Article

A Novel CARMIL2 Immunodeficiency Identified in a Subset of Cavalier King Charles Spaniels with Pneumocystis and Bordetella Pneumonia

by
Emily L. Coffey
1,*,
Liang Ma
2,
Ousmane H. Cissé
2,
Joseph A. Kovacs
2,
Katie M. Minor
1,
Antti Sukura
3,
Patrizia Danesi
4,
Steven G. Friedenberg
1,
Jonah N. Cullen
1,
Christiane Weissenbacher-Lang
5,
Julie C. Nadeau
6,
Amber M. Graham
6,
Martin N. Granick
7,
Natalie K. Branson
8,
Kyle C. Branson
9,
Barbara Blasi
5,
Casandra M. Jacobs
10 and
Eva Furrow
1
1
Department of Veterinary Clinical Sciences, College of Veterinary Medicine, University of Minnesota, Saint Paul, MN 55108, USA
2
Critical Care Medicine Department, NIH Clinical Center, National Institutes of Health, Bethesda, MD 20892, USA
3
Department of Veterinary Biosciences, University of Helsinki, 00014 Helsinki, Finland
4
Laboratory of Parasitology, Mycology and Medical Enthomology, Istituto Zooprofilattico Sperimentale delle Venezie, 35020 Legnaro, PD, Italy
5
Department of Biological Sciences and Pathobiology, Institute of Pathology, University of Veterinary Medicine Vienna, Veterinärplatz 1, 1210 Vienna, Austria
6
Veterinary Specialty Services, Manchester, MO 63021, USA
7
Pacific Northwest Pet ER & Specialty Center, Vancouver, WA 98686, USA
8
Kirkwood Animal Hospital, Kirkwood, MO 63122, USA
9
St. Luke’s Hospital, Chesterfield, MO 63017, USA
10
Desert Veterinary Medical Specialists, Peoria, AZ 85345, USA
*
Author to whom correspondence should be addressed.
J. Fungi 2024, 10(3), 198; https://doi.org/10.3390/jof10030198
Submission received: 7 February 2024 / Revised: 23 February 2024 / Accepted: 29 February 2024 / Published: 5 March 2024
(This article belongs to the Special Issue Evolving Concepts of Pneumocystis Epidemiology, Host Specificity and Evolution)
Browse Figure
Review Reports Versions Notes

Abstract

:
Pet dogs are a valuable natural animal model for studying relationships between primary immunodeficiencies and susceptibility to Pneumocystis and other opportunistic respiratory pathogens. Certain breeds, such as the Cavalier King Charles Spaniel, are over-represented for Pneumocystis pneumonia (PCP), suggesting the presence of a primary immunodeficiency in the breed. Here, we report the discovery of a CARMIL2 nonsense variant in three Cavalier King Charles Spaniel dogs with either PCP (n = 2) or refractory Bordetella pneumonia (n = 1). CARMIL2 encodes a protein that plays critical roles in T-cell activation and other aspects of immune function. Deleterious CARMIL2 variants have recently been reported in human patients with PCP and other recurrent pneumonias. In addition to opportunistic respiratory infection, the affected dogs also exhibited other clinical manifestations of CARMIL2 deficiencies that have been reported in humans, including early-onset gastrointestinal disease, allergic skin disease, mucocutaneous lesions, abscesses, autoimmune disorders, and gastrointestinal parasitism. This discovery highlights the potential utility of a natural canine model in identifying and studying primary immunodeficiencies in patients affected by PCP.

1. Introduction

Pneumocystis is a highly diverse genus of yeast-like fungal organisms that inhabit the pulmonary alveoli of mammalian hosts [1,2]. In individuals with underlying immune dysfunction, these organisms can lead to severe opportunistic infections, including life-threatening Pneumocystis pneumonia (PCP) [3]. Acquired immunodeficiencies increase susceptibility to PCP in several mammalian species. In humans, common acquired immunodeficiencies associated with PCP include co-morbidities (e.g., human immunodeficiency virus) or iatrogenic causes (e.g., immunosuppressive medications) [3,4]. Primary immunodeficiencies (PIs) also predispose to Pneumocystis infections [5]. Characterization of PIs that underlie PCP can help identify at-risk patients and advance disease management strategies for patients with this disease [5].
Pet dogs spontaneously infected with Pneumocystis canis are a valuable natural model for studying the role of host immunity and susceptibility to Pneumocystis infections [6]. Both Miniature Dachshunds and Cavalier King Charles Spaniels (CKCSs) are disproportionately affected by PCP, suggesting that inherited risk factors contribute to PCP susceptibility in these dog breeds [7,8,9]. In humans, genetic heterogeneity and the high incidence of PCP secondary to acquired immunodeficiencies complicate the discovery of genetic risk factors. In contrast, dog breeds have lower genetic diversity, allowing disease-causing variants to be more readily identified [10]. Dogs also represent an important large animal model for defining host immune responses to pathogens given similarities in the development and function of the immune systems between dogs and humans [11,12].
The purpose of this study was to describe the discovery and clinical presentation of a PI attributed to a CARMIL2 nonsense variant in two CKCSs affected by Pneumocystis canis pneumonia and one CKCS with refractory pneumonia caused by the respiratory pathogen Bordetella bronchiseptica. This discovery demonstrates the advantages of using a natural canine model to decipher the dynamics between inherited immunodeficiencies, immune function, and host susceptibility to Pneumocystis and other opportunistic respiratory pathogens.

2. Materials and Methods

2.1. CARMIL2 Variant Discovery

Prior to this study, whole genome sequencing (Illumina HiSeq2500 platform with 150-base paired-end reads) was performed on a respiratory sample obtained from a CKCS previously diagnosed with PCP (dog 1; D1) [13,14]. Quality control of reads, followed by mapping and variant calling, was performed using a previously described pipeline with minor modifications [15,16]. Briefly, the reads were mapped to the dog CanFam3.1 reference genome using BWA version 0.7.15-r1140 [17,18]. GATK tools were used to call single-nucleotide polymorphisms (SNPs) and indels [19]. Variants were filtered to remove those with a Phred-scaled quality score <20 and those with only a single read supporting the variant. Ensembl Variant Effect Predictor (VEP; RRID SCR_007931, v98) was used to annotate variants [20], and variants were further filtered for those predicted to have moderate or high impact on the protein (e.g., splice site, nonsense, frameshift, or missense). Based on the suspected autosomal recessive inheritance of PCP susceptibility in the CKCS breed [21], variants present in a homozygous state in D1 were prioritized. These variants were screened against an internal database of canine whole genome sequencing variant calls for 580 dogs of 57 breeds, including 21 CKCS dogs, to identify private and rare variants (allele frequency <0.005) [16]. For missense variants, pathogenicity was predicted using MutPred2 (RRID SCR_010778) and PolyPhen-2 HumVar (RRID SCR_013189), but variants were not filtered based on these scores [22,23]. The Human Phenotype Ontology database (RRID SCR_006016) was searched for the terms “recurrent respiratory infections” (HP:0002205) and “recurrent pneumonia” (HP:0006532) to determine whether the remaining variants were associated with these phenotypes [24]. A single variant, harboring a nonsense nucleotide change in CARMIL2, met this criterion and was selected for further investigation. The Ensembl Variation database was used to determine if the variant is a known SNP in dogs or humans [25,26].

