Dent. J. 2019, 7(3), 76; https://doi.org/10.3390/dj7030076

Case Report
Unusual Imaging Features of Dentigerous Cyst: A Case Report
1
Laboratory of Oral & Maxillofacial Pathology, Oral Medicine and Oral and Maxillofacial Pathology Unit, Division of Oral Maxillofacial Surgery, Department of Surgery, Geneva University Hospitals, University of Geneva, 1211 Geneva, Switzerland
2
Centre for Diagnosis and Treatment of Oral Diseases, Ribeirão Preto 14025-250, Brazil
*
Author to whom correspondence should be addressed.
Received: 26 March 2019 / Accepted: 5 July 2019 / Published: 1 August 2019

Abstract

:
Dentigerous cysts (DC) are cystic lesions radiographically represented by a well-defined unilocular radiolucent area involving an impacted tooth crown. We present an unusual radiographic feature of dentigerous cyst related to the impacted mandibular right second molar, in a 16-year-old patient, which suggested an ameloblastoma or odontogenic keratocyst (OKC) because of its multilocular appearance seen on the panoramic radiography. A multi-slice computed tomography (MSCT), however, revealed a unilocular lesion without septations, with an attenuation coefficient from 3.9 to 22.9 HU suggesting a cystic lesion. Due to its extension, a marsupialization was performed together with the histopathological analysis of the fragment removed which suggested a dentigerous cyst. Nine months later, the lesion was reduced in size and then totally excised. The impacted mandibular right second molar was also extracted. Histopathological examination confirmed the diagnosis of a dentigerous cyst. One year later, the panoramic radiography showed a complete mandible bone healing. Large dentigerous cysts can sometimes suggest other more aggressive pathologies. Precise diagnosis is important to avoid mistakes since DC, OKC and ameloblastoma require different treatments. Histological examination is, therefore, essential to establish a definitive diagnosis. In our case, MSCT and the tissue attenuation coefficient analysis contributed to guide the diagnosis and management of the dentigerous cyst.
Keywords:
dentigerous cyst; radiographic differential diagnosis; multislice computed tomography; hounsfield unit analysis

1. Introduction

A dentigerous cysts (DC) are defined as cystic lesions involving the crown of impacted teeth caused by fluid accumulation between the follicular epithelium and the crown of the tooth. It is considered the most common type of noninflammatory odontogenic cyst, and it occurs mainly in the lower third molar tooth of male patients with peak incidences in adolescents or young adults. Dentigerous cysts present a slow painless swelling and can cause the teeth displacement or teeth and bone resorption. Large cysts, however, may be associated with pain [1,2,3,4]. Histologically, they are represented by a cavity lined by the non-keratinizing thin epithelium without rete pegs. Their wall is usually fibrous and devoid of inflammatory cells [1].
Radiographically, DCs often present a unilocular radiolucent area around the crown of the impacted tooth surrounded by a well-defined sclerotic area [1,2,4,5]. Large cysts may cause cortical bone expansion. Moreover, DCs can rarely show a multilocular feature in the panoramic radiography. This is probably due to the cyst growth in areas of different bone densities [2]. In this case, the differential diagnosis should be made with other more aggressive lesions, such as ameloblastomas, odontogenic keratocysts (OKCs), other odontogenic tumours [1,2,3].
Computed tomography (CT), such as Cone Beam CT (CBCT) or multi-slice computed tomography (MSCT), has an important application in the evaluation of head and neck lesions. It is a non-invasive technique that permits the lesion size and margins, the bone destruction and expansion patterns to be precisely analysed [6,7]. In addition, MSCT provides an accurate measurement of the tissue attenuation coefficient [7,8,9,10]. Each tissue has the ability to absorb a certain proportion of X-rays as the bone, for example, which absorbs a lot of X-rays while the air almost none. An arbitrary scale named the Hounsfield scale shows these attenuation coefficients: −1000 Hounsfield unit (HU) represents the air attenuation, 0 is the water attenuation and +1000 HU is the bone attenuation [7,8].
This paper illustrates a case of an unusual dentigerous cyst initially diagnosed as ameloblastoma due to its multiloculated feature observed in panoramic radiography.

