This article presents a novel, compact, and flexible dual-band magnetoelectric dipole rectenna designed for radio frequency (RF) energy harvesting. The rectenna consists of a unique antenna structure, combining electric and magnetic dipoles to create unidirectional radiation patterns, minimizing interference from the human body. The rectifier is integrated with the antenna through conjugate matching, eliminating the need for additional matching circuits, reducing circuit losses, minimizing design complexity, and improving conversion efficiency. The proposed rectenna utilizes a flexible graphene film as the radiating element, which offers excellent conductivity and corrosion resistance, enabling conformal operation in diverse scenarios. Simulation and experimental results show that the rectenna operates effectively at 3.5 GHz and 4.9 GHz, achieving peak conversion efficiencies of 53.43% and 43.95%, respectively, at an input power of 4 dBm. The simulated and measured results achieved good agreement. The rectenna maintains stable performance under various bending conditions, demonstrating its suitability for flexible, wearable RF energy-harvesting systems. Full article

In this paper, a novel topology and method for designing a multi-band rectenna is proposed to improve its RF-DC efficiency. The rectifier achieves simultaneous rectification using both series and parallel configurations by connecting two branches to the respective terminals of the diode, directing the energy input from two ports to the anode and cathode of the diode. Six desired operating frequency bands are evenly distributed across these two branches, each of which is connected to antennas corresponding to their specific operating frequencies, serving as the receiving end of the system. To optimize the design process, a low-pass filter is incorporated into the rectifier design. This filter works in conjunction with a matching network that includes filtering capabilities to isolate the two ports of the rectifier. The addition of the filter ensures that each structure within the rectifier can be designed independently without adversely affecting the performance of the already completed structures. Based on the proposed design methodology, a dual-port rectenna operating at six frequency bands—1.85 GHz, 2.25 GHz, 2.6 GHz, 3.52 GHz, 5.01 GHz, and 5.89 GHz—was designed, covering the 4G, 5G, and Wi-Fi/WLAN frequency bands. The measured results indicate that high-power conversion efficiency was achieved at an input power of −10 dBm: 43.01% @ 1.85 GHz, 41.00% @ 2.25 GHz, 41.33% @ 2.6 GHz, 35.88% @ 3.52 GHz, 22.36% @ 5.01 GHz, and 19.27% @ 5.89 GHz. When the input power is −20 dBm, the conversion efficiency of the rectenna can be improved from 5.2% for single-tone input to 27.7% for six-tone input, representing a 22.5 percentage point improvement. The proposed rectenna demonstrates significant potential for applications in powering low-power sensors and other devices within the Internet of Everything context. Full article

A dual-band metasurface array is presented in this paper for electromagnetic (EM) energy harvesting in the Wi-Fi band and Ku band. The array consists of metasurface unit cells, rectifiers, and load resistors. The metasurface units within each column are interconnected to establish two channels of energy delivery, enabling the transmission and aggregation of incident power. At the terminals of two channels, a single series diode rectifier and a voltage doubler rectifier are integrated into them to rectify the energy in the Wi-Fi band and the Ku band, respectively. A 7 × 7 prototype of the metasurface array is fabricated and tested. The measured results in the anechoic chamber show that the RF-to-dc efficiencies of the prototype at 2.4 GHz and 12.6 GHz reach 64% and 55% accordingly, when the available incident power at the surface is 3 dBm and 14 dBm, respectively. Full article

In this paper, we proposed a high-efficiency 2.45 GHz and 5.8 GHz dual-band rectenna for wireless energy harvesting (WEH). First, a dual-band dielectric resonant antenna (DRA) was designed. A 4-element DRA array was further developed using a compact feeding network. The measured gains of the DRA array were 5.5 dBi at 2.45 GHz and 12.9 dBi at 5.8 GHz. Then, a new type of impedance regulation stub (IRS) was introduced that significantly improved the conversion efficiency of the rectenna. The result showed that the conversion efficiency of the rectifier was 66% and 62% at 2.45 GHz and 5.8 GHz, respectively, when the input power level was 10 dBm. Furthermore, the proposed rectenna was validated to activate a standard BQ25504 DC-to-DC boost converter and charge a supercapacitor. The results demonstrated that the proposed rectenna could be an appropriate solution for WEH applications. Full article

