First Description of the Female of the Trinidadian Theraphosine Spinosatibiapalpus trinitatis (Pocock, 1903) (Araneae: Theraphosidae) ^†

Abstract

The hitherto unknown female of the theraphosine Spinosatibiapalpus trinitatis (Pocock, 1903) is herein described based on the paralectotype series of the schismatotheline Neoholothele incei (F. O. Pickard-Cambridge, 1899) housed in the collections of the Natural History Museum, London.

1. Introduction

The genus Spinosatibiapalpus Gabriel & Sherwood, 2020 currently contains four species recognised by version 22.5 of the World Spider Catalog [1] namely: Spinosatibiapalpus bora Sherwood & Gabriel, 2021 [2], Spinosatibiapalpus spinulopalpus (Schmidt & Weinmann, 1997) [3], Spinosatibiapalpus tansleyi Gabriel & Sherwood, 2020 [4] and Spinosatibiapalpus trinitatis (Pocock, 1903) [5].

Originally described as Metriopelma trinitatis Pocock, 1903, S. trinitatis was based on a single male collected with the location of simply “Trinidad” [5] (p. 114). Subsequently, in 1911, Petrunkevitch [6] considered this species to belong to the genus Crypsidromus Ausserer, 1871 [7], following Simon [8] who had considered Crypsidromus synonymous with Metriopelma Becker, 1878 [9] in 1892. Strand [10] described a subspecies, Crypsidromus trinitatis pauciaculeis Strand, 1916, based on a single male, also from the general locality of “Trinidad” [10] (p. 84). One hundred years later, Gabriel [11], in his revision of Metriopelma (alongside other genera), tentatively transferred both C. trinitatis and C. trinitatis pauciaculeis to Pseudhapalopus Strand, 1907 [12] where they remained until the redescription and transfer of P. trinitatis to the newly described Spinosatibiapalpus by Gabriel and Sherwood [4]. In the same work, Gabriel and Sherwood [4] considered P. trinitatis pauciaculeis to be a junior synonym of S. trinitatis based on the near-identical morphology of the male palpal bulb, tibial apophysis and palpal tibial apophysis. This resolved the placement of the subspecies shortly after it was preliminarily considered a subspecies inquirenda by Nentwig et al. [13] whose important work served to stabilise the taxonomy of a significant number of subspecific taxa described by Embrik Strand (1876–1947) during the late nineteenth and early twentieth century. Many (but not all) of Strand’s type specimens from 1906–1917 deposited in German museums were destroyed during RAF bombing raids in the Second World War.

Despite the recent redescription of S. trinitatis, the female of this species was still unknown. Recently, JPLG contacted DS and RG regarding four female specimens which he had provisionally identified several years earlier as a potentially undescribed species of Ami Pérez-Miles, 2008 [14] (now Neischnocolus Petrunkevitch, 1925 [15] per Pérez-Miles, Gabriel and Sherwood [16]) in his joint work on another Trinidadian theraphosid spider, Neoholothele incei (F. O. Pickard-Cambridge, 1899) [17] (see Guadanucci and Weinmann [18]). JPLG had since noticed the specimens may be more congruently placed in the genus Spinosatibiapalpus. Based on this useful information, DS was able to examine these specimens, held in the Natural History Museum, London, in October 2021 and determined they were indeed Spinosatibiapalpus specimens, based on the medium quantity of labial cuspules and presence of Type I urticating setae in conjunction with their small body size. Furthermore, the general morphology of the spermathecae was superficially similar to that of the prior-known female of S. spinulopalpus. We also additionally had the opportunity to compare this material against photographs of two more recent preserved specimens of S. trinitatis, allowing us to confirm, based on spermathecal morphology and body size, that the paralectotype females of N. incei can indeed be considered conspecific with S. trinitatis.

In this work, we are thus able to describe the female of S. trinitatis for the first time, thereby providing additional and novel data for this taxon.