2. Case Presentation

A 16-year-old male was referred to the Centre for Diagnosis and Treatment of Oral Diseases with a clinical diagnosis of ameloblastoma having hemi-mandibulectomy as the suggested therapy. At admission, no relevant aspects within his medical history were observed. He brought a panoramic radiography (Figure 1) which revealed the presence of a multilocular lesion involving the impacted mandibular right second molar suggesting mainly an ameloblastoma or an OKC. It extended from the right mandibular notch to the lower right first premolar. A displacement of the mandibular canal and the lower right third molar towards the mandibular notch was also observed. We had access to another radiography taken at the age of thirteen, which presented a well-defined sclerotic area around the crown of the mandibular right second molar suggesting a hyperplastic dental follicle or a dentigerous cyst (Figure 2). During those three years, the patient did not consult. Intraoral examination revealed a slight painless swelling of the buccal and lingual cortical extending from the lower right first molar region to the mandibular branch (not shown).
With the aim of further analysis of the lesion, an MSCT (Figure 3) was carried out, and unlike the panoramic radiography, it showed an area of hypoattenuation without septations. The Hounsfield unit (HU) value in the lesion varied from 3.9 to 22.9 HU, which suggested a lesion containing liquid that could be compatible with a dentigerous cyst or even a unicystic ameloblastoma. From this tissue attenuation coefficient analysis, a lesion such as an ameloblastoma (solid/multicystic type), or a cystic lesion containing a cheese-like substance as found in odontogenic keratocyst could be disregarded. Because of the lesion extension, marsupialization was performed together with the histopathological analysis of the fragment removed, which suggested a dentigerous cyst. During this procedure, a clear and pale fluid flowed out of the cavity. The lesion was irrigated weekly with chlorhexidine gluconate 0.12% oral solution. During treatment, a candida (Candida sp.) infection of the contents coming from the cavity (not shown) was detected through cytological examination and promptly treated with itraconazole capsules (1× daily for 10 days). After nine months, a considerable decrease of the lesion was observed on panoramic radiography (not shown). Excision of the cystic lesion, as well as extraction of the impacted mandibular right second molar, was then performed. Histopathological examination confirmed the diagnosis of a dentigerous cyst (Figure 4). One year later, a new panoramic radiography was carried out showing a complete mandible bone healing (Figure 5). The mandibular right third molar was only removed after its migration to the retromolar region in order to cause the least surgical trauma (Figure 5).

