This study addresses inlet flow distribution and pressure pulsation-induced vibration in LNG dual-pump parallel systems. We investigate an LNG dual-submerged pump tower system. Our approach combines computational fluid dynamics with vortex dynamics theory. We examine inlet flow characteristics under different flow conditions. Pressure pulsation propagation patterns are analyzed. System stability mechanisms are investigated. A 3D model incorporates inducers, impellers, guide vanes, outlet sections, and base structures. The SST k-ω turbulence model and Q-criterion vortex identification reveal key features. Results show minimal head differences during parallel operation. The inlet flow field remains uniform without significant vortices. However, local low-velocity zones beneath the base may cause flow separation at low flows. Pressure pulsations are governed by guide vane rotor–stator interactions. These disturbances propagate backward to impellers and inducers. Outlet sections show asymmetric pressure fluctuations. This asymmetry results from spatial positioning differences. Complex base geometries generate low-intensity vortices. Vortex intensity stabilizes at higher flows. These findings provide theoretical foundations for vibration suppression. Full article

In the winter, a certain LNG receiving terminal operates exclusively with the submerged combustion vaporizer (SCV). However, due to the high operational costs associated with the SCV, a new combined operation scheme utilizing both the SCV and the open rack vaporizer (ORV) has been proposed. First, models for the SCV and ORV gasification units were developed in Aspen HYSYS and validated using actual operational parameters. Next, the relationship between the seawater inlet–outlet temperature difference and the minimum seawater flow rate for the ORV was determined, and an optimized seawater pump operation strategy, considering LNG export volumes, was formulated. Additionally, the relationship between the SCV fuel gas flow rate and LNG export volume was analyzed, and a comparison was made between the operating costs of SCV running independently and the combined SCV-ORV operation under winter conditions. The results of the combined operation experiments indicated that at a seawater inlet–outlet temperature difference of 3 °C, the joint operation mode could save costs by 70–77%; at 2.5 °C difference, it saves 60–67%; at 2 °C difference, it saves 45–50%; at 1.5 °C difference, it saves 35–38%; and at 1 °C difference, it saves 20–23%. This approach achieves optimized economic performance for LNG terminal operations. Full article

In today’s competitive industrial landscape, Reliability Engineering plays a vital role in minimizing costs and expenses in energy projects. The main focus of this paper is to propose the integration of a fuzzy-based FMECA process into a RAM analysis to assess modernization and reconfiguration strategies for LNG facilities. This approach estimates, through a systematic procedure, the system’s failure probabilities and gauges the impact of various maintenance and topological modification initiatives on the asset and the system’s availability as a driver of profitability. A methodology based on fuzzy-FMEA is proposed to collect and process imprecise data about reliability and maintainability of the components of the facility. Furthermore, Monte Carlo-based RAM experiments are performed. The selection of parameters for conducting Monte Carlo experiments is done after the defuzzification of MTBF and MTTR values defined in the FMEA stage. The proposed procedure allows for the prediction of the system’s reliability across hypothetical scenarios, incorporating design tweaks and potential improvements. As a case study, the proposed was applied to a Pumping and Vaporization facility in a Chilean LNG plant. Sensitivity analysis was performed on critical elements, leading to an optimization strategy for key components like Open Rack Vaporizers (ORV) and Submerged Combustion Vaporizers (SCV). The anticipated availability rate was found to be 99.95% over an 8760 h operating period. Final conclusions and managerial insights are discussed. Full article

