Without a GNSS (global navigation satellite system) signal, the integrated navigation system in vehicles with a fixed trajectory (e.g., railcars) is limited to the use of micro-electromechanical system-inertial navigation system (MEMS-INS) and odometer (ODO). Due to the significant measurement error of the MEMS inertial device and the inability of ODO to output attitude, the positioning error is generally large. To address this problem, this paper presents a new integrated navigation algorithm based on a dynamically constrained Kalman model. By analyzing the dynamics of a railcar, several new observations have been investigated, including errors of up and lateral velocity, centripetal acceleration, centripetal D-value (difference value), and an up-gyro bias. The state transition matrix and observation matrix for the error state model are represented. To improve navigation accuracy, virtual noise technology is applied to correct errors of up and lateral velocity. The vehicle-running experiment conducted within 240 s demonstrates that the positioning error rate of the dead-reckoning method based on MEMS-INS is 83.5%, whereas the proposed method exhibits a rate of 4.9%. Therefore, the accuracy of positioning can be significantly enhanced. Full article

Micro-electro-mechanical system inertial measurement unit (MEMS-IMU), a core component in many navigation systems, directly determines the accuracy of inertial navigation system; however, MEMS-IMU system is often affected by various factors such as environmental noise, electronic noise, mechanical noise and manufacturing error. These can seriously affect the application of MEMS-IMU used in different fields. Focus has been on MEMS gyro since it is an essential and, yet, complex sensor in MEMS-IMU which is very sensitive to noises and errors from the random sources. In this study, recurrent neural networks are hybridized in four different ways for noise reduction and accuracy improvement in MEMS gyro. These are two-layer homogenous recurrent networks built on long short term memory (LSTM-LSTM) and gated recurrent unit (GRU-GRU), respectively; and another two-layer but heterogeneous deep networks built on long short term memory-gated recurrent unit (LSTM-GRU) and a gated recurrent unit-long short term memory (GRU-LSTM). Practical implementation with static and dynamic experiments was carried out for a custom MEMS-IMU to validate the proposed networks, and the results show that GRU-LSTM seems to be overfitting large amount data testing for three-dimensional axis gyro in the static test. However, for X-axis and Y-axis gyro, LSTM-GRU had the best noise reduction effect with over 90% improvement in the three axes. For Z-axis gyroscope, LSTM-GRU performed better than LSTM-LSTM and GRU-GRU in quantization noise and angular random walk, while LSTM-LSTM shows better improvement than both GRU-GRU and LSTM-GRU networks in terms of zero bias stability. In the dynamic experiments, the Hilbert spectrum carried out revealed that time-frequency energy of the LSTM-LSTM, GRU-GRU, and GRU-LSTM denoising are higher compared to LSTM-GRU in terms of the whole frequency domain. Similarly, Allan variance analysis also shows that LSTM-GRU has a better denoising effect than the other networks in the dynamic experiments. Overall, the experimental results demonstrate the effectiveness of deep learning algorithms in MEMS gyro noise reduction, among which LSTM-GRU network shows the best noise reduction effect and great potential for application in the MEMS gyroscope area. Full article

The application of inertial measurement units (IMU) in electronically power-assisted cycles (EPACs) has become increasingly important for improving their functionalities. One central issue of such an application is to calibrate the orientation of the IMU on the EPAC. The approach presented in this paper utilizes common bicycling motions to calibrate the 2D- and 3D-mounting orientation of a micro-electro-mechanical system (MEMS) IMU on an electric bicycle. The method is independent of sensor biases and requires only a very low computation expense and, thus, the estimation can be realized in real-time. In addition, the acceleration biases are estimated using a barometric pressure sensor. The experimental results show high accuracy of the calibrated orientation and estimated sensor biases. Full article

Electronic appliances and ferromagnetic materials can be easily found in any building in urban environment. A steady magnetic environment and a pure value of geomagnetic field for calculating the heading of the smartphone in case of pedestrian walking indoors is hard to obtain. Therefore, an independent inertial heading correction algorithm without involving magnetic field but only making full use of the embedded Micro-Electro-Mechanical System (MEMS) Inertial measurement unit (IMU) device in the smartphone is presented in this paper. Aiming at the strict navigation requirements of pedestrian smartphone positioning, the algorithm focused in this paper consists of Gravity Assisted (GA) and Middle Time Simulated-Zero Velocity Update (MTS-ZUPT) methods. With the help of GA method, the different using-mode of the smartphone can be judged based on the data from the gravity sensor of smartphone. Since there is no zero-velocity status for handheld smartphone, the MTS-ZUPT algorithm is proposed based on the idea of Zero Velocity Update (ZUPT) algorithm. A Kalman Filtering algorithm is used to restrain the heading divergence at the middle moment of two steps. The walking experimental results indicate that the MTS-ZUPT algorithm can effectively restrain the heading error diffusion without the assistance of geomagnetic heading. When the MTS-ZUPT method was integrated with GA method, the smartphone navigation system can autonomously judge the using-mode and compensate the heading errors. The pedestrian positioning accuracy is significantly improved and the walking error is only 1.4% to 2.0% of the walking distance in using-mode experiments of the smartphone. Full article

The correct identification of smartphones has various applications in the field of security or the fight against counterfeiting. As the level of sophistication in counterfeit electronics increases, detection procedures must become more accurate but also not destructive for the smartphone under testing. Some components of the smartphone are more likely to reveal their authenticity even without a physical inspection, since they are characterized by hardware fingerprints detectable by simply examining the data they provide. This is the case of MEMS (Micro Electro-Mechanical Systems) components like accelerometers and gyroscopes, where tiny differences and imprecisions in the manufacturing process determine unique patterns in the data output. In this paper, we present the experimental evaluation of the identification of smartphones through their built-in MEMS components. In our study, three different phones of the same model are subject to repeatable movements (composing a repeatable scenario) using an high precision robotic arm. The measurements from MEMS for each repeatable scenario are collected and analyzed. The identification algorithm is based on the extraction of the statistical features of the collected data for each scenario. The features are used in a support vector machine (SVM) classifier to identify the smartphone. The results of the evaluation are presented for different combinations of features and Inertial Measurement Unit (IMU) outputs, which show that detection accuracy of higher than 90% is achievable. Full article
