Nickel is used in aerospace, military, energy, and chemical sectors. Commercially pure (CP) Ni, and its alloys, including solid-solution strengthened (SSS), precipitation strengthened (PS), and specialty alloys (SA), are widely utilized, typically at elevated temperatures, in corrosive settings and in cryogenic milieu. Ni or Ni-based alloys frequently require welding realized, inter alia, via methods using electric arc and beam power. Tungsten inert gas (TIG) and Electron-beam welding (EBW) have been utilized most often. Friction stir welding (FSW) is the most promising solid-state welding technique for connecting Ni and its alloys. The primary weldability issues related to Ni and its alloys are porosity, as well as hot and warm cracking. CP Ni exhibits superior weldability. It is vulnerable to porosity and cracking during the solidification of the weld metal. Typically, SSS alloys demonstrate superior weldability when compared to PS Ni alloys; however, both types may experience weld metal solidification cracking, liquation cracking in the partially melted and heat-affected zones, as well as ductility-dip cracking (DDC). Furthermore, PS alloys are prone to strain-age cracking (SAC). The weldability of specialty Ni alloys is limited, and brazing might provide a solution. Employing appropriate filler metal, welding settings, and minimal restraint can reduce or avert cracking. Full article

Ultra-high strength steel (UHSS) contributes significantly to lightweight design, environmental compatibility and lower fuel consumption. However, it is essential to maintain excellent mechanical properties in terms of structural integrity, strength and ductility after the applied welding process. In this study, the effect of post-welding heat treatments on the welding of UHSS S1100MC was investigated in order to compensate for the deterioration in toughness that occurred as a result of joining by electron beam welding. Electron beam welding (EBW) provides high energy density and therefore relatively low heat input compared to arc welding. However, the narrow fusion zone (FZ) and heat-affected zone (HAZ) may have insufficient toughness values due to rapid cooling of the joint. In order to protect the relationship between strength and toughness, both the material and the joint were subjected to heat treatment at 500, 650 and 750 °C temperatures for 2 h and were cooled in the furnace. Microstructural characterization and mechanical testing, namely hardness, Charpy impact and tensile tests, were performed to correlate the influence of post-weld heat treatment on the microstructural formation and the corresponding mechanical properties. While the material and the joint maintained their hardness values at 500 °C of around 412 ± 15 HV_0.2, there was an approximately 8% decrease in hardness to 378 ± 18 HV_0.2 at 650 °C. At 750 °C, it dramatically lost its high hardness properties, resulting in a low 178 ± 9 HV_0.2. However, direct quenching from the austenitic temperature resulted in fresh martensite, which provided both the required strength and toughness values in the EBW joint. With a hardness of 437 HV_0.2, a tensile strength of 1345 MPa and a fracture elongation of more than 9%, superior mechanical properties could be achieved. Full article

One of the new areas that requires extensive study of the structure and properties of welded joints is the heat-affected zone (HAZ). This issue is particularly important for new constructions made of aluminium alloys intended for battery housing for powering electric car engines. Modern welding methods, such as EBW and FSW, meet the requirements related to the high precision of the process and the quality of the welded joint itself. This article presents the results of an analysis of the structure and strengthening of the HAZ of chemically modified AlMgSi(Cu) alloys via EBW and FSW. Microstructural observation was performed via SEM for each welded joint to determine the morphology of the precipitates. In the HAZ, β-Mg₂Si, Q-Al,MgCu,Si and α-Al,Fe,Si (Mn,Cu) phases with larger sizes and rounded shapes were visible than they were directly in the weld made via the EBW method. The joints produced by the FSW method were characterised by a wide weld area and an irregular weld line. Analysis of the crystallographic orientation via EBSD and grain orientation spread (GOS) revealed differences in the shape of the grains and the degree of recrystallisation in the weld area between the FSW and EBW methods. The distributions of HB (FSW) hardness and HV (EBW) microhardness measurements revealed a slight decrease in hardening in the HAZ. In joints welded by both methods, the hardness of the welds for alloys with increased copper and chromium contents increased by approximately 5%. Full article