2.2. Phenotype Cohorts

After identification of the CARMIL2 variant in D1, genotyping was performed to screen additional dogs from three phenotypic cohorts. The first cohort consisted of 11 CKCSs with a suspected PI based on a diagnosis of PCP or recurrent pneumonia from other respiratory pathogens. DNA from nine of these dogs was submitted to the University of Minnesota Canine Genetics Laboratory (UMN CGL) for genetic testing for a PI, while DNA from the other two dogs came from a collection at the National Institutes of Health (NIH) from previous research on PCP in dogs [13]. The second cohort included 15 dogs of other (not CKCSs) or unknown breeds that were previously diagnosed with PCP (Table S1). These samples also came from the collection at NIH, originating from Italy and Austria in previous studies [6,27]. The final cohort included 115 control CKCSs with no PCP or clinical suspicion of a PI. These samples were biobanked at the UMN CGL from previous studies.

2.3. CARMIL2 Genotyping

DNA was extracted from either bronchoalveolar lavage (BAL) fluid, whole blood, or cheek swabs during routine veterinary care with informed owners’ consent. To screen for the CARMIL2 variant in the first and second cohorts, standard PCR was performed to amplify a 406 bp fragment encompassing exon 11 of CARMIL2 (the location of the nonsense mutation) using forward primer 5′-CTCCAGGTGTCTGCTGAGAG-3′ and reverse primer 5′-TGGTTCTCAGAGCCTTGAGG-3′ on a Bio-Rad T100 thermal cycler (Bio-Rad Laboratories, Inc., Hercules, CA, USA). The thermocycling program started with an initial denaturation at 94 °C for 15 min, followed by 40 cycles with denaturation at 94 °C for 30 s, annealing at 58 °C for 30 s, and extension at 72 °C for 30 s and by a final elongation at 72 °C for 10 min. PCR products were then directly sequenced by Sanger sequencing.
To examine the presence of the CARMIL2 nonsense variant in the third cohort of control CKCSs, a custom TaqMan SNP Genotyping Assay (Assay ID: ANYM6AW, Thermo Fisher Scientific Inc., Waltham, MA, USA) was performed on a Bio-Rad CFX96 real-time PCR system (Bio-Rad Laboratories, Inc., Hercules, CA, USA). All dogs with PCP in the first and second cohorts were also genotyped for a CD40L p.R120* variant initially identified in a Shih Tzu dog with PCP using a previously described PCR and sequencing protocol [28].
Available medical records for dogs that were homozygous for the CARMIL2 variant were reviewed, and data related to the patient’s clinical presentation, medical history, diagnostic results, medications, and clinical outcomes were collected.

3. Results

3.1. Whole Canine Genome Sequencing and Variant Filtering

Whole genome sequencing of D1 identified eight variants that passed all filtering steps and were selected for further evaluation. These variants included seven missense variants and a nonsense variant (Table 1); all variants were detected in a homozygous state in D1, as per one of the filtering criteria. None of the missense variants were predicted to be pathogenic by PolyPhen-2 HumVar or MutPred2 (Table 1). One variant was predicted to be “possibly damaging” by PolyPhen-2 HumVar but resided in a gene that has since been retired by Ensembl. A nonsense variant in exon 11 of CARMIL2 (CanFam3.1 CFA5 g.81801920G>A, Dog10K_Boxer_Tasha CFA5 g.81791628, UniProt A0A8I3NGS3 p.R291*) was identified as the likely pathogenic variant given the role of the gene in immune function and previous reports in humans potentially linking CARMIL2 variants with PCP [29,30]. CARMIL2 variants reported to cause PI in human patients result in significantly reduced to undetectable levels of protein expression [29,30,31]. The canine CARMIL2 protein consists of 1394 amino acids; the p.R291* variant identified here results in a loss of 79% of the protein sequence. This variant is a reported SNP in dogs (rs3330142729), with a homologous counterpart also documented in humans (rs1270039585) [26]. Among the 207 dog genotypes listed in the Ensembl Variation database (as of 28 December 2023), only 1 is heterozygous for the p.R291* variant and none are homozygous, with an overall allele frequency of 0.2%; breed information is not reported for these dogs. No phenotype data were reported for the canine SNP. For humans, this site is multiallelic, including both nonsynonymous variants and synonymous SNPs. The nonsense variant (UniProt Q6F5E8 p.R290*) is rare with an allele frequency of 4.2 × 10−6 and 1.3 × 10−5 in the gnomAD exomes r2.1.1 and gnomAD genomes v3.1.2, respectively; its clinical significance in ClinVar (RRID SCR_006169) was reported as pathogenic by a single submitter based on the known pathogenicity of other CARMIL2 nonsense variants (no direct evidence provided).

3.2. CARMIL2 Genotyping

Genotyping results for CARMIL2 p.R291*are summarized in Table 2. Of the 11 additional CKCS dogs with clinical suspicion for a PI, 2 were homozygous for the CARMIL2 p.R291* variant, including 1 with PCP and 1 with refractory Bordetella pneumonia. The 9 CKCS dogs and the 15 dogs of other or unknown breeds (Table S1) with a suspected PI were homozygous for the reference allele. The CD40L p.R120* variant previously found in a Shih Tzu dog with PCP was not detected in D1 or the other 26 dogs with clinical suspicion for a PI.
Of the 21 CKCS dogs in the internal database of whole genome sequencing variant calls, 1 was heterozygous, and 20 were clear of the CARMIL2 variant. Of the 115 control CKCS dogs genotyped by the UMN CGL, 12 were heterozygous and 103 were clear of the variant. The variant allele frequency in the combined group of CKCS database and control dogs was 4.8% (95% CI 2.8–8.0%). The 559 dogs of other breeds in the internal database were all homozygous for the reference allele.

