Novel Variant in CLDN16: A Further Step in the Diagnosis of Familial Hypomagnesemia with Hypercalciuria and Nephrocalcinosis—A Case Report

Abstract

Familial hypomagnesemia with hypercalciuria and nephrocalcinosis (FHHNC) is a rare tubulopathy characterized by renal loss of calcium and magnesium leading to progressive renal failure. The disorder is caused by variants to the tight junction proteins claudin-16 and -19. While rare, this disorder causes a significant burden to patients based on its clinical manifestations of various electrolyte abnormalities, nephrocalcinosis, and early progression to renal failure. In this report we describe the diagnosis of a novel variant of CLDN16 which clinically presented with severe hypomagnesemia, hypocalcemia, nephrocalcinosis, and renal failure.

1. Introduction

Familial hypomagnesemia with hypercalciuria and nephrocalcinosis (FHHNC) is a rare autosomal recessive disorder caused by pathogenic variants in CLDN16 and CLDN19, which encode the tight junction proteins claudin-16 and -19 [1,2,3]. Defects in these proteins lead to defective paracellular reabsorption of magnesium and calcium in the thick ascending limb of the loop of Henle and subsequent hypomagnesemia and hypercalciuria [4]. Sequela of these electrolyte abnormalities are responsible for FHHNC’s clinical presentation, characterized by polyuria, urinary tract infections, nephrocalcinosis, and chronic kidney disease (CKD) with early progression to renal failure [5]. Biochemical findings and clinical features are suggestive of FHHNC, but genetic testing has been increasingly used in a confirmatory role.

The understanding of the pathophysiology of FHHNC continues to evolve with approximately 130 cases reported since its initial description in the 1970s. Here we add to that fund of knowledge with a case report of an individual with symptomology typical of FHHNC, with a novel variant of uncertain significance (VUS), and a pathogenic variant in CLDN16.

2. Case Report

A 43-year-old male with a longstanding history of nephrolithiasis was transferred to our hospital in late 2017. His first stone episode was at the age of 10 years and since then he has passed ‘hundreds to thousands of stones’. His past medical history is notable for gout, recurrent urinary tract infections (UTI) and CKD stage III, and creatinine (Cr) 1.7 (eGFR 53 mL/min/1.73 m²), stable over the past 13 years. He had no other hormonal or metabolic disorders. His past surgical history included multiple failed treatments with extracorporeal shockwave lithotripsy. He reported no family history of nephrolithiasis or renal disease. Prior to presentation, he was managed on hydrochlorothiazide (HCTZ) 12.5 mg daily, potassium chloride 15 mEq twice a day, colchicine 0.6 mg twice a day, and prophylactic trimethoprim/sulfamethoxazole (dose unknown).

He was transferred to the Mayo Clinic due to severe electrolyte abnormalities in October 2017. His labs were notable for a Cr of 1.95 (eGFR 49 mL/min/1.73 m²), potassium of 2.6 mmol/L, bicarbonate 26.5 mmol/L, magnesium of 0.5 mg/dL, and calcium of 5.2 mg/dL. His parathyroid hormone (PTH) was 96.3 pg/mL, vitamin D 27 ng/mL, and 1,25-dihydroxy vitamin D 47 pg/mL. Of note, the patient had had a computational tomography of this neck in the past to evaluate his elevated PTH. This showed no parathyroid adenomas or masses. CT of the abdomen and pelvis during admission was notable for extensive calcifications of the medullary regions of both kidneys consistent with nephrocalcinosis and an obstructing 1 cm right renal pelvis stone (Figure 1). The patient had a ureteral stent placed for the obstructing stone and his electrolytes were normalized with supplementation. He was discharged on magnesium oxide 800 mg four times a day, calcium carbonate 1000 mg three times a day, amiloride 5 mg daily, colchicine 0.6 mg twice a day, and allopurinol 100 mg daily, and advised to continue HCTZ 12.5 mg daily and potassium chloride 15 mEq twice a day.

