The phenomenon of the floor upheaval occurs in virtually every type of rock mass and at every depth, accompanying the process of excavation of tunnels and headings. Despite its inconvenience, it is rarely studied because of the complexity of the process and the multiplicity of the factors causing deformations in floor rocks. To quantify the effect of the selected factors on floor upheaval, this article presents an analysis of results of in situ measurements carried out in three coal mine roadways at 15 measuring stations. These measurements were taken over varying periods of time, between 129 and 758 days. Groundwater and fault zones intersecting the excavations were considered as the key factors that affect floor upheavals. Therefore, the measurement bases were located at local faults and sites of water inflow. To compare the results, the stations were also located where the rock mass was not exposed to any factors other than stresses resulting from the depth of the excavation. The excavations were driven in various rocks and were located at different depths from 750 to 1010 m. The analyses of the study results show that the floor upheaval always depends on time and can be described in polynomial form: u_fl = a·t² + b·t + c or by a power function: u_fl = a·t^b. However, the further regression analyses show that roadway’s floor upheaval can be expressed by a complex form using the key parameters determining the phenomena. In the absence of an impact of geological factors on the stability of the excavation, the floor upheaval depends on floor rocks compressive strength σ_c and Young’s modulus E: $ln(u_{fl})=a·ln\left(\frac{t}{{\sigma }_c}\right)-\frac{b}{E}-c$; in the case of rock mass condition affected by water depends on the rock compressive strength reduction after submerging rock in water σ_{cs 6h}: $u_{fl}=a·t^{0.5}-b\frac{{\sigma }_{cs 6h}}{{\sigma }_c}+c$ and in the case of fault depends on the fault’s throw f: $u_{fl}=a·t^{0.8}+b·f^{1.2}-c$. Statistical analysis has shown that the matching of the models to the measurement data is high and amounts to r = 0.841–0.895. Hence, in general, the analysis shows that the floor upheaval in underground excavation in any geological conditions may grow indefinitely. Full article

The paper presents the procedure and results of monitoring conducted by using a 3D measurement model, taking advantage of integrated surveying technologies developed for a building located within an activated landslide area. Geodynamic interactions within the building have resulted in a spatial deformation condition, leading to significant cracks of structure components and local basement floor upheavals. Conducted site research shows a reactivation of an old landslide form. To provide safe use conditions for the building, it was decided to monitor the structure and the area in its vicinity. Meeting this demand required developing an in-house monitoring system for the landslide form and the very structure. Measurements provided detailed information on the sizes and directions for the displacements of ground surface points and building structure points, as well as the dynamic properties of this phenomenon. Obtained results show the opportunity to use monitoring systems to acquire credible measurements data reflecting the real impact of ground landslide deformations on structures. Full article
