Distinct and Quantitative Validation Method for Predictive Process Modeling with Examples of Liquid-Liquid Extraction Processes of Complex Feed Mixtures

Institute for Separation and Process Technology, Clausthal University of Technology, 38678 Clausthal-Zellerfeld, Germany
*
Author to whom correspondence should be addressed.
Processes 2019, 7(5), 298; https://doi.org/10.3390/pr7050298
Received: 18 March 2019 / Revised: 4 May 2019 / Accepted: 13 May 2019 / Published: 19 May 2019
(This article belongs to the Special Issue Processes Accelerating Biologics Manufacturing by Modelling)
  |
PDF [4883 KB, uploaded 28 May 2019]
  |

Abstract

As of today, industrial process development for liquid-liquid extraction and scale-up of extraction columns is based on an experimental procedure that requires tests in pilot-scale. This methodology consumes large amounts of material and time and the utilized scale-up equations are crude estimates including considerable safety margins. This approach is practical for well-known systems or low-value products coupled with high production scale, where such a scale-up methodology has less impact on the overall profitability. However, for new high-value products in biologics manufacturing, a process development based on process understanding and the use of validated process models is imperative. Therefore, a distinct and quantitative validation workflow for liquid-liquid extraction modeling is presented on the example of two complex feed mixtures. Monte-Carlo simulations based on the presented model parameter determination concept result for both examples in prediction accuracy comparable to the experiments and prediction precision within the deviation of the respective experiments. Identification of statistically significant parameters is demonstrated. The presented methodology for model validation will support the implementation of liquid-liquid extraction in the manufacturing of new high value biological products in regulated industries by providing a workflow to derive a Quality-by-Design compatible process model. View Full-Text
Keywords: liquid-liquid extraction; atpe; modeling; simulation; validation; verification; monte-carlo; design-of-experiments; quality-by-design; biologics liquid-liquid extraction; atpe; modeling; simulation; validation; verification; monte-carlo; design-of-experiments; quality-by-design; biologics
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
