28 pages, 6574 KiB
Article
Design of Segmented Ultra-Wideband TEM Horn Antenna for Calibration of Wideband Electromagnetic Pulse Sensors
by Tianchi Zhang, Yongli Wei, Yuan Wang, Changjiao Duan, Lihua Wang, Zongxiang Li, Xiao Li, Xin Li and Baofeng Cao
Sensors 2025, 25(12), 3599; https://doi.org/10.3390/s25123599 - 7 Jun 2025
Viewed by 531
Abstract
Wideband electromagnetic pulse detection is a crucial method for lightning disaster monitoring. However, the random nature of lightning events presents challenges in fulfilling real-time calibration requirements for electromagnetic pulse sensors. This paper introduces a segmented ultra-wideband TEM horn antenna tailored for portable calibration [...] Read more.
Wideband electromagnetic pulse detection is a crucial method for lightning disaster monitoring. However, the random nature of lightning events presents challenges in fulfilling real-time calibration requirements for electromagnetic pulse sensors. This paper introduces a segmented ultra-wideband TEM horn antenna tailored for portable calibration experiments in electromagnetic pulse detection systems. The radiating plates feature a four-section polygonal design, and an end-loaded metal plate is integrated to reduce reflection signal interference. Rigorous simulation analyses were performed on three key factors impacting antenna radiation performance: aperture impedance, tapering profile, and end loading configuration. Experimental results show that the designed antenna achieves a peak field strength of 48.9 V/m at a 10 m distance, with a rise time of 0.87 ns and a full width at half maximum of 1.75 ns. The operating frequency ranges from 48 MHz to 150 MHz, with main lobe beamwidths of 43° and 83° in the E-plane and H-plane radiation patterns, respectively. These parameters meet the technical requirements for electromagnetic pulse sensor calibration experiments. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

15 pages, 7617 KiB
Article
Design, Fabrication and Testing of a Multifrequency Microstrip RFID Tag Antenna on Si
by Timothea Korfiati, Christos N. Vazouras, Christos Bolakis, Antonis Stavrinidis, Giorgos Stavrinidis and Aggeliki Arapogianni
Computation 2024, 12(6), 122; https://doi.org/10.3390/computation12060122 - 13 Jun 2024
Viewed by 1530
Abstract
A configurable design of a microstrip square spiral RFID tag antenna, for a wide range of microwave frequencies in the S- and C-band, is presented. The design is parameterized in dimensions, and hence changing the design frequency (or frequencies) is easy, by changing [...] Read more.
A configurable design of a microstrip square spiral RFID tag antenna, for a wide range of microwave frequencies in the S- and C-band, is presented. The design is parameterized in dimensions, and hence changing the design frequency (or frequencies) is easy, by changing only an initial value for the spiral geometry. A tag specimen was fabricated using a Cu electroplating technique according to the design for frequencies of interest in the areas of 2.4 and 5.8 GHz. The substrate material is 320 μm high-resistivity Si and the bridge dielectric is 15 μm polyimide PI2525. The steps of the microfabrication process involve metallic structure pattern transfer techniques with optical UV lithography procedures. The reflection coefficient and antenna gain of the specimen were measured inside an anechoic enclosure using a vector network analyzer (VNA) and a TEM horn test antenna over a frequency range of up to 6 GHz. Simulated and measured results, exhibiting reasonable agreement, are presented and discussed. Full article
Show Figures

Figure 1

16 pages, 5444 KiB
Article
Compact Wideband Double-Slot Microstrip Feed Engraved TEM Horn Strip Antennas on a Multilayer Substrate Board for in Bed Resting Body Positions Determination Based on Artificial Intelligence
by Jiwan Ghimire, Ji-Hoon Kim and Dong-You Choi
Sensors 2022, 22(23), 9555; https://doi.org/10.3390/s22239555 - 6 Dec 2022
Cited by 1 | Viewed by 2530
Abstract
In this paper, a horn-shaped strip antenna exponentially tapered carved on a multilayer dielectric substrate for an indoor body position tracking system is proposed. The performance of the proposed antenna was verified by testing it as a tracking state of an indoor resting [...] Read more.
In this paper, a horn-shaped strip antenna exponentially tapered carved on a multilayer dielectric substrate for an indoor body position tracking system is proposed. The performance of the proposed antenna was verified by testing it as a tracking state of an indoor resting body position. Among different feeding techniques, the uniplanar T-junction power divider approach is used. The performance verification of the proposed antenna is explained through its compact size and 3D shape, along with a performance comparison of the return loss radiation pattern and the realized gain. The suggested antenna has an 88.88% fractional bandwidth and a return loss between 6 and 15.6 GHz, with a maximum gain of 9.46 dBi in the 9.5 GHz region. Within the intended band, the radiation pattern had an excellent directivity characteristics. The proposed antenna was connected to an NVA-R661 module of Xethru Inc. for sleeping body position tracking. The performance of the antenna is measured through microwave imagining of the state of the resting body in various sleeping positions on the bed using a Recurrent Neural Network (RNN). The predicted outcomes clearly define the antenna’s performance and could be used for sensing and prediction purposes. Full article
(This article belongs to the Section Radar Sensors)
Show Figures