He underwent a standard (30 fr) right percutaneous nephrolithotomy in December 2017. This demonstrated a large right renal pelvis stone as well as numerous stones in the collecting system and emanating from the parenchyma. Given the extensive stone burden, he was unable to be rendered visually stone-free. Stone analysis revealed a mixed composition stone, 70% calcium phosphate (apatite), 20% calcium oxalate monohydrate, and 10% calcium oxalate dehydrate.

The patient underwent a metabolic urine evaluation in January 2018. This demonstrated hypercalciuria, severe hypocitraturia, elevated urinary pH, and adequate urinary volume (

Table 1. 24 h urine samples.

24 h Urinary Parameters	January 2018 #1	January 2018 #2	May 2018	November 2020	Reference Range	Units/24 h
Volume	4.11	4.15	4.07	3.7	0.5–4	L
Calcium	327	366	320	269	<250	mg
Oxalate	25	24	22	19	20–40	mg
Citrate	<62	<62	<61	<55	>450	mg
Uric Acid	0.362	0.374	0.381	0.198	<0.800	g
Sodium	153	184	201	164	50–150	mEq/L
pH	6.732	6.671	6.599	6.973	5.8–6.2
SS calcium oxalate	2.88	2.75	2.16	2.03	6–10	RS
SS calcium phosphate	0.83	0.81	0.7	0.91	0.5–2	RS
SS uric acid	0.04	0.05	0.06	0.01	0–1	RS

). The patient was started on chlorthalidone 12.5 mg daily in lieu of HCTZ for management of hypercalciuria, his allopurinol dose was increased to 200 mg daily and he was advised to continue electrolyte supplementation.

Over the next 26 months, the patient had a total of eight ureteroscopic stone procedures to treat his extensive bilateral nephrocalcinosis. At each procedure complete stone clearance was attempted. Given the patients large stone burden, staged procedures were required. Ureteral stents were placed after each procedure and removed after 5 days unless a staged procedure was planned in the future. Of note, the patients most recent ureteroscopies were performed with the thulium fiber laser and, anecdotally, superior stone clearance was noted. Subsequent stone analysis revealed predominantly calcium phosphate (apatite) stones. Throughout this period, the patient continued to have hypercalciuria (269–320 mg/day) and hypomagnesaemia (1.2 mg/dL) on laboratory evaluations. The patient’s Cr ranged from 2.16 to 2.49 (37–30 eGFR mL/min/1.73 m²). His serum bicarbonate level ranged from 20 to 27 mmol/L. Most recently, the patient is being managed with chlorthalidone 25 mg daily, amiloride 5 mg in the morning and 10 mg nightly, 1000 mg of calcium supplementation four times a day, magnesium chloride 143 mg, and calcitriol 0.25 mg three times a week. He has been followed with renal ultrasounds and kidney–ureter–bladder X-rays every 6–9 months.

Given the constellation of electrolyte abnormalities, urinary metabolic findings, nephrocalcinosis, and childhood onset of symptoms, he was recommended for genetic testing.

3. Genetic Testing

The patient underwent genetic testing with a focused 41-gene panel (GeneDx, Gaithersburg, MD, USA) in April 2020. This showed two heterozygous variants in CLDN16: NM_006580.3:c.697G > T − p. (Gly233Cys) and NM_006580.3:c.310G > A − p. (Asp104Asn). The former variant was classified as likely pathogenic and the latter as a VUS following the ACMG/AMP 2015 guidelines [6]. A limitation of the genetic testing is that it cannot determine the phase of the reported CLDN16 variants (cis or trans). Therefore, family variant testing (FVT) was offered to the patient’s mother and brother. His mother underwent FVT, which confirmed that she carries the likely pathogenic variant and does not carry the VUS. These results, in addition to his clinical presentation, suggest the variants are in trans. The patient’s brother has not yet undergone genetic testing.

4. Discussion

As our clinical knowledge of FHHNC has grown so has our understanding of its underlying genetic causes. According to the Human Gene Mutation Database, there are 69 genetic variants described in CLDN16 and 22 variants in CLDN19 that have been associated with FHHNC [1,7]. Since FHHNC is inherited in an autosomal recessive manner, affected individuals are homozygous or compound heterozygous for the disease-causing variants. The reported pathogenic variants are located scattered across the gene, so there is no definitive genotype–phenotype correlation; although, individuals with biallelic loss-of-function variants usually progress more rapidly than individuals with missense variants.

