Traditional Instrument Landing Systems (ILSs) suffer from inherent limitations, including limited signal coverage and high maintenance costs. To address these issues, we propose a novel approach procedure design method based on the BeiDou Satellite-Based Augmentation System (BDSBAS), which is particularly suitable for airports with complex terrain conditions or no ground-based navigation infrastructure. In this method, a geometric constraint model of the approach trajectory is constructed in a local Cartesian coordinate system, and obstacle clearance performance is evaluated based on the Obstacle Assessment Surface (OAS) theory. Global Navigation Satellite System (GNSS) observations and BDSBAS augmentation data are processed collaboratively to calculate aircraft position solutions, as well as the corresponding horizontal and vertical protection levels, enabling comprehensive evaluation of the navigation system’s accuracy, integrity, continuity, and availability. The feasibility and performance of the proposed method are verified through practical airport deployment and dynamic flight tests. Experimental results show that the 95th-percentile horizontal and vertical position errors reach 1.31 m and 4.17 m, respectively, and all valid observation epochs fully comply with the protection level and alert limit specifications. Compared with the conventional ILS-based scheme, the proposed method reduces the total OAS area and the missed-approach Z-surface area by 44.25% and 67.90%, respectively. The findings demonstrate that BDSBAS can effectively support approach procedure design and guarantee high-precision navigation performance, while significantly reducing the reliance on airport-specific ground navigation infrastructure. Full article

The BeiDou Satellite-Based Augmentation System (BDSBAS), based on the Radio Technical Commission for Aeronautics (RTCA) protocol, aims to provide high-precision, single-frequency positioning with integrity assurance for civil aviation users in China and surrounding regions. Given the anticipated high solar activity between 2023 and 2025, ionospheric anomalies may degrade positioning accuracy and significantly impact BDSBAS integrity performance. To enhance BDSBAS integrity, this study evaluates and analyzes the system’s ionospheric degradation parameters for 2023. The results indicate that during the active ionospheric period in 2023, the rate of ionospheric grid delay changes exceeding the limits of the currently broadcasted parameters increased by 0.86%, posing potential integrity risks compared to 2022. To address this issue, we propose a novel algorithm for ionospheric degradation parameters and assess its applicability, stability, and effectiveness using BDSBAS single-frequency service message data from IGS monitoring stations in China. Statistical analysis in the localization domain demonstrates that the new method reduces the rate of ionospheric degradation parameters exceeding the threshold by 1.10% in 2023–2024. This approach significantly enhances BDSBAS integrity service capabilities, supporting its performance improvement and official deployment. Full article

The most commonly used real-time augmentation services in China are the International GNSS Service’s (IGS) real-time service (RTS), PPP-B2b service, and Double-Frequency Multi-Constellation (DFMC) service of the BeiDou Satellite-Based Augmentation System (BDSBAS) service. However, research on the performance evaluation, comparison, and application scope of these three products is still incomplete. This article introduces methods for obtaining real-time augmentation information and real-time orbit and clock offset recovery. Based on real-time orbit and clock offset accuracy, positioning accuracy, and positioning availability, this article systematically evaluates the performance and analyzes the application fields of Centre National d’Études Spatiales (CNES), PPP-B2b, and BDSBAS augmentation information. The results of the evaluation revealed that the radial accuracy of the CNES and PPP-B2b real-time orbit product is consistent, and the Root Mean Square (RMS) is better than 5 cm. The CNES real-time orbit product can achieve centimeter-level accuracy in both along-track and cross-track components, surpassing PPP-B2b’s decimeter-level accuracy. Both services demonstrate consistent accuracy in the real-time clock offset, with PPP-B2b showing similar standard deviations (STDs) of 0.16 ns for different satellites. However, for CNES, the STD of the real-time clock offset varies, with values of 0.10 ns, 0.19 ns, and 0.60 ns, respectively, for GPS, BDS-3 Medium Earth Orbit (MEO), and BDS-3 Inclined Geosynchronous Satellite Orbit (IGSO) satellites. Centimeter-level accuracy is achieved after convergence and positioning availability exceeds 99% for CNES and PPP-B2b services. Therefore, the difference between the two services in application areas depends on the acquisition of augmentation information. However, BDSBAS, which concentrates on code observations, demonstrates inferior performance in real-time orbit, clock offset, positioning accuracy, and positioning availability when compared to the other two services. Its primary application is in the aviation and maritime domains, where there is a greater need for service integrity, continuity, and reliability. Full article

To guarantee the integrity of a global navigation satellite system (GNSS) for safety-critical users, a satellite-based augmentation system (SBAS) makes use of the integrity monitoring architecture, of which the signal quality monitor (SQM) is an important component to address the potential risks caused by satellite-induced signal anomalies. Due to the introduction of dual-frequency multi-constellation (DFMC) techniques in 2025, the ranging uncertainty will be reduced by the elimination of first-order ionospheric delay, but the biases measured in each individual signal will be inflated by the ionosphere-free combinations. Moreover, multiple modulations of DFMC signals might introduce applicability uncertainty of a traditional SQM method that has been protecting GPS L1C/A signal only. Thus, higher requirements are put forward for future SQM methods in detection sensitivity and modulation independence. This paper first proposes a design methodology for the SQM algorithm for BDS B1C/B2a signals, which could be easily extended to the DF combinations of other GNSS core constellations. Then, by comparing the performances of SQM baseline algorithms based on traditional multi-correlator and emerging chip domain observables (CDOs), respectively, the superiority of CDO-based SQM is declared. Detailed design iterations are further discussed, including the algorithm practicalization with optimizing code-phase bin length and lowering sampling frequency, as well as the metric simplification, to promote the overall performance while preserving a lower implementation complexity. Ultimately, a CDO-based SQM algorithm for BDS B1C/B2a signals is reached, which would be considered as an effective candidate in new generation DFMC SBASs. Full article