Figure 1

11 pages, 6721 KiB
Communication
A Low-Profile SIW-Based CTS Array with Reconfigurable Four Beams and Dual Polarizations for K-Band Sensing
by Yitong Jin, Yuanqing Chen, Yafei Ding, Ziwen Zou, Feng Qian, Yong Luo and Guangli Yang
Sensors 2022, 22(9), 3563; https://doi.org/10.3390/s22093563 - 7 May 2022
Cited by 1 | Viewed by 2166
Abstract
A dual-polarized continuous transverse stub (CTS) K-band antenna with reconfigurable four beams and low profile is proposed based on substrate-integrated-waveguide (SIW) design. It consists of a line source generator (LSG) on the bottom surface, a spherical-wave to plane-wave transforming part on the middle [...] Read more.
A dual-polarized continuous transverse stub (CTS) K-band antenna with reconfigurable four beams and low profile is proposed based on substrate-integrated-waveguide (SIW) design. It consists of a line source generator (LSG) on the bottom surface, a spherical-wave to plane-wave transforming part on the middle layer, and CTS radiators on the top surface. Particularly, the LSG has four SIW-based H-plane horns, and a chip is integrated to switch among the two pairs of horns, so as to transfer the quasi-TEM waves on the bottom surface by a ±10° deflection angle to the middle layer for the CTS radiators on the top surface, resulting in four reconfigurable scanning beams with 10° for two polarizations. The measurements show that it realizes four reconfigurable beams with a 25.8 dBi gain at 24 GHz, verifying the design. The proposed antenna takes into account the advantages of reconfigurable multi-beam, dual polarization, low side lobes, low profile, and high gain, which can be applied to K-band sensing, especially for wind profile radars. Full article
(This article belongs to the Special Issue Antenna and Microwave Sensors)
Show Figures

Figure 1

18 pages, 6645 KiB
Article
Antenna Array with TEM-Horn for Radiation of High-Power Ultra Short Electromagnetic Pulses
by Vladimir M. Fedorov, Mikhail V. Efanov, Vasiliy Ye. Ostashev, Vladimir P. Tarakanov and Aleksander V. Ul’yanov
Electronics 2021, 10(9), 1011; https://doi.org/10.3390/electronics10091011 - 23 Apr 2021
Cited by 22 | Viewed by 4028
Abstract
An antenna array with short shielded transverse electromagnetic horns (S-TEM-horns) for emitting high-power radiation of ultra-short electromagnetic pulses (USEMP) has been created and researched. The antenna unit consists of an ultra-wideband antenna array with four S-TEM horns, with each connected to a two-wire [...] Read more.
An antenna array with short shielded transverse electromagnetic horns (S-TEM-horns) for emitting high-power radiation of ultra-short electromagnetic pulses (USEMP) has been created and researched. The antenna unit consists of an ultra-wideband antenna array with four S-TEM horns, with each connected to a two-wire HF transmission line, and these four lines are connected to an antenna feeder. This feeder is connected to a semiconductor generator with the following parameters: a 50 Ohm connector, 10–100 kV high-voltage monopolar pulses, a rise time of about 0.1 ns, FWHM = 0.2–1 ns, and pulse repetition rates of 1–100 kHz. The antenna array was designed and optimized to achieve a high efficiency of about 100% for the antenna aperture by using a 2 × 2 array with S-TEM-horns, with shielding rectangular plates for the return current. The transient responses were studied by simulation using the electromagnetic 3D code “KARAT” at the time domain and experimentally with the use of our stripline sensor for measurement of the impulse electrical field with a 0.03 ns rise time and a 7 ns duration at the traveling wave. The radiators were emitting USEMP waves with a hyperband frequency spectrum of 0.1–6 GHz. The radiation with an amplitude of 5–30 kV/m of the E-field strength at a distance of up to 20 m was successfully applied to test the electronics for immunity to electromagnetic interference. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

