Sparse synthetic aperture radar (SAR) imaging has demonstrated excellent potential in image quality improvement and data compression. However, conventional observation matrix-based methods suffer from high computational overhead, which is hard to use for real data processing. The approximated observation sparse SAR imaging method relieves the computation pressure, but it needs to manually set the parameters to solve the optimization problem. Thus, several deep learning (DL) SAR imaging methods have been used for scene recovery, but many of them employ dual-path networks. To better leverage the complex-valued characteristics of echo data, in this paper, we present a novel complex-valued convolutional neural network (CNN)-based approximated observation sparse SAR imaging method, which is a single-path DL network. Firstly, we present the approximated observation-based model via the chirp-scaling algorithm (CSA). Next, we map the process of the iterative soft thresholding (IST) algorithm into the deep network form, and design the symmetric complex-valued CNN block to achieve the sparse recovery of large-scale scenes. In comparison to matched filtering (MF), the approximated observation sparse imaging method, and the existing DL SAR imaging methods, our complex-valued network model shows excellent performance in image quality improvement especially when the used data are down-sampled. Full article

Sparse-representation-based synthetic aperture radar (SAR) imaging technology has shown superior potential in the reconstruction of nonsparse scenes. However, many existing compressed sensing (CS) methods with sparse representation cannot obtain an optimal sparse basis and only apply to the sensing matrix obtained by exact observation, resulting in a low image quality occupying more storage space. To reduce the computational cost and improve the imaging performance of nonsparse scenes, we formulate a deep learning SAR imaging method based on sparse representation and approximated observation deduced from the chirp-scaling algorithm (CSA). First, we incorporate the CSA-derived approximated observation model and a nonlinear transform function within a sparse reconstruction framework. Second, an iterative shrinkage threshold algorithm is adopted to solve this framework, and the solving process is unfolded as a deep SAR imaging network. Third, a dual-path convolutional neural network (CNN) block is designed in the network to achieve the nonlinear transform, dramatically improving the sparse representation capability over conventional transform-domain-based CS methods. Last, we improve the CNN block to develop an enhanced version of the deep SAR imaging network, in which all the parameters are layer-varied and trained by supervised learning. The experiments demonstrate that our proposed two imaging networks outperform conventional CS-driven and deep-learning-based methods in terms of computing efficiency and reconstruction performance of nonsparse scenes. Full article

Synthetic aperture radar (SAR), which can generate images of regions or objects, is an important research area of radar. The chirp scaling algorithm (CSA) is a representative SAR imaging algorithm. The CSA has a simple structure comprising phase compensation and fast Fourier transform (FFT) operations by replacing interpolation for range cell migration correction (RCMC) with phase compensation. However, real-time processing still requires many computations and a long execution time. Therefore, it is necessary to develop a hardware accelerator to improve the speed of algorithm processing. In addition, the demand for a small SAR system that can be mounted on a small aircraft or drone and that satisfies the constraints of area and power consumption is increasing. In this study, we proposed a CSA-based SAR processor that supports FFT and phase compensation operations and presents field-programmable gate array (FPGA)-based implementation results. We also proposed a modified CSA flow that simplifies the traditional CSA flow by changing the order in which the transpose operation occurs. Therefore, the proposed CSA-based SAR processor was designed to be suitable for modified CSA flow. We designed the multiplier for FFT to be shared for phase compensation, thereby achieving area efficiency and simplifying the data flow. The proposed CSA-based SAR processor was implemented on a Xilinx UltraScale+ MPSoC FPGA device and designed using Verilog-HDL. After comparing the execution times of the proposed SAR processor and the ARM cortex-A53 microprocessor, we observed a 136.2-fold increase in speed for the 4096 × 4096-pixel image. Full article

Quadrature-polarimetric synthetic aperture radar (quad-pol SAR) has extensive applications, including climate zones classification, extraction of surface roughness, soil moisture mapping, moving target indication, and rice mapping. Hybrid quad-pol SAR ameliorates the range ambiguity performance of conventional quad-pol SAR. However, the azimuth ambiguity of its cross-polarized (cross-pol) echo signals is serious, limiting the swath width of SAR. Therefore, this paper proposes a spaceborne weighted amplitude modulation (WAM) full-polarimetric (full-pol) SAR system, and it can suppress the azimuth ambiguity of hybrid quad-pol SAR. The performance boost of the azimuth ambiguity by the two imaging modes of the proposed SAR system is detailed and evaluated with the L-band system parameters. Moreover, the chirp scaling algorithm (CSA) is adopted to execute scene simulations for the two imaging modes. The results indicate that the proposed SAR system can effectively suppress the azimuth ambiguity of hybrid quad-pol SAR and verify the theoretical analysis. Full article

The expansion and improvement of synthetic aperture radar (SAR) technology have greatly enhanced its practicality. SAR imaging requires real-time processing with limited power consumption for large input images. Designing a specific heterogeneous array processor is an effective approach to meet the power consumption constraints and real-time processing requirements of an application system. In this paper, taking a commonly used algorithm for SAR imaging—the chirp scaling algorithm (CSA)—as an example, the characteristics of each calculation stage in the SAR imaging process is analyzed, and the data flow model of SAR imaging is extracted. A heterogeneous array architecture for SAR imaging that effectively supports Fast Fourier Transformation/Inverse Fast Fourier Transform (FFT/IFFT) and phase compensation operations is proposed. First, a heterogeneous array architecture consisting of fixed-point PE units and floating-point FPE units, which are respectively proposed for the FFT/IFFT and phase compensation operations, increasing energy efficiency by 50% compared with the architecture using floating-point units. Second, data cross-placement and simultaneous access strategies are proposed to support the intra-block parallel processing of SAR block imaging, achieving up to 115.2 GOPS throughput. Third, a resource management strategy for heterogeneous computing arrays is designed, which supports the pipeline processing of FFT/IFFT and phase compensation operation, improving PE utilization by a factor of 1.82 and increasing energy efficiency by a factor of 1.5. Implemented in 65-nm technology, the experimental results show that the processor can achieve energy efficiency of up to 254 GOPS/W. The imaging fidelity and accuracy of the proposed processor were verified by evaluating the image quality of the actual scene. Full article
