Offshore wind power has attracted significant attention due to its high potential, capability for large-scale farms, and high capacity factor. However, it faces high investment costs and issues with subsea power transmission. Conventional high-voltage AC (HVAC) methods are limited by charging current, while high-voltage DC (HVDC) methods suffer from the high cost of power conversion stations. The low-frequency AC (LFAC) method mitigates the charging current through low-frequency operation and can reduce power conversion station costs. This paper aims to identify the economically optimal frequency by comparing the investment costs of LFAC systems at various frequencies. The components of LFAC, including transformers, offshore platforms, and cables, exhibit frequency-dependent characteristics. Lower frequencies result in an increased size and volume of transformers, leading to higher investment costs for offshore platforms. In contrast, cable charging currents and losses are proportional to frequency, causing the total cost to reach a minimum at a specific frequency. To determine the optimal frequency, simulations of investment costs for varying capacities and distances were conducted. Full article

In this paper, a new multifunctional compound, 1,1′-(oxalylbis(4,1-phenylene))bis(1H-pyrrole-2,5-dione) (BVM), is grafted onto crosslinked polyethylene (XLPE) by radical-initiated grafting to play triple roles as a voltage stabilizer, space-charge inhibitor and crosslinking auxiliary and to achieve the purpose of comprehensively enhancing the DC dielectric properties of polymers while decreasing the type and number of additives. By analyzing the DC breakdown field strength, current density and space-charge distribution of the materials at different temperatures, it is demonstrated that BVM grafting can comprehensively and effectively enhance the electrical properties of the materials, with little dependence on temperature. The BVM molecule has two polar groups and an effective molecular structure that acts as a voltage stabilizer, thus enabling the introduction of dense, uniform, deeply trapped energy levels within the material to inhibit the space charge and to capture high-energy electrons to prevent damage to the material structure; however, the two functions do not affect each other. This is also consistent with first-principles calculations and quantum-chemical calculations. Gel content testing shows no effect on polymer crosslinking, even with a 27.8% reduction in the amount of the crosslinking agent di-isopropyl peroxide (DCP), which reduces the damage to the polymer’s electrical resistance caused by the byproducts of DCP decomposition. Therefore, grafting multifunctional BVM compounds to improve the dielectric characteristics of polymers is a viable area of study in the development of high-voltage direct current (HVDC) cable materials. Full article

High Voltage Direct Current power links are usually designed to adopt, on a continuous basis or during emergency operations, two grounding plants using the soil or seawater as a link–current return path. Such DCs flowing into the ground can cause problems, of which one of the most important is the increased risk of the corrosion of metallic structures in the area. Normally, the simplest mitigation technique is to keep an adequate distance between the main grounding plants and any metallic structure that can be corroded. Normally, such distances are not less than 5 km. However, there are situations where this approach cannot be applied, for example due to geographical constraints. In this paper, we describe and analyze the behavior of a mitigation technique that can be adopted when the HV pole cable is laid closer than the recommended distance to the main ground electrode. This paper is focused on the minimization of deleterious effects on the cable’s metallic sheath and its earthing points, distributed along it by means of sheath segmentation. The suggested approach appears well-suited to substantially diminishing the current flowing through the sheath of an HVDC power cable. In the segmented scenario, the sheath’s power dissipation is less than one-hundredth of that in the typical continuous configuration. Full article

To enhance the direct current (DC) dielectric properties of cross-linked polyethylene (XLPE) for high-voltage (HV) cable insulation, the polyethylene molecular chain is modified by grafting bismaleimide ethane (BMIE), which creates carrier deep traps within the polymer material. Compared to the traditional modified molecule maleic anhydride (MAH), BMIE has a significantly higher boiling point than the production temperature of XLPE. Additionally, it does not release bubbles during the production process and, thus, preserves the dielectric properties. It was proved by infrared spectroscopy and a gel content test that BMIE was successfully grafted onto the polyethylene molecular chain and had no effect on the crosslinking degree of the polymer while reducing the amount of crosslinker, thereby reducing the influence of the by-products of the decomposition of dicumene peroxide (DCP) on the electrical resistance of polymers. The analysis of DC breakdown field strength, current density, and space charge distribution at various temperatures demonstrates that grafting BMIE can greatly enhance the dielectric properties of insulation. Polar groups in the BMIE molecule create deep trap energy levels in XLPE-g-BMIE, and these trap energy levels contribute to the formation of a charged layer near the electrode, which is shielded by Coulomb potential. As a result, the charge injection barrier increases. Additionally, the presence of these polar groups reduces the mobility of charge carriers through trap-carrier scattering, effectively suppressing the accumulation of space charge within the material. First-principle calculations also confirm that bound states can be introduced as carrier traps by grafting BMIE onto polyethylene molecules. The agreement between experimental results and simulation calculations indicates that grafting BMIE to enhance the dielectric properties of polyethylene is a new and feasible research direction in the exploitation of materials for HVDC cables. Full article

