Lymphatic Phenotype of Noonan Syndrome: Innovative Diagnosis and Possible Implications for Therapy

Lotte E. R. Kleimeier
Caroline van Schaik
Erika Leenders
Maxim Itkin
Willemijn M. Klein
2 and
Jos M. T. Draaisma
Department of Pediatrics, Radboudumc Amalia Children’s Hospital, Radboud Institute for Health Sciences, Radboud University Medical Center, 6525 GA Nijmegen, The Netherlands
Department of Medical Imaging, Radboud University Medical Center, 6525 GA Nijmegen, The Netherlands
Department of Human Genetics, Radboud University Medical Center, 6525 GA Nijmegen, The Netherlands
Department of Radiology, Penn Center for Lymphatic Disorders, University of Pennsylvania, Philadelphia, PA 19104, USA
Author to whom correspondence should be addressed.
J. Clin. Med. 2022, 11(11), 3128;
Submission received: 3 May 2022 / Revised: 16 May 2022 / Accepted: 30 May 2022 / Published: 31 May 2022
(This article belongs to the Special Issue Noonan Syndrome: New Insights in Clinical and Genetic Features)


Dysregulation of the Ras/Mitogen-activated protein kinase (MAPK) signaling pathway is suggested to play a pivotal role in the development of the lymphatic system in patients with Noonan Syndrome (NS). Pathogenic gene variants in the Ras/MAPK pathway can therefore lead to various lymphatic diseases such as lymphedema, chylo-thorax and protein losing enteropathy. Diagnosis and treatment of the lymphatic phenotype in patients with NS remain difficult due to the variability of clinical presentation, severity and, probably, underlying unknown pathophysiologic mechanism. The objective of this article is to give an overview of the clinical presentation of lymphatic disease in relation to central conducting lymphatic anomalies (CCLA) in NS, including new diagnostic and therapeutic options. We visualized the central conducting lymphatic system using heavily T2-weighted MR imaging (T2 imaging) and Dynamic Contrast-enhanced MR Lymphangiography (DCMRL) and compared these results with the lymphatic clinical presentation in seven patients with NS. Our results show that most patients with NS and lymphatic disease have CCLA. Therefore, it is probable that CCLA is present in all patient with NS, presenting merely with lymphedema, or without sensing lymphatic symptoms at all. T2 imaging and DCMRL can be indicated when CCLA is suspected and this can help to adjust therapeutic interventions.

1. Introduction

Noonan Syndrome (NS) is a multisystem disorder, caused by dysregulation of the Ras/MAPK signaling pathway [1,2,3] and 19 Pathogenic variants in genes encoding for components of this pathway have been identified and linked to NS, of which PTPN11, SOS1, RAF1 and RIT1 are the most prevalent [4,5,6]. Other, less prevalent, mutated genes include BRAF, KRAS, LZTR1, MAP2K1, MAP2K2, NRAS, RRAS and SOS2 [4]. Pathogenic variants in these genes lead to an over-activation of the Ras/MAPK pathway, resulting in an over-activation of Extracellular Signal-regulated kinase (ERK)-1 and ERK-2. These kinases are suggested to play a pivotal role in the development of the lymphatic system [7,8]. Therefore, excessive ERK activation is thought to be the cause of lymphatic disease in patients with NS leading to as chylo-thorax, lymphedema and protein losing enteropathy [9]. On prenatal imaging, abnormal lymphatic development may present as increased nuchal translucency, hydrops fetalis, hydrothorax and ascites [10].
A recently conducted retrospective cohort study and systematic review shows that the lifetime prevalence of lymphatic disease in patients with NS is 36%. [10]. Genotype-phenotype studies in patients with NS found that lymphatic disease is more prevalent in patients with NS due to pathogenic variants in SOS2 and RIT1 [10,11,12].
Diagnosis and treatment of lymphatic diseases in patients with NS remain difficult due to its variable presentation, severity and, probably, underlying unknown pathophysiologic mechanism. Some authors suggest that lymphatic disease in patients with NS may be the sequalae of Central Conducting Lymphatic Anomalies (CCLA) [1,13,14,15,16,17]. CCLA is a disease that affects large lymphatic vessels in the middle of the torso, resulting in blockage and subsequent leakage of normal drainage of lymph fluid [14,18,19]. CCLA have traditionally been unsuitable for traditional medical and surgical interventions.
The definitive diagnosis for CCLA requires physical examination and medical history as well as visualization of the central lymphatic system. The central lymphatic system can be visualized using heavily T2-weighted MR imaging (T2 imaging) due to its high water content. However, this technique does not provide information about the lymphatic flow and is not specific to the lymphatic tissue. Dynamic contrast enhanced lymphangiography (DCMRL) is a new imaging technique that is performed by introducing the gadolinium contrast agent into inguinal lymph nodes. DCMRL allows the evaluation of anatomy as well as the flow in the lymphatic system with excellent temporal and spatial resolution [20]. According to Ricci et al. (2021), findings in line with the CCLA diagnosis include demonstration of enlargement of the lymphatic channels (lymphangiectasia), lymphatic fluid reflux, and/or failure to empty into the thoracic duct or the subclavian vein at the thoracic duct outlet. A standardized scoring system was used to evaluate the DCMRL findings (Supplementary Materials) [21].
In this article we describe the spectrum of imaging modalities, the clinical lymphatic phenotype in relation to the radiological findings of the central conducting lymphatic system in seven patients with NS, and possible implications for therapeutic options.

