Sci. Pharm. 2019, 87(1), 2; https://doi.org/10.3390/scipharm87010002

Article
Preliminary Phytochemical Analysis of Berberis goudotii Triana & Planch. ex Wedd. (Berberidaceae) with Anticariogenic and Antiperiodontal Activities
1
Department of Pharmacy, Faculty of Sciences, Universidad Nacional de Colombia, 111321 Bogotá, Colombia
2
Department of Chemistry, Faculty of Sciences, Pontificia Universidad Javeriana, 110231 Bogotá, Colombia
3
Dentistry Research Center, Faculty of Dentistry, Pontificia Universidad Javeriana, 110231 Bogotá, Colombia
4
Department of Microbiology, Faculty of Sciences, Pontificia Universidad Javeriana, 110231 Bogotá, Colombia
*
Authors to whom correspondence should be addressed.
Received: 17 November 2018 / Accepted: 28 December 2018 / Published: 12 January 2019

Abstract

:
Berberis goudotii is an endemic Colombian plant found in the paramo ecosystem. It has been used in food preparation and as a medicinal plant for diverse treatments. Additionally, it is used as a mouthwash to strengthen the gums and combat throat irritations and periodontitis. The present research evaluated Berberis goudotii aerial parts extract and fractions antimicrobial activities. Ultrasonic-assisted extraction was used to attain total ethanol-water extract. Solid-liquid fractionation was used to obtain hexane fraction. The residue was dispersed in water and liquid-liquid fractionation was carried-out to acquire dichloromethane, butanol and water fractions. Preliminary phytochemical analysis was performed on total extract and phenol, polyphenol, flavonoid, and proanthocyanidin, while tannin content was quantified. Antimicrobial activity assessment was performed by agar diffusion method using disks and wells employing Ceftazidime as a positive control against Streptococcus mutans, Streptococcus sobrinus, Lactobacillus acidophilus, Lactobacillus casei, Porphyromonas gingivalis, Prevotella intermedia and Fusobacterium nucleatum. Antimicrobial activity was determined as relative percentage inhibition (RPI), minimum inhibitory concentration (MIC) and minimum bactericidal concentration (MBC). Phenols (92.5 ± 7.7 mg GA/10 g), polyphenols (87.7 ± 8.1 mg PG/10 g) and tannins (44.1 ± 4.3 mg PG/10 g) were among the highest secondary metabolites observed. Total extract presented an MBC of 1.0 µg/µL against cariogenic bacteria (Streptococcus mutans and Streptococcus sobrinus) and 0.12 µg/µL against bacteria associated with periodontal disease (Porphyromonas gingivalis, Prevotella intermedia and Fusobacterium nucleatum). Butanol and hexane fractions showed antiperiodontal activity with MBC of 0.12 and 1.0 µg/µL, respectively. In conclusion, Berberis goudotii total extract demonstrated antimicrobial activity against cariogenic and periodontal microorganisms, on the other hand, hexane and butanol fractions displayed antiperiodontal activity.
Keywords:
Berberis goudotii; anticariogenic; antiperiodontal; Streptococcus mutans; Streptococcus sobrinus; Lactobacillus acidophilus; Lactobacillus casei; Porphyromonas gingivalis; Prevotella intermedia; Fusobacterium nucleatum; bacteriostatic; bactericide

1. Introduction

Oral diseases are registered as some of the most prevalent and high cost public health concerns, taking into account not only their economic burden, but their impact on the individual’s quality of life [1,2,3]. Worldwide tooth loss is attributed to caries and periodontal disease, which causes chewing dysfunction, malnutrition, low self-esteem and speech difficulties, preventing the individual from social interaction [4]. Dental caries is a disease that initially produces enamel tissue demineralization, followed by tooth decay when acidogenic bacteria, mainly Streptococcus mutans and Lactobacillus acidophilus present in the biofilm remain active in the oral cavity [5,6,7,8,9]. Demineralization ensues when an equilibrium between mineral loss, caused by these microorganisms, and mineral recovery aided by saliva is lost [10]. Periodontal disease is a chronic inflammatory disease affecting the tissue surrounding teeth, resulting in tooth loss [11]. These diseases have been classified as gingivitis, characterized only by gingival mucosa inflammation and periodontitis, where supporting tissue is destroyed, such as gum alveolar bone and periodontal ligament [12]. Its etiology has been associated with biofilm microorganisms, such as Porphyromonas gingivalis, Prevotella intermedia, Fusobacterium nucleatum and Aggregatibacter actinomycetemcomitans [9,13].
At present caries management is based on bacteria biofilm removal by tooth brushing with tooth paste, use of fluorinated substances [14,15] and sealant application, among other options that promote remineralization and preservation of dental tissue [16,17]. In regard to periodontal disease treatment, in addition to traditional protocols, recent studies report on biofilm, endotoxin and contaminated cement removal by scaling and root planning (SRP) [18,19]. Various strategies have been proposed to remove pathogens, especially in deep periodontal pockets of difficult access. One of them is a drying agent that allows for easier biofilm removal. It is a safe technique, which diminishes bacterial load, thus reducing inflammation in periodontitis treatment [20,21,22]. Likewise, other studies propose herbal chlorhexidine in post-surgery protocols, as biofilm inhibitors, providing comfort to the patient after surgery [23]. Other studies demonstrate good outcomes in periodontitis treatment using a combination of diode laser therapy with scaling and SRP [24].
However, another alternative for caries and periodontal disease treatment is based on bacterial activity inhibition by means of medicinal plants. They provide low cost solutions for the community, are less invasive and don’t have toxicity associated problems, as is the case of fluoride [25,26]. Various studies with plant extracts and secondary metabolites report high antimicrobial activity. As a case in point, macelignan obtained from Myristica fragrans acts against Streptococcus mutans [27,28,29]. Moreover, antibacterial activity was evidenced with bakuchiol (obtained from Psoralea coryfolia) against Streptococcus mutans, Streptocccus sanguis, Streptococcus salivarus, Streptococcus sobrinus, and Lactobacillus acidophilus [30]. Hwang et al. described very low isopanduratine A inhibitory concentrations, obtained from Kaempferia pandurata acting in very short time, against Streptococcus mutans, Streptococcus sobrinus, Streptocccus sanguis and Streptococcus salivarius [31]. Akhalwaya et al. reported on Spirostachys africana an effect on Streptococcus mutans reduced adhesion, suggesting potential use of this plant in dental caries treatment, periodontal disease and possibly cold sores [32]. Recently, Gamboa et al. reported antimicrobial activities against periodontal disease from Piper marginatum Jacq. and Ilex guayusa Loes extracts and fractions [33].
Colombia has a privileged geographical location, allowing for great biological resource diversity. Thus, some authors have called it the “the cradle of modern ethnobotany” [34]. In 2011 authors such as Bernal et al., reported a total of 2404 medicinal plants, 214 considered exclusive to Colombia, which have been addressed in some ethnobotanical reports and a few studies related to pharmacognosy, phytochemistry and toxicology [35]. As far as we know, Berberis rigidifolia and Berberis goudotii are endemic Colombian plants, commonly known as “Uña de gato”, “Espino” or “Tachuelo”. They have been used by indigenous, peasant and local communities for treatment or prevention of human or animal pathologies, such as ulcers, spleen swelling, diarrhea, amoebiasis, gastroenteritis, uterine hemorrhages, leishmaniasis, malaria, and rheumatic syndrome. They have also been used for antibacterial and antiprotozoal applications, including to address mouth and/or throat irritations, caries and periodontitis. These plants have also been used as febrifuge, hypotensive, diaphoretic, laxative, tonic, and as hemostatic purgative agents [35,36,37,38].
To the best of our knowledge, phytochemical analyses and pharmacognosy of the Berberis goudotti species (endemic to Colombia) have not been carried-out. Therefore, this work represents a first approximation to evaluate if the plant shows antimicrobial activity against cariogenic and periodontopathogenic bacteria, in order to support popular medicinal use for oral cavity disease prevention and treatment, such as caries and periodontitis [35,38].