Large and remote offshore wind farms (OWFs) usually use voltage source converter (VSC) systems to transmit electrical power to the main network. Submarine high-voltage direct current (HVDC) cables are commonly used as transmission links. As they are liable to insulation breakdown, fault location in the HVDC cables is a major issue in these systems. Exact fault location can significantly reduce the high cost of submarine HVDC cable repair in multi-terminal networks. In this paper, a novel method is presented to find the exact location of the DC faults. The fault location is calculated using extraction of new features from voltage signals of cables’ sheaths and a trained artificial neural network (ANN). The results obtained from a simulation of a three-terminal HVDC system in power systems computer-aided design (PSCAD) environment show that the maximum percentage error of the proposed method is less than 1%. Full article

High-voltage direct current (HVDC) links are starting to become widely implemented thanks to their interesting advantages such as reduced operation losses, the absence of reactive power, which allows energy transport via underground cables over long distances, and improved power control. The latter advantage is very essential for renewable energy resource integration into power grids. However, a thorough understanding of the behavior of insulation systems for HVDC components is critical so as to ensure a more reliable service. Indeed, the existence of the direct current (DC) voltage in HVDC components may induce surface and space charge accumulation that can stress insulation further or even promote discharge inception and propagation. As such, this work focuses on showcasing the effect of surface charge on streamers that develop on the interface of liquid–solid insulation due to the advent of lightning impulse (LI) voltage in the HVDC link. This study was performed using finite-element-based numerical simulations that include a quasi-electrostatic model for surface charge accumulation and an electrohydrodynamic fluid model for streamer initiation and propagation. The geometry used was point–plane configuration where the high voltage is applied to the needle electrode located above the liquid–solid interface. The obtained results suggest that streamer initiation is affected by both the accumulated surface charge density and polarity. For a positive streamer, an accumulation of positive surface charge increases the discharge inception voltage as a result of a weakening in the electric field, while an accumulation of negative surface charge decreases the discharge inception voltage due to an intensification in the electric field. Moreover, streamer travel distance and velocity are also both shown to be affected by surface charge accumulation. Full article

Despite similar material composition and insulation application, the alternating current (AC) cross-linked polyethylene (XLPE) and direct current (DC) XLPE materials cannot replace each other due to different voltage forms. Herein, this work presents a systematical investigation into the effects of thermal aging on the material composition and properties of 500 kV-level commercial AC XLPE and DC XLPE materials. A higher content of antioxidants in the AC XLPE than in the DC XLPE was experimentally demonstrated via thermal analysis technologies, such as oxidation-induced time and oxidation-induced temperature. Retarded thermal oxidation and suppression of space charge effects were observed in thermally aged AC XLPE samples. On the other hand, the carbonyl index of DC XLPE dramatically rose when thermal aging was up to 168 h. The newly generated oxygen-containing groups provided deep trapping sites (~0.95 eV) for space charges and caused severe electric field distortion (120%) under −50 kV/mm at room temperature in the aged DC XLPE samples. For the unaged XLPE materials, the positive space charge packets were attributed to the residue crosslinking byproducts, even after being treated in vacuum at 70 °C for 24 h. Thus, it was reasoned that the DC XLPE material had a lower crosslinking degree to guarantee fewer crosslinking byproducts. This work offers a simple but accurate method for evaluating thermal oxidation resistance and space charge properties crucial for developing high-performance HVDC cable insulation materials. Full article

Owing to its lack of crosslinking, polypropylene (PP) is considered an environmentally friendly alternative to crosslinked polyethylene as high-voltage direct current (HVDC) cable insulation. However, pure PP can accumulate space charges under a HVDC, and thus must be modified for use as an insulating material for HVDC cables. In this study, 4-methylstyrene is grafted onto PP using an aqueous suspension grafting method to improve its properties. The effects of the swelling time, reaction time, and 4-methylphenylene concentration on the reaction were investigated. The optimum process conditions were determined, including an optimum grafting ratio of 0.97%. The volume resistivity, ability to suppress space-charge accumulation, and DC breakdown strength of modified PP were also studied. Modified PP with a grafting ratio of 0.88% showed optimal space-charge suppression and the highest volume resistivity and breakdown strength. The work will facilitate the design and development of more efficient insulation materials for HVDC cables. Full article