3.3. Clinical Summary for CKCSs Homozygous for the CARMIL2 Variant Allele

Clinical data for the three dogs homozygous for the CARMIL2 p.R291* variant are summarized in Table 3. D1 was an intact male CKCS diagnosed with PCP at 1.5 years of age [14]. The diagnosis was confirmed by cytology, immunohistochemistry with anti-Pneumocystis antibody, and PCR using lower respiratory samples (Figure 1). Whole genome sequencing showed that D1 was infected with two Pneumocystis populations, denoted as CK1 and CK2, potentially representing distinct species [13]. Serum electrophoresis demonstrated a low gamma globulin fraction and a peak in the alpha-2-globulin fraction. Therapy with trimethoprim–sulfonamide (TMS, 60 mg/kg/day) was initiated, but the patient died the day of starting therapy. Other previous medical history included an abscess in the stifle region, gastroenteritis, a tibial fracture, and erosive oral inflammation, all occurring within the first year of life. Postmortem examinations revealed shrunken lymph nodes and spleen with aberrant histological structures, suggesting lymphatic hypoplasia.
Dog 2 (D2) was a neutered male CKCS diagnosed with PCP at 16 months of age via PCR testing of a deep oropharyngeal swab. Immunoglobulin assays showed all values within the normal reference intervals (IgM: 350 mg/dL, RI: 100–400 mg/dL; IgG: 1200 mg/dL, RI: 670–1650 mg/dL; IgA: 240 mg/dL, RI: 35–270 mg/dL). Treatment with a 6-week course of TMS (30 mg/kg every 8 h) and an anti-inflammatory dose of prednisone (0.5 mg/kg/day) resulted in resolution of both clinical and radiographic manifestations. After completing TMS therapy, no prophylaxis to prevent recurrence was given. At the time of writing, one year after PCP diagnosis, the patient has not had any relapses of respiratory infection. Additional medical history included chronic diarrhea, atopic dermatitis, an anal gland abscess, and gastrointestinal (GI) parasitism.
Dog 3 (D3) was an intact male CKCS that suffered from a chronic cough since approximately 2 months of age. He was diagnosed with pneumonia secondary to Bordetella bronchiseptica and Mycoplasma cynos infections at 5 months of age. The diagnosis was made by a PCR panel, cytology, and cultures of endotracheal wash fluid. Pneumocystis PCR of the fluid was negative. Prednisone (1 mg/kg/day) and doxycycline therapy (5 mg/kg every 12 h) provided an initial clinical improvement in cough and respiratory effort, though the effects were transient. Bronchoscopy and BAL were performed, and the patient was diagnosed with persistent Bordetella infection via culture of the lavage fluid. The patient was then given gentamicin nebulization and enrofloxacin (10 mg/kg/day). At the time of writing, four months after initiating therapy, the patient was still receiving inhaled gentamicin. His respiratory signs have improved overall, though he still experiences an intermittent cough and exercise intolerance. Additional medical history included chronic hypocholesterolemia with mixed bowel diarrhea, giardiasis, coccidiosis, coprophagia, and masticatory muscle myositis (MMM), which was diagnosed at 3 months of age. No other causes of acquired immunodeficiency (e.g., immunosuppressive medication) were noted for any of the three dogs.

3.4. Clinical Summary for CKCSs with Suspected PI Clear of the CARMIL2 Variant Allele

Nine CKCSs with suspected PI (six males and three females) tested clear of the CARMIL2 p.R291* variant. The median age was four months (range: three months–six years), with all dogs less than one year old except for one. All dogs had a history of respiratory signs that were characterized as chronic, recurrent, or refractory to therapy. Respiratory pathogens identified included Pneumocystis alone in two dogs, Bordetella alone in one dog, and co-infections of Pneumocystis and Bordetella in one dog, Bordetella and Mycoplasma in three dogs, and Bordetella and Pasteurella in one dog. No other causes of acquired immunodeficiency were identified for any dogs.