2. Imaging the Lymphatic System

Visualization and imaging of nearly translucent, lymphatic vessels has always been very challenging. Few scientists have risen to the challenge of studying the lymphatic system by introducing contrast into the lymphatic vessels. In the 17th century, Frederik Ruysch injected air into the lymphatic vessels, and visualized the semilunar valves that allow the unidirectional flow in the lymph vessels. The anatomist Mascagni visualized the lymphatic vessels by filling them with mercury (1787) [22]. During recent decades several radiological and nuclear methods have been developed to image the lymphatic vessels.
Lymphoscintigraphy has traditionally been the modality of choice for peripheral lymphedema. It is performed by injecting colloidal imaging agents subcutaneously between the toes or fingers. The image acquisition in lymphoscintigraphy is performed repeatedly over time thus allowing direction and quantification of the lymphatic flow. One of the main drawbacks in lymphoscintigraphy is low spatial resolution. Coupling it with single photon emission computed tomography (SPECT) provides much better spatial information [23].
Visualization of the central lymphatics can be performed using T2 imaging that is designed to image all water containing structures, including the lymphatic vessels. However, T2-imaging is static and does not provide any information about flow direction or velocity. DCMRL is performed by injecting gadolinium-based contrast agent into inguinal lymph nodes and following the propagation of the contrast through the para-iliac lymphatic vessels into the thoracic duct using a series of short T1 weighted MR sequences, which can be reconstructed into a time lapse movie visualizing the dynamics [24]. DCMRL has demonstrated its usefulness in central lymphatic flow disorders, such as chylothorax, protein losing enteropathy, chylous ascites, lymphedema or scrotal/vaginal chyle leakage, often present in NS [20].
In the Radboud University Medical Center (Nijmegen, the Netherlands), we use both the T2 imaging and DCMRL in NS patients with suspected central conducting lymphatic anomalies. The inguinal injection is performed using local anesthesia and general anesthesia is reserved for patients who cannot tolerate the 90 min MR session. All MR images are analyzed and reported using a standardized scoring system.

