A new method for the synchronous vibration parameter identification of constant-speed rotating blades based on blade tip clearance (BTC) measurement and blade tip timing (BTT) is introduced. A BTC sensor is used to measure the BTC when the blade tip passes through each sensor. The BTT method is used to determine whether the blade tip arrives in advance or lags. The geometric model between the BTC and the blade tip vibration displacement (BTVD) is established, and the BTVD of the blade tip passing through each sensor is obtained. Then, the nonlinear least squares method is used to determine the synchronous vibration parameters of the constant-speed rotating blade. The results show that with an increase in amplitude, the higher the accuracy of the vibration parameter identification proposed in this paper; with a decrease in the random error of the BTC measurement, the higher the accuracy of the vibration parameter identification proposed in this paper; with a decrease in the random error in the measurement of the blade disk dimensions, the higher the accuracy of the vibration parameter identification proposed in this paper. In addition, the smaller the ratio of the blade length to the blade disk radius, the higher the accuracy of the vibration parameter identification method introduced in this paper. Because the structure of the gas turbine compressor and turbine blade disk has a small blade disk ratio, the method proposed in this paper is suitable for the simultaneous vibration parameter identification of gas turbine compressor blades and turbine blades. Full article

As the existing Blade Tip Timing (BTT) vibration measurement methods have serious under-sampling problems, where the blade resonance frequency is usually higher than the sampling frequency of the data acquisition system of the BTT method, resulting in large errors in the identification of blade vibration parameters, new solutions are needed to extend the capability of BTT to nonlinear and multimodal vibration analysis. Therefore, it is the current research direction to pursue new and more accurate measurement and signal processing methods. By analyzing the waveform data from the BTT sensor and using it for vibration analysis, it significantly extends the BTT database. To avoid the current problems of under-sampling and low recognition accuracy, this paper conducts a study on the recognition of rotating blade vibration parameters based on the Radial Basis Function (RBF) model by establishing a RBF neural network prediction model to analyze the static calibration experimental data and predict the waveform of the BTT sensor, and comparing the prediction curves of various models. As the results show, for the RBF model, the prediction accuracy is closely related to the source data of the sampling point data, when the source data predicted by the RBF model is close to the center of the samples, the prediction accuracy is high, meanwhile, the prediction accuracy decreases as it is far away from the center of these data. At the same time, the number of samples is too small to affect the prediction ability of the RBF model. By using this method, more waveforms under the Blade Tip Clearance (BTC) can be predicted with the available sample point data, and the errors in the experimental measurement process can be corrected. Full article

Blade tip clearance (BTC) measurement and active clearance control (ACC) are becoming crucial technologies in aero-engine health monitoring so as to improve the efficiency and reliability as well as to ensure timely maintenance. Eddy current sensor (ECS) offers an attractive option for BTC measurement due to its robustness, whereas current approaches have not considered two issues sufficiently. One is that BTC affects the response time of a measurement loop, the other is that ECS signal decays with increasing speed. This paper proposes a speed adjustment model (SAM) to deal with these issues in detail. SAM is trained using a nonlinear regression method from a dynamic training data set obtained by an experiment. The Levenberg–Marquardt (LM) algorithm is used to estimate SAM characteristic parameters. The quantitative relationship between the response time of ECS measurement loop and BTC, as well as the output signal and speed are obtained. A BTC measurement method (BTCMM) based on the SAM is proposed and a geometric constraint equation is constructed to assess the accuracy of BTC measurement. Experiment on a real-time BTC measurement during the running process for a micro turbojet engine is conducted to validate the BTCMM. It is desirable and significative to effectively improve BTC measurement accuracy and expand the range of applicable engine speed. Full article
