Search Results (30)

Search Parameters:
Keywords = MEMS-based LiDAR

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
15 pages, 6406 KiB
Communication
Design and Static Analysis of MEMS-Actuated Silicon Nitride Waveguide Optical Switch
by Yan Xu, Tsen-Hwang Andrew Lin and Peiguang Yan
Micromachines 2025, 16(8), 854; https://doi.org/10.3390/mi16080854 - 25 Jul 2025
Abstract
This article aims to utilize a microelectromechanical system (MEMS) to modulate coupling behavior of silicon nitride (Si3N4) waveguides to perform an optical switch based on a directional coupling (DC) mechanism. There are two states of the switch. First state, [...] Read more.
This article aims to utilize a microelectromechanical system (MEMS) to modulate coupling behavior of silicon nitride (Si3N4) waveguides to perform an optical switch based on a directional coupling (DC) mechanism. There are two states of the switch. First state, a Si3N4 wire is initially positioned up suspended in the air. In the second state, this wire will be moved down to be placed between two arms of the DC waveguides, changing the coupling behavior to achieve bar and cross states of the optical switch function. In the future, the MEMS will be used to move this wire down. In this work, we present simulations of the two static states to optimize the DC structure parameters. Based on the simulated results, the device size is 8.8 μm × 55 μm. The insertion loss is calculated to be approximately 0.24 dB and 0.33 dB, the extinction ratio is approximately 24.70 dB and 25.46 dB, and the crosstalk is approximately −24.60 dB and −25.56 dB, respectively. In the C band of optical communication, the insertion loss ranges from 0.18 dB to 0.47 dB. As such, this device will exhibit excellent optical switch performance and provide advantages in many integrated optics-related optical systems applications. Furthermore, it can be used in optical communications, data centers, LiDAR, and so on, enhancing important reference value for such applications. Full article
Show Figures

Figure 1

14 pages, 3375 KiB
Article
Scanning Mirror Benchmarking Platform Based on Two-Dimensional Position Sensitive Detector and Its Accuracy Analysis
by Hexiang Guo, Junya Wang and Zheng You
Micromachines 2025, 16(3), 348; https://doi.org/10.3390/mi16030348 - 19 Mar 2025
Viewed by 484
Abstract
A MEMS scanning mirror is a beam scanning device based on MEMS technology, which plays an important role in the fields of Lidar, medical imaging, laser projection display, and so on. The accurate measurement of the scanning mirror index can verify its performance [...] Read more.
A MEMS scanning mirror is a beam scanning device based on MEMS technology, which plays an important role in the fields of Lidar, medical imaging, laser projection display, and so on. The accurate measurement of the scanning mirror index can verify its performance and application scenarios. This paper designed and built a scanning mirror benchmark platform based on a two-dimensional position-sensitive detector (PSD), which can accurately measure the deflection angle, resonance frequency, and angular resolution of the scanning mirror, and described the specific test steps of the scanning mirror parameters, which can meet the two-dimensional measurement. Secondly, this paper analyzed and calculated the angular test uncertainty of the designed test system. After considering the actual optical alignment error and PSD measurement error, when the distance between the PSD and MEMS scanning mirror is 100 mm, the range of mechanical deflection angle that can be measured is (−6.34°, +6.34°). When the mechanical deflection angle of the scanning mirror is 0.01°, the accuracy measured by the test system is 0.00097°, and when the mechanical deflection of the scanning mirror is 6.34°, the accuracy measured by the test system is 0.011°. The test platform has high accuracy and can measure the parameters of the scanning mirror accurately. Full article
Show Figures

