White blood cell (WBC) classification plays a crucial role in hematopathology and clinical diagnostics. However, traditional methods are constrained by limited receptive fields and insufficient utilization of contextual information, which hinders classification performance. To address these limitations, this paper proposes an enhanced WBC classification algorithm, CCE-YOLOv7, which is built upon the YOLOv7 framework. The proposed method introduces four key innovations to enhance detection accuracy and model efficiency: (1) A novel Conv2Former (Convolutional Transformer) backbone was designed to combine the local pattern extraction capability of convolutional neural networks (CNNs) with the global contextual reasoning of transformers, thereby improving the expressiveness of feature representation. (2) The CARAFE (Content-Aware ReAssembly of Features) upsampling operator was adopted to replace conventional interpolation methods, thereby enhancing the spatial resolution and semantic richness of feature maps. (3) An Efficient Multi-scale Attention (EMA) module was introduced to refine multi-scale feature fusion, enabling the model to better focus on spatially relevant features critical for WBC classification. (4) Soft-NMS (Soft Non-Maximum Suppression) was used instead of traditional NMS to better preserve true positives in densely packed or overlapping cell scenarios, thereby reducing false positives and false negatives. Experimental validation was conducted on a WBC image dataset acquired using the Fourier ptychographic microscopy (FPM) system. The proposed CCE-YOLOv7 achieved a detection accuracy of 89.3%, showing a 7.8% improvement over the baseline YOLOv7. Furthermore, CCE-YOLOv7 reduced the number of parameters by 2 million and lowered computational complexity by 5.7 GFLOPs, offering an efficient and lightweight model suitable for real-time clinical applications. To further evaluate model effectiveness, comparative experiments were conducted with YOLOv8 and YOLOv11. CCE-YOLOv7 achieved a 4.1% higher detection accuracy than YOLOv8 while reducing computational cost by 2.4 GFLOPs. Compared with the more advanced YOLOv11, CCE-YOLOv7 maintained competitive accuracy (only 0.6% lower) while using significantly fewer parameters and 4.3 GFLOPs less in computation, highlighting its superior trade-off between accuracy and efficiency. These results demonstrate that CCE-YOLOv7 provides a robust, accurate, and computationally efficient solution for automated WBC classification, with significant clinical applicability. Full article

Autonomous Fourier Ptychographic Microscopy (FPM) is a technology widely used in the field of pathology. It is compatible with high resolution and large field-of-view imaging and can observe more image details. Red blood cells play an indispensable role in assessing the oxygen-carrying capacity of the human body and in screening for clinical diagnosis and treatment needs. In this paper, the blood cell data set is constructed based on the FPM system experimental platform. Before training, four enhancement strategies are adopted for the blood cell image data to improve the generalization and robustness of the model. A blood cell detection algorithm based on SCD-YOLOv7 is proposed. Firstly, the C-MP (Convolutional Max Pooling) module and DELAN (Deep Efficient Learning Automotive Network) module are used in the feature extraction network to optimize the feature extraction process and improve the extraction ability of overlapping cell features by considering the characteristics of channels and spatial dimensions. Secondly, through the Sim-Head detection head, the global information of the deep feature map (mean average precision) and the local details of the shallow feature map are fully utilized to improve the performance of the algorithm for small target detection. MAP is a comprehensive indicator for evaluating the performance of object detection algorithms, which measures the accuracy and robustness of a model by calculating the average precision (AP) under different categories or thresholds. Finally, the Focal-EIoU (Focal Extended Intersection over Union) loss function is introduced, which not only improves the convergence speed of the model but also significantly improves the accuracy of blood cell detection. Through quantitative and qualitative analysis of ablation experiments and comparative experimental results, the detection accuracy of the SCD-YOLOv7 algorithm on the blood cell data set reached 92.4%, increased by 7.2%, and the calculation amount was reduced by 14.6 G. Full article