2. Materials and Methods

Specimens were examined under binocular microscopes. Photographs of spermathecae were made using a Canon EOS 6D Mark II attached to a Leica MZ12.5 with images stacked using Helicon Focus software. Description style follows Sherwood et al. [19]. Abbreviations, Institutes: BMNH = Natural History Museum, London, United Kingdom; SMF = Senckenberg Forschungsinstitut und Naturmuseum, Frankfurt am Main, Germany. Structures: ALE = anterior lateral eyes, AME = anterior median eyes, GP = guard plates (of spermathecae sensu Gabriel and Sherwood [4]), PLE = posterior lateral eyes, PME = posterior median eyes. Other: coll. = collector; colln. = collection; det. = determined by. Abbreviations for museum collections follow Evenhuis [20]. Leg spine terminology follows Petrunkevitch [15] with the modifications proposed by Bertani [21]: d = dorsal, v = ventral, r = retrolateral, p = prolateral. Leg formulae start with the longest leg to the shortest in order of decreasing size, e.g., 4, 1, 2, 3. Urticating setae terminology follows Cooke, Roth and Miller [22]. Palpal bulb morphology follows Bertani [23] with the modifications outlined in Gabriel and Sherwood [4]. All measurements are in mm. Authors’ emphases in [ ].

3. Results

Spinosatibiapalpus trinitatis (Pocock, 1903)

Metriopelma trinitatis Pocock, 1903: 114.

Crypsidromus trinitatis: Petrunkevitch, 1911: 56.

Crypsidromus trinitatis pauciaculeis Strand, 1916: 85.

Pseudhapalopus trinitatis: Gabriel, 2016: 87.

Pseudhapalopus trinitatis pauciaculeis: Gabriel, 2016: 87.

Pseudhapalopus trinitatis pauciaculeis: Nentwig et al., 2019: 45. (subspecies inquirenda)

Spinosatibiapalpus trinitatis: Gabriel and Sherwood, 2020: 311, figs. 35–41.

LSID: [urn:lsid:nmbe.ch:spidersp:002215]

Type material: Holotype ♂ Metriopelma trinitatis (BMNH 1901.8.1.7), Trinidad, coll. W. Ince, examined; holotype ♂ Crypsidromus trinitatis pauciaculeis (SMF 2669), Mittel-Südamerika, Trinidad und Tobago, Trinidad, Gerold leg. 1888, E. Strand det., examined; paralectotypes 4 ♀♀ Neoholothele incei [not conspecific to lectotype] (BMNH 1898.4.2.56–63), Trinidad, coll. W. Ince, examined.

Diagnosis: (modified from Gabriel and Sherwood [4]) S. trinitatis can be distinguished from males of S. spinulopalpus by the absence of a tibial apophysis (tibial apophysis present in S. spinulopalpus), from S. tansleyi by the PI longer than the PS (PS longer than PI in S. tansleyi) and further by its smaller body size (known total length ≤ 25.0 vs. 38.0 in holotype of S. tansleyi), and from S. bora by the weakly developed PI (PI developed in S. bora), comparatively less distinct PAR (PAR comparatively more distinct in S. bora), PI longer than PS (PS and PI of approximately equal length in S. bora), and by the increased number of spines on the palpal tibia (>20 vs. 8 in S. bora). Females of S. trinitatis can be distinguished from S. spinulopalpus by the straighter spermathecal receptacles (Figure 1) (spermathecal receptacles strongly curved retrolaterally in S. spinulopalpus, see Gabriel and Sherwood [4]). The females of S. bora and S. tansleyi are unknown.

Male: See Gabriel and Sherwood [4] (pp. 311–312, figs. 35–41).

Description of female: Paralectotype female 1 of N. incei [not conspecific to lectotype] (BMNH 1898.4.2.56–63): Total length including chelicerae: 21.7. Carapace: length 8.9, width 6.6. Caput: raised. Ocular tubercle: raised, length 0.5, width 1.4. Eyes: ALE > AME, AME > PLE, PLE > PME, anterior row procurved, posterior row recurved. Clypeus: narrow; clypeal fringe: long. Fovea: deep, slightly recurved. Chelicera: length 5.0, width 1.8. Abdomen: (damaged) length 7.8, width 3.5. Maxilla with 70–80 cuspules, covering approximately 37% of proximal edge. Labium: length 0.8, width 1.2, with 15–20 labial cuspules most separated by 0.5–1.0 × the width of a single cuspule. Labio-sternal mounds: joined. Sternum: (damaged) length 3.7, width 3.6, with three pairs of sigilla. Tarsi II–IV divided by band of setae (tarsus I missing but presumably also divided by band of setae as in all other specimens examined for this work). Metatarsal scopulae: I (unable to measure as segment missing); II 83%; III 27%; IV ascopulate. Lengths of leg and palpal segments: see

