This work analyzes the aero-elastic oscillations of cantilever beams reinforced by carbon nanotubes (CNTs). Four different distributions of single-walled CNTs are assumed as the reinforcing phase, in the thickness direction of the polymeric matrix. A modified third-order piston theory is used as an accurate tool to model the supersonic air flow, rather than a first-order piston theory. The nonlinear dynamic equation governing the problem accounts for Von Kármán-type nonlinearities, and it is derived from Hamilton’s principle. Then, the Galerkin decomposition technique is adopted to discretize the nonlinear partial differential equation into a nonlinear ordinary differential equation. This is solved analytically according to a multiple time scale method. A comprehensive parametric analysis was conducted to assess the influence of CNT volume fraction, beam slenderness, Mach number, and thickness ratio on the fundamental frequency and lateral dynamic deflection. Results indicate that FG-X reinforcement yields the highest frequency response and lateral deflection, followed by UD and FG-A patterns, whereas FG-O consistently exhibits the lowest performance metrics. An increase in CNT volume fraction and a reduction in slenderness ratio enhance the system’s stiffness and frequency response up to a critical threshold, beyond which a damped beating phenomenon emerges. Moreover, higher Mach numbers and greater thickness ratios significantly amplify both frequency response and lateral deflections, although damping rates tend to decrease. These findings provide valuable insights into the optimization of CNTR composite structures for advanced aeroelastic applications under supersonic conditions, as useful for many engineering applications. Full article

This study develops a new type of decorative bridge panel by ultra-high-performance concrete (UHPC) based on the project of the Guangyangwan Bridge. First, the numerical analysis was carried out using MIDAS and ABAQUS to find the critical position of the bridge and decorative panels. The numerical results showed that the last concrete cantilever segment had the greatest vertical deflection, and the corresponding panel had the greatest stress response. Based on the numerical results, this study conducted a series of full-scale, self-balanced bending tests to examine the crack resistance of six UHPC panels and six glass fiber-reinforced concrete (GRC) panels with varying curved section thicknesses (from 25 to 40 mm). The experimental results indicate that, due to the high strength of the UHPC matrix and the wall effect of steel fiber distribution, the crack resistance of UHPC panels is significantly superior to that of GRC panels. UHPC panels possessed superior stiffness and ductility, while GRC panels showed brittle fracture when the curved section thickness reached 34 mm. The uniaxial tensile cracking strength of UHPC with a steel fiber volume fraction of 1.6% was 14.7% greater than that of GRC with a glass fiber volume fraction of 5%. At the same curved section thicknesses, UHPC decorative panels exhibit cracking loads and ultimate loads that are 64.3% to 123.0% and 29.2% to 115.0% greater than GRC panels, respectively. Hence, UHPC is more suitable to produce ultra-thin decorative panels for bridges that are subjected to severe environmental action and external forces. Full article

Retaining walls are often used to construct basements and underground station boxes. This unique case study compares the field-measured contiguous bored pile (CBP) wall, surrounding geology, and hydrogeology or groundwater responses against the results using 2D and 3D numerical back analyses of a deep excavation project that experienced localized groundwater drawdown through the leaking ground anchor points. Site observations indicated that the ground anchor installation works had caused larger than expected through-the-wall leakages that subsequently triggered nearby ground and building settlements. In order to study the complex soil–structure interaction behavior, back analyses using a hybrid modeling technique of through-the-wall transient hydrogeological seepage and geomaterial stress-strain analyses was implemented. Through these soil-structure interaction back analyses, it was evidently revealed that the presence of the continuous capping beam was key in providing pile head restraints against the active earth pressures when the groundwater was depressed, as well as efficiently distributing the beneficial wall corner effects towards the middle CBP wall, leading to smaller bending moment magnitudes, characterized by their ‘S-shaped’ profiles. This behavior had been correctly diagnosed, as opposed to the ‘D-shaped’ bending moment profile usually only seen in a typical free-head cantilever wall in similar geology. The eventual results show that the wall and ground responses, i.e., deflection, bending moment, and settlement, were reasonably well predicted when compared against the instrumented field data, thus validating the reliability of the geotechnical modeling technique, key geological parameters, and hydrogeological fluctuations adopted in the 2D and 3D numerical models, as well as the beneficial contributions of the continuous capping beam, which tend to be overlooked during routine retaining wall design. Full article

The very high cycle fatigue (VHCF) failure of in-service components is mainly caused by the vibration of thin-wall elements at a high frequency. In this work, a novel model of ultrasonic fatigue test was developed to test thin-wall material in bending up to VHCF with an accelerated frequency. The theoretical principle and finite element analysis were introduced for designing a sample that resonated at the frequency of 20 kHz in flexural vibration. In the advantage of the second-order flexural vibration, the gauge section of the sample was in the pure bending condition which prevented the intricate stress condition for thin-wall material as in the root of cantilever or the contact point of three points bending. Moreover, combining the constraint and the loading contact in one small section significantly reduced heating that originated from the friction at an ultrasonic frequency. Both strain gauge and deflection angle methods were applied to verify the controlling of stress amplitude. The fractography observation on Ti6Al4V samples indicated that the characterized fracture obtained from the novel model was the same as that from the conventional bending test. Full article

The main objective of this study is to propose an artificial neural network (ANN)-based tool for predicting the cantilever wall deflection in undrained clay. The excavation width, the excavation depth, the wall thickness, the at-rest lateral earth pressure coefficient, the soil shear strength ratio at mid-depth of the wall, and the soil stiffness ratio at mid-depth of the wall were selected as the input parameters, whereas the cantilever wall deflection was selected as an output parameter. A set of verified numerical data were utilized to train, test, and validate the ANN models. Two commonly used performance indicators, namely, root mean square error (RMSE) and mean absolute error (MAE), were selected to evaluate the performance of the proposed model. The results indicated that the proposed model can reliably predict the cantilever wall deflection in undrained clay. Moreover, the sensitivity analysis showed that the excavation depth is the most important parameter. Finally, a graphical user interface (GUI) tool was developed based on the proposed ANN model, which is much easier and less expensive to be used in practice. The results of this study can help engineers to better understand and predict the cantilever wall deflection in undrained clay. Full article

Thin-walled workpieces, such as aero-engine blisks and casings, are usually made of hard-to-cut materials. The wall thickness is very small and it is easy to deflect during milling process under dynamic cutting forces, leading to inaccurate workpiece dimensions and poor surface integrity. To understand the workpiece deflection behavior in a machining process, a new real-time nonintrusive method for deflection monitoring is presented, and a detailed analysis of workpiece deflection for different machining stages of the whole machining process is discussed. The thin-film polyvinylidene fluoride (PVDF) sensor is attached to the non-machining surface of the workpiece to copy the deflection excited by the dynamic cutting force. The relationship between the input deflection and the output voltage of the monitoring system is calibrated by testing. Monitored workpiece deflection results show that the workpiece experiences obvious vibration during the cutter entering the workpiece stage, and vibration during the machining process can be easily tracked by monitoring the deflection of the workpiece. During the cutter exiting the workpiece stage, the workpiece experiences forced vibration firstly, and free vibration exists until the amplitude reduces to zero after the cutter exits the workpiece. Machining results confirmed the suitability of the deflection monitoring system for machining thin-walled workpieces with the application of PVDF sensors. Full article