Fourier ptychographic microscopy (FPM) has recently emerged as an important non-invasive imaging technique which is capable of simultaneously achieving high resolution, wide field of view, and quantitative phase imaging. However, FPM still faces challenges in the image reconstruction due to factors such as noise, optical aberration, and phase wrapping. In this work, we propose a semi-supervised Fourier ptychographic transformer network (SFPT) for improved image reconstruction, which employs a two-stage training approach to enhance the image quality. First, self-supervised learning guided by low-resolution amplitudes and Zernike modes is utilized to recover pupil function. Second, a supervised learning framework with augmented training datasets is applied to further refine reconstruction quality. Moreover, the unwrapped phase is recovered by adjusting the phase distribution range in the augmented training datasets. The effectiveness of the proposed method is validated by using both the simulation and experimental data. This deep-learning-based method has potential applications for imaging thicker biology samples. Full article

In this study, we proposed a multiplexed color illumination strategy to improve the data acquisition efficiency of Fourier ptychography microscopy (FPM). Instead of sequentially lighting up one single channel LED, our method turns on multiple white light LEDs for each image acquisition via a color camera. Thus, each raw image contains multiplexed spectral information. An FPM prototype was developed, which was equipped with a 4×/0.13 NA objective lens to achieve a spatial resolution equivalent to that of a 20×/0.4 NA objective lens. Both two- and four-LED illumination patterns were designed and applied during the experiments. A USAF 1951 resolution target was first imaged under these illumination conditions, based on which MTF curves were generated to assess the corresponding imaging performance. Next, H&E tissue samples and analyzable metaphase chromosome cells were used to evaluate the clinical utility of our strategy. The results show that the single and multiplexed (two- or four-LED) illumination results achieved comparable imaging performance on all the three channels of the MTF curves. Meanwhile, the reconstructed tissue or cell images successfully retain the definition of cell nuclei and cytoplasm and can better preserve the cell edges as compared to the results from the conventional microscopes. This study initially validates the feasibility of multiplexed color illumination for the future development of high-throughput FPM scanning systems. Full article

Fourier ptychographic microscopy (FPM) is a computational imaging technology that can acquire high-resolution large-area images for applications ranging from biology to microelectronics. In this study, we utilize multifocal plane imaging to enhance the existing FPM technology. Using an RGB light emitting diode (LED) array to illuminate the sample, raw images are captured using a color camera. Then, exploiting the basic optical principle of wavelength-dependent focal length variation, three focal plane images are extracted from the raw image through simple R, G, and B channel separation. Herein, a single aspherical lens with a numerical aperture (NA) of 0.15 was used as the objective lens, and the illumination NA used for FPM image reconstruction was 0.08. Therefore, simultaneous multifocal plane FPM with a synthetic NA of 0.23 was achieved. The multifocal imaging performance of the enhanced FPM system was then evaluated by inspecting a transparent organic light-emitting diode (OLED) sample. The FPM system was able to simultaneously inspect the individual OLED pixels as well as the surface of the encapsulating glass substrate by separating R, G, and B channel images from the raw image, which was taken in one shot. Full article

Fourier Ptychographic Microscopy (FPM) is a microscopy imaging technique based on optical principles. It employs Fourier optics to separate and combine different optical information from a sample. However, noise introduced during the imaging process often results in poor resolution of the reconstructed image. This article has designed an approach based on a residual local mixture network to improve the quality of Fourier ptychographic reconstruction images. By incorporating channel attention and spatial attention into the FPM reconstruction process, the network enhances the efficiency of the network reconstruction and reduces the reconstruction time. Additionally, the introduction of the Gaussian diffusion model further reduces coherent artifacts and improves image reconstruction quality. Comparative experimental results indicate that this network achieves better reconstruction quality, and outperforming existing methods in both subjective observation and objective quantitative evaluation. Full article

Fourier ptychographic microscopy, as a computational imaging method, can reconstruct high-resolution images but suffers optical aberration, which affects its imaging quality. For this reason, this paper proposes a network model for simulating the forward imaging process in the Tensorflow framework using samples and coherent transfer functions as the input. The proposed model improves the introduced Wirtinger flow algorithm, retains the central idea, simplifies the calculation process, and optimizes the update through back propagation. In addition, Zernike polynomials are used to accurately estimate aberration. The simulation and experimental results show that this method can effectively improve the accuracy of aberration correction, maintain good correction performance under complex scenes, and reduce the influence of optical aberration on imaging quality. Full article