Figure 1

13 pages, 5299 KiB
Article
Modeling and Implementation of Synchronization for Large-Aperture Electromagnetic MEMS Mirrors
by Fahu Xu and Lingxiao Zhao
Micromachines 2025, 16(3), 268; https://doi.org/10.3390/mi16030268 - 26 Feb 2025
Cited by 1 | Viewed by 539
Abstract
MEMS-based LiDAR has showcased extensive application potential in the autonomous driving sector, attributed to its cost-effectiveness, compactness, and seamless integration capabilities. However, MEMS LiDAR suffers from a short detection range, due to the small receiving aperture of the MEMS mirror. Our early study [...] Read more.
MEMS-based LiDAR has showcased extensive application potential in the autonomous driving sector, attributed to its cost-effectiveness, compactness, and seamless integration capabilities. However, MEMS LiDAR suffers from a short detection range, due to the small receiving aperture of the MEMS mirror. Our early study attempted to increase the detection range of MEMS LiDAR with a semi-coaxial design. In this paper, we further investigate the synchronization method for large-aperture electromagnetic MEMS mirrors, in which a synchronous motion transfer model of electromagnetic MEMS mirrors is constructed. The results of the simulations and experiments demonstrate that two electromagnetic MEMS mirrors are synchronous with an aperture of 60 π mm2, FoV of 60°, and scanning frequency of 220 Hz. The entire synchronization process of the electromagnetic MEMS mirrors is completed within 10 s, which verifies the feasibility of synchronizing large-aperture electromagnetic MEMS mirrors to increase the detection range of MEMS LiDAR. Full article
(This article belongs to the Special Issue Recent Advances in MEMS Mirrors)
Show Figures

Figure 1

24 pages, 13744 KiB
Article
When-to-Loop: Enhanced Loop Closure for LiDAR SLAM in Urban Environments Based on SCAN CONTEXT
by Xu Xu, Lianwu Guan, Jianhui Zeng, Yunlong Sun, Yanbin Gao and Qiang Li
Micromachines 2024, 15(10), 1212; https://doi.org/10.3390/mi15101212 - 29 Sep 2024
Cited by 1 | Viewed by 4561
Abstract
Global Navigation Satellite Systems (GNSSs) frequently encounter challenges in providing reliable navigation and positioning within urban canyons due to signal obstruction. Micro-Electro-Mechanical System (MEMS) Inertial Measurement Units (IMUs) offers an alternative for autonomous navigation, but they are susceptible to accumulating errors. To mitigate [...] Read more.
Global Navigation Satellite Systems (GNSSs) frequently encounter challenges in providing reliable navigation and positioning within urban canyons due to signal obstruction. Micro-Electro-Mechanical System (MEMS) Inertial Measurement Units (IMUs) offers an alternative for autonomous navigation, but they are susceptible to accumulating errors. To mitigate these influences, a LiDAR-based Simultaneous Localization and Mapping (SLAM) system is often employed. However, these systems face challenges in drift and error accumulation over time. This paper presents a novel approach to loop closure detection within LiDAR-based SLAM, focusing on the identification of previously visited locations to correct time-accumulated errors. Specifically, the proposed method leverages the vehicular drivable area and IMU trajectory to identify significant environmental changes in keyframe selection. This approach differs from conventional methods that only rely on distance or time intervals. Furthermore, the proposed method extends the SCAN CONTEXT algorithm. This technique incorporates the overall distribution of point clouds within a region rather than solely relying on maximum height to establish more robust loop closure constraints. Finally, the effectiveness of the proposed method is validated through experiments conducted on the KITTI dataset with an enhanced accuracy of 6%, and the local scenarios exhibit a remarkable improvement in accuracy of 17%, demonstrating improved robustness in loop closure detection for LiDAR-based SLAM. Full article
Show Figures

