), the MTSCR can realize the same low Vt1 characteristic but less area penalty of ~44.3% reduction. The results of the transmission line pulsing (TLP) measurement shows that the MTSCR possesses above 2.42 V holding voltage (Vh) and a low Vt1 of ~5.03 V, making it very suitable for the ESD protections for 1.8 V input/output (I/O) ports in CMOS technologies. Full article
(This article belongs to the Section D1: Semiconductor Devices)
Show Figures

Figure 1

20 pages, 10067 KiB
Article
Layout Strengthening the ESD Performance for High-Voltage N-Channel Lateral Diffused MOSFETs
by Sheng-Kai Fan, Shen-Li Chen, Po-Lin Lin and Hung-Wei Chen
Electronics 2020, 9(5), 718; https://doi.org/10.3390/electronics9050718 - 27 Apr 2020
Cited by 5 | Viewed by 10067
Abstract
An electrostatic discharge (ESD) event can negatively affect the reliability of integrated circuits. Therefore, improving on ESD immunity in high-voltage (HV) n-channel (n) lateral diffused metal–oxide–semiconductor field-effect transistor (HV nLDMOS) components through drain-side layout engineering was studied. This involved adjusting the operating voltage, [...] Read more.
An electrostatic discharge (ESD) event can negatively affect the reliability of integrated circuits. Therefore, improving on ESD immunity in high-voltage (HV) n-channel (n) lateral diffused metal–oxide–semiconductor field-effect transistor (HV nLDMOS) components through drain-side layout engineering was studied. This involved adjusting the operating voltage, improving the non-uniform turned-on phenomenon, and examining the effects of embedded-device structures on ESD. All proposed architectures for improving ESD immunity in this work were measured and evaluated using a transmission-line pulse system. The corresponding trigger voltage (Vt1), holding voltage (Vh) and secondary breakdown current (It2) results of the tested devices were obtained. This paper first addresses the drift-region length modulation to design different operating voltages, which decreased as the drift region length and shallow trench isolation (STI) length shrunk. When an HV nLDMOS device decreased to the shortest drift region length, the Vt1 and Vh values were closest to 21.85, and 9.27 V, respectively. The It2 value of a low-voltage operated device could be increased to a maximum value of 3.25 A. For the channel width modulation, increasing the layout finger number of an HV LDMOS device did not really help the ESD immunity that because it may suffer the problem of non-uniform turned-on phenomenon. Therefore, adjusting the optimized channel width was the best one method of improvement. Furthermore, to improve the low ESD reliability problem of nLDMOS devices, two structures were used to improve the ESD capability. The first was a drain side—embedded silicon-controlled rectifier (SCR). Here, the SCR PNP-arranged type in the drain side had the best ESD capability because the SCR path was short and had been prior to triggering; however, it also has a latch-up risk and low Vh characteristic. By removing the entire heavily doped drain-side N+ region, the equivalent series resistance in the drain region was increased, so that the It2 performance could be increased from 2.29 A to 3.98 A in the structure of a fully embedded drain-side Schottky diode. This component still has sufficiently high Vh behaviour. Therefore, embedding a full Schottky-diode into an HV nLDMOS in the drain side was the best method and was efficient for improving the ESD/Latch-up abilities of the device. The figure of merit (FOM) of ESD, Latch-up, and cell area considerations improved to approximately 80.86%. Full article
(This article belongs to the Special Issue Intelligent Electronic Devices)
Show Figures

Figure 1
