In the process of micro-EDM, tool electrode wear is inevitable, especially for complex three-dimensional cavities or microgroove structures. Tool electrode wear accumulates during machining, which will finally affect machining accuracy and machining quality. It is necessary to reduce electrode wear and compensate it through micro-EDM. Therefore, based on an established L27 orthogonal experiment, this paper uses the grey relational analysis (GRA) method to realize multi-objective optimization of machining time and electrode wear, so as to achieve the shortest machining time and the minimum electrode wear during machining under the optimal machining parameter combination. Then, the orthogonal experiment results are used as dataset of artificial neural networks (ANNs), and an ANN prediction model is established. Combined with image processing technology, the bottom profile of the machined microgroove is extracted and then an electrode axial wear compensation equation is fitted, and a fixed-length nonlinear compensation method for electrode axial wear is proposed. Finally, the GRA optimal experiment shows that machining time, electrode axial wear and radial wear are reduced by 13.89%, 3.31%, and 10.80%, respectively, compared with the H17 orthogonal experiment with the largest grey relational grade. For the study of electrode axial wear compensation methods, the consistency of the depth and width of the machined microgroove structure with compensation is significantly better than that of the microgroove structure without compensation. This result shows that the proposed fixed-length nonlinear compensation method can effectively compensate electrode axial wear in micro-EDM and improve machining quality to a certain extent. Full article

Biological bone screws play an important role in fixing fractures and bone defects. The machining of helical grooves on xenogenic materials is a key part of fabricating biological bone screws. The fabrication of helical grooves on bovine bone using micro-abrasive air jets was investigated in this paper. The helical groove shapes were classified and their formation mechanisms were studied. Analyses of the material removal mechanism and the effect of process parameters on the groove shapes were carried out. The results show that the helical grooves could be effectively machined using micro-abrasive air jets with a spring mask. The shapes of the helical grooves could be classified as U-, V-, and W-shaped. Cracks that propagated along the cement line may have led to the formation of a slot. Meanwhile, cracks that propagated in the interstitial lamella may have led to the formation of ridges. The slots and ridges resulted in the appearance of stripes on the groove bottom. The cracks propagated along the axial direction of the osteon at the same time as it propagated into the osteon, leading to the formation of dimples on the groove sidewall. The experimental method proposed in this study can be regarded as a suitable method to fabricate helical grooves on bones. Full article

Nowadays, high aerodynamic load has made blade separation an issue for compact axial compressors under high-altitude low-Reynolds-number conditions. In this study, herringbone grooves inspired by bird feathers were applied to suppress the suction side separation and reduce loss. To study the effect of bio-inspired herringbone grooves on the aerodynamic performance of compressor cascades, a high subsonic compressor cascade was taken as the research object. Under the conditions of different Reynolds numbers, the effects of herringbone grooves of different depths on the flow separation were numerically studied. The research results show that at a high-Reynolds-number condition (Re = 5.6 × 10⁵), the sawtooth-shaped wake induced by herringbone grooves increases the turbulent mixing loss near the suction surface, and the blade performance deteriorates. At a low-Reynolds-number condition (Re = 1.3 × 10⁵), the span-wise secondary flow and micro-vortex structure induced by the herringbone grooves effectively suppress the laminar separation on the suction surface of the blade, and there is an optimal depth for the herringbone grooves that reduces the profile loss by 8.33% and increases the static pressure ratio by 0.55%. The selection principle of the optimal groove depth with the Re is discussed based on the research results under six low-Reynolds-number conditions. Full article

The slot milling cutter is primarily used for machining the tongue and groove of the steam turbine rotor, which is a critical operation in the manufacturing process of the steam turbine rotor. It is challenging to predict the milling force of a groove milling cutter due to variations in rake, rake angles and cutting speeds of the main cutting edge. Firstly, based on a limited amount of experimental data on turning, we have developed an equivalent turning force model that takes into account the impact of the rounded cutting edge radius, the tool’s tip radius and the feed rate on tool’s geometric angle. It provides a more accurate frontal angle for the identification method of the Johnson–Cook material constitutive equation. Secondly, the physical parameters, such as shear stress, shear strain and strain rate on the main shear plane, are calculated through the analysis of experimental data and application of the orthogonal cutting theory. Thirdly, the range of initial constitutive parameters of the material was determined through the split Hopkinson pressure bar (SHPB) test. The objective function was defined as the minimum error between the theoretical and experimental values. The optimal values of the Johnson–Cook constitutive equation parameters A, B, C, n and m are obtained through a global search using a genetic algorithm. Finally, the shear stress is determined by the governing equations of deformation, temperature and material. The axial force, torque and bending moment of each micro-segment are calculated and summed using the unit cutting force vector of each micro-segment. As a result, a milling force prediction model for slot milling cutters is established, and its validity is verified through experiments. Full article