Figure 1

25 pages, 17785 KiB
Article
Compressing and Recovering Short-Range MEMS-Based LiDAR Point Clouds Based on Adaptive Clustered Compressive Sensing and Application to 3D Rock Fragment Surface Point Clouds
by Lin Li, Huajun Wang and Sen Wang
Sensors 2024, 24(17), 5695; https://doi.org/10.3390/s24175695 - 1 Sep 2024
Viewed by 4976
Abstract
Short-range MEMS-based (Micro Electronical Mechanical System) LiDAR provides precise point cloud datasets for rock fragment surfaces. However, there is more vibrational noise in MEMS-based LiDAR signals, which cannot guarantee that the reconstructed point cloud data are not distorted with a high compression ratio. [...] Read more.
Short-range MEMS-based (Micro Electronical Mechanical System) LiDAR provides precise point cloud datasets for rock fragment surfaces. However, there is more vibrational noise in MEMS-based LiDAR signals, which cannot guarantee that the reconstructed point cloud data are not distorted with a high compression ratio. Many studies have illustrated that wavelet-based clustered compressive sensing can improve reconstruction precision. The k-means clustering algorithm can be conveniently employed to obtain clusters; however, estimating a meaningful k value (i.e., the number of clusters) is challenging. An excessive quantity of clusters is not necessary for dense point clouds, as this leads to elevated consumption of memory and CPU resources. For sparser point clouds, fewer clusters lead to more distortions, while excessive clusters lead to more voids in reconstructed point clouds. This study proposes a local clustering method to determine a number of clusters closer to the actual number based on GMM (Gaussian Mixture Model) observation distances and density peaks. Experimental results illustrate that the estimated number of clusters is closer to the actual number in four datasets from the KEEL public repository. In point cloud compression and recovery experiments, our proposed approach compresses and recovers the Bunny and Armadillo datasets in the Stanford 3D repository; the experimental results illustrate that our proposed approach improves reconstructed point clouds’ geometry and curvature similarity. Furthermore, the geometric similarity increases to 0.9 above in our complete rock fragment surface datasets after selecting a better wavelet basis for each dimension of MEMS-based LiDAR signals. In both experiments, the sparsity of signals was 0.8 and the sampling ratio was 0.4. Finally, a rock outcrop point cloud data experiment is utilized to verify that the proposed approach is applicable for large-scale research objects. All of our experiments illustrate that the proposed adaptive clustered compressive sensing approach can better reconstruct MEMS-based LiDAR point clouds with a lower sampling ratio. Full article
(This article belongs to the Special Issue Short-Range Optical 3D Scanning and 3D Data Processing)
Show Figures

Figure 1

17 pages, 5535 KiB
Article
Responsiveness and Precision of Digital IMUs under Linear and Curvilinear Motion Conditions for Local Navigation and Positioning in Advanced Smart Mobility
by Luciano Chiominto, Emanuela Natale, Giulio D’Emilia, Sante Alessandro Grieco, Andrea Prato, Alessio Facello and Alessandro Schiavi
Micromachines 2024, 15(6), 727; https://doi.org/10.3390/mi15060727 - 30 May 2024
Cited by 3 | Viewed by 3579
Abstract
Sensors based on MEMS technology, in particular Inertial Measurement Units (IMUs), when installed on vehicles, provide a real-time full estimation of vehicles’ state vector (e.g., position, velocity, yaw angle, angular rate, acceleration), which is required for the planning and control of cars’ trajectories, [...] Read more.
Sensors based on MEMS technology, in particular Inertial Measurement Units (IMUs), when installed on vehicles, provide a real-time full estimation of vehicles’ state vector (e.g., position, velocity, yaw angle, angular rate, acceleration), which is required for the planning and control of cars’ trajectories, as well as managing the in-car local navigation and positioning tasks. Moreover, data provided by the IMUs, integrated with the data of multiple inputs from other sensing systems (such as Lidar, cameras, and GPS) within the vehicle, and with the surrounding information exchanged in real time (vehicle to vehicle, vehicle to infrastructure, or vehicle to other entities), can be exploited to actualize the full implementation of “smart mobility” on a large scale. On the other hand, “smart mobility” (which is expected to improve road safety, reduce traffic congestion and environmental burden, and enhance the sustainability of mobility as a whole), to be safe and functional on a large scale, should be supported by highly accurate and trustworthy technologies based on precise and reliable sensors and systems. It is known that the accuracy and precision of data supplied by appropriately in-lab-calibrated IMUs (with respect to the primary or secondary standard in order to provide traceability to the International System of Units) allow guaranteeing high quality, reliable information managed by processing systems, since they are reproducible, repeatable, and traceable. In this work, the effective responsiveness and the related precision of digital IMUs, under sinusoidal linear and curvilinear motion conditions at 5 Hz, 10 Hz, and 20 Hz, are investigated on the basis of metrological approaches in laboratory standard conditions only. As a first step, in-lab calibrations allow one to reduce the variables of uncontrolled boundary conditions (e.g., occurring in vehicles in on-site tests) in order to identify the IMUs’ sensitivity in a stable and reproducible environment. For this purpose, a new calibration system, based on an oscillating rotating table was developed to reproduce the dynamic conditions of use in the field, and the results are compared with calibration data obtained on linear calibration benches. Full article
Show Figures