4. Discussion

This report describes the discovery of a novel CARMIL2 nonsense variant in two CKCSs with PCP and in a third CKCS with refractory Bordetella pneumonia. CKCSs are over-represented for PCP when compared to other dog breeds [7,8], suggesting that a PI exists in the breed and increases susceptibility to opportunistic Pneumocystis infection. CARMIL2 deficiencies are also a potential underlying risk factor for PCP and other recurrent pneumonia in humans [29,30,31]. In addition to respiratory infection, several clinical parallels have been observed between these dogs and the reported human cases of CARMIL2 deficiencies, including chronic diarrhea, allergic skin disease, mucocutaneous lesions, autoimmune disorders, GI parasitism, and abscess formation [31]. Eighteen other dogs with PCP, including three CKCSs, tested clear of the CARMIL2 variant (homozygous for the reference allele); these dogs also tested clear for a CD40L variant previously reported in a Shih Tzu with PCP [28]. This suggests that additional PIs likely exist in dogs with PCP, including within the CKCS breed. The discovery of the CARMIL2 variant in dogs with PCP demonstrates shared immune responses that contribute to host defense against Pneumocystis across mammalian species. Affected dogs can serve as a natural model to improve our understanding of CARMIL2 deficiencies in humans.
P. jirovecii pneumonia was recently described in two young human patients with CARMIL2 deficiencies, although interpretation of this finding is complicated by alternative risk factors present in these patients (e.g., infliximab therapy and stem cell transplant) [29,30]. However, recurrent respiratory tract infection has also been reported as one of the most common infectious manifestations of CARMIL2 deficiencies [31,32]. CARMIL2 deficiencies produce a combined immunodeficiency with defects in T-cell, B-cell, and NK cell function [31,32,33]. CARMIL2 is a multidomain protein expressed in the cytoplasm, particularly of skin, lymphoid tissue, and the GI tract [34]. The protein is necessary for maintaining proper immune function at the cellular and molecular levels due to its roles in actin assembly, cell migration, and T-cell activation. T-cell function relies on both T-cell antigen receptors and co-signaling pathways, such as CD28. The CARMIL2 protein binds to cell membranes through vimentin and ligates CD28 and CARMA1, thereby mediating NF-kB signaling [31,33,34] and promoting T-cell activation. In mice expressing mutated CARMIL2 genes, CD28-mediated activation of T-cells is impaired, producing downstream detrimental effects on the development of effector memory CD4+ T-cells and regulatory T-cells [35,36].
Although the specific roles and relative importance of different lymphocyte subsets in Pneumocystis clearance are not fully understood, total CD4+ T-cells are a critical and well-established component of Pneumocystis immunity [37]. The effect of CARMIL2 on T-cell activation, proliferation, and differentiation provides biological support for increased susceptibility to Pneumocystis in patients with CARMIL2 immunodeficiencies. Humans with CARMIL2 variants also exhibit defects in memory B-cell formation, impaired antibody responses, and alterations in cytotoxic function [31,33,38]. While less is known about the role of B-cells and NK cells in Pneumocystis immunity, evidence suggests that these cell types also play important roles [37]. For instance, B-cells are increasingly recognized as having critical roles in antigen presentation during the immune response to Pneumocystis [39,40], providing additional avenues by which CARMIL2 deficiencies may increase risk of PCP. Collectively, CARMIL2 deficiencies lead to immune dysregulation that increases susceptibility to opportunistic pathogens like Pneumocystis.
Less than 100 human case reports of CARMIL2 immunodeficiencies have been documented [32], leaving our understanding of CARMIL2 variants and their biological implications incomplete. As dogs are affected by both the CARMIL2 variant and Pneumocystis infections, they represent a valuable natural model for studying the impact of this PI and host immune responses to Pneumocystis. Unfortunately, we are unable to draw conclusions about the interplay between the CARMIL2 variant and individual Pneumocystis species, as genome sequencing and strain identification of the Pneumocystis organism was available for only one dog (D1) [13]. No samples were available from other infected dogs for additional Pneumocystis genetic testing. Though the causative agent of human PCP (P. jirovecii) is phylogenetically different from that of dog PCP (P. canis) [13], the clinical parallels in CARMIL2 deficiencies between humans and these dogs indicate important similarities in host immune responses, regardless of the infecting Pneumocystis species.
Beyond respiratory infections, other common clinical manifestations in humans with CARMIL2 deficiencies include dermal disease, failure to thrive, other recurrent infections, allergic symptoms, chronic diarrhea, Epstein–Barr virus-related leiomyomas, mucocutaneous candidiasis, skin abscesses, and respiratory allergies [31]. The CKCSs with the CARMIL2 nonsense variant reported here also exhibited several of these clinical features, including chronic diarrhea, allergic skin disease, skin abscesses, and oral mucocutaneous lesions, with each reported in one or more affected dogs. Impaired regulatory T-cell development can increase the risk of autoimmune disease in human patients with CARMIL2 deficiencies [31,33], and one CKCS also suffered from MMM, an inflammatory myopathy that occurs when autoantibodies against 2M myofibers are produced. Interestingly, other cases of CKCSs developing MMM at a young age have been reported [41,42], but the relationship between this disorder and the CARMIL2 variant remains unclear. Parasitic infection of the GI tract, such as giardiasis, has also been reported in humans [33], and both giardiasis and other GI parasitic infections were reported in two of the three dogs in this study. One function of CD28 is the promotion of T helper 2 (Th2) cell differentiation, which is a major effector cell for helminth immunity. Therefore, both biological and clinical evidence suggests that human and canine patients affected by the CARMIL2 immunodeficiency might also be at increased risk for GI parasitism. Collectively, these findings suggest that dogs with CARMIL2 deficiencies exhibit similar clinical manifestations to those observed in humans.
These parallels between canine and human clinical manifestations of CARMIL2 immunodeficiency support the utility of a canine model for studying the natural course of this PI. Although only three dogs with the CARMIL2 variant have been identified, we anticipate that greater awareness of this PI among veterinarians, dog owners, and breeders will result in expanded genetic screening efforts and advance our understanding of the CARMIL2 variant and other immunodeficiencies. Dogs could also be used to study novel therapeutic strategies for immunodeficiencies, such as IL-2 administration, which has been proposed for humans with CARMIL2 deficiencies [29]. The CARMIL2 variant discovery also highlights how the dog might contribute to understanding host defenses against Pneumocystis.
In a 2018 meta-analysis, CKCSs represented nearly 40% of all dogs reported with PCP, raising concerns for a PI within the breed [8]. Interestingly, one study found that CKCSs with PCP have lower IgG levels and higher IgM levels than in breed- and age-matched controls [7], which mirrors the most common immunoglobulin derangements reported in human patients with CARMIL2 deficiency [29,30,31,38]. However, the relationship between CARMIL2 activity and immunoglobulin levels is not fully understood, and only two of the CKCSs reported here had immunoglobulin assays performed. In D1, serum electrophoresis showed a low gamma globulin fraction, whereas in D2, all immunoglobulin levels were within the normal range, though IgM levels were near the high end of the normal range. This finding raises the possibility that CARMIL2 variants were not responsible for the altered immunoglobulin levels observed in the previously reported CKCSs with PCP [7]. However, complete immunoglobulin assays in additional dogs with the CARMIL2 variant and PCP are needed to improve our understanding of these relationships. With improved awareness of the CARMIL2 variant and expanded genetic screening, additional dogs with this immunodeficiency can be identified, thereby offering opportunities for further investigation of CARMIL2 deficiency in both humans and animals.
The absence of the CARMIL2 variant in the 3 CKCSs and 15 other or unknown breed dogs with confirmed PCP suggests that additional PIs or acquired immunodeficiencies likely contribute to PCP susceptibility in dogs, much as in humans. All dogs with PCP also lacked the previously reported CD40L nonsense variant [28]. It is not uncommon for disease-causing variants to be restricted to a single dog breed, as some likely arose after breed formation or became more common in a particular breed due to genetic drift. For example, two different IL2RG variants have been reported to cause an X-linked severe combined immunodeficiency in dogs (OMIA: 000899-9615), and each has only been detected in a single breed [43,44,45]. Multiple genetic disorders can also co-exist in a single breed and result in similar disease manifestations, such as the multiple genetic forms of polyneuropathy existing within the Leonberger breed [46]. In the case of PCP, there are likely many different PIs across dog breeds that can contribute to susceptibility and at least one additional PI within the CKCS breed specifically. Therefore, each dog with PCP that tests clear of the described CARMIL2 and CD40L variants represents an opportunity to identify novel genetic defects for susceptibility.
Assays to define the effects of the p.R291* variant on CARMIL2 protein structure, quantity, and lymphocyte function were not performed, which is a limitation of this study. In humans, at least seven distinct homozygous variants have been identified, all of which were considered deleterious due to reduced or undetectable CARMIL2 protein levels in CD4+ and CD8+ T-cells [29,30,31]. Given the clinical evidence of an immunodeficiency in each affected dog, our findings strongly support the presence of a deleterious variant. Additionally, this canine variant produced a premature stop codon, which most commonly results in nonsense-mediated decay of mRNA that impedes protein production [47]. The premature stop codon occurs at residue 219 of the predicted 1394 protein coding amino acids. Thus, even if a truncated protein is produced, it is expected to lack approximately 80% of the expected coding sequence, including four of the five functional domains [35]. This strongly implies a loss-of-function defect with severe deleterious effects. Future studies to quantify CARMIL2 protein production and delineate the functional implications of this variant on host immunity are warranted.

