Search Results (6)

Search Parameters:
Keywords = dual-mode charge pump

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 7428 KiB
Article
Novel Power-Efficient Fast-Locking Phase-Locked Loop Based on Adaptive Time-to-Digital Converter-Aided Acceleration Compensation Technology
by Ligong Sun, Yixin Luo, Zhiyao Deng, Jinchan Wang and Bo Liu
Electronics 2024, 13(18), 3586; https://doi.org/10.3390/electronics13183586 - 10 Sep 2024
Cited by 1 | Viewed by 1588
Abstract
This paper proposes an adaptive acceleration lock compensation technology for phase-locked loops (PLLs) based on a novel dual-mode programmable ring voltage-controlled oscillator (ring-VCO). In addition, a time-to-digital converter (TDC) is designed to accurately quantify the phase difference from the phase frequency detector (PFD) [...] Read more.
This paper proposes an adaptive acceleration lock compensation technology for phase-locked loops (PLLs) based on a novel dual-mode programmable ring voltage-controlled oscillator (ring-VCO). In addition, a time-to-digital converter (TDC) is designed to accurately quantify the phase difference from the phase frequency detector (PFD) in order to optimize the dead-zone effect while dynamically switching an auxiliary charge pump (CP) module to realize fast phase locking. Furthermore, a TDC-controlled three/five-stage dual-mode adaptively continuously switched VCO is proposed to optimize the phase noise (PN) and power efficiency, leading to an optimal performance tradeoff of the PLL. Based on the 180 nm/1.8 V standard CMOS technology, the complete PLL design and a corresponding simulation analysis are implemented. The results show that, with a 1 GHz reference signal as the input, the output frequency is 50–324 MHz, with a wide tuning range of 260 MHz and a low phase noise of −98.07 dBc/Hz@1 MHz. The key phase-locking time is reduced to 1.11 μs, and the power dissipation is lowered to 1.86 mW with a layout area of 66 μm × 128 μm. A significantly remarkable multiobjective performance tradeoff with topology optimization is realized, which is in contrast to several similar design cases of PLLs. Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

18 pages, 8732 KiB
Article
Buck-Boost Charge Pump Based DC-DC Converter
by Evi Keramida, George Souliotis, Spyridon Vlassis and Fotis Plessas
J. Low Power Electron. Appl. 2023, 13(2), 27; https://doi.org/10.3390/jlpea13020027 - 21 Apr 2023
Cited by 5 | Viewed by 5261
Abstract
This paper presents a novel inductorless dual-mode buck-boost charge pump (CP) based DC-DC converter. The proposed architecture allows the same circuit to accomplish two modes of operation, buck and boost, for degrading or elevating the output voltage, respectively, compared to the input. To [...] Read more.
This paper presents a novel inductorless dual-mode buck-boost charge pump (CP) based DC-DC converter. The proposed architecture allows the same circuit to accomplish two modes of operation, buck and boost, for degrading or elevating the output voltage, respectively, compared to the input. To achieve each mode, only a switching of the input–output connections is needed without any other modification in the design of the DC-DC converter. The dual-mode configuration aims to merge two different functions into one circuit, minimizing the design time and the area the DC-DC converter occupies on the die. The proposed buck-boost CP has been designed using TSMC 65 nm complementary metal–oxide–semiconductor (CMOS) technology. The functional input voltage range of the CP in boost mode is 1.2 V to 1.8 V and the typical output voltage is 1.8 V. For the buck mode, the input voltage range is 3.2 V to 3.6 V and the output is 1.5 V. For both modes, the output can be easily modified to new values by changing the comparator configuration. Efficiency results are also provided for the two modes. Full article
Show Figures