To achieve a preferable compatibility between liquid silicone rubber (LSR) and cable main insulation in a cable accessory, we developed SiC/LSR nanocomposites with a significantly higher conductivity nonlinearity than pure LSR, whilst representing a notable improvement in space charge characteristics. Space charge distributions in polarization/depolarization processes and surface potentials of SiC/LSR composites are analyzed to elucidate the percolation conductance and charge trapping mechanisms accounting for nonlinear conductivity and space charge suppression. It is verified that SiC/LSR composites with SiC content higher than 10 wt% represent an evident nonlinearity of electric conductivity as a function of the electric field strength. Space charge accumulations can be inhibited by filling SiC nanoparticles into LSR, as illustrated in both dielectric polarization and depolarization processes. Energy level and density of shallow traps increase significantly with SiC content, which accounts for expediting carrier hopping transport and surface charge decay. Finite-element multiphysics simulations demonstrate that nonlinear conductivity acquired by 20 wt% SiC/LSR nanocomposite could efficiently homogenize an electric field distributed in high-voltage direct current (HVDC) cable joints. Nonlinear conductivities and space charge characteristics of SiC/LSR composites discussed in this paper suggest a feasible modification strategy to improve insulation performances of direct current (DC) cable accessories. Full article

Polyethylene, with its excellent mechanical and dielectric properties is used as an insulator for high-voltage direct current (HVDC) transmission. In ultra-high-voltage direct current (UHVDC) transmission, the ageing of insulation materials caused by space charge under high DC voltage becomes serious. Therefore, restraining the space charge and improving the dielectric properties of HVDC cables is important. In this study, low-density polyethylene (LDPE) was used as the raw material and combined with cooling media in a vulcanizing press. A polarizing microscope was used to observe the samples’ crystal morphologies. The space charge accumulation and dispersion were detected using pulsed electro-acoustic. Additionally, dielectric properties such as electrical conductivity and dielectric frequency spectrum were tested. The grain size in the air-cooled LDPE samples was found to be large and unevenly dispersed. However, the grain sizes in the water and oil cooling LDPE samples were small. The mean charge density of the oil cooling samples was the lowest. Under a short circuit measurement, more space charges were found in the natural and rapid air cooling samples. The mean charge densities of these two samples were high, with a fast decay rate. With an 8 and 50 kV/mm electric field strength, the oil cooling samples’ conductivity was the highest and lowest, respectively. Full article

Accessories such as joints and terminations represent weak points in HVDC cable systems. The DC field distribution is intimately dependent on the thermal conditions of the accessory and on material properties. Moreover, there is no available method to probe charge distribution in these conditions. In this work, the field distribution in non-stationary conditions, both thermally and electrically, is computed considering crosslinked polyethylene (XLPE) as cable insulation and different insulating materials (silicone, rubber, XLPE) for a 200 kV joint assembled in a same geometry. In the conditions used, i.e., temperatures up to 70 °C, and with the material properties considered, the dielectric time constant appears of the same order or longer than the thermal one and is of several hours. This indicates that both physical phenomena need to be considered for modelling the electric field distribution. Both the radial and the tangential field distributions are analysed, and focus is given on the field distribution under the stress cone on the ground side and near the central deflector on the high voltage side of the joint. We show that the position of the maximum field varies in time in a way that is not easy to anticipate. Under the cone, the smallest tangential field is obtained with the joint insulating material having the highest electrical conductivity. This results from a shift of the field towards the cable insulation in which the geometrical features produce a weaker axial component of the field. At the level of the central deflector, it is clear that the tangential field is higher when the mismatch between the conductivity of the two insulations is larger. In addition, the field grows as a function of time under stress. This work shows the need of precise data on materials conductivity and the need of probing field distribution in 3D. Full article

