Intra- and Interlayer Electron-Phonon Interactions in 12/12C and 12/13C BiLayer Graphene
Abstract
:1. Introduction
2. Interlayer Interactions
2.1. AB Stacked Bilayer Graphene
2.2. Twisted Systems
3. Electron-Phonon Interactions: Theoretical Background
3.1. The Fröhlich Hamiltonian
3.2. Phonon Frequencies and the Kohn Anomaly
3.3. Consequences of the Kohn Anomaly in Graphene
4. Inversion Symmetry in 2LG Systems
5. Intra- and Inter-Layer Phonon Energy Renormalizations
5.1. Interlayer-Related Phonons in 2LG
5.2. Isotopes
6. Final Remarks
Acknowledgments
Conflicts of Interest
References
