This study examines fracture-induced electromagnetic radiation (FEMR) to assess tectonic stress in the Ramon Crater, a geologically “stable” area in southern Israel. With its minor seismic activity, the Ramon Crater poses unique challenges for traditional methods of stress assessment. Here, we introduce FEMR as a novel approach for detecting regional stress orientations by capturing electromagnetic pulses from micro-cracks formed under stress. These FEMR pulses provide indirect but valuable indicators of stress directions on both local and regional scales, demonstrating FEMR’s capability to detect subtle stress changes even in low-activity regions. The findings show that FEMR offers a scalable and sensitive method for mapping stress orientations in stable tectonic environments, making it a promising alternative to conventional seismic techniques. This application of FEMR opens new avenues for understanding regional stress fields in areas with limited seismicity, providing critical insights into tectonic stress behaviors that influence faulting and fracture dynamics in such stable regions. Full article

This paper deals with the quantitative analysis of measured fracture-induced electromagnetic radiation (FEMR) near the Dead Sea Transform using the Angel-M1 instrument, which enables the recording of FEMR signals in a 3D manner. The results showed both the possibility of estimating the sizes of micro-fractures that are the sources of radiation and assessing the direction of the fractures’ locations to the measuring device, as well as the range of magnitude (Mw) of the impending “events” (EQs) associated with the FEMR measurements. Moreover, the relation between the measured FEMR activity (the number of FEMR hits per unit of time) and the FEMR event magnitudes showed consistency with the Gutenberg–Richter relationship for the region. Such measurements could therefore constitute a preliminary ‘field reinforcement’ towards a valid EMR method for a real earthquake forecast, which would provide much earlier warnings than seismic methods. The observed FEMR measurements could only be used to assess the stress concentrations and micro-fracturing in the region since they related to the very initial nucleation phase of a “virtual” earthquake. Nonetheless, they provide the necessary feasibility test for a forecasting method since all of the lab-measured FEMR features were confirmed in the field. Full article

In this work, first, it is confirmed that a recently introduced symbolic time-series-analysis method based on the prime-numbers-based algorithm (PNA), referred to as the “PNA-based symbolic time-series analysis method” (PNA-STSM), can accurately determine the exponent of the distribution of waiting times in the symbolic dynamics of two symbols produced by the 3D Ising model in its critical state. After this numerical verification of the reliability of PNA-STSM, three examples of how PNA-STSM can be applied to the category of systems that obey the dynamics of the on–off intermittency are presented. Usually, such time series, with on–off intermittency, present bimodal amplitude distributions (i.e., with two lobes). As has recently been found, the phenomenon of on–off intermittency is associated with the spontaneous symmetry breaking (SSB) of the second-order phase transition. Thus, the revelation that a system is close to SSB supports a deeper understanding of its dynamics in terms of criticality, which is quite useful in applications such as the analysis of pre-earthquake fracture-induced electromagnetic emission (also known as fracture-induced electromagnetic radiation) (FEME/FEMR) signals. Beyond the case of on–off intermittency, PNA-STSM can provide credible results for the dynamics of any two-symbol symbolic dynamics, even in cases in which there is an imbalance in the probability of the appearance of the two respective symbols since the two symbols are not considered separately but, instead, simultaneously, considering the information from both branches of the symbolic dynamics. Full article

The time–frequency characteristics of electromagnetic radiation (EMR) waveform induced by rock fracture are very important to the monitoring and early–warning using the EMR method for the mine rockburst. The empirical wavelet transform (EWT), as a waveform time–frequency analysis method, has the advantages of a clear theoretical basis, convenient calculation, and no modal aliasing. To apply EWT to the field of EMR time–frequency analysis, the operation of Fourier axis segmentation of EWT is improved. In detail, the adaptive selection method for a window width of closing operation and the adaptive determination method of segment number of Fourier axis are proposed for EWT. The Fourier axis obtained by short–time Fourier transform (STFT) is used in the EWT process, rather than that obtained by discrete Fourier transform (DFT), taking a better Fourier axis segmentation effect. The improved EWT together with Hilbert transform (HT) applied to the time–frequency analysis for the EMR waveform of rock fracture, and the time–frequency spectrum obtained by EWT–HT can well describe the time–frequency evolution characteristics. Compared with STFT and Hilbert–Huang transform (HHT), EWT–HT has significant advantages in time–frequency resolution and overcoming modal aliasing, providing a powerful tool for time–frequency analysis for the EMR waveform induced by rock fracture. Full article

