1. Introduction
Vitis vinifera L., (Vitales: Vitaceae) commonly known as grapevine, is one of the most important crops in Greece, as there are more than 60,000 ha, and it has been widely cultivated in the last centuries for its fruit, raisins, and wine [
1]. The Greek variety “Debina” is indigenous to the viticultural zone of Zitsa, Ioannina (Epirus, Greece) at 600–700 m altitude and is used for winemaking. Grapevine is considered a drought-resilient species and its cultivation in a small percentage of water stress can improve the quality of berries and wine composition [
2,
3], although the vast climate change conditions of overheating and the continuous lack of water, are going to significantly damage vine production, yielding low-quality grapes [
1]. An important impact of water deficit in grape cultivation is the alteration of gene expression that regulates the metabolic pathways that control the accumulation of secondary metabolites (flavonoids) that affect the quality characteristics of grape berries and wine flavor quality traits [
4,
5]. The diversity of metabolic responses to drought stress induced by deficit irrigation is common and depends on the genetic background of the variety [
6]. Usually, the grapevine during the application of various water deficit irrigation fractions, presents higher concentrations of phenolic compounds [
4,
5,
7,
8]. Climate change conditions can affect grapevine cultivation as many studies and reviews mention [
9,
10,
11,
12]. Kizildeniz et al., 2015 [
11] shows that drought combined with elevated temperatures can reduce grapevine performance. The combination of climate change factors that cause abiotic stress (elevated temperature and drought) drastically reduced vegetative growth, bunch fresh and dry weights in red and white Tempranillo grapevine cultivars [
11].
An alternative aspect that may bring some solutions to the upcoming drought stress in various crops [
13], including the grapevine, is expected to be microbiological formulations that can help plant defense to alleviate the harmful effects of abiotic stress, known as biostimulants [
14,
15]. Beneficial rhizobacteria have been studied for their positive effects on plant metabolism for a multitude of phytopathogens [
15] while it appears that they also benefit plant growth and therefore they act as biostimulants [
16] especially in abiotic stress conditions [
17]. Also, some PGPR biostimulants can regulate the reactive oxygen species (ROS) levels in many plants under abiotic stress, resulting in increased proline and sugar levels [
18,
19]. The most commonly responsible modes of action by PGPR for enhancing plant growth under abiotic conditions, are 1-aminocyclopropane-1-carboxylic acid (ACC) deaminase, auxin production of cytokinins (CK), gibberellins (GB), indole acetic acid (IAA), and solubilization of phosphate and nitrogen fixation [
18,
19].
Bacillus amyloliquefaciens (Bacillales: Bacillaceae) is widely used and well-known PGPR for its pathogen-fighting potential on the roots of many plants and lately looming to have a biostimulant effect on many cultivars [
20], even in stress conditions such as water regimes [
21]. Its positive effect on plant growth during salt stress in crops such as soybean
Glycine max L. (Fabales: Fabaceae), [
22] lettuce
Lactuca sativa L., (Asterales: Asteraceae), and tomato seedlings
Solanum lycopersicum L., (Solanales: Solanaceae) [
23], allows plants to tolerate abiotic stress factors [
24]. Its application can not only limit the use of agrochemicals [
25] against grapevine root pathogens [
26] but can enhance its metabolic and developmental characteristics [
27], to cope with abiotic conditions. Salomon et al., 2014 [
28] have reported that
Bacillus strains act as stress alleviators in
V. vinifera L., by inducing abscisic acid (ABA) synthesis and reducing water losses, while in a different study [
29] described ABA production and accumulation in grapevine diminished plant water loss rate.
Sinorhizobium meliloti (Hyphomicrobiales: Rhizobiaceae), has been characterized as an endophyte for its mutualistic associations with many plants [
30,
31] as it migrates endophytically into most of the plant parts [
32]. It is diazotrophic: it fixes the gaseous nitrogen into usable forms such as ammonia [
33], so plant and
S. meliloti can benefit nutritionally [
34] and the use of nitrogen fertilizers can be reduced [
35]. Many studies mention the symbiosis between
S. meliloti and legumes [
36] mostly for nitrogen fixation on roots. There is strong evidence of its acting-as-biostimulant effect on several plants such as fenugreek
Trigonella foenum-graecum L., (Fabales: Fabaceae) under water deficit stress [
37], on
L. sativa [
38], in black medic (
Medicago lupulina L., (Fabales: Fabaceae) [
39], on cowpea
Vigna unguiculata L., (Fabales: Fabaceae) [
40], and on
V. vinifera [
41] has been reported.