3. Clinical Manifestation Compared to Radiological Findings in Patients with NS

DCMRL and T2 imaging were performed in seven patients with NS and lymphatic diseases. Informed consent for publication was acquired from all parents and, when appropriate, patients aged 12 years or older. This study has been approved by the Medical Ethics Committee at Radboud University Medical Center Nijmegen (file number 2020-6852).
Patient 1: an 11-year-old female was diagnosed with NS and a de novo pathogenic variant in SOS2 (c.800T > A p. (Met267Lys)). Prenatal ultrasounds showed polyhydramnios. She had no signs of the lymphatic disorders until six years of age, when she presented with lower extremity lymphedema. The T2 imaging showed a partially developed thoracic duct, pulmonary (interstitial) and peri-portal edema and lymphangiectasia in the retroperitoneal space and mesentery. DCMRL demonstrated retrograde lymphatic flow in the lung interstitium, mesenteric and peri-portal lymphatic vessels, findings that are consistent with CCLA.
Patient 2: a 17-year-old female who was diagnosed with NS, with a pathogenic variant in SOS2 (c.800T > A p. (Met267Lys)). Prenatal ultrasounds showed an increased nuchal translucency (>3 mm) without poly-hydramnios. She had no signs of the lymphatic disorders until the age of nine years, when she developed lymphedema of the lower extremities and abdominal wall. In addition, she had neuropathic pain in both feet. The T2 images suggested a partial aplasia of the thoracic duct, an enlarged cisterna chyli, peritoneal lymphatic cysts, lymphangiectasia in the retroperitoneal space, and subcutaneous body wall, and signs of pulmonary interstitial edema were also noted. DCMRL showed no contrast opacification of the thoracic duct, and retrograde flow in the peri-bronchial, mesenteric and peri-portal lymphatic vessels, as well as dermal backflow in the abdominal wall, findings that are consistent with CCLA.
Patient 3: a 32-year-old female was diagnosed with NS, and a de novo pathogenic variant in SOS2 (c.800T > C p. (Met267Thr)). Prenatal ultrasounds showed poly-hydramnios. She presented with lymphedema in the extremities during infancy, which improved within the first few years of her life. At 16 years she again developed severe lymphedema of the upper and lower extremities. DCMRL showed a dilated, and intermittently duplicated, thoracic duct, without cisterna chyli. However, there was no failure to empty into the thoracic duct or the subclavian vein. In addition, there was no abnormal retrograde lymphatic flow or extravasation of contrast. Therefore, these findings were not consistent with CCLA, according to the definition of Ricci et al. (2021) [21].
Patient 4: ac20-year-old male was diagnosed with NS and a pathogenic variant in RIT1 (c.280G > A (p. (Ala77Thr)). At the age of 6 years, he developed chylous ascites, followed by chylo-thorax, lymphedema of the lower extremities and scrotal area, and scrotal chylous leakage. The T2 imaging showed left-sided pleural fluids and mesenteric edema. DCMRL images showed partial aplasia of the thoracic duct, retrograde contrast flow into the scrotum, as well as dermal backflow and lymphangiectasia behind the cecum and throughout the retro-peritoneum, findings that are consistent with CCLA Figure 1.
Patient 5: a 31-year-old female was diagnosed with NS and pathogenic variant in PTPN11 (c.181G > A p. (Asp61Asn)). Prenatal ultrasound information was not available. At the age of one year, she developed chylothorax after cardiac surgery for repair pulmonary valve stenosis. At the age of ten years, she developed lymphedema of the lower extremities as well as vulvar and labial lymphangiectasia, and genital lymphorrhea. At the age of 26 years, she underwent surgical resection of the vulvar lymphangiectasia, which has been reported by Winters et al. [25] T2 imaging shows a dilation of the thoracic duct and lymphangiectasia behind the cecum and throughout the retro-peritoneum. DCMRL showed dermal backflow towards the labia, lower extremities, and the abdominal wall, findings that are consistent with CCLA.
Patient 6: a 27-year-old male was diagnosed with NS and a pathogenic variant in SOS1 (c.1277A > C p. (Gln426Pro)). During adulthood, he was diagnosed with protein losing enteropathy. T2 images showed a normally developed thoracic duct. DCMRL demonstrated normal ante-grade flow in the thoracic duct; however, there was retrograde flow into the mesentery, which can potentially explain the protein losing enteropathy, findings that are consistent with CCLA.
Patient 7: a 34-year-old male was diagnosed with NS and pathogenic variant in PTPN11 (c.182A > G (p. Asp61Gly)). He was diagnosed with pericardial effusion at the age of 18 years, and chylo-thorax at the age of 32. T2 imaging visualized bilateral pleural and pericardial fluid as well as ascites, mesenterial and subcutaneous edema and pelvic cysts. DCMRL showed a tortuous, dilated and partially duplicated thoracic duct, without cisterna chyli, as well as retrograde flow into the peri-portal lymphatic vessels and dermal backflow in the abdominal wall, findings that are consistent with CCLA.
The clinical lymphatic diseases of CCLA seen in these patients include lymphedema, chylo-thorax, genital lymph leakage and protein losing enteropathy. In all patients the thoracic duct was abnormal. In six patients the retrograde flow in the peri-bronchial, peri-portal or mesenteric lymphatic vessels, or dermal backflow was demonstrated.