The massive integration of variable renewable energy (VRE) in modern power systems is imposing several challenges; one of them is the increased need for balancing services. Coping with the high variability of the future generation mix with incredible high shares of VER, the power system requires developing and enabling sources of flexibility. This paper proposes and demonstrates a single layer control system for coordinating the steady-state operation of battery energy storage system (BESS) and wind power plants via multi-terminal high voltage direct current (HVDC). The proposed coordinated controller is a single layer controller on the top of the power converter-based technologies. Specifically, the coordinated controller uses the capabilities of the distributed battery energy storage systems (BESS) to store electricity when a logic function is fulfilled. The proposed approach has been implemented considering a control logic based on the power flow in the DC undersea cables and coordinated to charging distributed-BESS assets. The implemented coordinated controller has been tested using numerical simulations in a modified version of the classical IEEE 14-bus test system, including tree-HVDC converter stations. A 24-h (1-min resolution) quasi-dynamic simulation was used to demonstrate the suitability of the proposed coordinated control. The controller demonstrated the capacity of fulfilling the defined control logic. Finally, the instantaneous flexibility power was calculated, demonstrating the suitability of the proposed coordinated controller to provide flexibility and decreased requirements for balancing power. Full article

In this paper, the applications of thermoplastic, thermoset polymers, and a brief description of the functions of each subsystem are reviewed. The synthetic route and characteristics of polymeric materials are presented. The mechanical properties of polymers such as impact behavior, tensile test, bending test, and thermal properties like mold stress-relief distortion, generic thermal indices, relative thermal capability, and relative thermal index are mentioned. Furthermore, this paper covers the electrical behavior of polymers, mainly their dielectric strength. Different techniques for evaluating polymers’ suitability applied for electrical insulation are covered, such as partial discharge and high current arc resistance to ignition. The polymeric materials and processes used for manufacturing cables at different voltage ranges are described, and their applications to high voltage DC systems (HVDC) are discussed. The evolution and limitations of polymeric materials for electrical application and their advantages and future trends are mentioned. However, to reduce the high cost of filler networks and improve their technical properties, new techniques need to be developed. To overcome limitations associated with the accuracy of the techniques used for quantifying residual stresses in polymers, new techniques such as indentation are used with higher force at the stressed location. Full article

Mass Impregnated PPLP cable, which is applied to various high-voltage direct current (HVDC) projects due to its excellent dielectric and temperature properties, has a problem wherein voids are formed inside the butt-gap due to cavitation. However, there has been no previous research into technology for void defect identification and insulation diagnosis on HVDC MI-PPLP cables. In this paper, to propose an insulation diagnosis method for void defects in HVDC MI-PPLP cable, the direct current (DC) void discharge patterns were analyzed according to the specimen temperature and the magnitude of applied voltage using the pulse sequence analysis method. In addition, to confirm the pre-symptoms of dielectric breakdown in MI-PPLP cable due to DC void discharge, partial discharge patterns were analyzed continuously until dielectric breakdown occurred. From the experimental results, DC void discharge patterns of the same shape were obtained regardless of the specimen temperature and the magnitude of applied voltage. In addition, it was confirmed that new insulation aging patterns were generated as electrical and thermal aging occurred due to the continuous DC void discharge. Therefore, it is demonstrated that identification and insulation diagnosis of void defects in HVDC MI-PPLP cable is possible through the obtained DC void discharge and insulation aging patterns. Full article

Blending thermoplastic elastomers into polypropylene (PP) can make it have great potential for high-voltage direct current (HVDC) cable insulation by improving its toughness. However, when a large amount of thermoplastic elastomer is blended, the electrical strength of PP will be decreased consequently, which cannot meet the electrical requirements of HVDC cables. To solve this problem, in this paper, the inherent structure of thermoplastic elastomer SEBS was used to construct acetophenone structural units on its benzene ring through Friedel–Crafts acylation, making it a voltage stabilizer that can enhance the electrical strength of the polymer. The DC electrical insulation properties and mechanical properties of acetylated SEBS (Ac-SEBS)/PP were investigated in this paper. The results showed that by doping 30% Ac-SEBS into PP, the acetophenone structural unit on Ac-SEBS remarkably increased the DC breakdown field strength of SEBS/PP by absorbing high-energy electrons. When the degree of acetylation reached 4.6%, the DC breakdown field strength of Ac-SEBS/ PP increased by 22.4% and was a little higher than that of PP. Ac-SEBS, with high electron affinity, is also able to reduce carrier mobility through electron capture, resulting in lower conductivity currents in SEBS/PP and suppressing space charge accumulation to a certain extent, which enhances the insulation properties. Besides, the highly flexible Ac-SEBS can maintain the toughening effect of SEBS, resulting in a remarkable increase in the tensile strength and elongation at the break of PP. Therefore, Ac-SEBS/PP blends possess excellent insulation properties and mechanical properties simultaneously, which are promising as insulation materials for HVDC cables. Full article