There is a research gap regarding the stimulatory potential that
S. meliloti may present in grapevine cultivation under water stress conditions [
42]. This research was aimed to evaluate the application of two commercial formulations, each of them containing
B. amyloliquefaciens and
S. meliloti, respectively, as biostimulants in grapevine cultivation under irrigation deficit conditions.
2. Materials and Methods
2.1. Experimental Design
In the experiment which lasted for 140 days, grapevine cuttings of the indigenous to Zitsa (Ioannina viticultural zone, Greece) Debina variety were used. The cuttings were placed under misting conditions, to acclimatize them and produce roots. The main goal of the experiment was to study the biostimulant effect of the commercial formulations as close to a realistic cultivation environment as possible. For this reason, clay soil from a vineyard in the area of the plain of Arta was used as a growth substrate. It is important to mention that the soil did not undergo any steam pasteurization treatment; therefore, the data of this study could constitute the foreground for the future repetition of the experiment on the same field from where the soil was taken. Using this soil, an important first insight into the performance of the formulations was obtained in conditions as close as possible to grapevine growing reality. Also, this attempt is a first screening, on whether the preparations can compensate for the water deficit, based on laboratory indications concerning the metabolism of the vine culture. When the grapevine cuttings were planted in 9 L pots, initial granular fertilizer (N12-P12-K17) was applied.
In order to study the effect of commercial strains on grapevine metabolism under water deficit conditions, the experiment was carried out in the greenhouse of the Agriculture Department of the University of Ioannina in Kostakioi, Arta (Greece). A drip irrigation system was built for the experimental vine cultivation pots, which communicated with a central computer program (ARGOS Electronics 2014), and the pots were irrigated at regular intervals. The amount and frequency of irrigation were based on climate data from greenhouse temperature and relative moisture sensors. To assess the optimal irrigation needs of experimental grape cultivation in the greenhouse, monthly measurements of the evapotranspiration of some selected plants in the treatment pots were carried out. Plants from each experimental treatment were selected and checked monthly in order to calculate their water losses. Finally, two categories of irrigation were determined: optimal irrigation at 100% of available water (AW) and deficit irrigation at 57% of AW to achieve a balanced mid-level water deficit. Reaching 57% of the AW irrigation deficit level, on the one hand, the metabolism of the grapevine plants was stressed, and on the other hand, their viability under extreme conditions was ensured. In addition, the relative soil moisture was regularly checked with a soil moisture meter (ΔΤ-SM150 Kit, Delta-T Devices, Ltd., Cambridge, UK) to have a complementary picture of the irrigation adequacy of each treatment.
The experimental setup was organized in irrigation channels on the greenhouse benches, including 6 treatments in a completely randomized design. Each treatment had 3 replications and each replication consisted of 9 plants. The preparations were applied in conditions of rational irrigation 100% of AW, and deficit irrigation (57% of AW). Any treatment beginning with the letter K means that deficit irrigation (57% of AW) was applied. For this purpose, two control treatments were used: C (100% of AW) and KC (57% of AW). Two commercial bacterial-based formulations were used: the biostimulant HYDROMAAT, FUTURECO BIOSCIENCE® containing Sinorhizobium meliloti cepa B2352 (2% w/w) applied on SM (100% of AW) and KSM (57% of AW) treatments, and the biofungicide SERENADE ASO, BAYER® containing B. amyloliquefaciens QST 713 (1.34% w/w) applied on BA (100% of AW) and KBA (57% of AW) treatments.
The reasoning behind choosing to study these liquid formed formulations lies in their availability on the market. Moreover, they are recommended for a wide range of crops including grapevine. Lastly, the lack of any reported cases in the literature concerning the grapevine makes this choice appropriate. HYDROMAAT is an oil dispersion (OD), which under water stress conditions, can regulate the genetic expression of the BetS protein, a glycine-betaine transporter, a molecule involved in the cell’s osmoregulation. It also regulates the proline dehydrogenase gene that plays a key role in the plant’s response to drought through osmoregulation. SERENADE ASO is a suspension concentrate (SC), recommended for a wide range of crops as well as for the vine as a biological fungicide to combat diseases caused by
Fusarium spp.,
Phytophthora spp.,
Pythium spp.,
Rhizoctonia spp., and
Verticillium spp. In addition, it has been reported for its biostimulant effect on buckwheat plants
Fagopyrum esculentum [
42].