Electron beam welding (EBW) is one of the most highly precise methods that is gaining more importance in high-strength structural steel (HSSS) thicker plate application in various vehicles, construction industries, etc. Since it offers particular advantages over arc welding processes like narrow welds, reduced heat-affected zone (HAZ), and low distortion, it inherits lower linear heat input characteristics. The main purpose of this study is to analyze and compare the effect of localized electron beam–post-weld heat treatment (LEB-PWHT) with that of an as-welded EB-welded S960QL joint of a thickness of 12 mm for various joint and HAZ properties. LEB-PWHT can be beneficial in terms of time saving, more local treatment, higher flexibility, energy saving, greater efficiency, increased productivity, etc. In this study, LEB-PWHT was applied to an autogenous EB-welded S960QL joint using a defocused beam. Microstructural characteristics were observed through light optical and scanning electron microscopy (SEM) while mechanical properties, including microhardness, tensile strength, bending, and Charpy V-notch (CVN) impact test, are compared in as-welded and LEB-PWHT joints. The microstructural results showed that the EBW coarse-grain heat-affected zone (CGHAZ) consists of martensite, while the PWHT weld metal contains tempered martensite with carbide precipitates. The fine-grain heat-affected zone (FGHAZ) of EBW exhibits a martensitic and bainitic microstructure, whereas the FGHAZ of the PWHT joint exhibits equiaxed grain with finely dispersed carbides. The hardness decrease after LEB-PWHT in the weld metal and HAZ was approximately 23% and 21%, respectively. An increase in tensile strength (3%) was observed in the LEB-PWHT joints (1082 MPa) compared to the EBW joint (1051 MPa). Both tensile and bending tests demonstrated improved ductility behavior after PWHT. However, the impact test at −40 °C indicated a reduction in toughness in the weld metal of LEB-PWHT (27 J) compared to EBW (63 J). Full article

The incorporation of additive manufactured (AM) metal parts to real assemblies is a crucial issue for the increasing of their industrial utilization. The presented research is devoted to the electron beam welding (EBW) of dissimilar steel joints. Dissimilarity is defined by the various types of steel and manufacturing processes used for the creation of specimens. Conventional AISI 316 stainless steel, selective laser melted (SLM) SS 316L stainless steel, and SLM M300 maraging steel were welded at variable parameters in the form of a welding current and a welding velocity. EBW joints were evaluated considering the macroscopic and microscopic characteristics, as well as a reached microhardness. The obtained preliminary results represent important input data for the follow-up experiments focused on the setting of optimal EBW parameters of welding the dissimilar joints including SLM products, with the consideration of their basic macroscopical and microscopical characteristics, mechanical properties, and residual stresses. Full article

Austenitic stainless steels are very popular due to their high strength properties, ductility, excellent corrosion resistance and work hardening. This paper presents the test results for joining AISI 316Ti austenitic steel. The technologies used for joining were the most popular welding techniques such as TIG (welding with a non-consumable electrode in the shield of inert gases), MIG (welding with a consumable electrode in the shield of inert gases) as well as high-energy EBW welding (Electron Beam Welding) and plasma PAW (plasma welding). Microstructural examinations in the face, center and root areas of the weld revealed different contents of delta ferrite with skeletal or lathy ferrite morphology. Additionally, the presence of columnar grains at the fusion line and equiaxed grains in the center of the welds was found. Microstructural, X-ray and ferroscope tests showed the presence of different delta ferrite contents depending on the technology used. The highest content of delta ferrite was found in the TIG and PAW connectors, approximately 5%, and the lowest in the EBW connector, approximately 2%. Based on the tests carried out on the mechanical properties, it was found that the highest properties were achieved by the MIG joint (R_m, 616, R_p0.2 = 335 MPa), while the lowest were achieved by the PAW joint (R_m = 576, R_p0.2 = 315 MPa). Full article