Figure 1

3 pages, 785 KiB
Abstract
Optical System Design and Characterization of MEMS Mirror-Based SPAD LiDAR System for Smart Factory Applications
by Jeong-Yeon Hwang, Paul Raschdorf, Andre Henschke, Manuel Ligges, Sara Weyer and Shanshan Gu-Stoppel
Proceedings 2024, 97(1), 112; https://doi.org/10.3390/proceedings2024097112 - 28 Mar 2024
Viewed by 1155
Abstract
This paper presents the optical system design for the MEMS mirror-based SPAD LiDAR system. The transmitter of the proposed LiDAR system consists of related optics for incident beam expansion and a piezoelectric MEMS mirror for a wide-scanning field of view. For the receiver [...] Read more.
This paper presents the optical system design for the MEMS mirror-based SPAD LiDAR system. The transmitter of the proposed LiDAR system consists of related optics for incident beam expansion and a piezoelectric MEMS mirror for a wide-scanning field of view. For the receiver unit, an SPAD array is utilized to collect the laser beam reflected from the target objects at a smart factory. The optical system of the proposed LiDAR system is presented, designed, and analyzed in various ways. Full article
(This article belongs to the Proceedings of XXXV EUROSENSORS Conference)
Show Figures

Figure 1

11 pages, 3889 KiB
Article
New Scheme of MEMS-Based LiDAR by Synchronized Dual-Laser Beams for Detection Range Enhancement
by Chien-Wei Huang, Chun-Nien Liu, Sheng-Chuan Mao, Wan-Shao Tsai, Zingway Pei, Charles W. Tu and Wood-Hi Cheng
Sensors 2024, 24(6), 1897; https://doi.org/10.3390/s24061897 - 15 Mar 2024
Cited by 1 | Viewed by 2374
Abstract
A new scheme presents MEMS-based LiDAR with synchronized dual-laser beams for detection range enhancement and precise point-cloud data without using higher laser power. The novel MEMS-based LiDAR module uses the principal laser light to build point-cloud data. In addition, an auxiliary laser light [...] Read more.
A new scheme presents MEMS-based LiDAR with synchronized dual-laser beams for detection range enhancement and precise point-cloud data without using higher laser power. The novel MEMS-based LiDAR module uses the principal laser light to build point-cloud data. In addition, an auxiliary laser light amplifies the single-noise ratio to enhance the detection range. This LiDAR module exhibits the field of view (FOV), angular resolution, and maximum detection distance of 45° (H) × 25° (V), 0.11° (H) × 0.11° (V), and 124 m, respectively. The maximum detection distance is enhanced by 16% from 107 m to 124 m with a laser power of 1 W and an additional auxiliary laser power of 0.355 W. Furthermore, the simulation results show that the maximum detection distance can be up to 300 m with laser power of 8 W and only 6 W if the auxiliary laser light of 2.84 W is used, which is 35.5% of the laser power. This result indicates that the synchronized dual-laser beams can achieve long detection distance and reduce laser power 30%, hence saving on the overall laser system costs. Therefore, the proposed LiDAR module can be applied for a long detection range in autonomous vehicles without requiring higher laser power if it utilizes an auxiliary laser light. Full article
(This article belongs to the Special Issue Multi-modal Sensor Fusion and 3D LiDARs for Vehicle Applications)
Show Figures

Figure 1

18 pages, 5754 KiB
Article
Method for Estimating Road Impulse Ahead of Vehicles in Urban Environment with Microelectromechanical System Three-Dimensional Sensor
by Shijie Zhao, Minghao Wang, Pengyu Wang, Yang Wang and Konghui Guo
Sensors 2024, 24(4), 1192; https://doi.org/10.3390/s24041192 - 11 Feb 2024
Cited by 1 | Viewed by 1474
Abstract
Most automated vehicles (AVs) are equipped with abundant sensors, which enable AVs to improve ride comfort by sensing road elevation, such as speed bumps. This paper proposes a method for estimating the road impulse features ahead of vehicles in urban environments with microelectromechanical [...] Read more.
Most automated vehicles (AVs) are equipped with abundant sensors, which enable AVs to improve ride comfort by sensing road elevation, such as speed bumps. This paper proposes a method for estimating the road impulse features ahead of vehicles in urban environments with microelectromechanical system (MEMS) light detection and ranging (LiDAR). The proposed method deploys a real-time estimation of the vehicle pose to solve the problem of sparse sampling of the LiDAR. Considering the LiDAR error model, the proposed method builds the grid height measurement model by maximum likelihood estimation. Moreover, it incorporates height measurements with the LiDAR error model by the Kalman filter and introduces motion uncertainty to form an elevation weight method by confidence eclipse. In addition, a gate strategy based on the Mahalanobis distance is integrated to handle the sharp changes in elevation. The proposed method is tested in the urban environment. The results demonstrate the effectiveness of our method. Full article
(This article belongs to the Section Radar Sensors)
Show Figures

