Visualization Method for Arbitrary Cutting of Finite Element Data Based on Radial-Basis Functions

1
Division of Materials, China Institute of Water Resources and Hydropower Research (IWHR), Beijing 100038, China
2
State Key Laboratory of Simulation and Regulation of Water Cycle in River Basin, China Institute of Water Resources and Hydropower Research (IWHR), Beijing 100038, China
3
Beijing Key Laboratory of Multimedia and Intelligent Software Technology, College of Metropolitan Transportation, Beijing University of Technology, Beijing 100124, China
*
Author to whom correspondence should be addressed.
Information 2019, 10(7), 229; https://doi.org/10.3390/info10070229
Received: 11 May 2019 / Revised: 30 June 2019 / Accepted: 1 July 2019 / Published: 3 July 2019
  |
PDF [2417 KB, uploaded 3 July 2019]
  |     |

Abstract

Finite element data form an important basis for engineers to undertake analysis and research. In most cases, it is difficult to generate the internal sections of finite element data and professional operations are required. To display the internal data of entities, a method for generating the arbitrary sections of finite element data based on radial basis function (RBF) interpolation is proposed in this paper. The RBF interpolation function is used to realize arbitrary surface cutting of the entity, and the section can be generated by the triangulation of discrete tangent points. Experimental studies have proved that the method is very convenient for allowing users to obtain visualization results for an arbitrary section through simple and intuitive interactions. View Full-Text
Keywords: radial basis function (RBF) interpolation function; finite element data; arbitrary cutting; visualization radial basis function (RBF) interpolation function; finite element data; arbitrary cutting; visualization
Figures

Figure 1