5. Conclusions

This study reports the presence of a combined immunodeficiency caused by a CARMIL2 variant in three CKCSs with PCP or refractory Bordetella pneumonia. These CKCSs also suffered from non-respiratory clinical manifestations that parallel CARMIL2 immunodeficiencies in humans. Given the rarity of CARMIL2 immunodeficiencies in humans, data from naturally affected dogs might expand the understanding of biological and clinical outcomes for this condition in both species. Furthermore, genetic testing of CKCSs for the CARMIL2 variant can aid in clinical diagnosis of a PI and guide breeding practices, thus reducing the frequency of this specific immunodeficiency in the breed. Collectively, these results demonstrate the value of a natural canine model for studying the interplay between PIs, host immune responses, and Pneumocystis susceptibility.

Supplementary Materials

The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/jof10030198/s1, Table S1: Clinical data for 15 dogs previously diagnosed with PCP and clear of the CARMIL2 variant.

Author Contributions

Conceptualization, E.L.C. and E.F.; methodology, E.F., L.M., K.M.M., S.G.F. and J.N.C.; formal analysis, E.L.C., K.M.M., S.G.F., J.N.C. and E.F.; investigation, E.L.C., E.F., L.M., O.H.C., J.A.K., K.M.M., S.G.F., J.N.C., C.W.-L., P.D., J.C.N., A.M.G., M.N.G., N.K.B., K.C.B., A.S., B.B. and C.M.J.; resources, E.L.C., E.F., L.M., O.H.C., J.A.K., K.M.M., S.G.F., J.N.C., C.W.-L., P.D., J.C.N., A.M.G., M.N.G., N.K.B., K.C.B., A.S., B.B. and C.M.J.; writing—original draft preparation, E.L.C.; writing—review and editing, E.L.C., E.F., L.M., O.H.C., J.A.K., K.M.M., S.G.F., J.N.C., C.W.-L., P.D., J.C.N., A.M.G., M.N.G., N.K.B., K.C.B., A.S., B.B. and C.M.J.; visualization, L.M. and A.S. All authors have read and agreed to the published version of the manuscript.

Funding

This work was supported in part by the Intramural Research Program of the National Institutes of Health (NIH) Clinical Center, NIH, Bethesda, Maryland. E.F. was supported in part by an NIH Office of the Director Special Emphasis Research Career Award, K01OD019912, and an NIH National Center for Advancing Translational Sciences grant, UL1TR002494. S.G.F. was supported in part by an NIH Special Emphasis Research Career Award (1 K01 OD027058) in Pathology and Comparative Medicine sponsored by the Division of Comparative Medicine, Office of Research Infrastructure Programs. The content is solely the responsibility of the authors and does not necessarily represent the official views of the NIH.

Institutional Review Board Statement

For the majority of dogs in the study, samples were collected for diagnostic purposes to aid in veterinary care, and no further ethics permissions were required. For samples collected for research purposes, the animal study protocol was approved by the Institutional Review Board of the University of Minnesota (protocol code: 2201-39732A, approval date: 24 January 2022), and informed owner consent was obtained from clients.

Data Availability Statement

The whole genome data used in this manuscript are available in NCBI’s Sequence Read Archive with accession number SRR27385252.

Acknowledgments

The authors would like to thank Seppo Saari, DVM, for his assistance with the diagnostics performed on dog 1 (D1).