Table 1. Spinosatibiapalpus trinitatis non-type female (paralectotype female 1 of N. incei [not conspecific to lectotype]) (BMNH 1898.4.2.56–63), podomere lengths * indicates segments missing.

	I	II	III	IV	Palp
Femur	6.1	5.1	4.5	6.4	4.6
Patella	3.3	3.3	2.6	3.2	2.5
Tibia	*	3.5	3.6	4.7	3.2
Metatarsus	*	3.3	3.6	6.3	-
Tarsus	*	2.5	2.5	2.6	3.1
Total	*	17.7	16.8	23.2	13.4

. Spination: (except tibia I and metatarsus I which are missing) femur III d 0–0–2, patella III p 0–0–1, r 0–0–1, tibia II v 0–1–2 (apical), p 1–1–1, III v 1–0–2 (apical), p 0–1–3, r 1–1–1, IV v 1–2–3 (apical), p 1–2–1, r 2–2–2, palp v 0-0-1, p 0-0-2, metatarsus II v 2–0–3 (apical), p 1–0–1, III v 8–2–3 (apical), p 1–1–2, r 1–0–0, IV d 1–0–2, v 1–2–6 (4 apical), p 1–2–1, r 2–2–2. Posterior lateral spinnerets with three segments: basal 1.3, medial 0.9, digitiform apical 1.3. Posterior median spinnerets with one segment. Spermathecae with two divergent receptacles emerging from a single wide base, GP sclerotised, receptacles generally straight. (Figure 1). Urticating setae: Type I present dorsally. Colour: alcohol preserved brown.

Variation: Paralectotype female 2 of N. incei [not conspecific to lectotype] (BMNH 1898.4.2.56–63): Total length including chelicerae: 21.7. Carapace: length 7.9, width 6.1. Ocular tubercle: length 0.7, width 1.4. Eyes: ALE > AME, AME > PLE, PLE > PME. Chelicera length 5.0, width 2.0. Abdomen: length 8.8, width 4.7. Maxilla: with 40–50 cuspules, covering approximately 45% of proximal edge. Labium: length 0.8, width 1.3, with 30–35 labial cuspules. Sternum: length 3.3, width 3.0. Metatarsal scopulae: I 100%; II 82%; III 25%; IV ascopulate. Lengths of leg and palpal segments see

Table 2. Spinosatibiapalpus trinitatis non-type female (paralectotype female 2 of N. incei [not conspecific to lectotype]) (BMNH 1898.4.2.56–63), podomere lengths.

	I	II	III	IV	Palp
Femur	4.8	3.6	3.7	4.6	3.3
Patella	3.3	2.8	2.5	2.8	2.2
Tibia	3.7	3.1	2.9	4.0	2.8
Metatarsus	2.9	2.7	2.9	5.2	-
Tarsus	2.6	2.3	2.3	2.3	2.4
Total	17.3	14.5	14.3	18.9	10.7

, legs 4, 1, 3, 2. Spination: femur III d 0–0–2, IV d 0–0–1, tibia II v 0–1–0, p 1–1–1, III v 0–1–2 (apical), p 1–1–1, r 1–1–1, IV v 1–0–3 (apical), p 1–1–1, r 1–2–1, palp v 0–0–2, p 0–0–1, metatarsus I v 0–1–2 (apical), II v 0–1–2 (apical), p 0–1–2, III v 2–2–4 (apical), p 0–2–2, r 3–1–3, IV v 3–2–5 (4 apical), p 3–2–2, r 2–2–3. Posterior lateral spinnerets with three segments: basal 1.4, median 1.0, digitiform apical 1.2.