The BeiDou global navigation satellite system (BDS-3) provides positioning, navigation and timing services for global users, moreover, it provides BDS satellite-based augmentation system (BDSBAS) single-frequency (SF) and dual-frequency multi-constellation (DFMC) services for users in China and its surrounding areas. The BDSBAS SF service is in accordance with Radio Technical Commission for Aeronautics (RTCA) standard protocol (RTCA MOPS) and augment GPS constellation, while the BDSBAS DFMC service is in line with SBAS L5 DFMC standard protocol and is aimed at supporting any combination of BDS/GPS/Galileo/GLONASS constellations, including only a single constellation operation. We introduced the development status of the BDSBAS system, including the system architecture and navigation user algorithms. Based on the GPS measurements, the accuracy, integrity and availability of the BDSBAS SF service were evaluated, and with the BDS measurements, the accuracy of the BDSBAS DFMC service was preliminarily analyzed. The integrity and availability of the BDSBAS DFMC service will be discussed in future work as some of the DFMC integrity parameters are still under discussion for optimization. The results show that, for BDSBAS SF service, the horizontal and vertical position accuracy were about 1.0 m and 2.0 m (95%), respectively, which were improved by 39% and 33%, respectively, compared with the GPS SF position accuracy. For BDSBAS DFMC service, the horizontal and vertical position accuracy were about 0.6 m and 1.2 m (95%), respectively, which were improved by about 25% and 20% compared with the BDS dual-frequency position accuracy. No system integrity risk event was detected during the testing period for BDSBAS SF service. The average availability of the BDSBAS SF service was about 98% which was mainly affected by the availability of ionospheric grid delay corrections. Full article

As an important part of the BeiDou global navigation satellite system (BDS-3), the BeiDou satellite-based augmentation system (BDSBAS) aims to provide a high-integrity navigation service for users in China and its surrounding areas. At present, BDSBAS has completed the preliminary construction of the system and formed the single frequency (SF) augmentation service. The paper introduces the composition and working process of BDSBAS, and expounds the solution and performance evaluation methods of the BDSBAS SF service. Tests based on a general aviation aircraft were carried out at Caihu Airport in Shenyang, China, which simulated the aircraft’s take-off and landing operation during the approach phase and the transition flight operation during the en-route phase. On this basis, the BDSBAS SF service performance was analyzed and evaluated. The horizontal positioning errors of the three flight tests are 1.62, 1.27, and 1.49 m, respectively, and the vertical positioning errors are 4.38, 4.30, and 4.04 m, respectively. In the first two tests, the APV-I availability and continuity of the service reach 100%. In the last test, a receiver false alarm event occurred, resulting in an APV-I availability and continuity of 99.993% and 99.989%, respectively. The event was confirmed to be caused by some aviation environmental factors and was not related to the system service. No integrity events occurred during the tests. The test results show that the positioning accuracy, availability, and integrity of the BDSBAS SF service meet the APV-I level requirements of the ICAO standards, which preliminarily illustrates the ability of BDSBAS to be used in the field of civil aviation. Full article

To satisfy the demands of civil aviation organizations and other users of satellite navigation systems for high-precision and high-integrity service performance, many countries and regions have established satellite-based augmentation systems (SBAS) referring to the Radio Technical Commission for Aeronautics (RTCA) service standards and agreements. The BeiDou SBAS (BDSBAS) provides both single-frequency service, which augments Global Positioning System (GPS) L1 C/A signal, and dual-frequency multi-constellation (DFMC) service, which augments BeiDou Navigation Satellite System (BDS) B1C and B2a dual frequency signals presently, meeting the requirements of the RTCA DO-229D protocol and the SBAS L5 DFMC protocol requirements, respectively. As one of the main error sources, the pseudorange bias errors of BDSBAS monitoring receivers were estimated and their effect on the performance of the BDSBAS service was analyzed. Based on the user algorithms of SBAS differential corrections and integrity information, the service accuracy, integrity, and availability of the BDSBAS were evaluated using real observation data. The results show that the maximum of monitoring receiver pseudorange bias errors between L1P and L1P/L2P can reach 1.57 m, which become the most important errors affecting the performance of the BDSBAS service. In addition, the results show that the pseudorange bias of GPS BlockIII is the smallest, while that of GPS BlockIIR is the largest. Compared with the positioning accuracy of the open service of the core constellation, the positioning accuracy of the BDSBAS service can be improved by approximately 47% and 36% for the RTCA service and DFMC service, respectively. For RTCA services, the protection limit (PL) calculated with the integrity information can 100% envelop the positioning error (PE) and no integrity risk event is detected. The service availability of BDSBAS for APV-I approach is approximately 98.8%, which is mainly affected by the availability of ionospheric grid corrections in the service marginal area. For DFMC service, the integrity risk is not detected either. The service availability for CAT-I approach is 100%. Improving the availability of ionospheric grid corrections is one of the important factors to improve service performance of BDSBAS RTCA service. Full article