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Aliouat-Denis, C.-M.; Chabé, M.; Demanche, C.; Aliouat, E.M.; Viscogliosi, E.; Guillot, J.; Delhaes, L.; Dei-Cas, E. Pneumocystis Species, Co-Evolution and Pathogenic Power. Infect. Genet. Evol. 2008, 8, 708–726. [Google Scholar] [CrossRef]
  2. Sokulska, M.; Kicia, M.; Wesołowska, M.; Hendrich, A.B. Pneumocystis Jirovecii—From a Commensal to Pathogen: Clinical and Diagnostic Review. Parasitol. Res. 2015, 114, 3577–3585. [Google Scholar] [CrossRef]
  3. Morris, A.; Norris, K.A. Colonization by Pneumocystis Jirovecii and Its Role in Disease. Clin. Microbiol. Rev. 2012, 25, 297–317. [Google Scholar] [CrossRef] [PubMed]
  4. Fillatre, P.; Decaux, O.; Jouneau, S.; Revest, M.; Gacouin, A.; Robert-Gangneux, F.; Fresnel, A.; Guiguen, C.; Le Tulzo, Y.; Jégo, P.; et al. Incidence of Pneumocystis Jiroveci Pneumonia among Groups at Risk in HIV-Negative Patients. Am. J. Med. 2014, 127, 1242.e11–1242.e17. [Google Scholar] [CrossRef] [PubMed]
  5. Ibrahim, A.; Chattaraj, A.; Iqbal, Q.; Anjum, A.; Rehman, M.E.U.; Aijaz, Z.; Nasir, F.; Ansar, S.; Zangeneh, T.T.; Iftikhar, A. Pneumocystis Jiroveci Pneumonia: A Review of Management in Human Immunodeficiency Virus (HIV) and Non-HIV Immunocompromised Patients. Avicenna J. Med. 2023, 13, 23–34. [Google Scholar] [CrossRef] [PubMed]
  6. Danesi, P.; Petini, M.; Falcaro, C.; Bertola, M.; Mazzotta, E.; Furlanello, T.; Krockenberger, M.; Malik, R. Pneumocystis Colonization in Dogs Is as in Humans. Int. J. Environ. Res. Public Health 2022, 19, 3192. [Google Scholar] [CrossRef] [PubMed]
  7. Watson, P.J.; Wotton, P.; Eastwood, J.; Swift, S.T.; Jones, B.; Day, M.J. Immunoglobulin Deficiency in Cavalier King Charles Spaniels with Pneumocystis Pneumonia. J. Vet. Intern. Med. 2006, 20, 523–527. [Google Scholar] [CrossRef]
  8. Weissenbacher-Lang, C.; Fuchs-Baumgartinger, A.; Guija-De-Arespacochaga, A.; Klang, A.; Weissenböck, H.; Künzel, F. Pneumocystosis in Dogs: Meta-Analysis of 43 Published Cases Including Clinical Signs, Diagnostic Procedures, and Treatment. J. Vet. Diagn. Investig. 2018, 30, 26–35. [Google Scholar] [CrossRef] [PubMed]
  9. Lobetti, R. Common Variable Immunodeficiency in Miniature Dachshunds Affected with Pneumonocystis Carinii Pneumonia. J. Vet. Diagn. Investig. 2000, 12, 39–45. [Google Scholar] [CrossRef] [PubMed]
  10. Shearin, A.L.; Ostrander, E.A. Leading the Way: Canine Models of Genomics and Disease. Dis. Models Mech. 2010, 3, 27–34. [Google Scholar] [CrossRef]
  11. Felsburg, P.J. Overview of Immune System Development in the Dog: Comparison with Humans. Hum. Exp. Toxicol. 2002, 21, 487–492. [Google Scholar] [CrossRef]
  12. Pereira, M.; Valério-Bolas, A.; Saraiva-Marques, C.; Alexandre-Pires, G.; Pereira Da Fonseca, I.; Santos-Gomes, G. Development of Dog Immune System: From in Uterus to Elderly. Vet. Sci. 2019, 6, 83. [Google Scholar] [CrossRef]
  13. Cissé, O.H.; Ma, L.; Dekker, J.P.; Khil, P.P.; Youn, J.-H.; Brenchley, J.M.; Blair, R.; Pahar, B.; Chabé, M.; Van Rompay, K.K.A.; et al. Genomic Insights into the Host Specific Adaptation of the Pneumocystis Genus. Commun. Biol. 2021, 4, 305. [Google Scholar] [CrossRef]
  14. Sukura, A.; Saari, S.; Järvinen, A.-K.; Olsson, M.; Kärkkäinen, M.; Ilvesniemi, T. Pneumocystis Carinii Pneumonia in Dogs—A Diagnostic Challenge. J. Vet. Diagn. Investig. 1996, 8, 124–130. [Google Scholar] [CrossRef] [PubMed]
  15. Friedenberg, S.G.; Meurs, K.M. Genotype Imputation in the Domestic Dog. Mamm. Genome 2016, 27, 485–494. [Google Scholar] [CrossRef] [PubMed]
  16. Cullen, J.N.; Friedenberg, S.G. Whole Animal Genome Sequencing: User-Friendly, Rapid, Containerized Pipelines for Processing, Variant Discovery, and Annotation of Short-Read Whole Genome Sequencing Data. G3 Genes Genomes Genet. 2023, 13, jkad117. [Google Scholar] [CrossRef] [PubMed]
  17. Lindblad-Toh, K.; Wade, C.M.; Mikkelsen, T.S.; Karlsson, E.K.; Jaffe, D.B.; Kamal, M.; Clamp, M.; Chang, J.L.; Kulbokas, E.J.; Zody, M.C.; et al. Genome Sequence, Comparative Analysis and Haplotype Structure of the Domestic Dog. Nature 2005, 438, 803–819. [Google Scholar] [CrossRef] [PubMed]
  18. Li, H.; Durbin, R. Fast and Accurate Short Read Alignment with Burrows–Wheeler Transform. Bioinformatics 2009, 25, 1754–1760. [Google Scholar] [CrossRef] [PubMed]
  19. McKenna, A.; Hanna, M.; Banks, E.; Sivachenko, A.; Cibulskis, K.; Kernytsky, A.; Garimella, K.; Altshuler, D.; Gabriel, S.; Daly, M.; et al. The Genome Analysis Toolkit: A MapReduce Framework for Analyzing next-Generation DNA Sequencing Data. Genome Res. 2010, 20, 1297–1303. [Google Scholar] [CrossRef] [PubMed]
  20. McLaren, W.; Gil, L.; Hunt, S.E.; Riat, H.S.; Ritchie, G.R.S.; Thormann, A.; Flicek, P.; Cunningham, F. The Ensembl Variant Effect Predictor. Genome Biol. 2016, 17, 122. [Google Scholar] [CrossRef] [PubMed]
  21. Giger, U.; Reagan, K. Hereditary and Acquired Immunodeficiencies. In Greene’s Infectious Diseases of the Dog and Cat; Elsevier/Saunders: St. Louis, MO, USA, 2021; pp. 1728–1745. [Google Scholar]
  22. Pejaver, V.; Urresti, J.; Lugo-Martinez, J.; Pagel, K.A.; Lin, G.N.; Nam, H.-J.; Mort, M.; Cooper, D.N.; Sebat, J.; Iakoucheva, L.M.; et al. Inferring the Molecular and Phenotypic Impact of Amino Acid Variants with MutPred2. Nat. Commun. 2020, 11, 5918. [Google Scholar] [CrossRef] [PubMed]
  23. Adzhubei, I.A.; Schmidt, S.; Peshkin, L.; Ramensky, V.E.; Gerasimova, A.; Bork, P.; Kondrashov, A.S.; Sunyaev, S.R. A Method and Server for Predicting Damaging Missense Mutations. Nat. Methods 2010, 7, 248–249. [Google Scholar] [CrossRef] [PubMed]