3. Discussion and Conclusions

Although dentigerous cysts often appear as a simple radiolucent area surrounding the crown of an impacted tooth, large cysts may show a multilocular feature and suggest other lesions such as ameloblastoma and OKC [2,3]. Therefore, a histological examination is essential in order to precise the diagnosis [1,11]. Dentigerous cysts present a cavity lined by a non-keratinized stratified epithelium containing between two and three layers of cuboidal and/or flattened cells. The connective tissue wall is usually fibrous and often devoid of inflammatory cells. Odontogenic keratocysts show a cavity lined by a thin and regular parakeratinized stratified squamous epithelium without rate pegs. The basal layer cells are cuboidal or columnar and are often hyperchromatic. The lumen of these cysts contains cheese-like material representing aggregated keratin scales. Similar to the dentigerous cyst, the interface between OKC’s epithelium and connective tissue is flat. Unicystic ameloblastomas are a variant of the ameloblastoma which appear as cysts. The epithelium lining these cysts, however, is composed of ameloblastic cells showing palisading and reverse nuclear polarity. The suprabasilar areas often display a loosen stellate reticulum appearance. The same histological features are found in the solid variant of ameloblastomas [1,2].
Unlike dentigerous cysts, ameloblastomas and odontogenic keratocysts have an aggressive behaviour and require different forms of treatment. Ameloblastomas are benign odontogenic tumours that usually require a wide surgical resection [2,12] whereas dentigerous cysts are usually treated with enucleation and curettage. Odontogenic keratocysts are benign cysts which have a relatively high rate of recurrence. They are preferably treated with surgical enucleation, marsupialization, decompression or marginal resection [13,14].
We presented a case of dentigerous cyst initially diagnosed as ameloblastoma having hemi-mandibulectomy as a suggested therapy. The ameloblastoma diagnosis was given by taking only the panoramic radiography and clinical aspect into account. The multilocular feature observed in the panoramic radiography is probably due to an uneven expansion of a large dentigerous cyst in areas of different bone densities [2]. It is known that panoramic radiography is a useful aid for diagnoses, but it only shows two-dimensional images of three-dimensional structures. In addition, it has a limited value to determine the lesion size and margins, tissue composition, as well as bone destruction and expansion patterns [15]. In our study, MSCT was carried out and, unlike the panoramic radiography, it showed an area of hypoattenuation without septations (Figure 3). We also found a variation of the tissue attenuation coefficient from 3.9 to 22.9 HU, which suggested a lesion containing serous fluid compatible with the content of a dentigerous cyst [16]. According to the literature, ameloblastomas (solid/multicystic type) have 35.9 plus/minus 12.6 HU and the OKCs show 28.4 plus/minus 10.5 [17] or up to 40 HU [14]. Unicystic ameloblastomas present a Hounsfield Unit of 31.0 plus/minus 6.0 HU [17]. It is known that MSCT provides accurate measurement of the tissue attenuation coefficient [7,8,9,10]. In addition, the incisional biopsy done during the marsupialization confirmed the diagnosis of dentigerous cyst [1,11].
Because of the lesion extension [11], the marsupialization was the initial treatment of choice. Decompression and marsupialization are both conservative procedures aimed at reducing the cyst size without damaging anatomical structures such as alveolar nerve, or even causing mandibular fracture during the surgery. In addition, these techniques allow a gradual apposition of bone tissue before the complete cyst enucleation [18,19,20,21].
Through cytological examination, Candida sp. infection coming from the cavity was observed and promptly treated with itraconazole (1× daily for 10 days). The cytological smear is used in clinical practice [22] and may be useful during the marsupialization treatment.
After a considerable decrease nine months later, the lesion was excised, and the impacted mandibular right second molar was extracted. According to Anavi et al. [19], the average of dentigerous cyst decompression is 7.6 months in patients under 18 years of age. In children, only the marsupialization, decompression and/or enucleation of the dentigerous cyst have been suggested in an attempt to preserve the tooth and promote its eruption [23,24,25]. In our case, preserving the tooth was not considered possible, mainly due to the size of the cystic lesion. Histological analysis confirmed the diagnosis of a dentigerous cyst which presented a wall of uninflamed fibrous connective tissue lined by a thin non-keratinized stratified epithelium.
In case of large or radiographically unusual cystic lesions, it is mandatory to perform a biopsy before planning surgical treatment. Depending on lesion size and diagnosis, an enucleation, marsupialization or decompression could be the forms of treatment chosen. In our case, the initial incisional biopsy made during the marsupialization process provided the diagnosis of a dentigerous cyst allowing a conservative approach. In addition, the tissue attenuation coefficient analysis done by MSCT was also useful in the diagnosis process to eliminate the possibility of other lesions such as a solid ameloblastoma or an odontogenic keratocyst.

Author Contributions

C.P.M.-K. and C.M.: cytological and histopathological diagnoses; T.L., C.R.M. and C.P.M.-K.: conception and drafting of the manuscript; C.R.M. and H.R.M.: patient care and interpretation of the MSCT-scan; C.M., T.L., C.P.M.-K., C.R.M. and H.R.M.: critical revision of the manuscript.

Funding

Not applicable.

Conflicts of Interest

The authors declare that there is no conflict of interest regarding the publication of this paper.

Ethics Statement

This case report is for academic communication only. It was carried out in accordance with The Code of Ethics of the World Medical Association (Declaration of Helsinki). Written consent was obtained from a family member and every precaution was taken to protect the privacy of the patient and the confidentiality of their personal information.