2. Materials and Methods

2.1. Acquisition of Plantspecimens

Plant samples corresponding to the aerial parts (leaves, stems, flowers and fruits—Figure 1) were collected in good condition without mechanical (trauma, defoliation), biological (leaf damage by herbivores) or microbiological damage (signs or symptoms of phytopathogens). Samples came from the village of Verjón in the municipality of Bogotá (department of Cundinamarca, Colombia). This species was taxonomically identified with voucher No. COL600163 (identified by N. Salinas/2017) at the Colombian National Herbarium.

2.2. Extraction and Fractionation

Collected material was dried at 40 °C in an oven with forced air circulation. Dried plant material was ground to a moderately fine particle size. Then, by triplicate, 100 grams of ground material was exposed to ultrasound-assisted extraction (Fischer Ultrasonic, Model 60, 50 kHz) for 60 min (20 min × 1 L × 3 times) using a total of 3.0 liters of ethanol:water (7:3). The extractive solution was concentrated using rotatory-evaporation at 40 °C and water concentrated extract was lyophilized. 15 g of dried crude extract were fractionated with solvents. The hexane fraction (C6H14, 100 mL × 3 times) was obtained by solid-liquid fractionation of the extract. The insoluble residue was suspended in 100 mL of distilled water and fractionated by liquid-liquid fractionation technique, first with dichloromethane (CH2Cl2, 100 mL × 3 times) then with butanol (BuOH, 100 mL × 3 times). The organic fractions were concentrated using rotatory-evaporation at 40 °C, then evaporated to dryness in a vacuum oven at 40 °C, and finally lyophilized to remove the saturation water residue. The residual water fraction was lyophilized. The extract and all fractions were stored at −50 °C in amber bottles [40,41,42,43].

2.3. Preliminary Phytochemical Analysis

To qualitatively determine secondary metabolites, such as alkaloids, carbohydrates, coumarins, cardiotonic glycosides, steroids and triterpenes, flavonoids, phenols, naphtho- and anthraquinones, saponins, sesquiterpene lactones, tannins, and terpenes in aerial parts (leaves, stems, fruits and flowers) and total extract were subjected to preliminary phytochemical analysis [41,44,45,46,47,48]. Likewise, quantification of several secondary metabolites, such as total phenols (Folin-Ciocalteu method), flavonoids (Aluminum chloride method), proanthocyanidins (Butanol-HCl assay), polyphenols and tannins (Brazilian Pharmacopoeia method) was carried out [41,45,49,50].

2.3.1. Qualitative Determination

Alkaloids: Dragendorff’s test was performed using bismuth iodide and potassium.
Coumarins: Fluoresence test was employed using filter paper and 0.1 N NaOH solution.
Cardiotonic glycosides: Kedde test was employed using a mix of 3,5-dinitrobenzoic acid and 10% NaOH solution at a 2:1 ratio.
Steroids and triterpenes: Liebermann-Burchard test was employed using acetic anhydride and concentrated sulfuric acid.
Flavonoids: Shinoda’s test was employed using magnesium and concentrated hydrochloric acid.
Phenols: 1% Ferric chloride test.
Naphtho- and anthraquinones: Bornträger-Kraus′s test using 20 volume H2O2, 50% sulfuric acid and 5% toluene and 5% NaOH.
Saponins: Froth test was performed using strongly agitated water. If the test was positive, then hemolysis of a red blood cell suspension was performed.
Sesquiterpene lactones: Ferric hydroxamate test using 2 N hydroxamate hydrochloride, 2 N KOH and 0.5 N HCl, and 1% ferric chloride.
Tannis: Gelatine-salt test using gelatine-salt reagent, 10 M urea and 1% ferric chloride.