An implantable antenna, operating at the dual Industrial, Scientific, and Medical (ISM) bands of 902–928 MHz and 2.4–2.48 GHz, is presented for RF energy harvesting and data transmission. By introducing multiple radiating branches and etching a C-shaped slot, multiple resonant frequencies were generated to produce the wide dual bands. The proposed antenna has compact dimensions of 7.9 × 7.7 × 1.27 mm³. The simulated impedance bandwidths of the antenna are 0.67–1.05 GHz (44.2%) and 2.11–2.96 GHz (33.5%), and the peak gains are −28.9 dBi and −29.5 dBi, respectively. The lower band can be applied in RF energy harvesting, while the upper band is designed for data transmission with external medical equipment. Furthermore, to convert RF power into DC power, in RF energy harvesting, a voltage-doubled rectifier was positioned under the ground plane of the proposed antenna. The rectifier circuit can achieve a maximum conversion efficiency of 52% at an input power of 5 dBm. Furthermore, the integrated scheme of the implantable rectenna was fabricated and the numerical performance of the wireless power transfer was verified with the measurement results. Full article

RF power is broadly available in both urban and semi-urban areas and thus exhibits as a promising candidate for ambient energy scavenging sources. In this research, a high-efficiency quad-band rectenna is designed for ambient RF wireless energy scavenging over the frequency range from 0.8 to 2.5 GHz. Firstly, the detailed characteristics (i.e., available frequency bands and associated power density levels) of the ambient RF power are studied and analyzed. The data (i.e., RF survey results) are then applied to aid the design of a new quad-band RF harvester. A newly designed impedance matching network (IMN) with an additional L-network in a third-branch of dual-port rectifier circuit is familiarized to increase the performance and RF-to-DC conversion efficiency of the harvester with comparatively very low input RF power density levels. A dual-polarized multi-frequency bow-tie antenna is designed, which has a wide bandwidth (BW) and is miniature in size. The dual cross planer structure internal triangular shape and co-axial feeding are used to decrease the size and enhance the antenna performance. Consequently, the suggested RF harvester is designed to cover all available frequency bands, including part of most mobile phone and wireless local area network (WLAN) bands in Malaysia, while the optimum resistance value for maximum dc rectification efficiency (up to 48%) is from 1 to 10 kΩ. The measurement result in the ambient environment (i.e., both indoor and outdoor) depicts that the new harvester is able to harvest dc voltage of 124.3 and 191.0 mV, respectively, which can be used for low power sensors and wireless applications. Full article

This paper proposes the design of a dual-band integrated rectenna. The rectenna has compact size of 0.4 × 0.3 × 0.25 cm${}^3$ and operates at 925 MHz and 2450 MHz bands. In general, the rectenna consists of two main parts, the metal-rimmed dual-band antenna used for harvesting the radio frequency (RF) signals from the environment and the rectifier circuit to convert these receiving powers to the direct current (DC). Because of the dual resonant structure of the antenna, the rectifier circuit can be optimized in terms of size and the frequency bandwidth, while the conversion efficiencies are always obtained 60% at the RF input power −2.5 dBm and −1 dBm for the lower band and the higher band, respectively. Measured results show that the metal-rimmed antenna exhibits −10 dB reflection coefficient in both desired frequency bands. Moreover, the antenna achieves 47% and 89% of total efficiency respectively at 925 MHz and 2450 MHz, which confirms that the proposed rectenna is well applicable in most of the miniaturized wireless sensor networks and IoT systems. Full article

In the article, a dual and wide band antenna array suitable for RF rectenna applications was synthesized and global rectenna systems are presented. The array consists of two bowtie-shaped patches, printed on the one side of a dielectric slab (FR4). On the other side of the slab, an aperture-textured metallic ground layer, is printed. Examples of full-wave rectifiers connected, through matching networks, to the antenna elements and forming integrated rectenna systems for radio-frequency (RF) power harvesting at 868 MHz, from 920 to 960 MHz and at 1.8 GHz, are presented. Statistical results over frequency and the directions of arrival (DoAs) of incoming waves were received showing, at the rectifier, mean direct current (DC) voltage of 580 mV, and mean power of 58 μW, for circularly polarized waves of field intensity of 1.8 V/m. The DC voltage can reach 800 mV, the power 120 μW and the efficiency 68% when the waves come from DoAs of maximum antenna’s gain. Due to the wideband performance of the antenna, it could be used at various frequency slots as long as the matching network’s operation frequency is changed. Thus the proposed rectennas could be suitable for energizing low-power sensors or at least to charge their batteries. Full article