Literature Review

There are several case reports, and one case-series, reporting on the clinical lymphatic diseases and radiological findings of CCLA in patients with NS. Combined, they reported ten patients with chylo-thorax, three patients with protein losing enteropathy, two patients with ascites, two patients with lymphedema, and two patients with additional lymphangiectasia, either mesenteric and retroperitoneal or pulmonary [1,13,15,16,17]. Table 1 summarizes the results of clinical manifestation of the radiological findings. In 12 out of 14 patients the anatomy of the thoracic duct was evaluated, all of them reporting on an abnormal development of the thoracic duct, which varies in nature. In addition, all articles report on lymphatic flow abnormalities, indicating CCLA.

4. Possible Implications for Therapeutic Options

Traditionally, the treatment approaches for the symptoms of lymphatic conditions are tailored to the clinical presentation. Physiotherapy, including compression therapy, exercise and manual lymphatic drainage, are often used in the treatment of lymphedema [26].
Pleural and abdominal cavity drainage is used as a symptomatic treatment of chylo-thorax and chylous ascites. This is often combined with diet modification to reduce chyle production. Similar diet modifications are used successfully in patients with protein losing enteropathy [27,28].
Pharmacological treatments include octreotide or propranolol. Octreotide is used to reduce the chyle production in chylous effusions, especially for the congenital form, and also in children with NS [29]. Propranolol therapy for chylous effusions was recently reported, but there is no experience with propranolol in NS patients [30]. The exact mechanism of propranolol is still unknown. Perhaps the inhibition of the β2 adrenergic receptors leads to decreased expression of proangiogenic factors, such as vascular endothelial growth factor (VEGF) [30].
In case of failure of conservative treatment, surgical interventions can be considered when the local lymphatic anatomy and flow pattern is known. Surgical lympho-venous anastomosis has been performed to treat lymphedema. Surgical ligation or percutaneous embolization of thoracic duct may be performed in patients with chylous effusions. Otman et al. [31]. described a 61-year-old man with NS with severe pulmonary insufficiency due to thoracic duct occlusion, who improved following surgical TD-venous anastomosis [32]. Winters et al. reported a patient with NS and recurrent vulvar lymphangiectasia that was successfully treated with a 2-stage approach using lympho-venous anastomosis followed by excision of the vulvar lesion and reconstruction [25].
All these therapeutic strategies target the specific clinical presentation, and not the general underlying mechanism. However, as shown before, in NS there may be an underlying CCLA. New insights into lymphangio-genesis and lymphatic vasculature remodelling show that pathogenic variants in genes in the Ras/MAPK signalling pathway may be the cause of persistent lymphatic dysfunction and abnormalities [14,33,34,35].
Knowledge of and experience with therapeutic interventions of the Ras/MAPK pathway is emerging across a spectrum of both adult and Pediatric cancers with somatic mutations in the Ras/MAPK pathway [13,14]. A drug therapy that is still in its experimental phase in patients with germline mutations is targeting the increased activity of the Ras/MAPK pathway that is stimulated by most NS genotypes [32]. This has led to the hypothesis that a MEK inhibitor, as used in oncologic patients, could be beneficial in patients with NS and severe lymphatic disease due to CCLA [13,14]. MEK inhibition could lead to resolution of symptoms and remodelling of the central lymphatic system.