Fourier ptychographic microscopy (FPM) is a computational imaging technology that has endless vitality and application potential in digital pathology. Colored pathological image analysis is the foundation of clinical diagnosis, basic research, and most biomedical problems. However, the current colorful FPM reconstruction methods are time-inefficient, resulting in poor image quality due to optical interference and reconstruction errors. This paper combines coloring and FPM to propose a self-supervised generative adversarial network (GAN) for FPM color reconstruction. We design a generator based on the efficient channel residual (ECR) block to adaptively obtain efficient cross-channel interaction information in a lightweight manner, and we introduce content-consistency loss to learn the high-frequency information of the image and improve the image quality of the staining. Furthermore, the effectiveness of our proposed method is demonstrated through objective indicators and visual evaluations. Full article

Fourier ptychographic microscopy (FPM) emerged as a prominent imaging technique in 2013, attracting significant interest due to its remarkable features such as precise phase retrieval, expansive field of view (FOV), and superior resolution. Over the past decade, FPM has become an essential tool in microscopy, with applications in metrology, scientific research, biomedicine, and inspection. This achievement arises from its ability to effectively address the persistent challenge of achieving a trade-off between FOV and resolution in imaging systems. It has a wide range of applications, including label-free imaging, drug screening, and digital pathology. In this comprehensive review, we present a concise overview of the fundamental principles of FPM and compare it with similar imaging techniques. In addition, we present a study on achieving colorization of restored photographs and enhancing the speed of FPM. Subsequently, we showcase several FPM applications utilizing the previously described technologies, with a specific focus on digital pathology, drug screening, and three-dimensional imaging. We thoroughly examine the benefits and challenges associated with integrating deep learning and FPM. To summarize, we express our own viewpoints on the technological progress of FPM and explore prospective avenues for its future developments. Full article

The diagnosis of many diseases relies, at least on first intention, on an analysis of blood smears acquired with a microscope. However, image quality is often insufficient for the automation of such processing. A promising improvement concerns the acquisition of enriched information on samples. In particular, Quantitative Phase Imaging (QPI) techniques, which allow the digitization of the phase in complement to the intensity, are attracting growing interest. Such imaging allows the exploration of transparent objects not visible in the intensity image using the phase image only. Another direction proposes using stained images to reveal some characteristics of the cells in the intensity image; in this case, the phase information is not exploited. In this paper, we question the interest of using the bi-modal information brought by intensity and phase in a QPI acquisition when the samples are stained. We consider the problem of detecting parasitized red blood cells for diagnosing malaria from stained blood smears using a Deep Neural Network (DNN). Fourier Ptychographic Microscopy (FPM) is used as the computational microscopy framework to produce QPI images. We show that the bi-modal information enhances the detection performance by $4\%$ compared to the intensity image only when the convolution in the DNN is implemented through a complex-based formalism. This proves that the DNN can benefit from the bi-modal enhanced information. We conjecture that these results should extend to other applications processed through QPI acquisition. Full article

Fourier ptychographic microscopy (FPM) is a novel technique for computing microimaging that allows imaging of samples such as pathology sections. However, due to the influence of systematic errors and noise, the quality of reconstructed images using FPM is often poor, and the reconstruction efficiency is low. In this paper, a hybrid attention network that combines spatial attention mechanisms with channel attention mechanisms into FPM reconstruction is introduced. Spatial attention can extract fine spatial features and reduce redundant features while, combined with residual channel attention, it adaptively readjusts the hierarchical features to achieve the conversion of low-resolution complex amplitude images to high-resolution ones. The high-resolution images generated by this method can be applied to medical cell recognition, segmentation, classification, and other related studies, providing a better foundation for relevant research. Full article