2.3.2. Quantitative Determination

Phenols: Approximately 1.0 g of ground plant material was weighed and 10 mL Me2CO:H2O (7:3) was added. Mix was agitated for 30 min, followed by centrifugation during 3 min at 3000 rpm. The extraction process was performed three times. At the end of the processes, supernatants were collected in a 50 mL volumetric flask and volume was completed with deionized water. Final sample solution was refrigerated at 4 °C, until metabolites were quantified. For the sample corresponding to total extract, a 1000 ppm methanol solution was prepared and stored under refrigeration at 4 °C [51].
12 µL sample (plant material or extract) as well as 200 µL distilled water were added in a microplate. In a dark room 40 µL Folin-Ciocalteu reagent (Sigma, St Louis, MO, USA) was added. The mix was agitated and incubated for 3 min at room temperature (RT). Subsequently, 12 µL 5% sodium carbonate were added and incubated at 40 °C for 30 min. Absorbance was read at 740 nm after 60-min incubation. Gallic acid solutions between 0.50 and 500 µg/mL were used for a standard curve. Results were expressed as mg gallic acid per 10 g of sample [33,52].
Flavonoids: Approximately 1.0 g of ground plant material was weighed and 10 mL MeOH was added, solution was heated under water reflux for 30 min. Solution was cooled and centrifuged for 3 min at 3000 rpm. The extraction process was carried out three times. At the end of all processes, supernatants were collected in a 100 mL volumetric flask and volume was completed with methanol [53]. The final sample solution was stored under refrigeration at 4 °C. For a total extract sample, a 1000 ppm methanol solution was prepared and stored under refrigeration at 4 °C.
125 µL sample (plant material or extract) were added in a microplate. In a dark room 125 µL 2% aluminum chloride was added. Mix was agitated and incubated for 15 min at 40 °C. Absorbance was read at 420 nm after 60-min incubation. Quercetin solutions between 1.0 and 50 µg/mL were employed as a standard curve. Results were expressed as mg quercetin per 10 g of sample [33,50].
Proanthocyanidins: Approximately 2.0 g of ground plant material was weighed and extracted by sonication with 15 mL Me2CO:H2O (7:3) for 15 min. The extraction process was carried-out three times. The final solution was filtered and volume was completed in a 100 mL volumetric flask. An extract solution aliquot of 10 mL was concentrated and 90 mL n-BuOH and 37% HCl at 95:5 ratio was added, and the solution was heated under water reflux for 2 h at 130 °C. At the end of the process the solution was transferred to a 100 mL volumetric flask and volume was completed with n-BuOH and 37% HCl at 95:5 ratio. Final solution absorbance was read at 540 nm and proanthocyanidins were quantified utilizing the equation 1:
%Proanthocyanidins = (Abs/M) × 4.115
where, Abs is sample absorbance and M is the sample mass in grams [50,54].
For the sample corresponding to the extract, approximately 100 mg were weighed and 10 mL Me2CO:H2O (7:3) were added. The sample was sonicated for 15 min at 30 °C. Subsequently it was filtered and a final volume of 50 mL was completed with Me2CO:H2O (7:3). A 20 mL aliquot was concentrated using a rotary evaporator at 40 °C. Residue was dissolved in n-BuOH and 37% HCl at a 95:5 ratio, and the solution was heated under oil reflux for 2 h. The solution was cooled and transferred into a volumetric flask. A final volume of 50 mL was completed with n-BuOH and 37% HCl at a 95:5 ratio. Absorbance was read at 540 nm using as blanc n-BuOH and 37% HCl at a 95:5 ratio of solution. Proanthocyanidins content was expressed as cyanogen chloride using equation 2:
%Proanthocyanidins = (Abs/M) × 1.02875
where, %Proanthocyanidins corresponds to proanthocyanidins percentage, Abs is sample absorbance and M is the sample mass in grams [50,53].
Polyphenols and tannins: Approximately 250 mg plant material was weighed and 15 mL deionized water was added. The solution was boiled, followed by water bath incubation at 60 °C for 30 min. The solution was allowed to cool down and then filtered and transferred to 25 mL volumetric flask, volume was completed with deionized water (solution S1) [53].
For total extract sample approximately 100 mg were weighed, and 5 mL deionized water was added. Mix was boiled, followed by water bath incubation for 30 min. The solution was allowed to cool down and then filtered and transferred to 10 mL volumetric flask, the volume was completed with deionized water (solution S2) [53].
For total polyphenol quantification 2.5 mL (solution S1 or S2) were taken and 5 mL deionized water was added in a volumetric flask. A 500 µL aliquot was taken and mixed with 200 µL Folin-Denis reactive. The volume was completed to 10 mL with 15% sodium carbonate (m/v) in a volumetric flask. Two min after adding sodium carbonate, absorbance (A1) was read at 715 nm.
For tannin quantification 2 mL solution S1 or S2 were taken and 25 mg skin powder were added, the resulting solution was agitated at 200 rpm for 60 min. Following, a dilution was performed with 1 mL of solution, taking it to a final volume of 2.5 mL. A 500 µL aliquot was taken and mixed with 200 µL Folin-Denis reactive. The volume was completed to 5 mL with 15% sodium carbonate (m/v) in volumetric flask. Two min after adding sodium carbonate, absorbance (A2) was read at 715 nm.
As a standard 5 mg pyrogallol (Sigma, St Louis, MO, USA) was dissolved in 10 mL deionized water. 500 µL aliquot was taken and completed to a final volume of 10 mL. A 500 µL aliquot was transferred to a 5 mL volumetric flask and 200 µL Folin-Denis reactive was added and volume was completed with 15% sodium carbonate (m/v) solution. Two min after adding sodium carbonate, absorbance (A3) was read at 715 nm.
Polyphenol percentage (PP) and tannin percentage (T) were expressed as percentages using the following equations: For %PP for S1 solution equation 3. For %T for S1 solution equation 4. For %PP for S2 solution equation 5. For %T for S2 solution equation 6.
%PP = (6.56 × A1)/(A3 × M)
%T = 6.56 × (A1 − A2)/(A3 × M)
%PP = (2.624 × A1)/(A3 × M)
%T = 2.624 × (A1 − A2)/(A3 × M)
where, M is sample quantity in grams, A1 is sample absorbance without treatment, A2 is sample absorbance with treatment and A3 is pyrogallol absorbance as a standard [49,53].