In order to strengthen disaster prevention control under deep resource development and space utilization, it is necessary to construct a damage intrinsic model under complex stress states to predict the mechanical behavior of deep-rock mass under cyclic loading. An indoor uniaxial cyclic loading test on sandstone was carried out in this paper. By analyzing the mechanical properties and energy transformation of the failure process, it was assumed that the failure of rock micro-units follows a Weibull density function, and the damage intrinsic relationship was constructed using the Mogi–Coulomb strength criterion. The constitutive rationality was verified via the nonlinear fitting of the experimental curve and theoretical curve, and the model parameters were analyzed. This study indicates that the cyclic loading procedure has a strengthening effect on the elastic modulus. The brittleness of the rock increases with the cycle amplitude, the axial strain accumulates continuously, and the hysteresis loop area increases gradually and moves to the right. The energy conversion of the loading process is mainly split into the energy storage phase before the damage and the release phase at the time of damage, and the dissipation energy percentage curve shows the groove evolution law. The damage intrinsic model based on the Mogi–Coulomb strength criterion accurately reflects the ontological relationship of sandstone under cyclic loading, and the model parameters have clear physical significance. This study has important theoretical and engineering meaning for predicting the deformation and destruction of rocks. Full article

This paper details an experimental investigation on the influence of the size effect when slot-milling a CMSX-4 single-crystal nickel-based superalloy using 1 mm- and 4 mm-diameter TiAlN-coated tungsten carbide (WC) end-mills. With all tools having similar cutting-edge radii (r_e) of ~6 µm, the feed rate was varied between 25–250 mm/min while the cutting speed and axial depth of cut were kept constant at 126 m/min and 100 µm, respectively. Tests involving the Ø 4 mm end-mills exhibited a considerable elevation in specific cutting forces exceeding 500 GPa, as well as irregular chip morphology and a significant increase in burr size, when operating at the lowest feed rate of 25 mm/min. Correspondingly for the Ø 1 mm micro-end-mills, high levels of specific cutting forces up to ~1000 GPa together with severe material ploughing and grooving at the base of the machined slots were observed. This suggests the prevalence of the size effect in the chip formation mechanism as feed per tooth/uncut chip thickness decreases. The minimum uncut chip thickness (h_min) when micromilling was subsequently estimated to be less than 0.10 r_e, while this increased to between 0.10–0.42 r_e when machining with the larger Ø 4 mm tools. Full article

In this work, a helical ionic polymer metal composite (IPMC) was fabricated by thermal treatment in a mold with helix grooves. The axial actuation behaviors of the helical IPMC actuator were observed, and the electromechanical and electrochemical characteristics were evaluated. The experimental results showed that as the voltage increased and the frequency decreased, the axial displacement, axial force, and electric current of the actuator all increased. Compared with square wave and sinusoidal signals, the actuator exhibited the most satisfactory motion under the direct current (DC) signal. For the electrochemical test, as the scanning rate decreased, the gravimetric specific capacitance increased. Within a suitable voltage range, the actuator was chemically stable. In addition, we coupled the Electrostatics module, Transport of Diluted Species module, and Solid Mechanics module in COMSOL Multiphysics software to model and analyze the helical IPMC actuator. The simulation data obtained were in good agreement with the experimental data. Finally, by using three helical IPMC actuators as driving components, an innovative three-degree-of-freedom (3-DOF) micro-parallel platform was designed, and it could realize a complex coupling movement of pitch, roll, and yaw under the action of an electric field. This platform is expected to be used in micro-assembly, flexible robots, and other fields. Full article

