This paper discusses improved design of two-dimensional (2D) arrays, potentially pushing the present state of the art of the high-Tc (and low-Tc) magnetic field detectors to a larger scale, i.e., higher sensitivity. We propose a two-plate geometry for parallel (and two-dimensional) arrays of Josephson junctions (JJs) for application in magnetic field detection. The arrays can be realized either by integration in the same substrate with a multilayer technology or on two different substrates. In the latter case, the substrates can be assembled in a flip-chip or piggyback configuration. A suggestion would be to divide a 2D array in two (equal) parts and to distribute each part on a different layer, one above the other. We model the current distribution in arrays connected in series so that the bias current flowing through the device flows in opposite direction in the layers. We demonstrate that this geometry greatly improves the uniformity of the bias current distribution across the width of the array, thereby restoring the critical current and, in principle, improving the Josephson array response. From the model, we conclude that the alignment of the arrays is not critical and that the realization of the devices requires only conventional techniques. Full article

Spectral analysis of terahertz (THz) and sub-THz emission from quantum cascade lasers has been recently demonstrated using conventional YBa₂Cu₃O_7−x bicrystal Josephson junctions made from c-axes thin films. Josephson frequencies of alternative bicrystal junctions made from YBa₂Cu₃O_7−x films with mutually tilted c-axes extend further into the THz range. However, these THz oscillations can weaken due to new absorption channels in the junction environment. Here, using Josephson admittance spectroscopy, THz losses in YBa₂Cu₃O_7−x bicrystal junctions with mutually tilted c-axes are studied. Absorption maximizes at a reproducible set of THz frequencies close to those of collective modes in bulk YBa₂Cu₃O_7−x recovered by Fourier spectroscopy. Annealing junctions in atomic oxygen reduces the losses at frequencies of 2.7 and 3.6 THz, while the losses increase at frequencies of 2.3 and 4.6 THz. Thus, as a THz spectrum analyzer, YBa₂Cu₃O_7−x bicrystal junctions require post-fabrication correction of the oxygen content. In addition, the fine structure of the absorption spectrum appears at frequencies near 4.6 THz. Significant absorption near 2.3 THz may be due to effects associated with the second Josephson harmonic or second-order nonlinearity of the susceptibility in YBa₂Cu₃O_7−x. This work paves the way towards probing collective modes in high-T_c materials in situ using the Josephson oscillations. Full article

Ordinary mixers can hardly meet the requirements in terahertz (THz) communications due to the low-power and expensive THz sources. Sensitive harmonic mixers have been widely studied to avoid this problem, owing to the fact that the higher the number of harmonics, the lower the local oscillator (LO) frequency, and the lower the cost. High-T_c superconducting (HTS) Josephson junction (JJ) mixers are performing candidates for THz receiver frontends because of the advantages of excellent sensitivity, wide bandwidth, high harmonic number and low LO power requirement. However, the normal-state resistance of HTS JJ is so low that traditional antennas are difficult to match it. In other words, it is quite a challenge to match the input impedance to a low input impedance for traditional antennas, especially for antennas fed by coplanar striplines (CPSs). In this work, based on the structure of bowtie, two types of stub tuners were integrated to decrease the impedance of the bowtie antenna so as to improve the coupling efficiency between the traditional bowtie antenna and the JJ. Furthermore, HTS YBa₂Cu₃O_7-δ (YBCO) JJ harmonic mixers coupled with the proposed structures and fed by CPSs are fabricated and measured. The measurements show that the JJ mixer coupled with a pair of open-end stubs of the bowtie antenna achieves up to 88 harmonics, with a conversion efficiency of −69.6 dB. In contrast, the JJ mixer coupled with a pair of lumped-element stubs of the bowtie antenna only attains to 30 harmonics, with a conversion efficiency of −73.4 dB. Additional numerical simulations indicate that the coupling efficiency is enhanced when the complex impedance of the antenna is explicitly considered. Compared with other coupled traditional antennas, the JJ mixer with bowtie antenna has the largest harmonic number. This work paves the way for the future application of low-frequency and low-cost LO for THz communications. Full article

Nanobridge Josephson junctions and nanometer-scale superconducting quantum interference devices (nanoSQUIDs) based on titanium nitride (TiN) thin films are described. The TiN films have a room temperature resistivity of ~15 µΩ·cm, a superconducting transition temperature T_c of up to 5.3 K and a coherence length ξ(4.2 K) of ~105 nm. They were deposited using pulsed DC magnetron sputtering from a stoichiometric TiN target onto Si (100) substrates that were heated to 800 °C. Electron beam lithography and highly selective reactive ion etching were used to fabricate nanoSQUIDs with 20-nm-wide nanobridge Josephson junctions of variable thickness. X-ray and high-resolution electron microscopy studies were performed. Non-hysteretic I(V) characteristics of the nanobridges and nanoSQUIDs, as well as peak-to-peak modulations of up to 17 µV in the V(B) characteristics of the nanoSQUIDs, were measured at 4.2 K. The technology offers prospects for superconducting electronics based on nanobridge Josephson junctions operating within the framework of the Ginzburg–Landau theory at 4.2 K. Full article

The nucleation and dynamics of Josephson and Abrikosov vortices determine the critical currents of layered high-T_c superconducting (HTS) thin films, grain boundaries, and coated conductors, so understanding their mechanisms is of crucial importance. Here, we treat pair creation of Josephson and Abrikosov vortices in layered superconductors as a secondary Josephson effect. Each full vortex is viewed as a composite fluid of micro-vortices, such as pancake vortices, which tunnel coherently via a tunneling matrix element. We introduce a two-terminal magnetic (Weber) blockade effect that blocks tunneling when the applied current is below a threshold value. We simulate vortex tunneling as a dynamic, time-correlated process when the current is above threshold. The model shows nearly precise agreement with voltage-current (V-I) characteristics of HTS cuprate grain boundary junctions, which become more concave rounded as temperature decreases, and also explains the piecewise linear V-I behavior observed in iron-pnictide bicrystal junctions and other HTS devices. When applied to either Abrikosov or Josephson pair creation, the model explains a plateau seen in plots of critical current vs. thickness of HTS-coated conductors. The observed correlation between theory and experiment strongly supports the proposed quantum picture of vortex nucleation and dynamics in layered superconductors. Full article