Paralectotype female 3 of N. incei [not conspecific to lectotype] (BMNH 1898.4.2.56–63): Total length including chelicerae: 17.6. Carapace: length 7.5, width 5.8. Ocular tubercle: length 0.7, width 1.2. Eyes: AME > ALE, ALE > PLE, PLE > PME. Chelicera length 3.3, width 1.9. Abdomen: length 6.8, width 5.0. Maxilla: with 50–60 cuspules, covering approximately 57% of proximal edge. Labium: length 0.9, width 1.1, with 30–35 labial cuspules. Sternum: length 2.9, width 2.8. Metatarsal scopulae: I 95%; II 80%; III 36%; IV (unable to measure as a particular leg IV matching the specimen could not be definitively associated, but presumably absent as in all other specimens examined for this work). Lengths of leg and palpal segments see

Table 3. Spinosatibiapalpus trinitatis non-type female (paralectotype female 3 of N. incei [not conspecific to lectotype]) (BMNH 1898.4.2.56–63), podomere lengths * indicates segments missing.

	I	II	III	IV	Palp
Femur	5.0	4.5	4.3	*	3.9
Patella	3.1	2.5	2.3	*	2.1
Tibia	3.4	2.8	2.6	*	2.6
Metatarsus	2.7	2.5	3.2	*	-
Tarsus	1.8	1.9	2.1	*	2.3
Total	16.0	14.2	14.5	*	10.9

. Spination: (except leg IV) femur III d 0–0–1, patella III r 0–2–0, tibia v 0–1–3 (apical), p 0–1–0, r 2–2–1, II p 0–0–2, III p 0–1–0, r 0–4–1, metatarsus I v 0–1–2 (apical), II v 0–0–2 (apical), p 0–0–2, III v 2–2–3 (apical), p 0–1–1, r 3–1–1. Posterior lateral spinnerets with three segments: basal 1.0, median 0.7, digitiform apical 1.1.

Paralectotype female 4 of N. incei [not conspecific to lectotype] (BMNH 1898.4.2.56–63): Total length including chelicerae: 21.9. Carapace: length 8.9, width 6.2. Ocular tubercle: length 0.8, width 1.5. Eyes: ALE > AME, AME > PLE, PLE > PME. Chelicera length 4.0, width 2.1. Abdomen: length 9.0, width 6.2. Maxilla: with 60–70 cuspules, covering approximately 50% of proximal edge. Labium: length 0.9, width 1.6, with 15–20 labial cuspules. Sternum: length 3.4, width 3.2. Metatarsal scopulae: I 96%; II 80%; III 22%; IV ascopulate. Lengths of leg and palpal segments see

Table 4. Spinosatibiapalpus trinitatis non-type female (paralectotype female 4 of N. incei [not conspecific to lectotype]) (BMNH 1898.4.2.56–63), podomere lengths.

	I	II	III	IV	Palp
Femur	5.2	4.8	4.7	6.0	4.2
Patella	3.6	3.0	2.7	3.0	2.6
Tibia	4.1	3.0	2.7	4.5	3.1
Metatarsus	3.3	3.2	3.7	5.1	-
Tarsus	2.4	2.3	2.2	2.5	2.5
Total	18.6	16.3	16.0	21.1	12.4

, legs 4,1,3,2. Spination: femur III d 0–0–1, patella III p 0–0–1, r 0–0–1, tibia II v 0–1–0, p 0–0–2, III 0–2–3 (apical), p 1–1–1, r 1–1–1, IV v 2–1–3 (apical), p 1–1–1, r 1–2–1, palp v 0–0–2, p 0–2–1, metatarsus I v 1–0–2 (apical), II v 0–2–3 (apical), p 1–1–1, III v 0–2–4 (3 apical), p 1–2–1, r 0–1–1, IV v 2–3–6 (3 apical), p 1–1–1, r 1–1–2. Posterior lateral spinnerets with three segments: basal 1.3, median 1.0, digitiform apical 1.3.