This paper presents a design study focusing on the thermal safety of an induction motor integrated with a pump unit, which operates submerged in liquefied natural gas (LNG) in the LNG tanks of LNG carrier ships ranging from 150 K to 200 K cubic meters (CBM). In this study, we carried out the electromagnetic design of the induction motor and verified the thermal safety against a temperature increase due to losses during the motor operation through thermal fluid analysis, taking into account the discharge flow of the emergency pump and the air gap of the motor. In the electromagnetic design, the resistivity of the stator winding copper conductors and the rotor aluminum bars, which act as important design constants for the rated operating and starting characteristics of the induction motor in cryogenic temperature environments, reflects the characteristic of linearly changing with the temperature. In cryogenic environments, the reduction in the resistance of the rotor bars of the induction motor leads to a decrease in the starting torque characteristics. Therefore, the shape optimization design of the rotor bar was performed to improve the starting torque characteristics, and 2D electromagnetic analysis was performed on the magnetic flux density distribution and magnetic saturation using Ansys Electromagnetics 16.0. After the electromagnetic design, a 3D thermal flow analysis was conducted using Ansys Fluent 17.0, considering the stator iron losses, rotor bar losses, stator and rotor iron losses, and stray load losses as heat sources. The flow analysis aimed to analytically verify the thermal safety concerning the vaporization of the LNG flowing through the emergency pump’s discharge flow path and the motor’s internal air gap. The motor was manufactured, and the rated and starting operating characteristics of the motor were measured under LN2 submerged conditions according to the IEEE 112 F1 method, to validate whether the performance characteristics met the specifications’ requirements. Subsequently, the thermal safety of the motor was finally verified through a temperature increase test under LNG submerged conditions after assembling it with the emergency pump. Full article

This paper focuses on improving the operating efficiency of the Liquified Natural Gas (LNG) submerged pump system in the LNG receiving terminals and achieve energy saving. The minimum input energy consumption of the LNG submerged pump system is taken as the objective function, and an optimization model for the operation of the LNG submerged pump system with variable frequency speed is established. LINGO18.0 optimization software is used to solve the model to get the optimal LNG submerged pump operation plan that satisfies the constraints. Taking a certain LNG receiving terminal as an example, the operation optimization of its LNG submerged pump system is carried out, and the input energy consumption of the system before and after optimization is compared. The results show that the use of variable frequency pumps can reduce the energy consumption of the LNG submerged pump system of LNG receiving terminals, and the optimization model can reduce the input power consumption of the system by about 10% under different transportation conditions. After applying the optimization model to actual production, it is found that the model has certain practicability for guiding the production of LNG receiving terminal. Full article

Based on CFD analysis technology, this paper studies the cavitation performance of an LNG submerged pump and the pressure pulsation characteristics under cavitation excitation. The variation laws of the waveform, amplitude and frequency of the pressure pulsation in the impeller of the LNG submerged pump under different flow rates and NPSH_a are also analysed. By calculating the root mean square of the pressure coefficient of the low-frequency pulsation, the influence of the aggravation process of cavitation on the low-frequency pulsation in the LNG submerged pump is quantitatively analysed, and the characteristics of the pressure pulsation in the LNG submerged pump under the cavitation condition are revealed. The results show that with the increase in flow rate, the pressure pulsation in the impeller becomes stronger, periodically, and the amplitude decreases. The influence of cavitation on the pressure pulsation in the primary impeller is greater than that in the secondary impeller. When critical cavitation occurs, the low-frequency signal amplitude of pressure pulsation in the primary impeller increases and exceeds the blade frequency, becoming the main frequency. Full article

Tank heel minimization is a significant issue in the design of LNG fuel tanks because it is associated with stable suction pump operation and thermal shock requirements during LNG bunkering. This study examined how the LNG tank heel is minimized, maintaining a suction pump fully submerged in LNG during dynamic vessel motion. The study assumed two LNG fuel tanks mounted on the forward deck of a 50,000 deadweight class oil product carrier. Information on the dimensions and shape of the LNG fuel tank was determined from Wartsila’s brochure, and the specifications of Vanzetti’s suction pump were referred to. The LNG fuel tank and LNG heel were modeled as rigid elements and hydrodynamically smoothed-particles, respectively. The number of particles could be determined by performing even keel analyzes by adding or subtracting particles until the target head was satisfied under the gravity load. To simulate the motion of the LNG fuel tank, the pitch and roll periods and amplitudes of the ship were calculated using the DNV classification rules. Visual observations of the dynamic flow during the pitch and roll motions with respect to the ship’s center of mass showed that the roll motion was more critical from the viewpoint of the LNG heel than the pitch motion. After performing the simulations for three cycles of roll and pitch motions, the suction pump submergence was reviewed in the last cycle. Under the conditions assumed in this study, a filling ratio of 15% was determined as the minimum LNG tank heel. Although the LNG heel has customarily been determined, the LNG heel needs to be determined through hydrodynamic analyses of each vessel because it depends on the shape of the fuel tank and the vessel motion characteristics. Full article
