Discrete Element Method Approach to Modeling Mechanical Properties of Three-Dimensional Ice Beams
Abstract
:1. Introduction
2. Numerical Modeling
2.1. Equations of Motion
2.2. Bond Model
2.3. Model Parameters
2.4. Model Verification
3. Results and Discussion
3.1. Uniaxial Compressive Test and Three-Point Bending Test
3.2. Effect of Bond Young’s Moduls
3.3. Effect of Bond Strength
3.4. Effect of Bond Friction Coefficient
3.5. Effect of Bond Stiffness Ratio ()
3.6. Prediction of Mechanical Property of Ice in the Bohai Sea
4. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