5. Future Research Opportunities

Our and other reports focused on imaging NS with lymphatic diseases such as chylo-thorax, lymphedema and others. However, it is possible the undiscovered and/or lymphatic abnormalities are present in NS patients, with unrecognized signs of lymphatic condition. To understand the mechanism behind CCLA in patients with NS and lymphatic disease, we have to improve our understanding of the normal central lymphatic system in patients with NS. Therefore, it may be necessary to systematically study the central conducting lymphatic system in all NS patients with (therapy resistant) symptoms of lymphatic disease.

6. Conclusions

Visualization of the lymphatic vessels has always been very challenging. However, it is now possible to image the central lymphatic system and lymphatic anatomical abnormalities using DCMRL. At the moment, most of the therapeutic approaches target specific clinical presentations. However, the potential interventions to treat the symptoms of lymphatic flow disorders depend on the pathophysiologic cause. In our study, NS patients with a diversity of lymphatic disease all appeared to have an abnormal central conducting lymphatic system. Often, but not always, the anatomical abnormality is accompanied by central flow disorders. These findings are in line with the results of other case reports and series. DCMRL can be considered as improving the understanding of the lymphatic flow abnormalities in NS and assisting in indicating and follow-up of the newest therapeutic options.

Supplementary Materials

The following supporting information can be downloaded at:, Standard scoring system.

Author Contributions

Conceptualization: L.E.R.K., W.M.K. and J.M.T.D.; methodology: L.E.R.K., C.v.S., W.M.K. and J.M.T.D.; formal and statistical analysis: not performed; investigation: L.E.R.K. and W.M.K.; data curation: not performed; writing—original draft preparation: L.E.R.K., C.v.S., E.L., M.I., W.M.K. and J.M.T.D.; writing—review and editing: L.E.R.K., C.v.S., E.L., M.I., W.M.K. and J.M.T.D.; supervision: W.M.K. and J.M.T.D. All authors have read and agreed to the published version of the manuscript.


This research received no external funding.

Institutional Review Board Statement

An Institutional Review Board Statement was not necessary due to the type of article.

Informed Consent Statement

Informed consent was obtained from all subjects involved in the study.

Data Availability Statement

The data presented in this study are openly available with the author.


Erika Leenders and Jos Draaisma are members of the European Reference Network for Developmental Anomalies and Intellectual Disability (ERN-ITHACA). Willemijn Klein is member of the Vascular Anomalies Working Group (VASCA WG) of the European Reference Network for Rare Multisystemic Vascular Diseases (VASCERN)—Project ID: 769036.

Conflicts of Interest

The authors have no conflict of interest to declare.