Figure 1

18 pages, 19415 KiB
Article
A Fast Registration Method for MEMS LiDAR Point Cloud Based on Self-Adaptive Segmentation
by Xuemei Li, Bin Liu, Shangsong Lv, Min Li and Chengjie Liu
Electronics 2023, 12(19), 4006; https://doi.org/10.3390/electronics12194006 - 23 Sep 2023
Viewed by 1606
Abstract
The Micro-Electro-Mechanical System (MEMS) LiDAR point cloud in autonomous vehicles has a large deflection range, which results in slow registration speed and poor applicability. To maximize speed, an improved Normal Distribution Transform (NDT) method that integrates point cloud density features has been proposed. [...] Read more.
The Micro-Electro-Mechanical System (MEMS) LiDAR point cloud in autonomous vehicles has a large deflection range, which results in slow registration speed and poor applicability. To maximize speed, an improved Normal Distribution Transform (NDT) method that integrates point cloud density features has been proposed. First, the point cloud is reduced using a modified voxel filter and a pass-through filter. Next, the Intrinsic Shape Signature (ISS) algorithm is utilized to analyze the point cloud features and extract key points; the Four-Point Congruent Set (4PCS) algorithm is then employed to calculate the initial pose under the constraints of the key point set to complete the coarse registration. Finally, the self-adaptive segmentation model is constructed by using a K-D tree to obtain the density features of key points, and the NDT algorithm is combined with this model to form an SSM-NDT algorithm, which is used for fine registration. Each algorithm was compared on the autonomous vehicle dataset PandaSet and actual collected datasets. The results show that the novel method increases the speed by at least 60% and takes into account good registration accuracy and strong anti-interference. Full article
(This article belongs to the Section Electrical and Autonomous Vehicles)
Show Figures

Figure 1

13 pages, 11223 KiB
Article
Biaxial Piezoelectric MEMS Mirrors with Low Absorption Coating for 1550 nm Long-Range LIDAR
by L. Mollard, J. Riu, S. Royo, C. Dieppedale, A. Hamelin, A. Koumela, T. Verdot, L. Frey, G. Le Rhun, G. Castellan and C. Licitra
Micromachines 2023, 14(5), 1019; https://doi.org/10.3390/mi14051019 - 9 May 2023
Cited by 8 | Viewed by 2575
Abstract
This paper presents the fabrication and characterization of a biaxial MEMS (MicroElectroMechanical System) scanner based on PZT (Lead Zirconate Titanate) which incorporates a low-absorption dielectric multilayer coating, i.e., a Bragg reflector. These 2 mm square MEMS mirrors, developed on 8-inch silicon wafers using [...] Read more.
This paper presents the fabrication and characterization of a biaxial MEMS (MicroElectroMechanical System) scanner based on PZT (Lead Zirconate Titanate) which incorporates a low-absorption dielectric multilayer coating, i.e., a Bragg reflector. These 2 mm square MEMS mirrors, developed on 8-inch silicon wafers using VLSI (Very Large Scale Integration) technology are intended for long-range (>100 m) LIDAR (LIght Detection And Ranging) applications using a 2 W (average power) pulsed laser at 1550 nm. For this laser power, the use of a standard metal reflector leads to damaging overheating. To solve this problem, we have developed and optimised a physical sputtering (PVD) Bragg reflector deposition process compatible with our sol-gel piezoelectric motor. Experimental absorption measurements, performed at 1550 nm and show up to 24 times lower incident power absorption than the best metallic reflective coating (Au). Furthermore, we validated that the characteristics of the PZT, as well as the performance of the Bragg mirrors in terms of optical scanning angles, were identical to those of the Au reflector. These results open up the possibility of increasing the laser power beyond 2W for LIDAR applications or other applications requiring high optical power. Finally, a packaged 2D scanner was integrated into a LIDAR system and three-dimensional point cloud images were obtained, demonstrating the scanning stability and operability of these 2D MEMS mirrors. Full article
Show Figures