The combination of a blood cell analyzer and artificial microscopy to detect white blood cells is used in hospitals. Blood cell analyzers not only have large throughput, but they also cannot detect cell morphology; although artificial microscopy has high accuracy, it is inefficient and prone to missed detections. In view of the above problems, a method based on Fourier ptychographic microscopy (FPM) and deep learning to detect peripheral blood leukocytes is proposed in this paper. Firstly, high-resolution and wide-field microscopic images of human peripheral blood cells are obtained using the FPM system, and the cell image data are enhanced with DCGANs (deep convolution generative adversarial networks) to construct datasets for performance evaluation. Then, an improved DETR (detection transformer) algorithm is proposed to improve the detection accuracy of small white blood cell targets; that is, the residual module Conv Block in the feature extraction part of the DETR network is improved to reduce the problem of information loss caused by downsampling. Finally, CIOU (complete intersection over union) is introduced as the bounding box loss function, which avoids the problem that GIOU (generalized intersection over union) is difficult to optimize when the two boxes are far away and the convergence speed is faster. The experimental results show that the mAP of the improved DETR algorithm in the detection of human peripheral white blood cells is 0.936. In addition, this algorithm is compared with other convolutional neural networks in terms of average accuracy, parameters, and number of inference frames per second, which verifies the feasibility of this method in microscopic medical image detection. Full article

Two-dimensional observation of biological samples at hundreds of nanometers resolution or even below is of high interest for many sensitive medical applications. Recent advances have been obtained over the last ten years with computational imaging. Among them, Fourier Ptychographic Microscopy is of particular interest because of its important super-resolution factor. In complement to traditional intensity images, phase images are also produced. A large set of $\mathcal{N}$ raw images (with typically $\mathcal{N}$ = 225) is, however, required because of the reconstruction process that is involved. In this paper, we address the problem of FPM image reconstruction using a few raw images only (here, $\mathcal{N}$ = 37) as is highly desirable to increase microscope throughput. In contrast to previous approaches, we develop an algorithmic approach based on a physics-informed optimization deep neural network and statistical reconstruction learning. We demonstrate its efficiency with the help of simulations. The forward microscope image formation model is explicitly introduced in the deep neural network model to optimize its weights starting from an initialization that is based on statistical learning. The simulation results that are presented demonstrate the conceptual benefits of the approach. We show that high-quality images are effectively reconstructed without any appreciable resolution degradation. The learning step is also shown to be mandatory. Full article

Fourier ptychographic microscopy is a new microscopic computational imaging technology. A series of low-resolution intensity images are collected by a Fourier ptychographic microscopy system, and high-resolution intensity and phase images are reconstructed from the collected low-resolution images by a reconstruction algorithm. It is a kind of microscopy that can achieve both a large field of view and high resolution. Here in this article, a Fourier ptychographic reconstruction method applied to a self-training physical model is proposed. The SwinIR network in the field of super-resolution is introduced into the reconstruction method for the first time. The input of the SwinIR physical model is modified to a two-channel input, and a data set is established to train the network. Finally, the results of high-quality Fourier stack microscopic reconstruction are realized. The SwinIR network is used as the physical model, and the network hyperparameters and processes such as the loss function and optimizer of the custom network are reconstructed. The experimental results show that by using multiple different types of data sets, the two evaluation index values of the proposed method perform best, and the image reconstruction quality is the best after model training. Two different evaluation indexes are used to quantitatively analyze the reconstruction results through numerical results. The reconstruction results of the fine-tuning data set with some real captured images are qualitatively analyzed from the visual effect. The results show that the proposed method is effective, the network model is stable and feasible, the image reconstruction is realized in a short time, and the reconstruction effect is good. Full article

Fourier ptychographic microscopy (FPM) has risen as a promising computational imaging technique that breaks the trade-off between high resolution and large field of view (FOV). Its reconstruction is normally formulated as a blind phase retrieval problem, where both the object and probe have to be recovered from phaseless measured data. However, the stability and reconstruction quality may dramatically deteriorate in the presence of noise interference. Herein, we utilized the concept of alternating direction method of multipliers (ADMM) to solve this problem (termed ADMM-FPM) by breaking it into multiple subproblems, each of which may be easier to deal with. We compared its performance against existing algorithms in both simulated and practical FPM platform. It is found that ADMM-FPM method belongs to a global optimization algorithm with a high degree of parallelism and thus results in a more stable and robust phase recovery under noisy conditions. We anticipate that ADMM will rekindle interest in FPM as more modifications and innovations are implemented in the future. Full article
