Technological and Environmental Behaviour of Traditional Ceramic Bodies Obtained by Recycling of Two Types of Residues
Abstract
:1. Introduction
2. Materials and Methods
3. Results and Discussion
4. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
- Tayibi, H.; Peña, C.; López, F.A.; López-Delgado, A. Management of MSW in Spain and recovery of packaging steel scrap. Waste Manag. 2006, 27, 1655–1665. [Google Scholar] [CrossRef] [PubMed]
- Costi, P.; Minciardi, R.; Robba, M.; Rovatti, M.; Sacile, R. An environmentally sustainable decision model for urban solid waste management. Waste Manag. 2004, 24, 277–295. [Google Scholar] [CrossRef]
- Hernández-Crespo, M.S.; Rincón, J.M. New porcelainized stoneware obtained by recycling of MSW incinerator fly ashes and granite sawing residues. Ceram. Int. 2001, 27, 713–720. [Google Scholar] [CrossRef]
- Montero, M.A.; Jordán, M.M.; Hernández, M.S.; Sanfeliu, T. The use of sewage sludge and marble residues in the manufacture of ceramic tile bodies. Appl. Clay Sci. 2009, 46, 404–408. [Google Scholar] [CrossRef]
- Zhang, L. Production of bricks from waste materials: A review. Constr. Build. Mater. 2013, 4, 643–655. [Google Scholar] [CrossRef]
- Nazer, A.; Payá, J.; Borrachero, M.V.; Monzó, J. Caracterización de escorias de cobre en fundiciones chilenas. Rev. Metal. 2016, 52, e083. [Google Scholar] [CrossRef] [Green Version]
- Murari, K.; Sissique, R.; Jain, K.K. Use of copper slag. A sustainable material. J. Mater. Cycles Wastes 2015, 17, 13–26. [Google Scholar] [CrossRef]
- Piatak, N.M.; Parsons, M.B.; Seal, R.R., II. Characteristics and environmental aspects of slag: A review. Apply. Geochem. 2015, 57, 236–266. [Google Scholar] [CrossRef]
- Díaz, M.; Plaza, P.; Blanco, D.; Jordán, M.M.; Sáez del Bosque, I.F.; Medina, C. The design and development of recycled concretes in a circular economy using mixed construction and demolition waste. Materials 2021, 14, 4762. [Google Scholar]
- ISO 10545-3:2018; Ceramic Tiles—Part 3: Determination of Water Absorption. ISO: Geneva, Switzerland, 2018.
- UNE-ENV 12506:2001; Characterization of Waste. Analysis of Eluates. Determination of pH, Cd, As, Cr (VI), Cu, Zn, Pb, Ni, SO42−, NO− and Cl−. UNE: Madrid, Spain, 2001.
- Jordán, M.M.; Montero, M.A.; Pardo, F. Technological behavior and leaching tests in ceramic tile bodies obtained by recycling of copper slag and MSW fly ashes. J. Mater. Cycles Waste Manag. 2021, 23, 707–716. [Google Scholar] [CrossRef]
- UNE 136020:2004; CTN 136—Clay Products for Construction. UNE: Madrid, Spain, 2004.
- UNE-EN 538:1995; Clay Roofing Tiles for Discontinuous Laying—Flexural Strength Test. UNE: Madrid, Spain, 1995.