  24. Köhler, S.; Gargano, M.; Matentzoglu, N.; Carmody, L.C.; Lewis-Smith, D.; Vasilevsky, N.A.; Danis, D.; Balagura, G.; Baynam, G.; Brower, A.M.; et al. The Human Phenotype Ontology in 2021. Nucleic Acids Res. 2021, 49, D1207–D1217. [Google Scholar] [CrossRef] [PubMed]
  25. Hunt, S.E.; McLaren, W.; Gil, L.; Thormann, A.; Schuilenburg, H.; Sheppard, D.; Parton, A.; Armean, I.M.; Trevanion, S.J.; Flicek, P.; et al. Ensembl Variation Resources. Database 2018, 2018, bay119. [Google Scholar] [CrossRef] [PubMed]
  26. Martin, F.J.; Amode, M.R.; Aneja, A.; Austine-Orimoloye, O.; Azov, A.G.; Barnes, I.; Becker, A.; Bennett, R.; Berry, A.; Bhai, J.; et al. Ensembl 2023. Nucleic Acids Res. 2023, 51, D933–D941. [Google Scholar] [CrossRef] [PubMed]
  27. Weissenbacher-Lang, C.; Fuchs-Baumgartinger, A.; Klang, A.; Kneissl, S.; Pirker, A.; Shibly, S.; von Ritgen, S.; Weissenböck, H.; Künzel, F. Pneumocystis Carinii Infection with Severe Pneumomediastinum and Lymph Node Involvement in a Whippet Mixed-Breed Dog. J. Vet. Diagn. Investig. 2017, 29, 757–762. [Google Scholar] [CrossRef] [PubMed]
  28. Merrill, K.; Coffey, E.; Furrow, E.; Masseau, I.; Rindt, H.; Reinero, C. X-Linked CD40 Ligand Deficiency in a 1-Year-Old Male Shih Tzu with Secondary Pneumocystis Pneumonia. Vet. Intern. Med. 2021, 35, 497–503. [Google Scholar] [CrossRef]
  29. Shamriz, O.; Simon, A.J.; Lev, A.; Megged, O.; Ledder, O.; Picard, E.; Joseph, L.; Molho-Pessach, V.; Tal, Y.; Millman, P.; et al. Exogenous Interleukin-2 Can Rescue in-Vitro T Cell Activation and Proliferation in Patients with a Novel Capping Protein Regulator and Myosin 1 Linker 2 Mutation. Clin. Exp. Immunol. 2020, 200, 215–227. [Google Scholar] [CrossRef]
  30. Yonkof, J.R.; Gupta, A.; Rueda, C.M.; Mangray, S.; Prince, B.T.; Rangarajan, H.G.; Alshahrani, M.; Varga, E.; Cripe, T.P.; Abraham, R.S. A Novel Pathogenic Variant in CARMIL2 (RLTPR) Causing CARMIL2 Deficiency and EBV-Associated Smooth Muscle Tumors. Front. Immunol. 2020, 11, 884. [Google Scholar] [CrossRef]
  31. Kolukisa, B.; Baser, D.; Akcam, B.; Danielson, J.; Bilgic Eltan, S.; Haliloglu, Y.; Sefer, A.P.; Babayeva, R.; Akgun, G.; Charbonnier, L.; et al. Evolution and Long-term Outcomes of Combined Immunodeficiency Due to CARMIL2 Deficiency. Allergy 2022, 77, 1004–1019. [Google Scholar] [CrossRef]
  32. Lévy, R.; Gothe, F.; Momenilandi, M.; Magg, T.; Materna, M.; Peters, P.; Raedler, J.; Philippot, Q.; Rack-Hoch, A.L.; Langlais, D.; et al. Human CARMIL2 Deficiency Underlies a Broader Immunological and Clinical Phenotype than CD28 Deficiency. J. Exp. Med. 2023, 220, e20220275. [Google Scholar] [CrossRef]
  33. Schober, T.; Magg, T.; Laschinger, M.; Rohlfs, M.; Linhares, N.D.; Puchalka, J.; Weisser, T.; Fehlner, K.; Mautner, J.; Walz, C.; et al. A Human Immunodeficiency Syndrome Caused by Mutations in CARMIL2. Nat. Commun. 2017, 8, 14209. [Google Scholar] [CrossRef]
  34. Stark, B.C.; Lanier, M.H.; Cooper, J.A. CARMIL Family Proteins as Multidomain Regulators of Actin-Based Motility. Mol. Biol. Cell 2017, 28, 1713–1723. [Google Scholar] [CrossRef]
  35. Roncagalli, R.; Cucchetti, M.; Jarmuzynski, N.; Grégoire, C.; Bergot, E.; Audebert, S.; Baudelet, E.; Menoita, M.G.; Joachim, A.; Durand, S.; et al. The Scaffolding Function of the RLTPR Protein Explains Its Essential Role for CD28 Co-Stimulation in Mouse and Human T Cells. J. Exp. Med. 2016, 213, 2437–2457. [Google Scholar] [CrossRef] [PubMed]
  36. Liang, Y.; Cucchetti, M.; Roncagalli, R.; Yokosuka, T.; Malzac, A.; Bertosio, E.; Imbert, J.; Nijman, I.J.; Suchanek, M.; Saito, T.; et al. The Lymphoid Lineage–Specific Actin-Uncapping Protein Rltpr Is Essential for Costimulation via CD28 and the Development of Regulatory T Cells. Nat. Immunol. 2013, 14, 858–866. [Google Scholar] [CrossRef] [PubMed]
  37. Charpentier, E.; Ménard, S.; Marques, C.; Berry, A.; Iriart, X. Immune Response in Pneumocystis Infections According to the Host Immune System Status. JoF 2021, 7, 625. [Google Scholar] [CrossRef] [PubMed]
  38. Alazami, A.M.; Al-Helale, M.; Alhissi, S.; Al-Saud, B.; Alajlan, H.; Monies, D.; Shah, Z.; Abouelhoda, M.; Arnaout, R.; Al-Dhekri, H.; et al. Novel CARMIL2 Mutations in Patients with Variable Clinical Dermatitis, Infections, and Combined Immunodeficiency. Front. Immunol. 2018, 9, 203. [Google Scholar] [CrossRef] [PubMed]
  39. Opata, M.M.; Hollifield, M.L.; Lund, F.E.; Randall, T.D.; Dunn, R.; Garvy, B.A.; Feola, D.J. B Lymphocytes Are Required during the Early Priming of CD4+ T Cells for Clearance of Pneumocystis Infection in Mice. J. Immunol. 2015, 195, 611–620. [Google Scholar] [CrossRef]
  40. Kolls, J.K. An Emerging Role of B Cell Immunity in Susceptibility to Pneumocystis Pneumonia. Am. J. Respir. Cell Mol. Biol. 2017, 56, 279–280. [Google Scholar] [CrossRef]
  41. Di Tosto, M.; Callegari, C.; Matiasek, K.; Lacava, G.; Salvatore, G.; Muñoz Declara, S.; Betti, B.; Tirrito, F. Case Report: Atypical and Chronic Masticatory Muscle Myositis in a 5-Month Old Cavalier King Charles Spaniel. Clinical and Diagnostic Findings, Treatment and Successful Outcome. Front. Vet. Sci. 2022, 9, 955758. [Google Scholar] [CrossRef]
  42. Pitcher, G.D.C.; Hahn, C.N. Atypical Masticatory Muscle Myositis in Three Cavalier King Charles Spaniel Littermates. J. Small Anim. Pract. 2007, 48, 226–228. [Google Scholar] [CrossRef] [PubMed]