2.4. Anticariogenic and Antiperiodontal Activity

Anticariogenic and antiperiodontal activity was determined for total extract and its fractions using the agar diffusion technique per disc and per well [55,56,57,58,59]. Each assay was performed in biological and technical triplicates, (n = 3). A susceptibility screening for antimicrobials (antibiogram) was performed to select the positive control among 18 commercial antibiotics: amoxicillin/clavulanic acid (20/10 µg), optoquinone (5 µg), penicillin (10 µg), clindamycin (2 µg), ceftazidime (30 µg), ampicillin/sulbactam (10/10 µg), cefalotin (30 µg), novobiocin (30 µg), oxacillin (1 µg), bacitracin (0.04 µg), erythromycin (15 µg), chloramphenicol (30 µg), vancomycin (30 µg), streptomycin (10 µg), gentamicin (10 µg), amikacin (30 µg), ampicillin (10 µg) and amoxicillin (10 µg). As negative controls, C6H14, CH2Cl2, BuOH and DMSO were used [59].

2.5. Microorganisms

Evaluation of anticariogenic and antiperiodontal activity was performed using certified strains. Cariogenic bacteria; Lactobacillus acidophilus (ATCC 4365), Lactobacillus casei (ATCC 4646), Streptococcus mutans (ATCC 25175), Streptococcus sobrinus (ATCC 33478) and periodontal bacteria; Fusobacterium nucleatum (ATCC 25586), Porphyromonas gingivalis (ATCC 33277), Prevotella intermedia (ATCC 25611) were purchased from the American Type Culture Collection (ATCC) by the Center for Dental Research at the Pontificia Universidad Javeriana. Glycerol (25%) was used for strain conservation and storage at −70 °C. These conditions were necessary to maintain the genetic characteristics and bacterial resistance throughout the study.

2.6. Inoculum Preparation for Cariogenic Bacteria

All strains were reactivated under anaerobic conditions (H2: CO2: N2, 10:10:80) using BHI broth for 12 h at 37 °C. Bacteria grown in the BHI broth were plated on blood agar and incubated for 48 h at 37 °C in an anaerobic atmosphere (H2: CO2: N2, 10:10:80). Pure, viable colonies were reconfirmed using Gram stain and biochemical tests. From a pure culture of each strain to be evaluated, a suspension was prepared in BHI broth adjusted by turbidometry to a 0.5 McFarland standard (1.5 × 108 cells/mL) [60].

2.7. Inoculum Preparation for Periodontal Bacteria

Thioglycate broth (BBLTM Fluid, Becton Dickinson and Company) supplemented with hemine and menadione was added to lyophilized strains and incubated at 37 °C for 8 days under anaerobic conditions (H2: CO2: N2, 10:10:80). Then, isolation was carried-out using blood agar and Wilkins-Chalgren (Oxoid) anaerobic agar supplemented with 1% (v/v) hemin and menadione at 37 °C for 8 days under anaerobic conditions (H2: CO2: N2, 10:10:80). Then, isolation was performed using blood agar and Wilkins-Chalgren (Oxoid) anaerobic agar supplemented with 1% (v/v) hemin and menadione and incubated at 37 °C for 8 days under anaerobic conditions (H2: CO2: N2, 10:10:80). Finally, obligate anaerobic colonies were selected, and their purity was confirmed by Gram stain. Pure isolates of obligate anaerobes were identified with the RapIDTM ANA II system (Remel). Inoculum was obtained by taking 5 morphologically identical colonies from each bacterium and then they were suspended in 5 mL of BHI broth enriched with Hemin (5 µg/mL) and Menadione (1 µg/mL) and incubated for 5 days at 37 °C in anaerobiosis (H2: CO2: N2, 10:10:80). Suspension was then adjusted to the McFarland 0.5 scale (1.5 × 108 cells/mL) [58].

2.8. Agar Diffusion Methods—Disk and Well

For cariogenic bacteria, 250 μL microorganism suspension was mixed with 25 mL of Mueller-Hinton agar and poured into a Petri dish. For periodontal bacteria, 250 μL microorganism suspension was mixed with 25 mL of Wilkins-Chalgren anaerobic agar supplemented with 1% (v/v) hemin and menadione. For the disk diffusion method, blank Oxoid discs were taken and placed on Mueller-Hinton and Wilkins-Chalgren media [57]. For agar diffusion method per well (Mueller-Hinton and Wilkins-Chalgren agars), wells were perforated (6.0 mm diameter), in each well 25 µL of extract or fraction were dosed at concentrations ranging from 1.0 to 50 µg/µL. 25 µL of DSMO, C4H6, CH2Cl2, BuOH and H2O were used as negative controls and 25 µL of ceftazidime (30 µg), as a positive control. All Petri dishes were incubated under anaerobic conditions for 48 h at 37 °C for cariogenic bacteria and 8 days at 37 °C for periodontal bacteria [59]. Inhibition halos were measured (mm) and the antimicrobial activity was determined as a relative percentage of the inhibition (RPI) using as a positive control the selected antibiotic chosen from the antibiogram using the formula:
RPI = [(Di − Dn)/(Dp − Dn)] × 100
where, Di is the diameter of the inhibition zone of the extract or fraction, Dn is the inhibition zone diameter of the negative control and Dp is diameter of the positive control inhibition zone [61].