To enhance welding quality and performance, preheating and post-heating are usually employed on high-temperature materials, concurrently with welding. This is a novel technique in vacuum chamber electron beam welding (EBW). TC17 and Ti₂AlNb alloys are the hot topics in aero-engine parts, and the welding of dissimilar materials is also a broad prospect. To settle welding cracks of Ti₂AlNb, EBW with preheating and post-heating was investigated on TC17 and Ti₂AlNb dissimilar alloy, which improved the manufacturing technology on high-temperature materials. The dissimilar joint no longer had cracks after preheating, which exhibited excellent welding stability and metallurgical homogeneity, and preheating and annealing had an important effect on mechanical properties. The joint strength after 630 °C annealing is higher than that of TC17 alloy base metal (BM) and other annealing temperatures, reaching 1169 MPa at room temperature and 894 MPa at 450 °C tensile condition. The joint plasticity after 740 °C annealing is equivalent to TC17 BM. EBW with preheating improved the microstructure characteristics and enhanced the plasticity of Ti₂AlNb alloy weld and dissimilar joint, which would contribute to the application of Ti₂AlNb alloy and Ti₂AlNb dissimilar parts. Full article

In this work, the results of an investigation of electron-beam-welded samples of commercially pure titanium (CP-Ti) and the titanium alloy Ti6Al4V (Ti64) using fillers of various beta-stabilizing elements (Nb, V, Cu) are presented. The fillers were in the form of deposited layers on each of the two specimens via DC magnetron sputtering. The specimens were then subjected to electron-beam welding (EBW) under the same technological conditions. The structure of the obtained welded joints was investigated by scanning electron microscopy (SEM). X-ray diffraction (XRD) was used to investigate the phase composition of the fusion zone (FZ). The study of the mechanical properties of the samples was carried out via tensile tests and microhardness measurements. The results showed a different influence of the used fillers on the structure and properties of the obtained joints, and in all cases, the yield strength increased compared to the samples welded using the same technological conditions without the use of filler material. In the case of using Nb and V as a filler, the typical transformation of titanium welds into elongated αTi particles along with α’-Ti martensitic structures was observed. The addition of a Cu filler into the structure of the welds resulted in a unification and refining of the structure of the last, which resulted in the improvement of the mechanical properties of the weld, particularly its ductility, which is a known issue where electron-beam welding is concerned. Full article

Vacuum electron-beam welding (EBW) was used to join the precipitation-strengthened GH4169 superalloy and a new nickel-based superalloy IC10 to fabricate the turbine blade discs. In this study, a solid solution (1050 °C/2 h for GH4169 and 1150 °C/2 h for IC10) and different heat-exposure temperatures (650 °C, 750 °C, 950 °C and 1050 °C/200 h, respectively) were used to study the high-temperature tensile properties and microstructure evolution of welded joints; meanwhile, the formation and evolution of the second phases of the joints were analyzed. After EBW, the welded joint exhibited a typical nail morphology, and the fusion zone (FZ) consisted of columnar and cellular structures. During the solidification process of the molten pool, Mo elements are enriched in the dendrites and inter-dendrites, and that of Nb and Ti elements was enriched in the dendrites, which lead to forming a non-uniform distribution of Laves eutectic and MC carbides in the FZ. The microhardness of the FZ gradually increased during thermal exposure at 650 °C and reached 300–320 HV, and the γ′ and γ″ phases were gradually precipitated with size of about 50 nm. Meanwhile, the microhardness of the FZ decreased to 260–280 HV at 750 °C, and the higher temperature resulted in the coarsening of the γ″ phase (with a final size of about 100 nm) and the formation of the acicular δ-phase. At 950 °C and 1050 °C, the microhardness of FZ decreased sharply, reaching up to 170~190 HV and 160~180 HV, respectively. Moreover, the Laves eutectic and MC carbides are dissolved to a greater extent without the formation of γ″ and δ phases; as a result, the absent of γ″ and δ phases are attributed to the significant improvement of segregation at higher temperatures. Full article