Ceramic Clay | |
SiO2 | 52.59 (%) |
Al2O3 | 15.85 (%) |
Fe2O3 | 5.95 (%) |
CaO | 12.29 (%) |
MgO | 1.95 (%) |
Na2O | 0.373 (%) |
K2O | 5.20 (%) |
P2O5 | 0.225 (%) |
Total SO3 | 0.650 (%) |
O.M. 500 °C | 2.00 (%) |
LOI (1000 °C) | 12.20 (%) |
CaCO3 | 26.00 (%) |
SO42− (solubles) | 4420 (ppm) |
Cl− (solubles) | 139.90 (ppm) |
MSW Fly Ash | |
O.M. 500 °C | 42.50 (%) |
LOI (1000 °C) | 63.97 (%) |
CaCO3 | 8.96 (%) |
SO42− (solubles) | 8055 (ppm) |
Cl− (solubles) | 739.1 (ppm) |
SiO2 | 12.55 (%) |
Al2O3 | 45.30 (%) |
Fe | 9281 (mg/kg) |
Ca | 57 (mg/kg) |
Mg | 43 (mg/kg) |
Na | 1231 (mg/kg) |
K | 2325 (mg/kg) |
P | 32.36 (mg/kg) |
Cu | 91 (mg/kg) |
Zn | 166 (mg/kg) |
Pb | 49 (mg/kg) |
Hg | 0.25(mg/kg) |
As | 0.22 (mg/kg) |
Cd | 3.38 (mg/kg) |
Cu-Slag | |
SiO2 | 51.07 (%) |
Fe2O3 | 17.19 (%) |
CaO | 18.33 (%) |
MgO | 1.10 (%) |
K2O | 2.19 (%) |
CuO | 0.92 (%) |
SO3 | 0.15 (%) |
Al2O3 | 8.95 (%) |
Zn | 0.20 (%) |
Co3O4 | 0.08 (%) |
PbO | 0.31(%) |
As2O3 | 0.49 (%) |
LOI | −1.17 (%) |
Tmax: 900 °C Added By-Products (%) | As | Pb | pH Values |
---|---|---|---|
W | 0.1 ± 0.05 | 0.08 ± 0.02 | 7.8 ± 0.2 |
A | 0.59 ± 0.02 | 0.09 ± 0.02 | 7.7 ± 0.2 |
B | 0.73 ± 0.03 | 0.46 ± 0.01 | 7.9 ± 0.1 |
C | 0.79 ± 0.01 | 0.65 ± 0.03 | 8.1 ± 0.2 |
D | 1.2 ± 0.02 | 0.73 ± 0.01 | 8.5 ± 0.3 |
E | 1.3 ± 0.05 | 0.81 ± 0.04 | 8.7 ± 0.2 |
Tmax: 950 °C | |||
W | 0.21 ± 0.06 | 0.06 ± 0.02 | 7.5 ± 0.3 |
A | 0.35 ± 0.05 | 0.09± 0.01 | 7.6 ± 0.4 |
B | 0.51 ± 0.03 | 0.33 ± 0.03 | 7.8 ± 0.1 |
C | 0.62 ± 0.02 | 0.52 ± 0.02 | 8.1 ± 0.3 |
D | 0.82 ± 0.03 | 0.63 ± 0.01 | 8.2 ± 0.1 |
E | 0.93 ± 0.06 | 0.72 ± 0.04 | 8.3 ± 0.2 |
Tmax: 1000 °C | |||
W | 0.11 ± 0.02 | <0.05 | 7.4 ± 0.2 |
A | 0.14 ± 0.04 | <0.05 | 7.5 ± 0.1 |
B | 0.23 ± 0.02 | <0.05 | 7.7 ± 0.1 |
C | 0.34 ± 0.04 | <0.05 | 7.8 ± 0.2 |
D | 0.43 ± 0.01 | <0.05 | 8.1 ± 0.1 |
E | 0.49 ± 0.05 | <0.05 | 8.2 ± 0.3 |
Tmax: 1050 °C | |||
W | 0.04 ± 0.01 | <0.05 | 7.2 ± 0.1 |
A | 0.12 ± 0.02 | <0.05 | 7.4 ± 0.2 |
B | 0.13 ± 0.02 | <0.05 | 7.6 ± 0.3 |
C | 0.19 ± 0.01 | <0.05 | 7.8 ± 0.2 |
D | 0.23 ± 0.03 | <0.05 | 7.9 ± 0.1 |
E | 0.39 ± 0.04 | <0.05 | 7.8 ± 0.2 |
Inert wastes landfill | 0.5 | 0.5 | Limits regulated |
Non-hazardous wastes ladfill | 0.2 | 10 |