  1. Biko, D.M.; Reisen, B.; Otero, H.J.; Ravishankar, C.; Victoria, T.; Glatz, A.C.; Rome, J.J.; Dori, Y. Imaging of central lymphatic abnormalities in Noonan syndrome. Pediatr. Radiol. 2019, 49, 586–592. [Google Scholar] [CrossRef]
  2. Kouz, K.; Lissewski, C.; Spranger, S.; Mitter, D.; Riess, A.; Lopez-Gonzalez, V.; Lüttgen, S.; Aydin, H.; Von Deimling, F.; Evers, C.; et al. Genotype and phenotype in patients with Noonan syndrome and a RIT1 mutation. Genet. Med. 2016, 18, 1226–1234. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  3. Tidyman, W.E.; Rauen, K.A. Expansion of the RASopathies. Curr. Genet. Med. Rep. 2016, 4, 57–64. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  4. Grant, A.R.; Cushman, B.J.; Cave, H.; Dillon, M.W.; Gelb, B.D.; Gripp, K.W.; Lee, J.A.; Mason-Suares, H.; Rauen, K.A.; Tartaglia, M.; et al. Assessing the gene-disease association of 19 genes with the RASopathies using the ClinGen gene curation framework. Hum. Mutat. 2018, 39, 1485–1493. [Google Scholar] [CrossRef] [PubMed]
  5. Roberts, A.E.; Allanson, J.E.; Tartaglia, M.; Gelb, B.D. Noonan syndrome. Lancet 2013, 381, 333–342. [Google Scholar] [CrossRef] [Green Version]
  6. Tartaglia, M.; Gelb, B.D.; Zenker, M. Noonan syndrome and clinically related disorders. Best Pract. Res. Clin. Endocrinol. Metab. 2011, 25, 161–179. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  7. Deng, Y.; Simons, M. Lymphatic fate determination: Playing RAF with ERK. Cell Cycle 2013, 12, 1157–1158. [Google Scholar] [CrossRef] [Green Version]
  8. Makinen, T.; Boon, L.M.; Vikkula, M.; Alitalo, K. Lymphatic Malformations: Genetics, Mechanisms and Therapeutic Strategies. Circ. Res. 2021, 129, 136–154. [Google Scholar] [CrossRef]
  9. Myers, A.; Bernstein, J.A.; Brennan, M.L.; Curry, C.; Esplin, E.D.; Fisher, J.; Homeyer, M.; Manning, M.A.; Muller, E.A.; Niemi, A.K.; et al. Perinatal features of the RASopathies: Noonan syndrome, cardiofaciocutaneous syndrome and Costello syndrome. Am. J. Med. Genet. A 2014, 164, 2814–2821. [Google Scholar] [CrossRef]
  10. Swarts, J.K.L.; Leenders, E.; Klein, W.M.; Draaisma, J.M.T. Lymphatic anomalies during lifetime in patients with Noonan Syndrome: Retrospective cohort study. Am. J. Hum. Genet. 2021; in press. [Google Scholar]
  11. Lissewski, C.; Chune, V.; Pantaleoni, F.; De Luca, A.; Capri, Y.; Brinkmann, J.; Lepri, F.; Daniele, P.; Leenders, E.; Mazzanti, L.; et al. Variants of SOS2 are a rare cause of Noonan syndrome with particular predisposition for lymphatic complications. Eur. J. Hum. Genet. 2021, 29, 51–60. [Google Scholar] [CrossRef] [PubMed]
  12. Sleutjes, J.; Kleimeier, L.; Leenders, E.; Klein, W.; Draaisma, J. Lymphatic abnormalities in Noonan syndrome spectrum disorders: A systematic review. Mol. Syndromol. 2021, 13, 1–11. [Google Scholar] [CrossRef] [PubMed]
  13. Dori, Y.; Smith, C.; Pinto, E.; Snyder, K.; March, M.E.; Hakonarson, H.; Belasco, J. Severe Lymphatic Disorder Resolved With MEK Inhibition in a Patient With Noonan Syndrome and SOS1 Mutation. Pediatrics 2020, 146, e20200167. [Google Scholar] [CrossRef] [PubMed]
  14. Li, D.; March, M.E.; Gutierrez-Uzquiza, A.; Kao, C.; Seiler, C.; Pinto, E.; Matsuoka, L.S.; Battig, M.R.; Bhoj, E.J.; Wenger, T.L.; et al. ARAF recurrent mutation causes central conducting lymphatic anomaly treatable with a MEK inhibitor. Nat. Med. 2019, 25, 1116–1122. [Google Scholar] [CrossRef]