Figure 1

18 pages, 3533 KiB
Article
Efficient Dual Output Regulating Rectifier and Adiabatic Charge Pump for Biomedical Applications Employing Wireless Power Transfer
by Noora Almarri, Peter Langlois, Dai Jiang and Andreas Demosthenous
J. Low Power Electron. Appl. 2023, 13(1), 20; https://doi.org/10.3390/jlpea13010020 - 4 Mar 2023
Cited by 1 | Viewed by 3193
Abstract
A power management unit (PMU) is an essential block for diversified multi-functional low-power Internet of Things (IoT) and biomedical electronics. This paper includes a theoretical analysis of a high current, single-stage ac-dc, reconfigurable, dual output, regulating rectifier consisting of pulse width modulation (PWM) [...] Read more.
A power management unit (PMU) is an essential block for diversified multi-functional low-power Internet of Things (IoT) and biomedical electronics. This paper includes a theoretical analysis of a high current, single-stage ac-dc, reconfigurable, dual output, regulating rectifier consisting of pulse width modulation (PWM) and pulse frequency modulation (PFM). The regulating rectifier provides two independently regulated supply voltages of 1.8 V and 3.3 V from an input ac voltage. The PFM control feedback consists of feedback-driven regulation to adjust the driving frequency of the power transistors through adaptive buffers in the active rectifier. The PWM/PFM mode control provides a feedback loop to adjust the conduction duration accurately and minimize power losses. The design also includes an adiabatic charge pump (CP) to provide a higher voltage level. The adiabatic CP consists of latch-up and power-saving topologies to enhance its power efficiency. Simulation results show that the dual regulating rectifier has 94.3% voltage conversion efficiency with an ac input magnitude of 3.5 Vp. The power conversion efficiency of the regulated 3.3 V output voltage is 82.3%. The adiabatic CP has an overall voltage conversion efficiency (VCE) of 92.9% with a total on-chip capacitance of 60 pF. The circuit was designed using 180 nm CMOS technology. Full article
(This article belongs to the Special Issue Energy-Harvesting and Self-Powered Devices)
Show Figures

Figure 1

17 pages, 20052 KiB
Article
A 33 MHz Fast-Locking PLL with Programmable VCO and Automatic Band Selection for Clock Generator Application
by Neeraj Agarwal, Neeru Agarwal, Chih-Wen Lu and Masahito Oh-e
Electronics 2021, 10(14), 1743; https://doi.org/10.3390/electronics10141743 - 20 Jul 2021
Cited by 1 | Viewed by 5726
Abstract
This paper presents a prototype of an auto-ranging phase-locked loop (PLL) with low jitter noise over a wide operating frequency range using the multiband programmable voltage-controlled oscillator (VCO) gain stage with automatic band selection. We successfully reduce the VCO gain (Kvco) and retain [...] Read more.
This paper presents a prototype of an auto-ranging phase-locked loop (PLL) with low jitter noise over a wide operating frequency range using the multiband programmable voltage-controlled oscillator (VCO) gain stage with automatic band selection. We successfully reduce the VCO gain (Kvco) and retain the desired frequency band. The proposed PLL comprises a prescaler, phase frequency detector (PFD), charge pump (CP), programmable VCO and automatic band selection circuit. The PLL prototype with all subblocks was implemented using the TSMC 0.18 μm 1P6M process. Contrary to conventional PLL architectures, the proposed architecture incorporates a real-time check and automatic band selection circuit in the secondary loop. A high-performance dual-loop PLL wide tuning range was realized using an ASIC digital control circuit. A suitable way to maintain the Kvco low is to use multiple discrete frequency bands to accommodate the required frequency range. To maintain a low Kvco and fast locking, the automatic frequency band selection circuit also has two indigenous, most probable voltage levels. The proposed architecture provides the flexibility of not only band hopping but also band twisting to obtain an optimized Kvco for the desired output range, with the minimum jitter and spurs. The proposed programmable VCO was designed using a voltage-to-current-converter circuit and current DAC followed by a four-stage differential ring oscillator with a cross-coupled pair. The VCO frequency output range is 150–400 MHz, while the input frequency is 25 MHz. A sequential phase detection loop with a negligible dead zone was designed to adjust fine phase errors between the reference and feedback clocks. All circuit blocks of the proposed PLL were simulated using the EDA tool HSPICE and layout generation by Laker. The simulation and measured results of the proposed PLL show high linearity, with a dead zone of less than 10 pV. The differential VCO was used to improve the linearity and phase noise of the PLL. The chip measured results show rms jitter of 19.10 ps. The PLL prototype also has an additional safety feature of a power down mode. The automatic band selection PLL has good immunity for possible frequency drifting due to temperature, process and supply voltage variations. The proposed PLL is designed for −40 to +85 °C, a wide temperature range. Full article
(This article belongs to the Special Issue Design of Mixed Analog/Digital Circuits)
Show Figures

