Search Results (8)

In this study, the magnetic signatures of ship structures were investigated. The magnetic signature impacts both navigation safety and the health of the marine ecosystem. Reducing this signature is essential for minimising risks associated with navigation and protecting marine biodiversity. A finite element model was developed to assess the magnetic signature of honeycomb sandwich panels for ship structures. A theoretical approach was proposed, and the predicted results were compared with the values obtained by the finite element analyses. Different types of structures were compared to evaluate the combined effect of materials and geometry on the magnetic signature. The finite element results and the theoretical predictions indicate that the use of metamaterial structures, consisting of honeycomb sandwich panels with a steel core and aluminium skins, produces a significant reduction of the ship magnetic signature compared to the one arising from a steel panel with the same bending stiffness. Full article

Ultimate strength is critical for hull structures because it determines the maximum load the structure can withstand before catastrophic failure. Aluminium honeycomb sandwich panels provide excellent energy absorption and a high strength-to-weight ratio. However, further investigation of honeycomb sandwich panel structural performance is needed in typical marine conditions. This study focuses on the numerical analysis of honeycomb sandwich panels employing the nonlinear finite element method through the commercial software ANSYS. It investigates their performance under uniaxial compression and varying lateral pressure conditions while considering different cell edge lengths and core height configurations. Several structural configurations are compared to the experimental work published in the literature. Enhanced by experimental accuracy, the present study is a further step in expanding the application of honeycomb sandwich panels for ship hull applications that may lead to light and energy-efficient structures. Full article

The study aims to develop an integrating risk-based formulation and cost-benefit analysis for identifying an optimal ship hull structural design solution where the steel cargo holds aluminium honeycomb sandwich panels to replace inner side shells. The risk of progressive structural failure includes hazards related to environmental pollution due to accidental fuel and oil spills, possible loss of cargo, crew members and ship during operations, and air pollution during shipyard construction and ship voyages. The structural failure incorporates progressive time-dependent structural degradation coupled with ship hull load-carrying capacity in predicting structural integrity during the service life. The ship hull structural failure and associated risk are estimated over the ship’s service life as a function of the design solution. The carbon footprint and cost to mitigate the impact for the entire steel and hybrid ship hull structural solution implemented as a sustainable life cycle solution are analysed where the steel ship hull structure is built through primary construction. The cost of structural measures accounts for redesigning the ship structure and implementing aluminium honeycomb composite panels instead of steel plates, reducing steel weight, environmental pollution and cost and increasing the transported cargo and corrosion degradation resistance. It has been found that design solutions AHS1 and AHS2, in which aluminium honeycomb panels replace the inner steel shell plates, enhance the corrosion degradation resistance, and reduce the ship hull’s lightweight, reflecting a better beta-reliability index at the time of the first repair with a lower repair cost and more transported cargo. The cost of the ship associated with the design solutions AHS1 and AHS2 is about 11% lower than the steel solutions. Full article

The ship hull structure is composed of plates and stiffened panels. Estimating the maximum load-carrying capacity, or the ultimate strength, of these structural components is fundamental. One of the main challenges nowadays is the implementation of new materials and technologies to enhance the structural integrity, economy, safety and environmentally friendly design of the ship’s hull structure. A new design solution may be represented by aluminium alloy honeycomb sandwich structures, both as plane panels or stiffened ones, which are characterised by excellent impact-absorption capabilities and a high stiffness-to-weight ratio. Still, their response to some conditions typical of ship structural design needs to be deeply investigated. Axial compressive loading is one of the most critical conditions that could impact the structural integrity of such light-weight solutions. Hence, the uniaxial compressive behaviour of aluminium honeycomb sandwich structures has to be deeply investigated to promote their integration in ship structural design. Within this context, the present work performs an experimental and numerical study of a honeycomb sandwich panel subjected to uniaxial compressive loads. The results will help develop models for predicting the uniaxial compressive load-carrying capacity of hybrid honeycomb sandwiches of aluminium alloy design. Full article

