Search Results (3)

Search Parameters:
Keywords = circular coils with magnetic medium

Order results
Result details
Results per page
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:
11 pages, 994 KiB
Article
Mutual Inductance Calculation of Circular Coils Sandwiched between 3-Layer Magnetic Mediums for Wireless Power Transfer Systems
by Minsheng Yang, Zhongqi Li, Min Zhang and Jingying Wan
Electronics 2021, 10(23), 3043; https://doi.org/10.3390/electronics10233043 - 6 Dec 2021
Cited by 11 | Viewed by 4114
Abstract
The mutual inductance between coils directly affects many aspects of performance in wireless power transmission systems. Therefore, a reliable calculation method for the mutual inductance between coils is of great significance to the optimal design of transmission coil structures. In this paper, a [...] Read more.
The mutual inductance between coils directly affects many aspects of performance in wireless power transmission systems. Therefore, a reliable calculation method for the mutual inductance between coils is of great significance to the optimal design of transmission coil structures. In this paper, a mutual inductance calculation for circular coils sandwiched between 3-layer magnetic mediums in a wireless power transmission system is proposed. First, the structure of circular coils sandwiched between 3-layer magnetic mediums is presented, and then a mutual inductance model of the circular coils is established. Accordingly, a corresponding magnetic vector potential analysis method is proposed based on Maxwell equations and the Bessel transform. Finally, the mutual inductance calculation method for circular coils between 3-layer magnetic mediums is obtained. The correctness of the proposed mutual inductance calculation method is verified by comparing the calculated, simulated, and measured mutual inductance data. Full article
(This article belongs to the Special Issue IoT Applications for Renewable Energy Management and Control)
►▼ Show Figures

Figure 1

16 pages, 3112 KiB
Article
Optimal Position of the Intermediate Coils in a Magnetic Coupled Resonant Wireless Power Transfer System
by Dongsheng Yang, Jiangwei Tian, Sokhui Won, Bowen Zhou, Zixin Cheng and Bo Hu
Energies 2019, 12(20), 3991; https://doi.org/10.3390/en12203991 - 20 Oct 2019
Cited by 7 | Viewed by 2895
Abstract
Coaxial coil topology is used as the transfer medium in traditional MCR-WPT (Magnetic Coupled Resonant Wireless Power Transfer) systems to improve the transfer characteristics. The intermediate coils are added to extend the transmission distance, whose positions are critical. This paper focuses on the [...] Read more.
Coaxial coil topology is used as the transfer medium in traditional MCR-WPT (Magnetic Coupled Resonant Wireless Power Transfer) systems to improve the transfer characteristics. The intermediate coils are added to extend the transmission distance, whose positions are critical. This paper focuses on the optimal intermediate coil positions for an MCR-WPT system with four coaxial planar circular spiral coils. By modeling the MCR-WPT system, the mathematical expression of the self-inductance and the mutual inductance are used to calculate the load power of the MCR-WPT system, which is composed of four planar circular spiral coaxial coils, and using MATLAB. The optimal distance ratio between the adjacent coils for maximizing the power of load is proposed. Furthermore, the experiments are implemented from the network analyzer and the experimental platform. In the platform, the load power is measured at the different intermediate coil positions, and the optimal position at which the load power is maximized is found. Both experimental results obtained by the network analyzer and the experimental platform have validated the theoretical and simulation results and provided the correctness of the suggested ratios. Full article
►▼ Show Figures

Figure 1

24 pages, 9011 KiB
Article
Analysis and Optimization of Four-Coil Planar Magnetically Coupled Printed Spiral Resonators
by Sadeque Reza Khan and GoangSeog Choi
Sensors 2016, 16(8), 1219; https://doi.org/10.3390/s16081219 - 3 Aug 2016
Cited by 55 | Viewed by 10507
Abstract
High-efficiency power transfer at a long distance can be efficiently established using resonance-based wireless techniques. In contrast to the conventional two-coil-based inductive links, this paper presents a magnetically coupled fully planar four-coil printed spiral resonator-based wireless power-transfer system that compensates the adverse effect [...] Read more.
High-efficiency power transfer at a long distance can be efficiently established using resonance-based wireless techniques. In contrast to the conventional two-coil-based inductive links, this paper presents a magnetically coupled fully planar four-coil printed spiral resonator-based wireless power-transfer system that compensates the adverse effect of low coupling and improves efficiency by using high quality-factor coils. A conformal architecture is adopted to reduce the transmitter and receiver sizes. Both square architecture and circular architectures are analyzed and optimized to provide maximum efficiency at a certain operating distance. Furthermore, their performance is compared on the basis of the power-transfer efficiency and power delivered to the load. Square resonators can produce higher measured power-transfer efficiency (79.8%) than circular resonators (78.43%) when the distance between the transmitter and receiver coils is 10 mm of air medium at a resonant frequency of 13.56 MHz. On the other hand, circular coils can deliver higher power (443.5 mW) to the load than the square coils (396 mW) under the same medium properties. The performance of the proposed structures is investigated by simulation using a three-layer human-tissue medium and by experimentation. Full article
(This article belongs to the Section Physical Sensors)
►▼ Show Figures

Figure 1

Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:

Displaying article 1-50 on page 1 of 1.