Figure 1

25 pages, 10417 KiB
Article
Multifrequency Induced-Charge Electroosmosis
by Kai Du, Jingni Song, Weiyu Liu, Ye Tao and Yukun Ren
Micromachines 2019, 10(7), 447; https://doi.org/10.3390/mi10070447 - 3 Jul 2019
Cited by 5 | Viewed by 3822
Abstract
We present herein a unique concept of multifrequency induced-charge electroosmosis (MICEO) actuated directly on driving electrode arrays, for highly-efficient simultaneous transport and convective mixing of fluidic samples in microscale ducts. MICEO delicately combines transversal AC electroosmotic vortex flow, and axial traveling-wave electroosmotic pump [...] Read more.
We present herein a unique concept of multifrequency induced-charge electroosmosis (MICEO) actuated directly on driving electrode arrays, for highly-efficient simultaneous transport and convective mixing of fluidic samples in microscale ducts. MICEO delicately combines transversal AC electroosmotic vortex flow, and axial traveling-wave electroosmotic pump motion under external dual-Fourier-mode AC electric fields. The synthetic flow field associated with MICEO is mathematically analyzed under thin layer limit, and the particle tracing experiment with a special powering technique validates the effectiveness of this physical phenomenon. Meanwhile, the simulation results with a full-scale 3D computation model demonstrate its robust dual-functionality in inducing fully-automated analyte transport and chaotic stirring in a straight fluidic channel embedding double-sided quarter-phase discrete electrode arrays. Our physical demonstration with multifrequency signal control on nonlinear electroosmosis provides invaluable references for innovative designs of multifunctional on-chip analytical platforms in modern microfluidic systems. Full article
(This article belongs to the Special Issue Micro/Nano-Chip Electrokinetics, Volume III)
Show Figures

Graphical abstract

17 pages, 6389 KiB
Article
Design and Analysis of a Novel Converter Topology for Photovoltaic Pumps Based on Switched Reluctance Motor
by Xiaoshu Zan, Ning Wu, Ruidong Xu, Mingliang Cui, Zhikai Jiang, Kai Ni and Mohammed Alkahtani
Energies 2019, 12(13), 2526; https://doi.org/10.3390/en12132526 - 1 Jul 2019
Cited by 8 | Viewed by 3522
Abstract
In order to improve the performance of switched reluctance motor (SRM) systems for photovoltaic (PV) pumps, this paper introduces a new converter topology for SRM with controllable multiple power sources. Only simple switching components need to be added at the front end of [...] Read more.
In order to improve the performance of switched reluctance motor (SRM) systems for photovoltaic (PV) pumps, this paper introduces a new converter topology for SRM with controllable multiple power sources. Only simple switching components need to be added at the front end of the asymmetric half-bridge converter in this topology, which enables the control of multiple power sources. The new PV pump system has four operating modes, which are the PV panel driven mode, battery bank driven mode, dual-source driven mode, and battery charging mode. By adjusting the state of the front-end converter switch, the voltage tracking of PV panel can be achieved, providing a stable bus voltage for the SRM system. By controlling the battery bypass switch, the bus voltage of SRM system can be increased, thereby increasing the system power level. Simulations and experiments based on a four-phase 8/6 SRM demonstrate the effect of the novel converter proposed in this paper. Full article
Show Figures

Figure 1