References

  1. Neville, B.; Damm, D.D.; Allen, C.; Bouquot, J. Oral and Maxillofacial Pathology, 3rd ed.; Saunders: St. Louis, MO, USA, 2008; pp. 678–740. [Google Scholar]
  2. Scholl, R.J.; Kellett, H.M.; Neumann, D.P.; Lurie, A.G. Cysts and cystic lesions of the mandible: Clinical and radiologic-histopathologic review. Radiographics 1999, 19, 1107–1124. [Google Scholar] [CrossRef] [PubMed]
  3. Manor, E.; Kachko, L.; Puterman, M.B.; Szabo, G.; Bodner, L. Cystic lesions of the jaws-a clinicopathological study of 322 cases and review of the literature. Int. J. Med. Sci. 2012, 9, 20–26. [Google Scholar] [CrossRef] [PubMed]
  4. Zhang, L.L.; Yang, R.; Zhang, L.; Li, W.; MacDonald-Jankowski, D.; Poh, C.F. Dentigerous cyst: A retrospective clinicopathological analysis of 2082 dentigerous cysts in British Columbia, Canada. Int. J. Oral Maxillofac. Surg. 2010, 39, 878–882. [Google Scholar] [CrossRef] [PubMed]
  5. Terauchi, M.; Akiya, S.; Kumagai, J.; Ohyama, Y.; Yamaguchi, S. An Analysis of Dentigerous Cysts Developed around a Mandibular Third Molar by Panoramic Radiographs. Dent. J. (Basel) 2019, 4, 7. [Google Scholar] [CrossRef] [PubMed]
  6. Adbolali, F.; Zoroofi, R.A.; Otake, Y.; Sato, Y. Automatic segmentation of maxillofacial cysts in cone beam CT images. Comput. Biol. Med. 2016, 72, 108–119. [Google Scholar]
  7. Goldman, L.W. Principles of CT: Multislice CT. J. Nucl. Med. Technol. 2008, 36, 57–68. [Google Scholar] [CrossRef] [PubMed]
  8. Gupta, P.; Bhargava, S.K.; Mehrotra, G.; Rathi, V. Role of Multislice Spiral, C.T. in the Evaluation of Neck Masses. JIMSA 2013, 26, 51–54. [Google Scholar]
  9. Perron, A.D. How to read a Head CT Scan. In Emergency Medicine: Clinical Essentials, 2nd ed.; Adams, J.G., Ed.; Saunders/Elsevier: Philadelphia, PA, USA, 2013; Chapter 69; pp. 753–763. [Google Scholar]
  10. Prokop, M.; Galanski, M.; van der Molen, A.J.; Schaefer-Prokop, C. Spiral and Multislice Computed Tomography of the Body; Georg Thieme Verlag: Stuttgart, Germany, 2003; p. 1090. [Google Scholar]
  11. Motamedi, M.H.; Talesh, K.T. Management of extensive dentigerous cysts. Br Dent. J. 2005, 26, 203–206. [Google Scholar] [CrossRef]
  12. Mendenhall, W.M.; Werning, J.W.; Fernandes, R.; Malyapa, R.S.; Mendenhall, N.P. Ameloblastoma. Am. J. Clin. Oncol. 2007, 30, 645–648. [Google Scholar] [CrossRef]
  13. Borghesi, A.; Nardi, C.; Giannitto, C.; Tironi, A.; Maroldi, R.; Di Bartolomeo, F.; Preda, L. Odontogenic keratocyst: Imaging features of a benign lesion with an aggressive behaviour. Insights Imaging 2018, 9, 883–897. [Google Scholar] [CrossRef]
  14. Sánchez-Burgos, R.; González-Martín-Moro, J.; Pérez-Fernández, E.; Burgueño-García, M. Clinical, radiological and therapeutic features of keratocystic odontogenic tumours: A study over a decade. J. Clin. Exp. Dent. 2014, 6, e259–e264. [Google Scholar] [CrossRef] [PubMed]
  15. Avril, L.; Lombardi, T.; Ailianou, A.; Burkhardt, K.; Varoquaux, A.; Scolozzi, P.; Becker, M. Radiolucent lesions of the mandible: A pattern-based approach to diagnosis. Insights Imaging 2014, 5, 85–101. [Google Scholar] [CrossRef] [PubMed]
  16. Cankurtaran, C.Z.; Branstetter, B.F., 4th; Chiosea, S.I.; Barnes, E.L., Jr. Best cases from the AFIP: ameloblastoma and dentigerous cyst associated with impacted mandibular third molar tooth. Radiographics 2010, 30, 1415–1420. [Google Scholar] [CrossRef] [PubMed]
  17. Crusoé-Rebello, I.; Oliveira, C.; Campos, P.S.; Azevedo, R.A.; dos Santos, J.N. Assessment of computerized tomography density patterns of ameloblastomas and keratocystic odontogenic tumors. Oral Surg. Oral Med. Oral Pathol. Oral Radiol. Endod. 2009, 108, 604–608. [Google Scholar] [CrossRef] [PubMed]