The disadvantage of aerostatic bearings is their low dynamic quality. The negative impact on the dynamic characteristics of the bearing is exerted by the volume of air contained in the bearing gap, pockets, and microgrooves located at the outlet of the feeding diaphragms. Reducing the volume of air in the flow path is a resource for increasing the dynamic quality of the aerostatic bearing. This article presents an improved design of an axial aerostatic bearing with simple diaphragms, an annular microgroove, and an elastic suspension of the movable center of the supporting disk. A mathematical model is presented and a methodology for calculating the static characteristics of a bearing and dynamic quality indicators is described. The calculations were carried out using dimensionless quantities, which made it possible to reduce the number of variable parameters. A new method for solving linearized and Laplace-transformed boundary value problems for transformants of air pressure dynamic functions in the bearing layer was applied, which made it possible to obtain a numerical solution of problems sufficient for practice accuracy. The optimization of the criteria for the dynamic quality of the bearing was carried out. It is shown that the use of an elastic suspension of the support center improves its dynamic characteristics by reducing the volume of compressed air in the bearing layer and choosing the optimal volume of the microgroove. Full article

Optimization of cutting parameters in micro-milling is an important measure to improve surface quality and machining efficiency of the workpiece. Investigation of micro-milling forces prediction plays a positive role in improving machining capacity. To predict micro-milling forces and optimize micro-milling cutting parameters (per-feed tooth (f_z), axial cutting depth (a_p), spindle speed (n) and tool extended length (l)), a rotatable center composite experiment of micro-milling straight micro-groove in the workpiece of Al7075-T6 were designed, based on second-order response surface methods. According to the experiment results, the least square method was used to estimate the regression coefficient corresponding to the cutting parameters. Simultaneously, the response prediction model of micro-milling was established and successfully coincide the predicted values with the experiment values. The significance of the regression equation was tested by analysis of variance, and the influence of micro-milling cutting parameters on force and top burrs morphology was studied. The experiment results show that in a specific range of cutting parameters, a_p and f_z have a significant linear relation with the micro-milling force and the top burrs width. According to the optimal response value, the optimized cutting parameters for micro-milling obtained as: n is 11,393 r/min, f_z is 6 µm/z, a_p is 11 μm and l is 20.8 mm. The research results provide a useful reference for the selection of cutting parameters for micro-milling. Full article

Micro-end-milling is a cutting technology that removes redundant material from machined workpieces by small-diameter end mills, and is widely used to manufacture miniature complex parts. During micro-end-milling, the cutting vibration caused by weak tool rigidity and high spindle speed is known as a key factor for decreasing machined quality and accelerating tool failure. This study reports on experiments of micro-end-milling of the straight groove for AISI 1045 steel. The waveform characteristics of acceleration vibration were revealed, the relationship between acceleration and milling parameters were analyzed and two types of relationship models were developed. The results show that, during micro-end-milling of the straight groove, the components of acceleration vibration from largest to smallest are in turn the transverse acceleration α_Y, the feed acceleration α_X and the axial acceleration α_Z. Compared with feed velocity v_f and axial depth of cut a_p, the spindle speed n has the highest influence on cutting vibration. The response surface model of acceleration vibration was shown to have a higher prediction accuracy compared to the power function model and is more suitable for the prediction and control of cutting vibration during micro-end-milling. Full article

Pipe design is one of the most significant research lines in the area of parabolic semi-cylindrical solar collectors. The main idea behind pipe design is to increase the capillarity angle by expanding the total area being heated, therefore boosting the work capacity of the device. Such capillarity depends on several factors, whose numerical calculations are highly complex. Moreover, some of those variables are integers, whereas some others are real; hence, it is necessary to use optimization techniques that are capable of searching in those numerical spaces. There are several optimization tools that allow individual codification as binary strings, granting the coding of integer, real, or any other, as part of the same individual. Consequently, in this paper we propose the comparison of four metaheuristics when they are utilized to maximize the capillarity angle of the pipe in a parabolic trough. Experimental results show a better performance of binary particle swarm optimization when compared against the other techniques, achieving improvements in the capillarity angle of on average $11\%$ in comparison with a similar study. Full article
