This work presents the implementation of a dual-extended Kalman filter (DEKF) in a double pipe counter-current heat exchanger. The DEKF aims to estimate online the heat transfer coefficient (HTC) to monitor the process. Some investigations estimate parameters in heat exchangers to detect fouling. However, there is limited research on online estimation using DEKF. The tests were performed at two operating conditions: in the first condition, the inlet temperatures were without perturbation; meanwhile, in the second operating condition, the cold-water inlet temperature was perturbed by the environmental heat. The experimental tests were carried out at different cold mass flow rates, which impact the temperatures and vary the heat transfer coefficient of the heat exchanger. The results showed adequate agreement between the estimated values of the heat transfer coefficients and those calculated with algebraic equations. This adequate agreement indicates that the DEKF method is conducive to detecting some problems in heat exchanger applications, such as poor heat transfer performance caused by fouling. Full article

This paper analyzes the performance of Kalman filter-based estimators for robust filtering and rotor asymmetry detection in wound rotor induction machines (WRIMs) using real-time data. Filter models were designed based on an extended model of WRIMs. The detection of rotor asymmetry was achieved by estimating the states of rotor resistance and speed using four filters. The sensitivity of the parameters under healthy and asymmetry conditions was thoroughly analyzed and categorized as low, medium, and high sensitivity parameters. Robust model-based estimators were designed to minimize the probability of false alarms. The performance analysis demonstrated that the dual unscented Kalman filter (DUKF) outperformed other Kalman filters such as the extended Kalman filter (EKF), dual extended Kalman filter (DEKF), and unscented Kalman filter (UKF) for state estimation of WRIM. Full article

Batteries are everywhere, in all forms of transportation, electronics, and constitute a method to store clean energy. Among the diverse types available, the lithium-iron-phosphate (LiFePO₄) battery stands out for its common usage in many applications. For the battery’s safe operation, the state of charge (SOC) and state of health (SOH) estimations are essential. Therefore, a reliable and robust observer is proposed in this paper which could estimate the SOC and SOH of LiFePO₄ batteries simultaneously with high accuracy rates. For this purpose, a battery model was developed by establishing an equivalent-circuit model with the ambient temperature and the current as inputs, while the measured output was adopted to be the voltage where current and terminal voltage sensors are utilized. Another vital contribution is formulating a comprehensive model that combines three parts: a thermal model, an electrical model, and an aging model. To ensure high accuracy rates of the proposed observer, we adopt the use of the dual extend Kalman filter (DEKF) for the SOC and SOH estimation of LiFePO4 batteries. To test the effectiveness of the proposed observer, various simulations and test cases were performed where the construction of the battery system and the simulation were done using MATLAB. The findings confirm that the best observer was a voltage-temperature (VT) observer, which could observe SOC accurately with great robustness, while an open-loop observer was used to observe the SOH. Furthermore, the robustness of the designed observer was proved by simulating ill-conditions that involve wrong initial estimates and wrong model parameters. The results demonstrate the reliability and robustness of the proposed observer for simultaneously estimating the SOC and SOH of LiFePO4 batteries. Full article

The acceleration of a vehicle is important information in vehicle states. The vehicle acceleration is measured by an inertial measurement unit (IMU). However, gravity affects the IMU when there is a transition in vehicle attitude; thus, the IMU produces an incorrect signal output. Therefore, vehicle attitude information is essential for obtaining correct acceleration information. This paper proposes a convolutional neural network (CNN) for attitude estimation. Using sequential data of a vehicle’s chassis sensor signal, the roll and pitch angles of a vehicle can be estimated without using a high-cost sensor such as a global positioning system or a six-dimensional IMU. This paper also proposes a dual-extended Kalman filter (DEKF), which can accurately estimate acceleration/angular velocity based on the estimated roll/pitch information. The proposed method is validated by real-car experiment data and CarSim, a vehicle simulator. It accurately estimates the attitude estimation with limited sensors, and the exact acceleration/angular velocity is estimated considering the roll and pitch angle with de-noising effect. In addition, the DEKF can improve the modeling accuracy and can estimate the roll and pitch rates. Full article

To enhance the efficiency of an energy storage system, it is important to predict and estimate the battery state, including the state of charge (SOC) and state of health (SOH). In general, the statistical approaches for predicting the battery state depend on historical data measured via experiments. The statistical methods based on experimental data may not be suitable for practical applications. After reviewing the various methodologies for predicting the battery capacity without measured data, it is found that a joint estimator that estimates the SOC and SOH is needed to compensate for the data shortage. Therefore, this study proposes an integrated model in which the dual extended Kalman filter (DEKF) and autoregressive (AR) model are combined for predicting the SOH via a statistical model in cases where the amount of measured data is insufficient. The DEKF is advantageous for estimating the battery state in real-time and the AR model performs better for predicting the battery state using previous data. Because the DEKF has limited performance for capacity estimation, the multivariate AR model is employed and a health indicator is used to enhance the performance of the prediction model. The results of the multivariate AR model are significantly better than those obtained using a single variable. The mean absolute percentage errors are 1.45% and 0.5183%, respectively. Full article

