3D X-ray Microscopy as a Tool for in Depth Analysis of the Interfacial Interaction between a Single Carbon Fiber and an Epoxy Matrix after Mechanical Loading
Abstract
:1. Introduction
2. Materials and Methods
2.1. Materials
2.2. Specimen Preparation
2.3. Broutman Test
2.4. Optical Investigation of Specimen
2.5. Modeling
3. Results
3.1. X-ray Imaging of as-Prepared Loaded and Nonloaded Broutman Test Specimen
3.2. FE Simulation of the Stress Distribution in the Partially Debonded Fiber−Matrix Interface and the C-Fiber
3.3. Discussion
4. Conclusions
5. Outlook
Supplementary Materials
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
