The planetary flywheel can significantly reduce the weight of the flywheel, allowing the inerter to be lightweight. When a planetary flywheel ball screw inerter-based active actuator is used in a vehicle suspension system, the nonlinear features of the actuator affect vehicle performance. The planetary flywheel inerter actuator’s nonlinear dynamic model is constructed in this study based on the dynamic features of the planetary flywheel ball screw inerter and the electromagnetic torque generating mechanism of the permanent magnet synchronous motor. The impact of ball screw–nut friction, transmission clearance, planetary gear friction, and gear backlash on the performance of an active tuned inerter damper suspension is then investigated. As a result, the impact and sensitivity of numerous nonlinear parameters on suspension performance are shown, providing a theoretical foundation for the design of planetary flywheel inerter actuator and active inerter suspension. Full article

Inerter is a novel type of mechanical element. As the important composition of vibration control systems, inerters are widely used. Meanwhile, the operation security issue of the inerter is becoming increasingly prominent. Dynamic-breakdown of the inerter (DBoI) means that the inerter’s two terminals come into contact, which can cause a huge impact force and destroy the system. The ball-screw inerter is an essential protype of inerters. The existence of dynamic-breakdown of a single inerter has been already proved by previous research. To confirm whether DBoI exists in the inerter-spring-damper (ISD) system, the research focuses on the dynamic-breakdown of a ball-screw inerter (DBoBSI) in the ISD system. The dynamic model of the DBoI in the ISD system is established and analyzed. On account of the model and analysis, DBoBSI is analyzed. A novel experimental system is established and experiments of DBoBSI in the ISD system are carried out. The coefficient of restitution e_t changes slightly with a value of about 0.5. The variation of momentum is nearly equal to the impulse, with an error within 15%. On account of the experimental data collected, the conclusions are that there is a DBoBSI in the ISD system, and the impact force during DBoI in the ISD system ought to be avoided. Full article

Inerters, a new type of mass element, have been successfully applied in various fields, such as in automotive and civil engineering. The development of a new element, named a mechatronic inerter, which consists of a ball-screw inerter and permanent magnet electric machinery, proves the feasibility of adopting electrical element impedances to simulate corresponding mechanical elements. In this paper, the structures of the bridge electrical network and series-parallel electrical network and their impedance characteristics are first introduced. Then, a seven-degree-of-freedom vehicle model is established. In addition, by comparison with passive suspension, a bridge network and a series-parallel network with various basic topologies are used to improve the vibration isolation performance of mechatronic inertial suspension, and the advantages of the bridge network (a) are demonstrated. Finally, a bridge electrical network (a) was designed and a real vehicle test was carried out. The test results showed that the mechatronic inertial suspension based on the bridge network (a) was superior to the passive suspension; the RMS (root-mean-square) values of the suspension working space and dynamic tire load of the left rear wheel suspension were reduced by 21.1% and 6.3%, respectively; and the RMS value of the centroid acceleration was improved by 1.8%. Full article

In this paper, an inerter-based device for structural vibration control is proposed with which inertance can be altered relying on the frequency changes of the excitation. In this manner, a tuned mass damper is developed in such a way that it is assembled with a ball-screw inerter along with a new continuously variable transmission system. The device is termed an adaptive tuned mass inertance damper (ATMID). The ATMID is able to produce an alterable inertance, which gives rise to seamless variability in device frequency; consequently, the device frequency can be tuned to that of the excitation. To assess the efficiency of the device, the response amplitude of a single-degree-of-freedom harmonically induced structure controlled by the ATMID is compared with those of the passive-controlled and uncontrolled structures. Results show that in the frequency band where the effectiveness of the passive device with a mass ratio of 0.2 is degraded and even destructed, the adaptive device with a mass ratio of 0.1 and diverse inertance behaves impressively. As a result, notable oscillation suppression is obtained using the proposed adaptive device compared with passive-controlled (56%) and uncontrolled cases (21%). The presented extensive variability in the frequency of the device utilizing its transmission ratio of 0.45–2.2 leads the device to a superior level of oscillatory motion reduction in structural responses along an enlarged frequency band. Full article

This paper deals with an experimental study on the modeling and identification of the hysterical behavior of inerters. Unlike existing methods that can only consider a constant inertance to capture a static model of the device, we develop three different dynamic models for a ball-screw type inerter. To eliminate the effects of the measurement noise, an empirical mode decomposition (EMD) method is proposed. Then, three dynamic models—the Dahl, LuGre and Bouc–Wen model—are used in order to model the friction behavior of the device. Using the least-square optimization method, the parameters of the models are estimated. The results of the tuned models are compared together within different frequencies. The good agreement between predicted and measured data shows that LuGre and Bouc–Wen models can be effective for modelling the hysteretic behavior of friction inside the inerter mechanism. It is also shown that the Bouc–Wen model has better correlation with the experimental results in all test frequencies and amplitudes. Full article

In this study, improved analytical models, numerical parametric explorations, and experimental characterization are presented for a mechanical inerter to bring out dependencies for dynamic mass amplification under low rates (<5 Hz) of excitation. Two common realizations of the inerter—the ball-screw and the rack-and-pinion versions—are considered. Theoretical models incorporating component inertias and sizing were developed for both versions. The dependence of the specific inertance on key design parameters is explored through simulations. Based on these simulations, a prototype rack-and-pinion inerter delivering a specific inertance above 90 was designed, fabricated, and tested under low-rate displacement and acceleration-controlled excitations. The measured specific inertance was found to display an exponential decline with an increase in excitation frequency for both cases. Deviations from predictions are attributable to the frequency dependence of internal stiffness and damping in the fabricated prototype. Using a phase-matching procedure for a representative lumped model, the internal stiffness and damping in the prototype were estimated. Examination of the phase spectra reveals an influence of the excitation frequency on the internal stiffness, damping, and consequently specific inertance. Further, based on the results of this study, design perspectives for such mechanical inerters, which are seeing increasing use in several low-frequency applications, are also presented. It is envisioned that this approach can be utilized to subsume the specific nonlinear characteristics of individual inerters into a simple yet unsimplistic model that can be used to more efficiently and accurately predict the behavior of multi-element, inerter-based systems that employ them. Full article

Earthquakes and ambient vibrations can cause serious problems for cultural heritage objects; consequently, preserving these objects against mentioned sources of vibration has received more attention in recent years. To address this problem, in this paper, inerter is used to overcome the deficiency of a vibration isolator in the lower frequency range and performance of this passive device is evaluated experimentally. Specifically, first, the scaled model of an actual isolator and statue is presented. This structure has been designed and manufactured based on the results of a performance test, which has been performed on a famous statue of Michelangelo Buonarroti: Pieta Rondanini. In order to improve the performance of the isolator, a ball-screw type inerter has been designed and manufactured in this research. This device is introduced to the scaled structure and its effect on the dynamic behavior of the isolator is checked using a sine sweep vibration test. The experimental tests were performed on a shaking table in the horizontal direction. Then, the effectiveness of inerters on the dynamic behavior of the isolation system is demonstrated. It is shown that the isolator equipped with the manufactured inerters has better performance in the lower frequency range. Full article