  15. Othman, S.; Azoury, S.C.; DiBardino, D.; Adams, D.M.; Itkin, M.; Kovach, S.J. Respiratory Failure in Noonan Syndrome Treated by Microsurgical Thoracic Duct-Venous Anastomosis. Ann. Thorac. Surg. 2021, 113, e219–e221. [Google Scholar] [CrossRef]
  16. Matsumoto, T.; Kudo, T.; Endo, J.; Hashida, K.; Tachibana, N.; Murakoshi, T.; Hasebe, T. Transnodal lymphangiography and post-CT for protein-losing enteropathy in Noonan syndrome. Minim. Invasive Ther. Allied Technol. 2015, 24, 246–249. [Google Scholar] [CrossRef]
  17. Keberle, M.; Mork, H.; Jenett, M.; Hahn, D.; Scheurlen, M. Computed tomography after lymphangiography in the diagnosis of intestinal lymphangiectasia with protein-losing enteropathy in Noonan’s syndrome. Eur. Radiol. 2000, 10, 1591–1593. [Google Scholar] [CrossRef]
  18. Hilliard, R.I.; McKendry, J.B.; Phillips, M.J. Congenital abnormalities of the lymphatic system: A new clinical classification. Pediatrics 1990, 86, 988–994. [Google Scholar] [CrossRef]
  19. Wassef, M.; Blei, F.; Adams, D.; Alomari, A.; Baselga, E.; Berenstein, A.; Burrows, P.; Frieden, I.J.; Garzon, M.C.; Lopez-Gutierrez, J.C.; et al. Vascular Anomalies Classification: Recommendations From the International Society for the Study of Vascular Anomalies. Pediatrics 2015, 136, e203–e214. [Google Scholar] [CrossRef] [Green Version]
  20. Chavhan, G.B.; Amaral, J.G.; Temple, M.; Itkin, M. MR Lymphangiography in Children: Technique and Potential Applications. Radiographics 2017, 37, 1775–1790. [Google Scholar] [CrossRef] [Green Version]
  21. Ricci, K.W.; Iacobas, I. How we approach the diagnosis and management of complex lymphatic anomalies. Pediatr. Blood Cancer 2021, e28985. [Google Scholar] [CrossRef]
  22. Van Schaik, C.J.; Boer, L.L.; Draaisma, J.M.T.; van der Vleuten, C.J.M.; Janssen, J.J.; Fütterer, J.J.; Schultze Kool, L.J.; Klein, W.M. The lymphatic system throughout history: From hieroglyphic translations to state of the art radiological techniques. Clin. Anat. 2022. [Google Scholar] [CrossRef]
  23. De Haas, M. Lymphoscintigraphy of the Lower Extremities; Meander Medical Centre Amersfoort: Amersfoort, The Netherlands; Available online: (accessed on 17 December 2021).
  24. Itkin, M.; Chidekel, A.; Ryan, K.A.; Rabinowitz, D. Abnormal pulmonary lymphatic flow in patients with paediatric pulmonary lymphatic disorders: Diagnosis and treatment. Paediatr. Respir. Rev. 2020, 36, 15–24. [Google Scholar] [CrossRef] [PubMed]
  25. Winters, H.; Tielemans, H.J.; Ulrich, D.J. Lymphovenous Anastomosis and Secondary Resection for Noonan Syndrome with Vulvar Lymphangiectasia. Plast. Reconstr. Surg. Glob. Open 2016, 4, e1007. [Google Scholar] [CrossRef] [PubMed]
  26. Damstra, R.J.; Halk, A.B.; Dutch Working Group on Lymphedema. The Dutch lymphedema guidelines based on the International Classification of Functioning, Disability, and Health and the chronic care model. J. Vasc. Surg. Venous Lymphat. Disord. 2017, 5, 756–765. [Google Scholar] [CrossRef]
  27. Strehl, J.; Schepke, M.; Wardelmann, E.; Caselmann, W.H.; Sauerbruch, T. Chronische Diarrhö bei einem 43-jährigen Patienten [Chronic diarrhea in a 43-year-old patient]. Internist 2003, 44, 626–630. [Google Scholar] [CrossRef]
  28. Prasad, D.; Srivastava, A.; Tambe, A.; Yachha, S.K.; Sarma, M.S.; Poddar, U. Clinical Profile, Response to Therapy, and Outcome of Children with Primary Intestinal Lymphangiectasia. Dig. Dis. 2019, 37, 458–466. [Google Scholar] [CrossRef]
  29. Downie, L.; Sasi, A.; Malhotra, A. Congenital chylothorax: Associations and neonatal outcomes. J. Paediatr. Child Health 2014, 50, 234–238. [Google Scholar] [CrossRef]