Combination of lightweight and sustainable marine structures represents a crucial step to accomplish weight reduction and improve structural response. A key point when considering the reliability of innovative structural solutions, which should not be neglected, is represented by large-scale experimental investigations and not only by small-scale specimen analysis. The present research activity deals with the experimental assessment of a lightweight ship balcony overhang, which incorporates an aluminium honeycomb sandwich structure and Al/Fe structural transition joints obtained by means of the explosion welding technique. The ship balcony overhang was formerly designed with the aim of proposing the replacement of ordinary marine structures with green and lightweight options. Experimental investigations of a large-scale structure were performed to validate the design procedure and to evaluate the feasibility of the proposed solution. Large-scale bending tests of the ship balcony overhang were performed considering representative configurations of severe loading conditions. The experimental analysis allowed the evaluation of the structure’s strength, stiffness and failure modes. Comparisons with analogous structures reported in the literature were performed with the aim of assessing the benefits and drawbacks of the proposed lightweight structure. Fatigue tests were also performed in order to evaluate the hardening and the hysteresis loops. The collapse modes of the structure were investigated using X-ray radiography. The structural transition joints have experienced no cracks during the static and fatigue tests. The results clearly indicated that the proposed solution can be integrated in new and existing ships, even if made of steel, as the Al/Fe structural transition joints produced by explosion welding can be used to connect the ship structure to the Al honeycomb balcony. The systematic analysis of the experimental results gave valuable data to enhance the design methodology of such structures. Full article

Integrating innovative solutions for ship design has always been a great challenge for the maritime sector due to complex design and construction processes. With this scenario in mind, the objective of this study was to develop a procedure to evaluate the potential benefits arising from the integration of innovative light-weight structures in ship hull structural design. To achieve such an objective, a hybrid light-weight ship hull structural design solution, in which aluminium honeycomb sandwich panels were used to build the conventional steel inner side shell of the cargo holds, was adopted for a bulk carrier. The authors of this study used a multiple criteria decision-making approach. An optimal ship hull structural design solution was identified based on capital cost, voyage cost, annual cost, energy efficiency design index, dismantling–reselling cost, cargo transportation, energy consumption and carbon footprint. The optimal solution, identified with the multiple criteria decision-making approach, improved the ship’s efficiency and costs by combining the hybrid structural design with efficient cargo transportation. In addition, using recycled aluminium was found to be a promising strategy to reduce the energy consumption and carbon footprint related to the shipbuilding process. Full article

Sandwich panels consisting of two Carbon Fibre Reinforced Polymer (CFRP) outer skins and an aluminium honeycomb core are a common structure of surfaces on commercial aircraft due to the beneficial strength–weight ratio. Mechanical defects such as a crushed honeycomb core, dis-bonds and delaminations in the outer skins and in the core occur routinely under normal use and are repaired during aerospace Maintenance, Repair and Overhaul (MRO) processes. Current practices rely heavily on manual inspection where it is possible minor defects are not identified prior to primary repair and are only addressed after initial repairs intensify the defects due to thermal expansion during high temperature curing. This paper reports on the development and characterisation of a technique based on conductive thermography implemented using an array of single point temperature sensors mounted on one surface of the panel and the concomitant induced thermal profile generated by a thermal stimulus on the opposing surface to identify such defects. Defects are classified by analysing the differential conduction of thermal energy profiles across the surface of the panel. Results indicate that crushed core and impact damage are detectable using a stepped temperature profile of 80 ${}^{\circ }$C The method is amenable to integration within the existing drying cycle stage and reduces the costs of executing the overall process in terms of time-to-repair and manual effort. Full article

This study investigates the shear capacity of aluminum alloy honeycomb sandwich plates connected by high-strength, ordinary, or self-tapping bolts. For that purpose, experimental tests and finite elements are carried out. The failure of a high-strength bolt connector is driven by bending deformations developed in the bolt that deform connection plate and pad openings. In the case of ordinary bolt connectors, stress concentration on the bolt shear surface causes a large shear deformation that finally leads to failure. In the case of self-tapping bolt connectors, the insufficient mechanical bite force of the screw thread yields the bolt misalignment and concentrates shear deformation. As a result, the high-strength bolt connector is the most efficient design solution. If the bolt hole edge distance is more than 1.5 times as much as the bolt diameter, the connection performance becomes insensitive to this parameter. The practical formula for evaluating the connector shear capacity is derived from experimental data. Full article