Figure 1

26 pages, 11430 KiB
Article
Performance Evaluation of MEMS-Based Automotive LiDAR Sensor and Its Simulation Model as per ASTM E3125-17 Standard
by Arsalan Haider, Yongjae Cho, Marcell Pigniczki, Michael H. Köhler, Lukas Haas, Ludwig Kastner, Maximilian Fink, Michael Schardt, Yannik Cichy, Shotaro Koyama, Thomas Zeh, Tim Poguntke, Hideo Inoue, Martin Jakobi and Alexander W. Koch
Sensors 2023, 23(6), 3113; https://doi.org/10.3390/s23063113 - 14 Mar 2023
Cited by 10 | Viewed by 5538
Abstract
Measurement performance evaluation of real and virtual automotive light detection and ranging (LiDAR) sensors is an active area of research. However, no commonly accepted automotive standards, metrics, or criteria exist to evaluate their measurement performance. ASTM International released the ASTM E3125-17 standard for [...] Read more.
Measurement performance evaluation of real and virtual automotive light detection and ranging (LiDAR) sensors is an active area of research. However, no commonly accepted automotive standards, metrics, or criteria exist to evaluate their measurement performance. ASTM International released the ASTM E3125-17 standard for the operational performance evaluation of 3D imaging systems commonly referred to as terrestrial laser scanners (TLS). This standard defines the specifications and static test procedures to evaluate the 3D imaging and point-to-point distance measurement performance of TLS. In this work, we have assessed the 3D imaging and point-to-point distance estimation performance of a commercial micro-electro-mechanical system (MEMS)-based automotive LiDAR sensor and its simulation model according to the test procedures defined in this standard. The static tests were performed in a laboratory environment. In addition, a subset of static tests was also performed at the proving ground in natural environmental conditions to determine the 3D imaging and point-to-point distance measurement performance of the real LiDAR sensor. In addition, real scenarios and environmental conditions were replicated in the virtual environment of a commercial software to verify the LiDAR model’s working performance. The evaluation results show that the LiDAR sensor and its simulation model under analysis pass all the tests specified in the ASTM E3125-17 standard. This standard helps to understand whether sensor measurement errors are due to internal or external influences. We have also shown that the 3D imaging and point-to-point distance estimation performance of LiDAR sensors significantly impacts the working performance of the object recognition algorithm. That is why this standard can be beneficial in validating automotive real and virtual LiDAR sensors, at least in the early stage of development. Furthermore, the simulation and real measurements show good agreement on the point cloud and object recognition levels. Full article
(This article belongs to the Special Issue Feature Papers in Optical Sensors 2023)
Show Figures

Figure 1

10 pages, 4746 KiB
Article
Optical Enhancement of Diffraction Efficiency of Texas Instruments Phase Light Modulator for Beam Steering in Near Infrared
by Jiafan Guan, Zhipeng Dong, Xianyue Deng and Yuzuru Takashima
Micromachines 2022, 13(9), 1393; https://doi.org/10.3390/mi13091393 - 26 Aug 2022
Cited by 2 | Viewed by 2609
Abstract
Phase light modulator (PLM) by MEMS mirror array operating in a piston-mode motion enables a high-speed diffractive beam steering in a random-access and flexible manner that makes a lidar system more intelligent and adaptive. Diffraction efficiency is determined by the range of the [...] Read more.
Phase light modulator (PLM) by MEMS mirror array operating in a piston-mode motion enables a high-speed diffractive beam steering in a random-access and flexible manner that makes a lidar system more intelligent and adaptive. Diffraction efficiency is determined by the range of the piston motion of the MEMS array; consequently, a larger range of the piston motion is required for beam steering in infrared, such as for lidar. We demonstrated how the range of the piston motion is optically enhanced by a factor of two with a light-recycling optics based on Talbot self-imaging. The proposed optical architecture extends the usable range of the wavelength so that a MEMS-PLM designed for visible wavelength is applicable for a high-efficiency beam steering at an infrared wavelength of 1550 nm with an improved diffraction efficiency of 30%. Full article
(This article belongs to the Special Issue Beam Steering via Arrayed Micromachines)
Show Figures