In this work, Zr-Sn-Nb alloy was joined by electron beam welding (EBW). A defect-free Zr-Sn-Nb joint with sound appearance was obtained. The grains in the weld zone (WZ) and heat-affected zone (HAZ) are significantly coarsened. The columnar grains with a maximum grain size of 0.5 mm are distributed in the upper region of the WZ, while the equiaxed grains are almost located in the bottom region of the WZ. The WZ is mainly composed of the dominant α-Zr, α′-Zr and a few β phases. The grain orientation of WZ and HAZ is uniform, indicating that no obvious preferred orientation existed. Coarse grains and fine acicular α′ phases increase the strength of the joint, but reduce the plasticity and toughness of the joint. The tensile strengths of the joints at room temperature (RT) and 375 °C were 438 MPa and 313 MPa, respectively. The RT impact energy of the joint is 18.5 J, which is only 58.3% of the BM. The high purity of the EBW process and unsignificant grain orientation minimizes damage to the corrosion resistance of Zr-Sn-Nb alloy joints. The corrosion weight gain of the joint specimen and the BM specimen were 12.91 mg/dm² and 12.64 mg/dm², respectively, and the thicknesses of the cross-section corrosion layer were 12–15 μm and 9–12 μm, respectively. Full article

The necessity for precise prediction of penetration depth in the context of electron beam welding (EBW) cannot be overstated. Traditional statistical methodologies, including regression analysis and neural networks, often necessitate a considerable investment of both time and financial resources to produce results that meet acceptable standards. To address these challenges, this study introduces a novel approach for predicting EBW penetration depth that synergistically combines computational fluid dynamics (CFD) modelling with artificial neural networks (ANN). The CFD modelling technique was proven to be highly effective, yielding predictions with an average absolute percentage deviation of around 8%. This level of accuracy is consistent across a linear electron beam (EB) power range spanning from 86 J/mm to 324 J/mm. One of the most compelling advantages of this integrated approach is its efficiency. By leveraging the capabilities of CFD and ANN, the need for extensive and costly preliminary testing is effectively eliminated, thereby reducing both the time and financial outlay typically associated with such predictive modelling. Furthermore, the versatility of this approach is demonstrated by its adaptability to other types of EB machines, made possible through the application of the beam characterisation method outlined in the research. With the implementation of the models introduced in this study, practitioners can exert effective control over the quality of EBW welds. This is achieved by fine-tuning key variables, including but not limited to the beam power, beam radius, and the speed of travel during the welding process. Full article

The paper presents the results of the joining tests of the EN AW-6082 T6 alloy. The materials were joined using the EBW high-energy (electron beam welding) and friction stir welding (FSW) methods. In the case of FSW welding, the following parameters were used: the linear speed was 355 mm/min, and the rotational speed of the welding tool was 710. In the case of EBW welding, the following parameters were used: accelerating voltage U = 120 kV, beam intensity I = 18.7 mA, welding speed v = 1600 mm/min and, in the case of a smoothing weld, U = 80 kV, beam intensity I = 17 mA, and welding speed v = 700 mm/min. Comprehensive microstructural tests of all welded joints (MO, SEM and TEM) and mechanical property tests (tensile and hardness tests) were carried out. The topographies of the fractures after the tensile test were also examined. Based on the results, it was found that the strength properties of the EBW joint were reduced by 23% and the FSW joint by 38% compared to the base material. A decrease in elongation was also noted, with an FSW elongation of 7.2% and an elongation of 2.7% for EBW. In the case of the EBW joint, magnesium evaporation was found in the weld during welding, while in the FSW joint, the dissolution of the Mg2Si particles responsible for strengthening the material during heat treatment to the T6 state was observed. Full article