Other material examined: 4 ♂♂, 1 unknown [sex indeterminable] BMNH 1933.12.20.1–6 (part), Trinidad, B.W.I., August-September 1926, coll J.S. Dunkerley; 1 ♀ (BMNH 1893.11.2.4), Trinidad, Beaven Rake Esq., ‘Hapalopus incei’, Spinosatibiapalpus trinitatis det. D. Sherwood 19 October 2021.

Distribution: Trinidad (see Sherwood and Gabriel [2] for map of the distribution of all presently known Spinosatibiapalpus species).

Remarks: The paralectotype females of N. incei (numbered herein 1–4 to allow ease of reference by future workers) are fragmented. Paralectotype 1 is the specimen from which the spermathecae was dissected by a previous worker. All specimens have legs detached from the body and, in some cases, certain legs are missing entirely. Some additional legs and leg segments were found mixed in the tube which contains the lectotype male of N. incei and another male of that taxon (thereby a paralectotype but not mentioned as such in Guadanucci and Weinmann [18]) but none of the extra legs could be matched unequivocally to any particular female of S. trinitatis. Therefore, we only included data for legs found in the tube which contained the females, and which could be definitively associated with a particular specimen. Some of the extra legs found loose in the tube with the males of N. incei are considerably larger than the other legs that could be associated with the four S. trinitatis specimens. Thus, they may be from an entirely different specimen (or specimens) altogether, no longer present in the sample. This possibility is further supported by the fact the accession number accounts for 8 specimens but only 6 (two males of N. incei sensu stricto and four females of S. trinitatis) were found to be present in the tubes in the jar. Pickard-Cambridge [17] (p. 895) states that Mr. Ince collected “four males and several females” thereby not specifying the precise number of females that he received from Ince. The two other males mentioned by Pickard-Cambridge [17] are not present in the jar and are probably lost, but the extra leg segments in the jar with the two present males of N. incei are far too large to be from other males of this species and thus must originate from some other specimen(s), possibly even a species unrelated to the other two taxa found in the sample. All specimens and parts of specimens found still associated with the tubes in the original jar were recurated by DS during the course of this work.

Whilst examining the above type material DS decided to check other historical specimens in the BMNH collection and located a jar containing a single female theraphosine labelled as “Hapalopus incei” from Trinidad collected by Beaven Neave Rake (1866–1922). Pickard-Cambridge [17] (p. 895) mentions additional, non-type, material collected by Beaven Rake and Thomas Potter (these two collectors operated individually from each other) which he considered conspecific with N. incei (as H. incei) and presumably this specimen is one of those additional “examples” from Rake mentioned by Pickard-Cambridge [17]. This specimen was found to share all the secondary taxonomic characters (see introduction) found in the paralectotypes of N. incei and dissection of the spermathecae confirmed the specimen to indeed be S. trinitatis (Figure 1C).

4. Discussion

Comparison of historical material against more recently collected material, where possible, is valuable for taxonomic works. We were recently able to view photographs from a colleague of two more recently preserved specimens (one male and one female) of S. trinitatis collected 2 km north of Port of Spain. The morphology of the male palpal bulb is congruent with that of the holotype of S. trinitatis, confirming the identity of these specimens and allowing us to compare the paralectotype series of N. incei against a more recently collected female. The female shared the characters mentioned above for the paralectotype series of N. incei, especially the morphology of the spermathecae, supporting the conclusion that the paralectotype females of N. incei can indeed be considered conspecific with the holotype male of S. trinitatis. We can also therefore solidify the presence of S. trinitatis on the island of Trinidad and indicate a more precise distribution, which at the very least encompasses an area in the north of the island, close to the capital.

The distribution of the congeneric S. tansleyi still needs clarification, and its location of “west-central Trinidad” may not necessarily refer to the island of Trinidad (see Gabriel and Sherwood [4]). Additionally, the females of S. trinitatis examined for this work are all >15 mm smaller in body length in comparison to that of the holotype male of S. tansleyi. This, in our opinion, also makes conspecifity very unlikely. We have now directly examined and measured a total of 12 specimens of S. trinitatis in museum collections (6 males, 5 females and one specimen of indeterminate sex) and have observed low intrasexual and intraspecific variation in body size, with no overlap in either sex with that of the holotype male of S. tansleyi.