Figure 1

13 pages, 5019 KiB
Article
Piezoelectric MEMS Mirror with Lissajous Scanning for Automobile Adaptive Laser Headlights
by Bin Xu, Yao Ji, Kai Liu and Jinhua Li
Micromachines 2022, 13(7), 996; https://doi.org/10.3390/mi13070996 - 25 Jun 2022
Cited by 11 | Viewed by 4851
Abstract
The emergence of smart headlights with reconfigurable light distributions that provide optimal illumination, highlight road objects, and project symbols to communicate with traffic participants further enhances road safety. Integrating all these functions in a single headlight usually suffers from issues of bulky multi-functional [...] Read more.
The emergence of smart headlights with reconfigurable light distributions that provide optimal illumination, highlight road objects, and project symbols to communicate with traffic participants further enhances road safety. Integrating all these functions in a single headlight usually suffers from issues of bulky multi-functional add-on modules with high cost or the use of conventional spatial light modulators with low optical efficiency and complex thermal design requirements. This paper presents a novel laser headlight prototype based on biaxially resonant microelectromechanical systems (MEMS) mirror light modulator for mapping blue laser patterns on phosphor plate to create structured white illumination and tunable road projection. The proposed headlight prototype system enables reconfigurable light distribution by leveraging laser beam scanning with fewer back-end lens and simple thermal design requirements. Built with thin-film lead zirconate titanate oxide (PbZrTiO3) actuators, the MEMS mirror achieved high-frequency biaxial resonance of 17.328 kHz, 4.81 kHz, and optical scan angle of 12.9°. The large mirror design of 2.0 mm facilitates more refined resolvable projection pixels, delivers more optical power, and provides moderate optical aperture to possibly serve as the common spatial light modulator of headlight and the light detection and ranging (LiDAR) towards all-in-one integration. The carefully designed bi-axial resonant frequency improves the device’s robustness by offsetting the lowest eigenmode away from the vehicle vibration. By establishing the laser headlight prototype systems of both 1D and 2D scanning modes, a mathematical model of laser modulation and MEMS electrical control principles of Lissajous scanning are proposed to tune the projection pattern density and shapes. It laid the foundation for developing a laser scanning control system with more complex project functions and prompting the application of MEMS for compact headlight system that addresses night driving visibility, eliminates glare effect, and renders interactive projection capabilities. Full article
(This article belongs to the Section A:Physics)
Show Figures

Figure 1

11 pages, 1807 KiB
Article
Reconfigurable Angular Resolution Design Method in a Separate-Axis Lissajous Scanning MEMS LiDAR System
by Fahu Xu, Dayong Qiao, Changfeng Xia, Xiumin Song, Wenhui Zheng, Yaojun He and Qiaodan Fan
Micromachines 2022, 13(3), 353; https://doi.org/10.3390/mi13030353 - 23 Feb 2022
Cited by 8 | Viewed by 2868
Abstract
MEMS-based LiDAR with a low cost and small volume is a promising solution for 3D measurement. In this paper, a reconfigurable angular resolution design method is proposed in a separate-axis Lissajous scanning MEMS LiDAR system. This design method reveals the influence factors on [...] Read more.
MEMS-based LiDAR with a low cost and small volume is a promising solution for 3D measurement. In this paper, a reconfigurable angular resolution design method is proposed in a separate-axis Lissajous scanning MEMS LiDAR system. This design method reveals the influence factors on the angular resolution, including the characteristics of the MEMS mirrors, the laser duty cycle and pulse width, the processing time of the echo signal, the control precision of the MEMS mirror, and the laser divergence angle. A simulation was carried out to show which conditions are required to obtain different angular resolutions. The experimental results of the 0.2° × 0.62° and 0.2° × 0.15° (horizontal × vertical) angular resolutions demonstrate the feasibility of the design method to realize a reconfigurable angular resolution in a separate-axis Lissajous scanning MEMS LiDAR system by employing MEMS mirrors with different characteristics. This study provides a reasonable potential to obtain a high and flexible angular resolution for MEMS LiDAR. Full article
(This article belongs to the Special Issue Optical MEMS, Volume III)
Show Figures

Figure 1