2.9. Minimum Inhibitory Concentration—Minimum Bactericidal Concentration

Minimum inhibitory concentration (MIC) is defined as the lowest concentration of the antimicrobial agent that inhibits visible growth of a microorganism under defined conditions. For this purpose, broth microdilution and agar diffusion techniques were used [59,62,63]. Total extract and fractions ranged between 0.06 and 32 µg/µL. A microplate reader was used for the microdilution technique (OD600) using 96-well plates and each well. 5 µL of the inoculum were added along with 220 µL BHI broth (for cariogenic microorganisms) or Wilkins-Chalgren broth (for periodontal bacteria), then 25 µL of each extract or fraction were added and incubated for 48 h (for cariogenic microorganisms) and 8 days (for periodontal bacteria) under anaerobic conditions at 37 °C. For the agar diffusion technique, 25 µL of the extract or fraction were taken and placed in 6 mm wells with BHI (for cariogenic bacteria) or Wilkins-Chalgren (for periodontal microorganisms) agars, previously inoculated with each microorganism. Once MIC was determined, reseeding was performed with two different concentrations, one above and one below MIC to evaluate extract and fraction bacteriostatic or bactericidal effect. Extract and fraction minimum bactericidal concentration (MBC) was determined based on the one, which did not allow visible growth of colonies in the Petri dish. If colony growth was observed, then the extract or fraction at the evaluated concentration was described to produce a bacteriostatic effect, in contrast to a bactericidal effect [64,65,66].

2.10. Statistical Analysis

All experiments were performed in triplicates (n = 3). Results are expressed as means ± standard deviations [67]. Subsequently, a completely randomized design was developed, for which parametric statistic compliance assumptions was determined by performing normality tests (Shapiro-Wilks) and homogeneity of variance (Levenne). An analysis of variance (ANOVA) was carried out with Tukey′s HSD post hoc comparison test of means to determine significant differences. For the data that did not fulfill the assumptions, transformations were performed (square root, natural logarithm, logarithm in base ten and reciprocal). Tests were performed using InfoStat/P software [67,68,69,70].

3. Results and Discussion

3.1. Extraction and Fractionation

In this study ultrasound-assisted extraction (UAE) was used to obtain Berberis goudotii total EtOH:H2O (7:3) extract [71,72]. This type of extraction (UAE) was used because it is a clean, efficient, economical, simple and environmentally friendly method, compared with the traditional techniques used to obtain raw extracts [73,74,75]. Likewise, UAE increases the content of potentially active compounds in raw extracts [76,77,78,79,80].
Total extract yield (based on dried herbal material mass) was 18.6 ± 1.6%. Since our study initiated with the Berberis goudotii phytochemical analysis, there is no information for result comparison. However, when comparing with other species of the Berberis genus such as Berberis koreana, extraction processes yields have been reported to be 8.4% with conventional extraction, 11.04% using high pressure extraction (HPE) and 12.3% for high pressure extraction with sonication (HPEWS) [81,82]. Using maceration and methanol techniques for Berberis aetnensis and Berberis libanotica extraction yields were 8.9 and 7.6%, respectively, as specified by Bonesi [83]. Likewise, for Berberis jaeschkeana a 4.5% extraction yield was described when using maceration with methanol [84]. For Berberis darwinii yields were 9.5 and 1.5% by maceration and infusion using methanol and water respectively [85]. For Berberis tabienses a yield of 9.5% was obtained, using the percolation method and ethanol [86]. Yields greater than 50% were found for Berberis vulgaris (52.4%) and Berberis croatica (52.1%) using 96% ethanol and UAE [72].
The calculated process yield was taken as a reference crude extract mass used for the fractionation. The highest extraction yield for the fractions was CH2Cl2 fraction (16.4 ± 3.1%), followed by C6H14 (9.7 ± 2.7%), BuOH (7.2 ± 1.4%) and H2O (4.2 ± 1.2%) fractions, respectively. No significant differences were observed (p > 0.01) between C6H14 and CH2Cl2 fractions. Also, between BuOH and H2O fractions, no significant differences were recognized. Significant differences were only detected (p < 0.01) between CH2Cl2 fraction and BuOH and H2O fractions (see Figure 2), suggesting that medium polar metabolites were more abundant in the Berberis goudotii extract (see Figure 2).