2.2. Plant Growth Parameters
Plant growth parameters were estimated on each treatment. At the end of the experiment the total plant length (cm) (central shoot and lateral shoots) was measured with a portable meter and leaf area (cm
2) was estimated by the Image J protocol [
43], by cutting the leaves of every plant on each treatment. Total plant biomass was ascertained by determining dry weight (g). Each plant on each treatment was separated into leaves, shoots, and roots, cleaned with diH
2O, and after 48 h on 80 ± 1 °C, weighed on a precision electronic scale (KERN EG-N).
2.3. Leaf Relative Water Content
To ascertain plant stress the relative water content of the vine leaves was estimated. This method can give an easy and quick answer for the state of abiotic stress in plant leaves. According to the protocol of Bertamini et al., 2006 [
44] discs were cut from grapevine leaf segments (0.3 g fresh mass) and weighed immediately to record their fresh mass (FW), on a precision balance and immediately immersed in diH
2O where they remained for 6 h in the dark at 4 °C.
The samples were then reweighed to record their turgid fresh mass (TW) and after 24 h at 80 ± 1 °C reweighed to obtain their dry mass (DW). The leaf relative water content (LRWC) of grapevine was calculated with the equation:
2.4. Total Chlorophyll Content of V. vinifera Leaves
The amount of total chlorophyll (Ca + Cb) gives an insight into the health status of the plants and was calculated in a non-destructive way with the SPAD-502 device (Minolta Co., Ltd., Osaka, Japan). In order to test the accuracy of the measurements, the SPAD readings were positively correlated (R
2 = 0.9265) with the destructive chemical method of chlorophyll determination, according to the protocol of Uddling et al., 2007 [
45]. As an extraction solvent, 10 mL of 100% acetone was used for 0.04 g of homogenized fresh leaf tissue (2.66 cm
2 leaf disc area). The grapevine leaf samples were crushed in a mortar with a pestle, poured into glass tubes, vortexed, and left overnight in the dark at 2–4 °C. The absorption of the samples was performed in a spectrophotometer (Jasco-V630 UV-VIS, Jasco International Co., Ltd., Tokyo, Japan) at 644.8 and 661.6 nm. The total chlorophyll content was calculated by the equations of Lichtenthaler and Buschmann, 2001 [
46] and expressed in μg of fresh leaf per cm
2 of leaf area:
2.5. Determination of Proline
Grapevine leaves were sampled for the determination of proline at days 0, 56 and 122 of the experiment. The chemical determination of proline was performed according to the protocol of Carillo and Gibon, 2011 [
47] with some modifications: 4 mL of 70% ethanol was used for 0.1 g of fresh homogenized grapevine leaf tissue and then centrifuged for 10 min at 4000×
g. A total of 1 mL of the supernatant extracted solution and 2 mL of freshly prepared acid–ninhydrin solution were placed in a new test tube, and the final mixture was vortexed and incubated for 25 min in a water bath (95 °C). The reaction mixture was cooled in an ice bath until room temperature was achieved and then centrifuged for 5 min at 4000×
g. The absorbance was determined in a spectrophotometer (Jasco-V630 UV-VIS, Jasco International Co., Ltd., Tokyo, Japan) at 520 nm. A calibration curve was established (R
2 = 0.9966), using proline solutions ranging from 0.025 to 0.8 mM, in the same medium as the one used for the extraction, and the data were reported in μmol of proline g
−1 of fresh leaf weight.
2.6. Assessment of Total Phenolic Content
The determination of Total Phenolic Components (TPC) was carried out at the days 0, 56, and 122 of the experiment, by the method described by Katalinic et al., 2013 [
48] with modifications. 0.1 g of dry leaf tissue was extracted with 80% ethanol solvent and centrifuged for 15 min in 3000×
g at 12 °C. 250 μL of the supernatant extracted solution were diluted in a final volume of 10 mL diH
2O. In a new test tube, 1mL of the diluted extract solution, 4.5 mL diH
2O, 500 μL of Folin–Ciocalteu 2N reagent, and after 3 min 4 mL of dehydrated Na
2CO
3 solution 7.5%
w/
v were added. The final mixture was vortexed and then incubated in a water bath (40 °C) for 20 min in the dark (room temperature). The absorption was recorded spectrophotometrically at 765 nm (Jasco-V630 UV-VIS) against the prepared blank. Gallic acid was used as a standard for the quantification of TPC and the results were reported in mg GAE (Gallic Acid Equivalent) g
−1 of dry leaf weight.
2.7. Statistical Analysis
Statistical analysis of the mean values of the parametric data was made to evaluate the results by using the software SPSS v.26 (IBM-SPSS Statistics, Armonk, NY, USA). One-way ANOVA variance analysis was performed, and the Bonferroni criterion was utilized for statistical significance to compare the means, with a significance level of 5% (p ≤ 0.05). Different letters between treatments indicate significant differences in each table according to the Bonferroni test.