Accurate, real-time estimation of battery state-of-charge (SoC) and state-of-health represents a crucial task of modern battery management systems. Due to nonlinear and battery degradation-dependent behavior of output voltage, the design of these estimation algorithms should be based on nonlinear parameter-varying models. The paper first describes the experimental setup that consists of commercially available electric scooter equipped with telemetry measurement equipment. Next, dual extended Kalman filter-based (DEKF) estimator of battery SoC, internal resistances, and parameters of open-circuit voltage (OCV) vs. SoC characteristic is presented under the assumption of fixed polarization time constant vs. SoC characteristic. The DEKF is upgraded with an adaptation mechanism to capture the battery OCV hysteresis without explicitly modelling it. Parameterization of an explicit hysteresis model and its inclusion in the DEKF is also considered. Finally, a slow time scale, sigma-point Kalman filter-based capacity estimator is designed and inter-coupled with the DEKF. A convergence detection algorithm is proposed to ensure that the two estimators are coupled automatically only after the capacity estimate has converged. The overall estimator performance is experimentally validated for real electric scooter driving cycles. Full article

An accurate state of charge (SOC) estimation is vital for the safe operation and efficient management of lithium-ion batteries. At present, the extended Kalman filter (EKF) can accurately estimate the SOC under the condition of a precise battery model and deterministic noise statistics. However, in practical applications, the battery characteristics change with different operating conditions and the measurement noise statistics may vary with time, resulting in nonoptimal and even unreliable estimation of SOC by EKF. To improve the SOC estimation accuracy under uncertain measurement noise statistics, a variational Bayesian approximation-based adaptive dual extended Kalman filter (VB-ADEKF) is proposed in this paper. The variational Bayesian inference is integrated with the dual EKF (DEKF) to jointly estimate the lithium-ion battery parameters and SOC. Meanwhile, the measurement noise variances are simultaneously estimated in the SOC estimation process to compensate for the model uncertainties, so that the adaptability of the proposed algorithm to dynamic changes in battery characteristics is greatly improved. A constant current discharge test, a pulse current discharge test, and an urban dynamometer driving schedule (UDDS) test are performed to verify the effectiveness and superiority of the proposed algorithm by comparison with the DEKF algorithm. The experimental results show that the proposed VB-ADEKF algorithm outperforms the traditional DEKF algorithm in terms of SOC estimation accuracy, convergence rate, and robustness. Full article

In order to estimate the diesel particulate filter (DPF) soot load and improve the accuracy of regeneration timing, a novel method based on an equivalent circuit model is proposed based on the electric-fluid analogy. This proposed method can reduce the impact of the engine transient operation on the soot load, accurately calculate the flow resistance, and improve the estimation accuracy of the soot load. Firstly, the least square method is used to identify the flow resistance based on the World Harmonized Transient Cycle (WHTC) test data, and the relationship between flow resistance, exhaust temperature and soot load is established. Secondly, the online estimation of the soot load is achieved by using the dual extended Kalman filter (DEKF). The results show that this method has good convergence and robustness with the maximal absolute error of 0.2 g/L at regeneration timing, which can meet engineering requirements. Additionally, this method can estimate the soot load under engine transient operating conditions and avoids a large number of experimental tests, extensive calibration and the analysis of complex chemical reactions required in traditional methods. Full article

The paper aims to realize a rapid online estimation of the state-of-power (SOP) with multiple constraints of a lithium-ion battery. Firstly, based on the improved first-order resistance-capacitance (RC) model with one-state hysteresis, a linear state-space battery model is built; then, using the dual extended Kalman filtering (DEKF) method, the battery parameters and states, including open-circuit voltage (OCV), are estimated. Secondly, by employing the estimated OCV as the observed value to build the second dual Kalman filters, the battery SOC is estimated. Thirdly, a novel rapid-calculating peak power/SOP method with multiple constraints is proposed in which, according to the bisection judgment method, the battery’s peak state is determined; then, one or two instantaneous peak powers are used to determine the peak power during $T$ seconds. In addition, in the battery operating process, the actual constraint that the battery is under is analyzed specifically. Finally, three simplified versions of the Federal Urban Driving Schedule (SFUDS) with inserted pulse experiments are conducted to verify the effectiveness and accuracy of the proposed online SOP estimation method. Full article

State of charge (SOC) and state of health (SOH) are key issues for the application of batteries, especially the absorbent glass mat valve regulated lead-acid (AGM VRLA) type batteries used in the idle stop start systems (ISSs) that are popularly integrated into conventional engine-based vehicles. This is due to the fact that SOC and SOH estimation accuracy is crucial for optimizing battery energy utilization, ensuring safety and extending battery life cycles. The dual extended Kalman filter (DEKF), which provides an elegant and powerful solution, is widely applied in SOC and SOH estimation based on a battery parameter model. However, the battery parameters are strongly dependent on operation conditions such as the SOC, current rate and temperature. In addition, battery parameters change significantly over the life cycle of a battery. As a result, many experimental pretests investigating the effects of the internal and external conditions of a battery on its parameters are required, since the accuracy of state estimation depends on the quality of the information regarding battery parameter changes. In this paper, a novel method for SOC and SOH estimation that combines a DEKF algorithm, which considers hysteresis and diffusion effects, and an auto regressive exogenous (ARX) model for online parameters estimation is proposed. The DEKF provides precise information concerning the battery open circuit voltage (OCV) to the ARX model. Meanwhile, the ARX model continues monitoring parameter variations and supplies information on them to the DEKF. In this way, the estimation accuracy can be maintained despite the changing parameters of a battery. Moreover, online parameter estimation from the ARX model can save the time and effort used for parameter pretests. The validation of the proposed algorithm is given by simulation and experimental results. Full article