3.2. Preliminary Phytochemical Analysis

Total extract qualitative phytochemical analysis revealed the presence of alkaloids, flavonoids, phenols, tannins, steroids and terpenes, as well as absence of coumarins, cardiotonic glycosides, naptho- and anthraquinones and sesquiterpenlactones (Table 1).
For Berberis genus protoberberins, isoquinoline, and bisbenzylisoquinoline alkaloids were present in greater quantities in root and bark [87,88,89,90,91]. In contrast, terpenes, anthocyanins, tannins and phenolic compounds have been found in leaves and fruits of Berberis vulgaris [92,93]. Coumarins and phytosterols have been identified from Berberis lycum roots [94]. Total phenols and flavonoids were found in Berberis aetnensis, Berberis croatica and Berberis libanotica roots, and Berberis microphylla fruits [72,83,95]. The presence of total phenols, flavonoids and tannins were reported for Berberis jaeschkeana and Berberis microphylla fruits, and Berberis asiatica leaves [71,95,96]. Alkaloids and saponins were reported for Berberis microphylla fruits [95].
Considering the presence of phenolic compounds and their antibacterial activity, in this work several phenolic metabolite classes were quantified in the dried aerial parts (leaves, stems, flowers and fruits) and in the dried hydroethanolic extract. In all cases the quantities reported for 10 grams of sample were as follows: milligrams of gallic acid (GA) for phenols, milligrams of pyrogallol (PG) for polyphenols and tannins, milligrams of quercetin (QE) for flavonoids, and milligrams of cyanidin (CI) for proanthocyanidins (Table 1). In all cases the extract contained at least double the quantity of phenolic metabolites compared to the herbal material, where the largest metabolites concentration was observed for total tannins with a 2.9 ratio. The extraction process performance was efficient, due to the solvent being used having a higher content of secondary metabolites in the extract than in the herbal material used to prepare the extract [53]. As expected, global phenolic classes (phenols and polyphenols) presented larger quantities than specific classes like flavonoids, tannins and proanthocyanidins. A larger P/E ratio for total tannins (2.9) than for proanthocyanidins (2.2) when using different methodologies suggested the presence of hydrolysable and condensed tannins in Berberis goudotii.
Phenolic metabolites quantities found in aerial parts of Berberis goudotii were less than the reported for other Berberis species. Zovko Koncic and collaborators [72] described total phenol content in leaves, small branches and roots of Berberis vulgaris quantified as 52.5, 12.5 and 10.3 mg of GA/g, respectively, and total flavonoids as 4.2, 0.5 and 0.2 mg of quercetin/g, respectively. In the roots of Berberis aetnensis and Berberis libanotica flavonoids (16.2 and 31.5 mg chlorogenic acid/g) and phenols (37.4 and 69.1 mg quercetin/g) were quantified [83]. Likewise, the content in Berberis jaeschkeana fruit tannins (32.4 mg tannic acid/g), flavonoids (188.4 mg quercetin/g) and total phenols (108.9 mg GA/g) have been determined [71]. Arena et al. found in Berberis microphylla fruit monomeric anthocyanins (9.7 mg/g), 7.6 mg catechin/g for flavonoids and 31.2 mg tannic acid/g for polyphenols [95]; for the same species, 39 mg/g of alkaloids were identified in root, 5 mg/g flavonoids, 95 mg/g tannins and 35 mg/g saponins [97]. In another work, Bewal and colleagues reported for Berberis asiatica leaves 132.6 mg of GA/g, 31.4 mg of quercetin/g and 145.2 mg of tannic acid/g for total phenols, total flavonoids and total tannins, respectively [96].
Several authors have established that compounds, such as phenols, polyphenols, flavonoids, proanthocyanidins and tannins, have antimicrobial activity [46,98,99]. These properties arise from polyphenol and tannin capacity to inhibit enzymes and alter membrane characteristics. Enzyme inhibition by phenols results from compound oxidation, possibly through sulfhydryl group reaction with or through nonspecific protein interactions. Flavonoids can cause cell membrane disruption, and form complexes with soluble and extracellular proteins as well as with membrane walls [46,99].