4. Discussion
In the present study, the applications of formulations containing PGPR showed a stimulating effect on grapevine saplings
V. vinifera in pot conditions, under deficit irrigation 57% of AW. Plant growth parameters such as length showed a significant quantitative increase in the application of PGPR formulations than in their absence, compared to the controls, and this result agrees with other works in which PGPR was applied [
50,
51].
Our results in PGPR treatments on increased roots and shoots dry biomass agree with those of Asari et al., 2017 [
52], where
B. amyloliquefaciens inhibited primary root growth on
Arabidopsis thaliana (Brassicales: Brassicaceae), an event that may be due to increased cytokinin levels on roots or because of the increased auxin levels that were detected on colonized roots. Also, our results agree with Vardharajua et al., 2010 [
53], where five
B. amyloliquefaciens strains inoculated on maize
Zea mays (L.) (Poales: Poaceae) increased root and shoot dry biomass under stress and non-stress conditions. For
S. meliloti, although it has been studied on a smaller scale, studies show that it creates an activating environment in the root of grapevine plants [
41,
54] including volatile organic compounds (VOCs) that are involved in stress defense mechanisms and play an important role in grapevines interaction with the environment.
An increased leaf surface of grapevine plants was observed in the stressed and non-stressed treatments with PGPR and this fact, according to the study by Horák et al., 2021 [
55], in combination with the increased weight of the leaves, could be indicative of an improvement in grape must quality. The increase in leaf area by the rhizobacterium
B. amyloliquefaciens has been mentioned before [
51] and agrees with the results of the present research.
Biological plant protection preparations are not related to plant growth promotion. However, when it comes to formulations containing PGPR, phenomena that benefit plant growth can occasionally be observed, if these formulations are applied with specific repeatability and dosage. PGPR contained in commercial formulations may enhance crops’ resistance to harsh environmental conditions such as drought stress [
56,
57,
58]. In the study of Witkowicz et al., 2019 [
42] the
B. amyloliquefaciens-based commercial formulation Serenade Aso was tested for its biostimulant potential on growth and nutrition of
F. esculentum (Caryophyllales: Polygonaceae), and resulted in a better-quality sprout production, a result that is in agreement with the beneficial effect of the same formulation in our findings, although the high levels of dry matter that was observed in the results of our work, is not reported in their research.
We also observed a high performance of PGPR formulations on plant stress indicators such as on leaf relative water content which agrees with the results of He et al., 2021 [
59] where the
Bacillus spp., was inoculated on ryegrass
Lolium perenae seed (Poales: Poaceae), improving leaf relative water content. PGPR inoculants can modulate plant antioxidant content, enriching plant metabolism by reducing ROS levels [
49].
Total phenolic components are products of the plant’s secondary metabolism and are an indicator of the metabolic status of grapevine plants [
60]. Phenols and polyphenols such as flavonoids act as antioxidants against cytotoxic toxic effects of oxygen radicals. The content of total phenolic components in all
V. vinifera treatments with PGPR was significantly increased compared to the controls, especially in the case of treatments where water stress was implemented, a fact that may be an important indicator of the behavior of grapevine plants in deficit irrigation conditions. The higher content of total phenolics in the deficit irrigation treatment with PGPR containing
S. meliloti may be an indication of its promoting effect in abiotic stress environments, as the accumulation of phenolics enhances plant metabolism, improving antioxidant enzyme production [
61] to cope with the abiotic stress, which is supported by the results of studies by Bianco & Defez 2009 [
62] with the application of
S. meliloti in barrelclover
Medicago truncatula (Fabales: Fabaceae) under salt stress. In our results, a suchlike status on the phenolic content appeared on the irrigation-stressed
V. vinifera treatments to which they were applied
S. meliloti (KSM) formulation, a depiction that has presented in other grapevine experiments, where an increased content of TPC is observed as a result of the application of PGPR [
63].