  30. Mitchell, K.; Weiner, A.; Ramsay, P.; Sahni, M. Use of Propranolol in the Treatment of Chylous Effusions in Infants. Pediatrics 2021, 148, e2020049699. [Google Scholar] [CrossRef]
  31. Nadolski, G.J.; Itkin, M. Thoracic duct embolization for nontraumatic chylous effusion: Experience in 34 patients. Chest 2013, 143, 158–163. [Google Scholar] [CrossRef]
  32. Othman, T.A.; Azenkot, T.; Moskoff, B.N.; Tenold, M.E.; Jonas, B.A. Venetoclax-based combinations for the treatment of newly diagnosed acute myeloid leukemia. Future Oncol. 2021, 17, 2989–3005. [Google Scholar] [CrossRef] [PubMed]
  33. Manevitz-Mendelson, E.; Leichner, G.S.; Barel, O.; Davidi-Avrahami, I.; Ziv-Strasser, L.; Eyal, E.; Pessach, I.; Rimon, U.; Barzilai, A.; Hirshberg, A.; et al. Somatic NRAS mutation in patient with generalized lymphatic anomaly. Angiogenesis 2018, 21, 287–298. [Google Scholar] [CrossRef] [PubMed]
  34. Barclay, S.F.; Inman, K.W.; Luks, V.L.; McIntyre, J.B.; Al-Ibraheemi, A.; Church, A.J.; Perez-Atayde, A.R.; Mangray, S.; Jeng, M.; Kreimer, S.R.; et al. A somatic activating NRAS variant associated with kaposiform lymphangiomatosis. Genet. Med. 2019, 21, 1517–1524. [Google Scholar] [CrossRef] [PubMed]
  35. Shibuya, M. VEGFR and type-V RTK activation and signaling. Cold Spring Harb. Perspect. Biol. 2013, 5, a009092. [Google Scholar] [CrossRef] [PubMed] [Green Version]
Figure 1. DCMRL results of a 20-year-old male with NS. 1. Abnormal tortuous thoracic duct and partial aplasia. 2. Left-sided pleural fluid.
Figure 1. DCMRL results of a 20-year-old male with NS. 1. Abnormal tortuous thoracic duct and partial aplasia. 2. Left-sided pleural fluid.
Jcm 11 03128 g001
Table 1. Summary of the clinical manifestation of lymphatic disease and radiological findings of 14 previously published case reports.
Table 1. Summary of the clinical manifestation of lymphatic disease and radiological findings of 14 previously published case reports.
Nr.Age (y) (m/f)Clinical Manifestation of Lymphatic DiseaseRadiological FindingsReference
TDFlow abnormalitiesOther findings
114 (f)CT, PLE, MLA, RLANDRetrograde mesenteric and pulmonary flowLeak of contrast into duodenal lumen, abnormal CLSDori, Y [13]
213 (m)LE, PLE, HTNDPleural fluids ascitesoedematous intestineKeberle, M [17]
317 (f)PLEabsentNDabdominal collateral lymphatics and bilateral iliac lymphangiectasiaMatsumoto, T [16]
461 (m)LE, SLEOcclusion at the neckIncreased pelvic and retroperitoneal flowPLA, abdominal ascitesOthman, S [15]
50.9 (f)CTDilatedBilateral perfusion-Biko [1]
60.6 (m)CTDouble duct, central TD not presentBilateral perfusionBody wall edemaBiko [1]
70.1 (m)CTNDBilateral pleural effusionsBody wall edema, ascitesBiko [1]
80.8 (m)CT, ascitesabsentBilateral perfusionBody wall edema, ascitesBiko [1]
97 (f)CTabsentBilateral perfusionPericardial effusion, ascitesBiko [1]
100.2 (m)CTabsentBilateral perfusionBody wall edemaBiko [1]
110.1 (f)CTrudimentaryBilateral perfusionascitesBiko [1]
120.1 (f)CTDouble ductPerfusion right lung-Biko [1]
130.1 (m)CT, anasarcaDilatedBilateral perfusionNetwork of lymphatic collaterals in left neck, body wall edema, ascitesBiko [1]
145 (m)ascitesabsentPeritoneum perfusionAscitesBiko [1]
CLS: central lymphatic system, CT: chylo-thorax, f: female, HT: hydrocele testis, LE: lymphedema, m: male, MLA: mesenteric lymphangiectasia, ND: no data, PLA: pulmonary lymphangiectasia, PLE: protein losing enteropathy, RLA: retroperitoneal lymphangiectasia, SLE: scrotal lymphedema.