Across the world, coal resource is widely utilized in industrial production. During coal mining activities, dynamic disasters may be induced, such as coal and gas outbursts, or rock burst, resulting in serious accidents or disasters. Previous studies have shown that electric potential (EP) signals can be produced during the deformation and fracture process of coal and rock mass under load. The abnormal response characteristics of EP can reveal the damage evolution and failure feather of coal mass. In this paper, the response characteristics of EP signals are analyzed with high gas testing during mining activities within deep coal seams, and the relationship between the EP response and outburst disaster hazard is studied. The results show that: (1) Under the comprehensive action of mining stress and gas effect, the coal mass was damaged and fractured, which can produce abundant EP signals, while the temporal EP response characteristics can reflect the loading state and damage evolution process inside the coal seam. (2) When coal cannon and a sudden increase of gas concentration occurred in the coal mass, the EP signal was at a high level and fluctuated violently. This can be regarded as precursory information for an outburst risk, which was verified by monitoring the results of mining stress and electromagnetic radiation (EMR). (3) Based on the unilateral inversion imaging method, EP spatial distribution law was studied and abnormal zones with high-value were identified. The zone is close to, or coincident with, the high value interval of EMR intensity and count indexes, which revealed the distribution characteristics of coal damage localization. Hence, EP monitoring results can forecast precursor information of outburst hazards temporally, and identify local zones with outburst hazard spatially. This study provides a new idea and application basis for using the EP method to monitor and prevent coal and rock dynamic disaster hazards in the field. Full article

This paper considers the joint use of two popular geophysical methods (fracture-induced electromagnetic radiation and seismic refraction tomography) to assess the stress-state in underground mine-workings. Such a combination of two indirect methods allows the identification of zones of increased stress in the rock along the axis of the mine-workings, and zones of intense weakening or disintegration in the rock massif above the roof of the mine-workings. The measurements of longitudinal and compressive wave speeds were used to calculate 2D sections of Young’s modulus and Poisson’s ratio to assess the rock mechanical properties in the vicinity of the mine-workings. It is shown that the anomalies of both elastic parameters correspond to those of fracture-induced electromagnetic radiation. Full article

This work extends research on the mechanism of electromagnetic radiation (EMR) induced by coal or rock fractures to the category of microscopic dynamic experimental research. A custom-made three-point bending test system and atomic force microscope (AFM) were integrated to obtain the microdynamic loading test system. The notched coal samples were prepared specially. The dynamic propagation of new microcracks in coal samples was measured, and the propagation velocity was calculated. The morphology and electro-mechanical characteristics of new microcracks were tested. More importantly, the causes of the changes in the electro-mechanical characteristics before and after fracture were analyzed, and the effects of these changes on the EMR were discussed. The results showed that the average propagation velocities during the same time interval are 9.5 μm/s, 12.1 μm/s, and 16.2 μm/s. The elastic modulus of the material at the microcrack edge is generally smaller than that of the material in other locations, while the adhesion and deformation are larger. Moreover, the closer the material is to the microcrack, the higher its surface potential. The electrons generated at the microcrack edge and emitted into the atmosphere, which made the greater potentials of the microcrack edge. Many electrons with different velocities and directions migrate in similar parallel-plate capacitors, which are formed by the relative microscale surface of the coal microcrack tip and have different field strengths, resulting in EMR with complex frequencies and different intensities. This study provides a micro-dynamic experimental basis for research on the electromagnetic radiation mechanism. Full article

During the process of coal road excavation, various interference signals, induced by environmental noise, drilling, and scraper loader, will affect the risk assessment of coal and gas outburst using acoustic emission (AE) and electromagnetic radiation (EMR) monitoring technology. To distinguish between different interference signals and danger signals, discrete wavelet transform (DWT) was used to decompose and reconstruct signals, and continuous wavelet transform (CWT) was used to obtain the time-frequency plane. The research results show that: (1) interference signals generally exhibit fluctuating changes within small ranges; in comparison, the intensity of AE and EMR signals caused by coal and rock fracture is found to continuously rise for a long period (longer than 2 h). (2) Different interference signals and danger signals differ significantly in their time-frequency plane. (3) Through decomposition and reconstruction of original signal, obvious precursor information can be found in the time-frequency plane of reconstructed signals. Full article