3.3. Anticariogenic and Antiperiodontal Activities

Due to antimicrobial screening results, ceftazidime (30 μg) was selected as a positive control. Ceftazidime is a beta-lactam antibiotic of the cephalosporins group and is considered a third-generation antibiotic of broad spectrum against Gram-positive and Gram-negative bacteria. Its mechanism of action is by cell wall and bacterial septum inhibition, probably by acylation of transpeptidases linked to the membrane, inhibiting cell division and growth [100,101]. This antibiotic is recommended by the Clinical and Laboratory Standards Institute (CLSI), the British Society for Antimicrobial Chemotherapy (BSAC) and Swedish Reference Group for Antibiotics (SRGA) [102]. The negative controls (C6H14, CH2Cl2, BuOH, DMSO and H2O) did not show activity against the microorganisms evaluated.
In this work the antimicrobial activity of Berberis goudotii extracts and fractions on cariogenic microorganisms (Streptococcus mutans, Streptococcus sobrinus, Lactobacillus acidophilus, Lactobacillus casei) and periodontal disease (Porphyromonas gingivalis, Prevotella intermedia and Fusobacterium nucleatum) was evaluated. To this end, agar diffusion methods by well and disk were employed [103]. Cariogenic and periodontal disease bacteria employed in this study were obtained from reference strains.
Berberis goudotii antimicrobial activity for total extract and fractions was only observed when well agar diffusion method was used. Dichloromethane and aqueous fractions did not show activity (see Table 2).
The Ibero-American Program of Science and Technology for Development (CYTED) recommends use of the disk diffusion method [104], due to its reproducibility. Nonetheless, to observe anaerobic microorganism susceptibility, authors such as Olsson and colleagues consider this method inappropriate. They estimate slow growing bacteria and antimicrobial substance concentrations are unsuitable, because the antimicrobial agent around the disk will not be present when bacteria initiate their growth phase [102]. Additionally, natural product extracts and fractions are complex in their composition, since they are a mixture of many compounds with structural diversities. Therefore, there are differences in intermolecular forces; some of these forces are responsible for retaining compounds within the disk. Paper disc composition is exclusively made of cellulose, a homopolymer of β-glucose molecules. Each β-glucose has free hydroxyl groups making the surface of the disk hydrophilic, and each hydroxyl provides hydrogen-bond type interactions. This type of intermolecular forces retains or absorbs polar compounds on the surface of the disk, preventing diffusion of compounds in the agar [105,106]. This could explain why agar diffusion method using disks presented no activity in this study.
Results suggest the agar diffusion method was more sensitive for natural products compared with the disc diffusion method. The response by agar diffusion method was associated with total extract solubility and DMSO fractions, since DMSO displayed diffusion on solid agar carrying along compounds responsible for antimicrobial activity. Diffusion is a physical irreversible process, where matter particles are introduced in a media, initially lacking them, augmenting entropy within the formed system by the diffused particles (DMSO and extract or fractions) and the media where they are diffused (solid agar). Diffusion is the movement of particles in an area, from an area of higher concentration to an area of lower concentration until equilibrium is reached [107].
Diffusion depends on numerous factors including molecule number, size and shape. Particle number is an important factor: molecules diffuse more rapidly at a greater concentration gradient. Particle volume also influences diffusion velocity: small particles diffuse more rapidly and large ones diffuse more slowly. With an increasing molecule radius (r), diffusion is expected to decrease proportionately to the r2, due to an increase in solute-solvent interaction. Additionally, with increasing temperatures, diffusion is enhanced, due to increased molecule mean kinetic energy. Time is another parameter having an effect on diffusion velocity: mean diffusion distance varies according to the square root of time [108]. Therefore, overnight incubation of agar containing Petri dishes with solubilized extract can increase natural product diffusion. The inoculated system (Petri dish) remains inactive at 2–4 °C during 12–16 h before 37 °C incubation. This process helps in obtaining better detection limits (sensibility) [109].
Therefore, data from our work demonstrated that when working with natural products, it is necessary to carry out more than one method to corroborate if extracts and plant fractions have antimicrobial activity [105,106,108,110,111,112].
Berberis goudotii total extract and active fractions (hexane and butanol) antimicrobial activity, measured as relative inhibition percentage (RPI) data are presented in Table 2. Moreover, results obtained from minimum inhibitory concentration (MIC) are described in Table 3. Last, total extract and bioactive fractions bactericidal or bacteriostatic effects are exemplified in Table 3. Some authors report this effect as minimum bactericidal concentration (MBC) [64,66,113]. In contrast to disk diffusion method, we observed that Berberis goudotii total extract presented anticariogenic activity against Streptococcus mutans with concentrations of 25 and 50 µg/µL with an RPI of 36.2 ± 5.7 and 51.2 ± 6.3% respectively. Bactericidal activity against Streptococcus sobrinus for total extract at 25 µg/µL presented a 23.5 ± 3.2% RPI and at 50 µg/µL a 38.8 ± 5.7% RPI. Similarly, total extract exhibited antiperiodontal activity against Fusobacterium nucleatum, Porphyromonas gingivalis and Prevotella intermedia for all concentrations evaluated (1 to 50 µg/µL). The highest observed activity was against Prevotella intermedia with RPI values of 22.1 ± 4.1, 32.3 ± 2.4 and 53.3 ± 6.2% for 1, 25 and 50 µg/µL respectively. In this work antimicrobial activity against Lactobacillus aciophilus and Lactobacillus casei was not observed.
Minimum inhibitory concentration was evaluated by agar diffusion and broth microdilution methods [55,63]. In addition, MBC was determined by performing a new MIC culture by the agar diffusion method [59,62,105]. For Berberis goudotii total extract MIC was determined in decreasing concentrations starting at 32, and decreasing as follows: 16, 8, 4, 2, 1 and 0.5 µg/µL on cariogenic bacteria. Additionally, for periodontal disease bacteria concentrations decreased as follows: 4, 2, 1, 0.5, 0.25, 0.12 and 0.06 µg/µL. Differences in concentrations were due to the response for each strain of bacteria evaluated. That is, periodontal bacteria presented greater susceptibility to antimicrobial agents (total extract and fractions) in comparison with cariogenic bacteria.
A higher sensitivity was observed for the microdilution method in broth with values of 0.12 µg/µL against all periodontal bacteria assayed, and 1.0 µg/µL against some cariogenic bacteria evaluated. In contrast, for evaluating periodontal bacteria by means of agar diffusion method, a MIC value of 1.0 µg/µL was the minimum concentration of total extract sufficient to prevent periodontal bacterial growth. A MIC of 4.0 µg/µL was required to prevent cariogenic bacteria growth. The difference in sensitivity between methods can be attributed to final inoculum concentration in the microdilution method (106 CFU/mL), which was lower than the concentration for the diffusion method (108 UFC/mL). Also, the diffusion phenomenon has an effect since polar compounds diffuse through the agar’s mesh, while polar and apolar compounds are in direct contact with the microorganism in the microdilution method [63,105].
Minimum bactericidal concentration showed a bacteriostatic effect against Streptococcus mutans and Streptococcus sobrinus cariogenic bacteria at concentrations of 1.0 µg/µL (Broth microdilution method) and 4.0 µg/µL (Agar diffusion method). At lower concentrations a bactericidal effect on periodontal disease bacteria Porphyromonas gingivalis, Prevotella intermedia and Fusobacterium nucleatum, was observed at concentrations of 0.12 µg/µL (Broth microdilution method) and 1.0 µg/µL (Agar diffusion method). According to observed results, Berberis goudotii total extract was ineffective at killing Streptococcus mutans and Streptococcus sobrinus, it only prevented their growth. Thus, although microorganisms remained viable, if treatment were to be suspended, bacteria could recover and proliferate again. On the other hand, Berberis goudotii total extract had a lethal effect against Porphyromonas gingivalis, Prevotella intermedia and Fusobacterium nucleatum [100,114,115].
Berberis goudotii active hexane and butanol fractions antimicrobial activity data, MIC and MBC are summarized in Table 2 and Table 3. As was described for total extract, fractions only presented antimicrobial activity when the agar diffusion method per well was employed. No activity was observed when the disk agar diffusion method was used, possibly due to compound fraction retention, as was previously explained [105,112].
Berberis goudotii hexane, dichloromethane, butanol and water fractions did not demonstrate any anticariogenic activity. Nevertheless, only antiperiodontal activity was observed for Berberis goudotii hexane and butanol fractions. Some reports with plant crude active extracts have described biological activity as being lost after the fractioning process, considering that activity is the result of an additive effect of synergy or of structural stabilization between compounds. Thus, at the moment of fractionation, antimicrobial activity is lost [116,117,118].
Anti-periodontal activities for all evaluated concentrations are presented in Table 3. It was observed for hexane and butanol fractions at 1, 25 and 50 µg/µL, with a better response obtained from the butanol fraction. At a 1.0 µg/µL concentration, butanol fraction had RPI of 21.5 ± 3.6, 16.0 ± 2.6 and 19.1 ± 2.7% against Fusobacterium nucleatum, Porphyromonas gingivalis and Prevotella intermedia, respectively. Whereas, for the hexane fraction at the same concentration 1.0 µg/µL, RPIs were lower: 12.9 ± 2.5 for Fusobacterium nucleatum, 7.9 ± 1.6 for Porphyromonas gingivalis and 17.2 ± 0.9% for Prevotella intermedia.
As was observed for total extract, MIC and MBC for fractions was determined by agar diffusion and microdilution methods, the latter with the greatest sensitivity, due to lower inoculum concentration and contact phenomenon for all compounds, as aforementioned [105,112]. For hexane and butanol fractions, the MIC by diffusion method was 1.0 µg/µL, while by the microdilution method they were 1.0 and 0.12 µg/µL for hexane and butanol fractions, respectively. The minimal bactericidal concentration effect on periodontal disease associated bacteria was of bacteriostatic type for the hexane fraction at a 1.0 µg/µL concentration (Agar diffusion and broth microdilution methods). Similarly, a bactericidal type effect was observed for the butanol fraction at concentrations of 1.0 µg/µL (Agar diffusion method) and 0.12 µg/µL (Broth microdilution method). In other words, the hexane fraction inhibits periodontal disease bacteria proliferation, and thus is a bacteriostatic. In contrast, the butanolic fraction is a bactericidal agent. Collectively, for antimicrobial agents (extract or fraction) bacteriostatic or bactericidal effects mainly depend on their mechanisms of action, molecule types and structures, antimicrobial agent concentration, types of microorganism evaluated, size of the inoculum, time of action and bacterial growth phase [100,119].
Regarding secondary metabolites Palombo et al, Viera et al, Milonova et al, among others, have directly associated plant extracts and fractions antimicrobial activity against oral cavity bacteria with secondary metabolite content, such as phenols, polyphenols, flavonoids, terpenes and alkaloids, among others [28,120,121].
This research pioneered in evaluating Berberis goudotii extracts and fractions anticariogenic and antiperiodontal activities. Furthermore, this is the first report on this species, being an important contribution in the search for new natural products that support Berberis goudotii traditional medicine use for the treatment and prevention of oral cavity diseases, such as caries and periodontal disease. However, it would be desirable to perform further studies on isolated and purified compound antimicrobial activity. Therefore, future studies will be carried out in order to isolate and purify chemical and biological markers.