The most frequent CLDN16 pathogenic variant is the NM_006580.3:c.453G > T − p. (Leu151Phe) being found in up to 50% of the Eastern European and German individuals with FHHNC [4,8]. The p. (Gly233Cys) present in the patient reported here is classified as likely pathogenic since it has been reported in trans with other pathogenic variant in families with FHHNC and it is predicted to impact protein function by in silico tools—such as the combined annotation-dependent depletion (CADD) and the rare exome variant ensemble learner (REVEL) [9,10,11]. Furthermore, there are other pathogenic variants at the same amino acid that have been associated with the disease.

Interestingly, the p. (Asp104Asn) was classified as a VUS by the clinical laboratory due to lack of evidence of pathogenicity. The variant lies at exon 1, in the first extracellular loop of the protein, a region very conserved throughout evolution. It is present in only one allele in the Genome Aggregation Database and it is predicted to be damaging by multiple in silico predictors [12,13]. Through family variant testing, it was proved that the CLDN16 variants were in trans. Based on the patient’s clinical presentation with a longstanding history of nephrolithiasis, gout, recurrent UTIs, early development of CKD, and classical laboratory findings, the VUS could be reclassified as likely pathogenic. Notably, most pathogenic variants reported in CLDN16 are missense located in one of the two extracellular loops, as is the case for the p. (Asp104Asn) identified in this patient [14]. The patient had manifestations of disease in childhood with a protracted course towards severe complications in adulthood. This slower disease progression highlights that the biallelic missense variants may cause partial loss of protein function.

There are currently no guidelines for the specific treatment of FHHNC. Care focuses around medical management to limit the development of profound nephrocalcinosis, with surgical intervention used to keep stone burden at bay. Thiazide diuretics are one of the mainstays of treatment and have demonstrated decreased rates of hypercalciuria; however, their effect on the course of the disease long-term has not been determined [4]. In our patient, treatment with thiazides did produce a significant change in hypercalciuria levels—demonstrating the variability in treatment response among patient with FHHNC. Hypomagnesemia, and other electrolyte abnormalities, are treated with supplementation. Amiloride may also play a role in treating patients with FHHNC; however, the mechanism of magnesium conservation with the use of the potassium-sparing diuretic is not understood. The patient also suffered from profound hypocitraturia; however, in the context of his stone composition and urinary pH, supplementation with citrate may have increased his risk of stone precipitation. Such competing considerations are common in patients with FHHNC and provide challenges in optimizing their medical management.

Despite optimal supplementation therapy, it is not uncommon for patients to require surgical intervention to address profound nephrocalcinosis. At present, our patient still has a significant stone burden despite multiple stone procedures. The development of advanced laser technology may offer opportunities for more efficient ureteroscopic procedures in the future [15]. The goals of disease management are ultimately to delay the development of renal failure. For those that do progress, renal transplantation is an effective option and has shown to resolve electrolyte abnormalities with no evidence of disease recurrence [14,16].

The etiology for renal deterioration in FHHNC patients has not been elucidated. Possible explanations include the effects of prolonged nephrocalcinosis, inflammation secondary to crystal nephropathy or renal dysplasia due to defective claudin-16 function [14,17,18]. The patient reported here has had a protracted decline which may be explained by a partial loss of function mutation, as prior studies have noted a more rapid decline when complete loss of function is seen [8]. Without an exact etiology for renal decline, management must focus on treatable sequalae.

5. Conclusions

In summary, we have examined the clinical course, diagnosis, and treatment of a middle-aged man with FHHNC. Genetic testing found a novel variant, c.310G > A − p. (Asp104Asn), that is likely pathogenic and may produce partial loss of function of CLND16. The treatment of FHHNC is complex and currently directed by best practices—utilizing both medical and surgical options. As more is understood about FHHNC and the reasons for progression to renal failure are clarified, future treatments may be better tailored.