18 pages, 2321 KiB
Article
An In-Line Coaxial-to-Waveguide Transition for Q-Band Single-Feed-Per-Beam Antenna Systems
by Marco Simone, Alessandro Fanti, Matteo Bruno Lodi, Tonino Pisanu and Giuseppe Mazzarella
Appl. Sci. 2021, 11(6), 2524; https://doi.org/10.3390/app11062524 - 11 Mar 2021
Cited by 12 | Viewed by 6378
Abstract
An in-line transition between a coaxial cable and rectangular waveguide operating in Q-band (33–50 GHz) is presented. The aim of the work is to minimize the modifications in the waveguide to the strictly necessary to overcome the manufacturing issues due to the high [...] Read more.
An in-line transition between a coaxial cable and rectangular waveguide operating in Q-band (33–50 GHz) is presented. The aim of the work is to minimize the modifications in the waveguide to the strictly necessary to overcome the manufacturing issues due to the high frequencies involved. In addition, the transition is compact and it does not increase the space occupation on the transverse section, this suggests its application in horn antennas clusters arrangement. The operating principle consists of both a modal conversion and an impedance matching between the devices. The modal conversion is realized in an intermediate region, where the coaxial penetrates in the waveguide: the device geometry is designed so that the electric field in the transition is a trade-off between the TEM mode of the coaxial and the TE10 of the guide. A shaped waveguide backshort and a reactive air gap in the coaxial cable co-participate to achieve the matching. An optimized Chebyshev stepped transformer completes the transition to fulfil the impedance mismatch with the full waveguide. The design issues and technological aspects are considered. The influences of the feeding pin misalignment, the presence of groove is included in the analysis and these practical aspects are discussed and numerically validated via the scattering parameters analysis of the proposed design. The return loss is higher than 25 dB over the whole Q-band. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

10 pages, 1575 KiB
Article
Robust Design of 3D-Printed 6–18 GHz Double-Ridged TEM Horn Antenna
by Sungwoo Lee, Youngoo Yang, Kang-Yoon Lee, Kyung-Young Jung and Keum Cheol Hwang
Appl. Sci. 2018, 8(9), 1582; https://doi.org/10.3390/app8091582 - 7 Sep 2018
Cited by 10 | Viewed by 7450
Abstract
A robust design of a 3D-printed 6–18 GHz double-ridged TEM horn antenna is proposed in this paper. The designed TEM horn antenna has two parts: an adaptor and a horn aperture. The adaptor is realized using a double-ridged waveguide to extend the operating [...] Read more.
A robust design of a 3D-printed 6–18 GHz double-ridged TEM horn antenna is proposed in this paper. The designed TEM horn antenna has two parts: an adaptor and a horn aperture. The adaptor is realized using a double-ridged waveguide to extend the operating bandwidth of the dominant mode (TE10 mode). Meanwhile, the horn aperture section is implemented in an exponentially tapered configuration to match the impedance of the double-ridged waveguide with the intrinsic impedance. The performance of the initially designed antenna shows that the reflection coefficient and gain levels are less than −13 dB and greater than 5.5 dBi within the 6–18 GHz band, respectively. The initial design was well done, but the noise factors that may occur during the manufacturing process were not taken into account. To design an antenna considering these noise factors, the parameters of the initial design are optimized by a novel robust design method also proposed in this paper. The robustness of the antenna optimized by the proposed method is approximately 12.4% higher than that of the initial antenna. The validity of the proposed method was tested by fabricating the antenna. A prototype of the optimized antenna with the proposed robust design method is fabricated using a 3D printer with a stereolithographic apparatus attached, and the surface of the frame is covered by a nano-silver plating. The measured results of the fabricated antenna are in good agreement with the simulation results over the operating band. The measured −10 dB reflection coefficient bandwidth of the antenna can cover 6–18 GHz. In addition, the measured gain ranges from 4.42 to 10.75 dBi within the 6–18 GHz band. Full article
(This article belongs to the Special Issue 3D Printed Antennas)
Show Figures

Figure 1