4. Conclusions

Berberis goudotii antimicrobial activity was determined against bacteria associated with caries and periodontal disease. Findings revealed that greater anticariogenic and antiperiodontal activity was observed by the agar diffusion method per well in total extract. In contrast, no antimicrobial activity was recognized when using the disk agar diffusion method. The results indicate that the diffusion method in agar by well was a more suitable assay for plant extract and fractions antimicrobial activity evaluation. Not all Berberis goudotii fractions in different solvents displayed anticariogenic activity. Nevertheless, activity against periodontal disease associated bacteria was observed, where the butanol fraction was the most active, followed by the hexane fraction. The butanol fraction had a bactericidal effect on periodontal microorganisms, while the hexane fraction evidenced a bacteriostatic effect. This work is the first study on Berberis goudotii antimicrobial activity of anticariogenic and antiperiodontal types. Berberis goudotii is a species of the Berberis genus endemic to Colombia. Additionally, this is the first time that phenols, flavonoids, proanthocyanidins, polyphenols and tannins contents have been reported for aerial parts and extract of this plant.

Author Contributions

This article was submitted in partial fulfillment of L.G.S.-C. doctoral thesis. Funding acquisition, S.J.G.-P., C.A.C.-Z. and L.G.S.-C. Conceptualization, S.J.G.-P., P.E.L.-C. and L.G.S.-C. Methodology, P.E.L.-C., F.G. and L.G.S.-C. Resources, S.J.G.-P., C.A.C.-Z. and L.G.S.-C. Formal analysis, C.C.M.-R., P.E.L.-C. and L.G.S.-C. Investigation, C.C.M.-R., C.A.C.-Z. and L.G.S.-C. Writing-original draft, S.J.G.-P., C.A.C.-Z. and L.G.S.-C. Writing-review and editing, F.G., P.E.L.-C. and L.G.S.-C.

Funding

This work was financed by the Academic Vice-Rectory and Vice-Rectory for Research of the Pontificia Universidad Javeriana (Projects 5392, 7341 and 8984) and Administrative Department of Science, Technology, and Innovation (COLCIENCIAS) support.

Acknowledgments

Authors thank María Alejandra Díaz and Nestor García, Biologists at Pontificia Universidad Javeriana for supporting the identification of plant material. At María Lucía Gutiérrez and Martha Margarita González for supporting the revision of the manuscript. Authors manifest their gratitude to Merck, and COLCIENCIAS (Administrative Department of Science, Technology, and Innovation) for financial support of the thesis titled “Phytochemical study of some Colombian native plants and evaluation of its antimicrobial activity and of its remineralizing effect on tooth enamel”.

Conflicts of Interest

The authors declare no conflict of interest.
