The development of integrated optical technology and the continuous emergence of various low-loss optical waveguide materials have promoted the development of low-cost, size, weight, and power optical gyroscopes. However, the losses in conventional optical waveguide materials are much greater than those in optical fibers, and different waveguide materials often require completely different etching processes, resulting in severely limited gyroscope performance, which is not conducive to the monolithic integration of gyroscope systems. In this paper, an ultra-low-loss Archimedean spiral waveguide structure is designed for an on-chip integrated optical gyroscope by using the high Q value and low-loss optical characteristics of the bound state in the continuum (BIC). The structure does not require the etching of high-refractive-index optical functional materials, avoiding the etching problem that has been difficult to solve for a long time. In addition, the optical properties of the BIC straight and the BIC bent waveguide are simulated using the finite element method (FEM) to find the waveguide structural parameters corresponding to the BIC mode, which is used to design the integrated sensing coil and analyze the gyroscope performance. The simulation results show that the gyroscope’s sensitivity can reach 0.6699°/s. This research is the first time a BIC optical waveguide has been used for an integrated optical gyroscope, providing a novel idea for the monolithic integration of optical gyroscopes. Full article

This paper presents the conceptual stages of the simulation and development of a modified transceiver antenna for a high-power pulsed nuclear quadrupole resonance (NQR) detector of explosives containing the ¹⁴N isotope. At a frequency of 4.645 MHz, better characteristics are obtained using a nine-turn coil shaped as half of a Fermat spiral with an outer radius of 75 mm. Using a COMSOL Multiphysics numerical parametric simulation and a materials browser, it was possible to calculate a physical system with parameters as close to reality as possible. According to the results of the experimental studies of the radio frequency (RF) energy, the proposed antenna features an increase in the working area compared to a similar antenna, the topology of the conductive coil of which has the form of an Archimedean spiral. The resulting diagrams of the distribution of the magnetic induction also indicate that the topology of the electromagnetic (EM) field does not depend on the orientation of the sample under study relative to the axis of the radial symmetry observed in square–rectangular planar antennas. Full article

In this paper, a simplified method for the calculation of a mutual inductance of the planar spiral coil, motivated from the Archimedean spiral, is presented. This method is derived by solving Neumann’s integral formula in a cylindrical coordinate system, and a numerical tool is used to determine the value of mutual inductance. This approach can calculate the mutual inductances accurately at various coaxial and non-coaxial distances for different coil geometries. The calculation result is compared with the 3D finite element analyses to verify its accuracy, which shows good consistency. Furthermore, to confirm it experimentally, Litz wire is used to fabricate the sample spiral coils. Finally, the comparison of a simplified method is also studied relative to the coupling coefficient. The accuracy of the calculation results with the simulation and the measurement results makes it a good candidate to apply it in wireless power applications. Full article

In this paper, a new method to calculate the self-inductance of the Archimedean spiral coil is presented. The proposed method is derived by solving Neumann’s integral formula, and the numerical tool is used to calculate the inductance value. The calculation results are verified with several conventional formulas derived from the Wheeler formula or its modified form and 3D finite element analyses. The comparison with simulation results shows that the conventional formula has an error of above 40% compared to the proposed method, which has below 7% when the wire diameter is reduced. To further check the validity, different sizes of the spiral coil are fabricated by changing the geometrical parameters such as the number of turns, turn spacing, inner radius, outer radius, and wire diameter. Litz wire is chosen for making the spiral coil, and bobbins are made using a 3D printer. Finally, the calculation results are compared with the experimental result. The error between them is less than 2%. The comparison with the conventional formulas, simulation, and measurement results shows the accuracy of the proposed method. This method can be used to calculate the self-inductance of wireless power coils, inductors and antenna design. Full article

Considering the helicity of Archimedean spiral coils, this paper proposes accurate expressions of mutual inductance and their numerical calculation methods, which can be applied in the wireless power transmission field, etc. Accurate expressions of mutual inductance are deduced respectively for two coils that are coaxial, laterally misaligned, or non-parallel, and numerical calculations are performed using Gaussian integration as well. In the case of coaxial coils, the calculation results are verified by the 3D finite element method (3D FEM) and compared with the results gained by the traditional method that approximates two spiral coils to two clusters of series-connected circular coils ignoring helicity. The comparison of the three methods shows that results achieved by the proposed expression are close to that of 3D FEM, while there is increasing error with the screw pitches of the coils when using the traditional circular coil approximation method. The influence of relative position on the mutual inductance of the two coils is also studied and it is further explained through magnetic field distribution. Finally, the validity of the proposed expressions of mutual inductance is verified by experimental results. Full article