  43. Henthorn, P.; Somberg, R.; Fimiani, V.; Puck, J.; Patterson, D.; Felsburg, P. IL-2Rγ Gene Microdeletion Demonstrates That Canine X-Linked Severe Combined Immunodeficiency Is a Homologue of the Human Disease. Genomics 1994, 23, 69–74. [Google Scholar] [CrossRef]
  44. Somberg, R.L.; Pullen, R.P.; Casal, M.L.; Patterson, D.F.; Felsburg, P.J.; Henthorn, P.S. A Single Nucleotide Insertion in the Canine Interleukin-2 Receptor Gamma Chain Results in X-Linked Severe Combined Immunodeficiency Disease. Vet. Immunol. Immunopathol. 1995, 47, 203–213. [Google Scholar] [CrossRef]
  45. Donner, J.; Freyer, J.; Davison, S.; Anderson, H.; Blades, M.; Honkanen, L.; Inman, L.; Brookhart-Knox, C.A.; Louviere, A.; Forman, O.P.; et al. Genetic Prevalence and Clinical Relevance of Canine Mendelian Disease Variants in over One Million Dogs. PLoS Genet. 2023, 19, e1010651. [Google Scholar] [CrossRef]
  46. Letko, A.; Minor, K.M.; Jagannathan, V.; Seefried, F.R.; Mickelson, J.R.; Oliehoek, P.; Drögemüller, C. Genomic Diversity and Population Structure of the Leonberger Dog Breed. Genet. Sel. Evol. 2020, 52, 61. [Google Scholar] [CrossRef] [PubMed]
  47. Karousis, E.D.; Mühlemann, O. Nonsense-Mediated mRNA Decay Begins Where Translation Ends. Cold Spring Harb. Perspect. Biol. 2019, 11, a032862. [Google Scholar] [CrossRef] [PubMed]
Jof 10 00198 g001
Figure 1. Lung tissue samples from D1 stained with hematoxylin–eosin (HE) and modified Grocott’s methenamine silver (GMS) conducted in a previous study [15]. (a) HE staining showing alveolar spaces filled with foamy eosinophilic exudates, a typical characteristic of Pneumocystis pneumonia. (b) GMS showing Pneumocystis cysts (arrowheads) within alveolar spaces.
Figure 1. Lung tissue samples from D1 stained with hematoxylin–eosin (HE) and modified Grocott’s methenamine silver (GMS) conducted in a previous study [15]. (a) HE staining showing alveolar spaces filled with foamy eosinophilic exudates, a typical characteristic of Pneumocystis pneumonia. (b) GMS showing Pneumocystis cysts (arrowheads) within alveolar spaces.
Jof 10 00198 g001
Table 1. Genetic variants with moderate-to-high impact (e.g., missense, nonsense, frameshift) identified in a homozygous state in a Cavalier King Charles Spaniel dog with Pneumocystis pneumonia and rare in a canine population database.
Table 1. Genetic variants with moderate-to-high impact (e.g., missense, nonsense, frameshift) identified in a homozygous state in a Cavalier King Charles Spaniel dog with Pneumocystis pneumonia and rare in a canine population database.
Genomic Alteration (CanFam3.1)GeneUniProt IDProtein
Alteration		PolyPhen-2 HumVar †MutPred2 †
CFA5 g.81801920G>ACARMIL2A0A8I3NGS3p.R291*NANA
CFA7 g.39301677C>TLBRA0A8C0SLC1p.P356L0.070.29
CFA7 g.40051413G>ANVLA0A8C0M6L5p.R134Q0.000.05
CFA14 g.32122502C>GENSCAFG00000002455A0A8I3N264p.R90Q0.000.31
CFA23 g.9564400C>GENSCAFG00000048903 ‡NA ‡p.Q618H0.540.47
CFA30 g.38173284A>CC30H15orf39A0A8C0TAG0p.E61A0.120.27
CFA30 g.38174844G>AC30H15orf39A0A8C0TAG0p.A581T0.030.05
Only the CARMIL2 variant (in bold) was predicted to be pathogenic for a primary immunodeficiency. † PolyPhen-2 HumVar and MutPred2 scores range from 0–1; a score of ≥0.5 indicates potential pathogenicity, and higher scores have lower false-positive rates. ‡ This gene and its associated transcript (ENSCAFT00000086561) and protein (ENSCAFP00000052210) have been retired.
Table 2. CARMIL2 variant (CFA5 g.81801920G>A; p.R291*) allele frequency in dogs with clinical suspicion for a primary immunodeficiency (n = 27) and in population controls (n = 695).
Table 2. CARMIL2 variant (CFA5 g.81801920G>A; p.R291*) allele frequency in dogs with clinical suspicion for a primary immunodeficiency (n = 27) and in population controls (n = 695).
CARMIL2 p.R291* Genotypes #Total Number of DogsVariant Allele Frequency
(var Alleles/Total Alleles)
var/varvar/refref/ref
PI suspects *
CKCS3 (2)09 (3)1225%
Other/unknown breeds 0015 (15)150%
Breed/population controls
CKCS0131231364.8%
Other/unknown breed005595590%
CKCS, Cavalier King Charles Spaniel; PI, primary immunodeficiency; var, variant allele; ref, reference allele. # The values are the numbers of dogs for each genotype, with the number of dogs with confirmed PCP provided in parentheses. * Includes dogs with confirmed Pneumocystis pneumonia (PCP) or recurrent pneumonia from other respiratory pathogens.
Table 3. Summary of clinical data for three CKCS dogs homozygous for the CARMIL2 p.R291* variant.
Table 3. Summary of clinical data for three CKCS dogs homozygous for the CARMIL2 p.R291* variant.
Age and SexDiagnosisConfirmation of DiagnosisOther ConditionsOutcome
D11.5 years, MIPCPCytology and immunocytochemistry (BAL, lung FNA); PCR, immunohistochemistry, electron microscopy (lung tissue, post-mortem)Skin abscess, early onset GI disease, erosive oral lesionsDied on the day of TMS therapy initiation
D216 months, MNPCPPCR (deep oropharyngeal swab)Atopic dermatitis, chronic diarrhea, GI parasitism Complete response to TMS and prednisone
D35 months, MIRefractory Bordetella pneumoniaAerobic culture (BAL fluid) and PCR (oropharyngeal swab)MMM, hypocholesterolemia, chronic diarrhea, GI parasitismPartial clinical response to inhaled gentamicin
BAL = bronchoalveolar lavage; CKCS = Cavalier King Charles Spaniel; FNA = fine-needle aspirate; GI = gastrointestinal; MI = male intact; MMM = masticatory muscle myositis; MN = male neutered; PCP = Pneumocystis pneumonia; TMS = trimethoprim–sulfonamide.