Ti-4Al-5Mo-5V-5Cr-1Nb (wt.%) is a new type of high-strength (~1300 MPa) titanium (Ti) alloy developed for aerospace applications. Until now, the research on its welding and subsequent heat treatment is barren. Herein, we employed electron beam welding (EBW) to a solutionized Ti-4Al-5Mo-5V-5Cr-1Nb with a phase constituent of α + β and investigated its microstructure and mechanical properties in both as-welded (AW) and post-weld aging treated (PWAT) conditions. Results showed that due to the thermal input of the welding process, the α phase in the original microstructure of base material (BM) transformed into the β phase in the fusion zone (FZ). Similar microstructural evolution was observed for the heat-affected zone (HAZ) near the FZ (Near-HAZ), whereas the HAZ far away from FZ (Far-HAZ) contained a small amount of round α phase (ghost α) due to its slower cooling rate. Such a microstructural change resulted in poor tensile strength (~780 Mpa) for the as-welded joint. After PWAT, a large number of acicular α precipitated in the FZ and HAZ and its size (S) in different zones followed the order of S_Far-HAZ < S_FZ ≈ S_Near-HAZ < S_BM. The presence of α_s precipitates remedied the tensile strength of the weld joint almost to the same as that of the BM. The present findings established the foundation of the application of this high-strength Ti alloy. Full article

The 316L thick plate electron beam welding (EBW) has been widely used in fusion test reactor manufacturing. Therefore, the numerical simulation of the 50 mm 316L austenitic stainless steel by two heat sources and experimental on microstructure and residual stress have been studied in this article. In the simulation study, the traditional heat source model (3D Gaussian heat source) and composite heat source (double ellipsoid heat source superimposed on the 3D Gaussian heat source) were proposed to simulate the welding of local joint. Weld cross-section, temperature curve, and residual stress after welding obtained by simulations were investigated. The experimental study involved residual stress tests and microstructure analysis. It turned out that the result of the composite heat source was closer to the actual joint. The residual stress distribution of simulation was validated and in accordance with experimental measurement. Moreover, the microstructures were studied by electro backscattered diffraction (EBSD) and compared with the temperature curve. The formation mechanism of microstructural heterogeneity was caused mainly by different thermal cycles at different positions of the thick plate. The top of the joint was more prone to stress concentration. Full article

In recent years, ultra-high-strength structural (UHSS) steel in quenched and tempered (Q+T) conditions, for example, S960QL has been found in wider application areas such as structures, cranes, and trucks due to its extraordinary material properties and acceptable weldability. The motivation of the study is to investigate the unique capabilities of electron beam welding (EBW) compared to conventional gas metal arc welding (GMAW) for a deep, narrow weld with a small heat-affected zone (HAZ) and minimum thermal distortion of the welded joint without significantly affecting the mechanical properties. In this study, S960QL base material (BM) specimens with a thickness of 15 mm were butt-welded without filler material at a welding speed of 10 mm/s using the high-vacuum (2 × 10⁻⁴ mbar) EBW process. Microstructural characteristics were analyzed using an optical microscope (OM), a scanning electron microscope (SEM), fractography, and an electron backscatter diffraction (EBSD) analysis. The macro hardness, tensile strength, and instrumented Charpy-V impact test were performed to evaluate the mechanical properties. Further, the results of these tests of the EBW joints were compared with the GMAW joints of the same steel grade and thickness. Higher hardness is observed in the fusion zone (FZ) and the HAZ compared to the BM but under the limit of qualifying the hardness value (450 HV10) of Q+T steels according to the ISO 15614-11 specifications. The tensile strength of the EBW-welded joint (1044 MPa) reached the level of the BM as the specimens fractured in the BM. The FZ microstructure consists of fine dendritic martensite and the HAZ predominantly consists of martensite. Instrumented impact testing was performed on Charpy-V specimens at −40 °C, which showed the brittle behavior of both the FZ and HAZ but to a significantly lower extent compared to GMAW. The measured average impact toughness of the BM is 162 J and the average impact toughness value of the HAZ and FZ are 45 ± 11 J and 44 ± 20 J, respectively. Full article