Proline shows a similar picture to the total phenolic components in our work. Proline accumulation is a known metabolic response when higher plants are exposed to water stress conditions and acts as an osmolyte in drought conditions and is involved in osmoregulation [
64]. Moreover, several studies have suggested a ROS scavenger role so its presence prevents plant oxidative damage [
49,
50,
65,
66]. Both commercial formulations were able to protect grapevine plants from water stress by increasing the content of proline in plant tissues, a fact that also applies to the work of Theoharis et al., 2012 [
67] where the addition of PGPR enhanced the accumulation of proline in grapevine tissues under cold stress. The same effect is described by Tiwari et al., 2017 [
68] where
B. amyloliquefaciens application increased proline levels in a rice crop under saline stress, and by Bittencourt et al., 2023 [
49] and Vardharajula et al., 2010 [
53] in maize crops under drought stress. In our results, contrary to the treatments that did not applied PGPR formulations, ROS did not undergo the same neutralization, due to the comparatively much lower accumulation of proline in the plant tissues, so we can assume that the oxidative damage was greater. This result is in agreement with the result of the rest stress indicators, such as the LRWC and total phenolic content, which were very low in these treatments. The rhizobacteria
B. amyloliquefaciens and
S. meliloti contained in the commercial formulations seem to enhance plant metabolism, increasing the accumulation of proline, thus creating a promoting environment that helps plants to recover more rapidly from the oxidative damage, based on the picture observed in other works [
69,
70].
The content of total chlorophyll either increases slightly or remains relatively constant in grapevine plants, while in the case of water stress the content decreases more, widening the difference between them. This difference is not only prevented by each of the PGPR formulations applied, but was overcompensated, boosting the plant metabolic defense mechanisms. Firstly, this difference may be because
B. amyloliquefaciens and
S. meliloti contribute to biological nitrogen fixation [
71]; secondly, the
B. amyloliquefaciens regulation of cytokinins [
65] plays a role in the physiological processes such as chlorophyll accumulation [
52,
72]. This picture of increased chlorophyll content in the BA and SM treatments was also presented in our previous work [
73] on grapevine saplings
V. vinifera.
Since there are no available data in the literature, the purpose of this computation was to underline the magnitude of water compensation that could be achieved by the application of PGPR
B. amyloliquefaciens and
S. meliloti formulations in the greenhouses, for the production of vine cuttings. In addition, this work may demonstrate a potential for the experimental research of the specific PGPR formulations at the level of young plants in the field, due to the encouraging results in the developmental and metabolic characteristics, which can find applications in semi-drought field conditions, helping to compensate for the lack of water. A considerable parameter of the existence of PGPR in a greenhouse environment is the elevated temperature that may slow down their population, as many beneficial bacteria thrive under lower temperatures [
74]. On the other hand, high temperature for PGPRs like
Bacillus spp. does not seem to be a deterrent factor, as several works present their successful action under intense elevated temperatures of greenhouses [
75,
76,
77], although optimal temperature conditions are a parameter that could be controlled in nurseries, for the establishment of new vineyards.
5. Conclusions
Drought, especially under elevated temperatures, can cause vegetative and biochemical changes in many Mediterranean grape varieties, and for this reason, it is important to approach alternative perspectives, regarding the management of grapevine cultivation, given climate change. In our study, these adverse conditions were simulated in the greenhouse, and our research showed that the two rhizobacteria commercial formulations managed to overcome the abiotic obstacles caused by deficit irrigation and benefit the metabolism and growth of grapevine plants. In the treatments where PGPR formulation were applied the growth of the grapevine plants was more improved, compared to the controls where no formulations were applied, as this was shown by the growth parameters such as the total length, leaf area, and total fresh and dry weight. The PGPR formulations additionally improved the total phenolic content and proline levels of grapevine, even under water deficit conditions.
This research initiates the discussion for upcoming studies for S. meliloti and corresponding PGPR formulations on grapevine, as it has been studied mostly on legumes. Additionally, we tried to simulate field soil conditions in greenhouse pots, choosing to place the vineyard soil intact under normal and deficit irrigation conditions. More field studies need to verify these results in real grape growing conditions and even more important is to investigate, if there is an impact on grape production, as some PGPR formulations enhance to a certain degree, the grape production. A future perspective in the experimentation with these formulations would be the observation of possible interactions between the microorganisms present in the soil and the microorganisms contained in PGPR formulations. For this reason, the microbiological analysis of the soil would provide valuable insights, so that there is a more accurate depiction of the mode of action of those PGPR formulations. Finally, we consider important for the future to test the formulations in steam-pasteurized soil, to obtain data on the specific mode of action of the microorganisms contained in these formulations, for the cultivation of the grapevine.
Nevertheless, the behavior investigation of grapevine plants treated with beneficial bacterial formulations, under water scarcity on field experiments, may give valuable insights in plants’ resistance. Regarding our results, we consider it necessary for a more vigorous verification of the biostimulant action of some commercial formulations containing PGPR and exist on the market as biological insecticides.
