The backscattering coefficient ${\sigma }^0$ of a rice field is closely related to the amplitude, power, and phase of its radar backscattered signals. An investigation of the statistics of indoor full-polarization scatterometric and synthetic aperture radar (SAR) measurements on rice fields in the Laboratory of Target Microwave Properties (LAMP) is implemented in terms of the amplitude, power, and phase difference of backscattered signals. The validity and accuracy of LAMP measured data are studied and confirmed for the first time. The Rayleigh fading model and phase difference statistical model are both validated by the experimental data. Continuous microwave spectrum is obtained after spatial and frequency averaging over N independent scatterometric samples and full-polarization images are generated by applying a focusing algorithm to the SAR data. Comparisons between scatterometric results and SAR images with three resolutions of rice field scene are conducted with respect to amplitude and co-pol phase difference (CPD) statistics, as well as backscattering coefficients. The results show that the measured statistics of a rice field scene are in good agreement with those calculated by theoretical formulas. Spatial and frequency averaging of scatterometric data can increase N and thus improve the estimation accuracy of the backscattering coefficients. SAR images show a shift to the near range due to the intrinsic height of the rice plants and the probable existence of the double bounce scattering between vertical rice stems and the water surface considering the measurement geometry. The measured amplitude statistics of the SAR images approach a Rayleigh distribution with reduction of the resolution cell size while the size has little effect on the CPD statistics. The differences between backscattering coefficients extracted from the scatterometric data and SAR images confirm a 1-dB calibration accuracy in power of the LAMP measurement system. Full article

Wetland ecosystems play a key role in hydrological and biogeochemical cycles. In emergent vegetation targets, the occurrence of double-bounce scatter is indicative of the presence of water and can be valuable for hydrological monitoring. Double-bounce scatter would lead to an increase of σ⁰_HH over σ⁰_VV and a non-zero co-polarized phase difference (CPD). In the Lower Paraná River floodplain, a total of 11 full polarimetric RADARSAT-2 scenes from a wide range of incidence angles were acquired during a month. Flooded targets dominated by two herbaceous species were sampled: Schoenoplectus californicus (four sites, Bulrush marshes) and Ludwigia peruviana (three sites, Broadleaf marshes). As a general trend, σ⁰_HH was higher than σ⁰_VV, especially at the steeper incidence angles. By modeling CPD with maximum likelihood estimations, we found results consistent with double-bounce scatter in two Ludwigia plots, at certain scene incidence angles. Incidence angle accounted for most of the variation on σ⁰_HH, whereas emergent green biomass was the main feature influencing σ⁰_HV. Multivariate models explaining backscattering variation included the incidence angle and at least two of these variables: emergent plant height, stem diameter, number of green stems, and emergent green biomass. This study provides an example of using CPD to decide on the contribution of double-bounce scatter and highlights the influence of vegetation biomass on radar response. Even with the presence of water below vegetation, the contribution of double-bounce scatter to C-band backscattering depends on scene incidence angles and may be negligible in dense herbaceous targets. Full article

Analysis of synthetic aperture radar (SAR) images in L-band of short-period internal waves (IWs), and classification of their radar signatures is presented by means of a polarimetric data set from ALOS-PALSAR mission. We choose the polarimetric feature named standard deviation(std) of the co-polarized phase difference (CPD) to identify fundamental differences in SAR signatures of internal waves, and divided them into three different classes, according to their backscattered modulation depths and morphology as well as the std CPD, namely: double-signed, single-negative, and single-positive signatures, for IW normalized image transects that display, respectively, signatures in the form of bright/dark, dark, and bright bands that correspond to positive/negative, negative, or positive variations of radar backscatter. These radar power types of signatures have a counterpart in the std CPD normalized transects, and in this paper we discuss those correlations and decorrelations. We focus in the single-negative type of signature, that is dark bands on gray background, and show that the std CPD is greatly enhanced over the troughs and rear slopes of those IWs. It is suggested that such behavior is consistent with the presence of surface slicks owing to enhanced surfactant concentration. Furthermore, those single-negative SAR signatures appear at locations where and when biological productivity is enhanced. It is found that the modulation depths associated to the std CPD is higher than the one associated to the HH-polarized radar backscatter for single-negative signatures propagating in the range direction, while the reverse occurs for the other types of signatures. Full article

This paper deals with the retrieval of snow depth (SD) and snow water equivalent (SWE) using dual-polarization (HH-VV) synthetic aperture radar (SAR) data. The effect of different snowpack conditions on the SD and SWE inversion accuracy was demonstrated by using three TerraSAR-X acquisitions. The algorithm is based on the relationship between the SD, the co-polar phase difference (CPD), and particle anisotropy. The Dhundi observatory in the Indian Himalaya was selected as a validation test site where a field campaign was conducted for ground truth measurements in January 2016. Using the field measured values of the snow parameters, the particle anisotropy has been optimized and provided as an input to the SD retrieval algorithm. A spatially variable snow density ( ${\rho }_s$ ) was used for the estimation of the SWE, and a temporal resolution of 90 m was achieved in the inversion process. When the retrieval accuracy was tested for different snowpack conditions, it was found that the proposed algorithm shows good accuracy for recrystallized dry snowpack without distinct layering and low wetness (w). The statistical indices, namely, the root mean square error (RMSE), the mean absolute difference (MAD), and percentage error (PE), were used for the accuracy assessment. The algorithm was able to retrieve SD with an average MAE and RMSE of 6.83 cm and 7.88 cm, respectively. The average MAE and RMSE values for SWE were 17.32 mm and 21.41 mm, respectively. The best case PE in the SD and the SWE retrieval were 8.22 cm and 18.85 mm, respectively. Full article

Synthetic aperture radar (SAR) has been widely used to detect oil-spill areas through the backscattering intensity difference between oil and background pixels. However, since the signal is similar to that produced by other phenomena, positive identification can be challenging. In this study we developed an algorithm to effectively analyze large-scale oil spill areas in SAR images by focusing on optimizing the input layer to artificial neural network (ANN) through removal the factor of lowering the accuracy. An ANN algorithm was used to generate probability maps of oil spills. Highly accurate pixel-based data processing was conducted through false or un-detection element reduction by normalizing the image or applying a non-local (NL) means filter and median filter to the input neurons for ANN. In addition, the standard deviation of co-polarized phase difference (CPD) was used to reduce false detection from the look-alike with weak damping effect. The algorithm was validated using TerraSAR-X images of an oil spill caused by stranded oil tanker Volganefti-139 in the Kerch Strait in 2007. According to the validation results of the receiver operating characteristic (ROC) curve, the oil spill was detected with an accuracy of about 95.19% and un-detection or false detection by look-alike and speckle noise was greatly reduced. Full article
