To optimize the modulated vibration generated by the integer-slot interior permanent magnet synchronous motor (IPMSM), a stepwise segmented skewed pole method was proposed, using an 8-pole 48-slot IPMSM as an example. First, the vibration characteristics of the motor were studied, and the theoretical mechanisms of the magnetic field modulation effect and radial force modulation effect were explained. The study showed that high-order radial forces can excite larger low-order vibrations under the influence of radial force modulation. Then, in response to the axial spacing in the linear skewed pole structure when canceling the 48th-order radial force, a stepwise skewed pole structure was proposed. The suppression mechanism of this skewed pole structure on the motor’s modulated vibration was analyzed, and the optimization effect of different segment numbers on the motor’s vibration acceleration at $12f_e$ was discussed. Finally, models for the motor’s magnetic field, structural field, and acoustic field before and after skewing were established, and simulations were conducted to compare the magnitudes of the radial forces at each order and their vibration noise performance. The results showed that after stepwise skewed pole optimization, the radial force that excites the modulated vibration was reduced by 68%, the maximum vibration acceleration on the casing surface was reduced by 84%, and the overall noise was reduced by 7.491 dB, effectively suppressing electromagnetic vibration noise. Full article

This article presents a detailed analysis of the electromagnetic force and vibration behavior of a new axial flux permanent magnet (AFPM) machine with a yokeless stator and interior PM rotor. Firstly, the configuration of an AFPM machine with a dual rotor and a sandwiched stator is introduced, including the structural design, fixation of the yokeless stator and segmented skew rotor structure. Then, the influence of anisotropic material and a fixed structure on stator modes is analyzed, including elastic modulus, shear model, the skew angle of slot and the thickness of stator yoke. Furthermore, a new non-equally segmented skew rotor structure is proposed and calculated for the reduction in vibration based on the multiphysics model. Three different segmented skew rotor schemes are compared to illustrate the influence of reducing vibration and noise. The predicted results show that the effect of the non-equally segmented skew rotor on reducing vibration is better than the other two schemes. Finally, a 120 kW AFPM motor is experimented with and the result matches well with the predicted data. The vibration performance of the AFPM motor with a dual rotor and sandwiched yokeless stator is revealed comprehensively. Full article

To reduce the negative impacts of stall and surge on compressor performance, a novel combined casing treatment (CCT) structure with axial skewed slots and injection groove is proposed in this paper. The aerodynamic performance, as well as the mechanisms of loss generation, of a transonic axial compressor with NASA Rotor 67 are investigated numerically. The simulation results indicate that, compared with individual casing treatment method, the CCT works effectively with regard to operation performance. The stall margin (SM) is increased by 14.7% with 1.12% decrease in the peak efficiency. The interaction of axial skewed slots and injection groove can be explained by the enhancement of exchange flow in slots and axial motion of fluid. As a result, the leakage flow near the blade tip is eliminated and the flow separation is further suppressed. What is more, an analysis of entropy generation is also conducted. The results reveal that the effect of CCT on loss reduction mainly concentrates in the tip part of the blade, with the loss decrease about 14.46% compared with the original rotor. The best control effect can be expected by appropriate match between geometrical parameters of axial skewed slots and mass flow rate of injection from the parameter analysis. Full article

In recent years, with developing technology in the field of electrical machines, more efficient and high power density electric motors have been produced. The use of high energy efficiency motors gains importance due to the increase in global energy demand. The main purpose of this study was to design an Axial Flux Induction Motor (AFIM) with the same efficiency class as the Radial Flux Induction Motor (RFIM) in premium efficiency (IE3) class which is used commonly in industrial applications. Various AFIMs are designed with different rotor slot numbers and performance analyses as efficiency and torque ripple changes are investigated. It is known that torque ripple is one of the key parameters in electrical machine design which should be kept as low as possible without decreasing efficiency and torque. Accordingly, AFIMs’ rotor slots are skewed considering the stator and rotor slot numbers. The use of a Soft Magnetic Composites (SMC) material in design is also investigated. As a result of the analyses, many premium efficiency classes for AFIMs are obtained. In addition, using SMC material and skewing the rotor slots provides that torque ripples be reduced. Full article

As one of the main parasitic parameters in permanent magnet (PM) synchronous machines (PMSMs), cogging torque is the main component of the torque ripple, which has always been the handicap in the high-performance, low-speed drive systems. Over the last two decades, various methods have been proposed to decrease the cogging torque in both radial-flux and axial-flux PMSMs. Among these methods, stator slot skewing, stator tooth notching, permanent magnet (PM) skewing, PM shifting, and pole pairing are extensively investigated. However, little work has been done on reducing the cogging torque of the claw pole machine (CPM), whose cogging torque cannot be ignored. In this paper, the general methods that have been used to reduce the cogging torque in radial-flux and axial-flux PMSMs are developed and verified in a CPM with a soft magnetic composite (SMC) core. The 3-D finite element method (FEM) is used to calculate the cogging torque and PM flux linkage per turn. By comparing different cogging torque reduction technologies, it can be found that the magnet step skewing and unequal claw pole width are very suitable for CPM. Full article