  18. Bodner, L.; Bar-Ziv, J. Characteristics of bone formation following marsupialization of jaw cyst. Dentomaxillofac. Radiol. 1998, 27, 166–171. [Google Scholar] [CrossRef] [PubMed]
  19. Anavi, Y.; Gal, G.; Miron, H.; Calderon, S.; Allon, D.M. Decompression of odontogenic cystic lesions: Clinical long-term study of 73 cases. Oral Surg. Oral Med. Oral Pathol. Oral Radiol. Endod. 2011, 112, 164–169. [Google Scholar] [CrossRef] [PubMed]
  20. Allon, D.M.; Allon, I.; Anavi, Y.; Kaplan, I.; Chaushu, G. Decompression as a treatment of odontogenic cystic lesions in children. J. Oral Maxillofac. Surg. 2015, 73, 649–654. [Google Scholar] [CrossRef]
  21. Gendviliene, I.; Legrand, P.; Nicolielo, L.F.P.; Sinha, D.; Spaey, Y.; Politis, C.; Jacobs, R. Conservative management of large mandibular dentigerous cysts with a novel approach for follow up: Two case reports. Stomatologija 2017, 19, 24–32. [Google Scholar]
  22. Mattos, B.S.; Sousa, A.A.; Magalhães, M.H.; André, M.; Brito, E.; Dias, R. Candida albicans in patients with oronasal communication and obturator prostheses. Braz. Dent. J. 2009, 20, 336–340. [Google Scholar] [CrossRef]
  23. Hyomoto, M.; Kawakami, M.; Inoue, M.; Kirita, T. Clinical conditions for eruption of maxillary canines and mandibular premolars associated with dentigerous cysts. Am. J. Orthod. Dentofac. Orthop. 2003, 124, 515–520. [Google Scholar] [CrossRef]
  24. Hu, Y.H.; Chang, Y.L.; Tsai, A. Conservative treatment of dentigerous cyst associated with primary teeth. Oral Surg. Oral Med. Oral Pathol. Oral Radiol. Endod. 2011, 112, e5–e7. [Google Scholar] [CrossRef] [PubMed]
  25. Ghandour, L.; Bahmad, H.F.; Bou-Assi, S. Conservative Treatment of Dentigerous Cyst by Marsupialization in a Young Female Patient: A Case Report and Review of the Literature. Case Rep. Dent. 2018, 2018, 7621363. [Google Scholar] [CrossRef] [PubMed]
Figure 1. Panoramic radiography: A well-defined multiloculated radiolucent lesion involving impacted mandibular right second molar.
Figure 1. Panoramic radiography: A well-defined multiloculated radiolucent lesion involving impacted mandibular right second molar.
Dentistry 07 00076 g001
Figure 2. Panoramic radiography made at the age of thirteen: A unilocular well-defined radiolucent lesion (measuring around 4 mm) surrounding impacted mandibular right second molar.
Figure 2. Panoramic radiography made at the age of thirteen: A unilocular well-defined radiolucent lesion (measuring around 4 mm) surrounding impacted mandibular right second molar.
Dentistry 07 00076 g002
Figure 3. Sagital multi-slice computed tomography (MSCT) image: A large uniloculated lesion involving impacted mandibular right second molar. The lesion attenuation coefficient varies from 3.9 to 22.9 HU.
Figure 3. Sagital multi-slice computed tomography (MSCT) image: A large uniloculated lesion involving impacted mandibular right second molar. The lesion attenuation coefficient varies from 3.9 to 22.9 HU.
Dentistry 07 00076 g003
Figure 4. Photomicrograph: A non-keratinizing epithelial lining without rete pegs and a fibrous wall with rare inflammatory cells. HES, ×20.
Figure 4. Photomicrograph: A non-keratinizing epithelial lining without rete pegs and a fibrous wall with rare inflammatory cells. HES, ×20.
Dentistry 07 00076 g004
Figure 5. Panoramic radiography one year later: A complete mandible bone healing.
Figure 5. Panoramic radiography one year later: A complete mandible bone healing.
Dentistry 07 00076 g005
